LUMIEN CORE D5A1 User manual

Lumien Lighting | Website: www.lumienlighting.com | E-mail: [e-mail]
INSTRUCTION MANUAL
(INTEGRATED LED)
MODELS
Up Light
Down Light
Flood Light
CORE
D5A1
D5A2
F5A1
WW PRO
D7A1
D7A2
F7A1
RGBWW PRO
D9A1
D9A2
F9A1
CORE
PRO
Wattage
8W
15W
WW: 12W
RGBWW: 12W
Voltage Range
10-15V
10-15V
10-15V
10-15V
Lumen Output
UP: 640 Lumens
DOWN: 600 Lumens
FLOOD: 600 Lumens
UP: 1200 Lumens
DOWN: 1000 Lumens
FLOOD: 1000 Lumens
UP: 840 Lumens
DOWN: 760 Lumens
FLOOD: 670 Lumens
UP: XXX Lumens
DOWN: XXX Lumens
FLOOD: XXX Lumens
Color Temp
2700K, 3000K
2700K/3000K
WW
RGBWW
CRI
80+
80+
80+
80+
Beam Angle
40⁰
40⁰
40⁰
40⁰
Lifespan
50,000 Hrs.
50,000 Hrs.
50,000 Hrs.
50,000 Hrs.
Finishes
Bronze, Black
Bronze, Black
Bronze, Black
Bronze, Black
Housing
Material
Aluminum
Aluminum
Aluminum
Aluminum
Wet Rated?
Yes
Yes
Yes
Yes
Light Source
Integrated LED
Integrated LED
Integrated LED
Integrated LED

Lumien Lighting | Website: www.lumienlighting.com | E-mail: [e-mail]
WARNING –To reduce the risk of FIRE OR INJURY TO PERSON:
• Turn off/unplug the fixture and allow to cool before replacing lamp.
• Lamp gets HOT quickly. Only touch the switch/plug when turning on.
• Do not touch the hot lens, guard, or enclosure.
• Keep lamp away from materials that could burn.
• Do not touch the lamp at any time. Use a soft cloth. The oils from skin could damage lamp.
• Do not operate the fixture with a missing or damaged shield.
WARNING –Risk of Electric Shock:
• Install all luminaires at least 10 feet (3.05 m) from a pool, spa, fountain, etc.
• A fixture shall not use tungsten halogen lamps unless the luminaire is marked for such lamps.
IMPORTANT:
(DO NOT EXCEED 15 VOLTS IN THIS FIXTURE!)
This fixture functions best when the incoming voltage is between 10–15 volts. Voltages outside of this range could
damage the fixture, shorten the life, and cause unsatisfactory performance.
The use of improper voltage voids the product warranty.
TRANSFORMERS
• Only use a UL1838 transformer for safety reasons and to ensure full lifespan of the fixture.
LOW VOLTAGE CABLE SHALL:
• Be protected by routing near the luminaire, or next to a building structure such as a house or deck.
• Not be buried more than 6 inches.
It is not recommended to use Quick Clip style connectors because they are not waterproof and can rot creating
resistance and shorts. Only use outdoor rated waterproof wire connectors. Install in accordance with all local codes and
ordinances.
LED LIFE
• For maximum light output, fixtures should be connected to 10-15 volts taps.
• Voltage can be regulated by adjusting load/run.
• To determine voltage, use a digital voltmeter.

Lumien Lighting | Website: www.lumienlighting.com | E-mail: [e-mail]
INSTALLATION
A - Shroud B - Front Cover Lens C- Lens Accessory Lock Ring D -Hexagon Louver E -Fixture Body F -back cover
G- Assembled Fixture H-Spike I-Waterproof Wire Nuts
•Carefully remove the fixture from its protective packaging.
•Disassemble A,B,C,D,E,F, according to the schematic diagram. To remove the optic lens, twist it counter-clockwise.
Fixture comes with a 40°Optic. (15°& 60°Options Sold Separately.)
•A hex louver and lock ring are located in the back cover storage area.
•Connect fixture wires to main low voltage wire, using outdoor rated waterproof wire nuts.
•For the PRO Fixture , please see the Remote User Guide in the remote box.

Lumien Lighting | Website: www.lumienlighting.com | E-mail: [e-mail]
Optional Shades
LIMITED WARRANTY
WHAT IS COVERED
The manufacturer warrants this lighting fixture to be free from defects in materials and workmanship from date of
purchase for a period of ten (10) years for Aluminum and Lifetime for Brass. This warranty applies only to the original
consumer purchaser and only to products used in normal use and service. If this product is found to be defective, the
manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the product at the
manufacturer’s discretion, provided that the product has not been damaged through misuse, abuse, accident,
modification, alteration, neglect, or mishandling.
WHAT IS NOT COVERED
This warranty shall not apply to any product that is found to have been improperly installed, set-up, or used in any way
not in accordance with the instructions supplied with the product. This warranty shall not apply to a failure of the
product because of an accident, misuse, abuse, negligence, alteration, faulty installation, or any other failure not
relating to faulty material or workmanship. This warranty shall not apply to the finish on any portion of the product,
such as surface and/or weathering, as this is considered normal wear and tear. The manufacturer does not warrant and
especially disclaims any warranty, whether expressed or implied, of fitness for a purpose, other than the warranty
contained herein. The manufacturer specifically disclaims any liability and shall not be liable for any consequential or
incidental loss or damage, including but not limited to any labor/expense costs involved in the replacement or repair of
said product.
