LUMIEN CORE User manual

Lumien Lighting | Website: www.lumienlighting.com | E-mail: [e-mail]
INSTRUCTION MANUAL
(MODULAR LED)
MODELS
CORE
Z4B1
WW PRO
Z7B1
RGBWW PRO
Z9B1
WARNING –To reduce the risk of FIRE OR INJURY TO PERSON:
• Turn off/unplug the fixture and allow to cool before handling; making any adjustments or repairs or replacing the
integrated light module.
• Integrated light module gets HOT quickly. Only touch the switch/plug when turning on.
• Do not touch the lens, guard, or enclosure when hot.
• Keep integrated light module away from materials that could ignite/ combust/ burn.
• Do not touch the integrated light module chip at any time. Use a soft cloth. The oils from skin could damage LED.
WARNING –Risk of Electric Shock:
●Install in accordance with all local codes and ordinances.
●A fixture shall not use tungsten halogen lamps unless the luminaire is marked for such lamps.
IMPORTANT
TRANSFORMER
●Install in accordance with all local codes and ordinances.
●Only use a UL1838 transformer for safety reasons and to ensure full lifespan of the fixture.
●Ensure that the transformer is plugged in to a GFCI protected circuit.
CORE
PRO
Wattage
10 Watts
WW: 10 Watts
RGBWW: 10 Watts
Voltage Range
10-15V
10-15V
Lumen Output
800 Lumens
WW: 610 Lumens
RGBWW: 445 Lumens
Color Temp
2700K/3000K
WW/RGBWW
CRI
80+
80+
Lifespan
50,000 Hrs.
50,000 Hrs.
Finishes
Antique
Antique
Housing
Material
Brass
Brass
Wet Rated?
Yes
Yes
Light Source
LED Module
LED Module

Lumien Lighting | Website: www.lumienlighting.com | E-mail: [e-mail]
FIXTURE
DO NOT EXCEED 15 VOLTS INPUT
•Install in accordance with all local codes and ordinances.
•This fixture functions best when the incoming voltage is between 10–15 volts. Voltages outside of this range
could damage the fixture, shorten the life, and cause unsatisfactory performance. The use of improper voltage
voids the product warranty.
LOW VOLTAGE CABLE
•Install in accordance with all local codes and ordinances.
•Be protected by routing near the luminaire, or next to a building structure such as a house or deck.
•Not be buried except for a maximum of 6 inches (15.2 cm) to connect to the main low voltage cable.
•Have the length cut off so that it is connected to a connector within 6 inches (15.2 cm) from a building
structure, a luminaire, or fitting.
It is not recommended to use Quick Clip style connectors because they are not waterproof and can rot creating resistance
and shorts. Only use outdoor rated waterproof wire connectors. Install in accordance with all local codes and ordinances.
LED LIFE
•For maximum light output, adjust lighting circuits to provide between 10-15 volts.
•Voltage can be regulated by adjusting circuit load/run.
•To determine circuit voltage, use a digital voltmeter at the fixture.
INSTALLATION
Recessed Installation
A1 –Temporary Plastic Cover A2 –Cap B- Glass Lens C –LED Module D- O-Ring
E- Female Connector F- Lock Nut G -Silicone Sleeve H- Fixture I-PVC pipe J-Waterproof Wire Nuts

Lumien Lighting | Website: www.lumienlighting.com | E-mail: [e-mail]
Installation Procedure
•Remove temporary plastic cover (A1) before installation process.
•Assemble A2, B, C, D, E, F, G into fixture according to the diagram (H).
•Choose the appropriate PVC pipe (I) (Sold Separately).
•Pull the wire out of the PVC pipe (I) and connect the fixture to the main line with a waterproof wire nuts (J) (not
included).
•Insert the fixture (H), into the PVC Pipe (I).
•For PRO modules, follow the instruction on our LumienPRO’s remote control.
Cap Options
Hanging Installation
A1 –Temporary Plastic Cover A2 –Glass Shroud B- Glass Lens C –LED Module D- O-Ring
E- Female Connector F1- Lock Nut F2 -Ring Mount H- Stainless Steel Wire I- Waterproof Wire Nut

Lumien Lighting | Website: www.lumienlighting.com | E-mail: [e-mail]
Installation Procedure
•Remove temporary plastic cover (A1) and lock nut (F1) before installation process.
•Assemble A2, B, C, D, E, F2 into fixture according to the diagram (G).
•Fixture should always have the light source facing downward. Using the desired metal cable (H), loop the cable
around the top eyelet and secure as shown below.
•Connect fixture wires to main low voltage wire using outdoor rated waterproof (I) wire nuts.
•For PRO modules, follow the instruction on our LumienPRO’s remote control.
Optional Shades
LIMITED WARRANTY
WHAT IS COVERED
The manufacturer warrants this lighting fixture to be free from defects in materials and workmanship from date of
purchase for a period of ten (10) years for Aluminum and Lifetime for Brass. This warranty applies only to the original
consumer purchaser and only to products used in normal use and service. If this product is found to be defective, the
manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the product at the
manufacturer’s discretion, provided that the product has not been damaged through misuse, abuse, accident,
modification, alteration, neglect, or mishandling.
WHAT IS NOT COVERED
This warranty shall not apply to any product that is found to have been improperly installed, set-up, or used in any way
not in accordance with the instructions supplied with the product. This warranty shall not apply to a failure of the product
because of an accident, misuse, abuse, negligence, alteration, faulty installation, or any other failure not relating to faulty
material or workmanship. This warranty shall not apply to the finish on any portion of the product, such as surface and/or
weathering, finish defects or fusing of the metals are considered normal wear and tear due to proximity to harsh
environments; this includes but is not limited to coastal areas, ground water (minerals and impurities) and chemicals used
in the landscape. The manufacturer does not warrant and especially disclaims any warranty, whether expressed or implied,
of fitness for a purpose, other than the warranty contained herein. The manufacturer specifically disclaims any liability
and shall not be liable for any consequential or incidental loss or damage, including but not limited to any labor/expense
costs involved in the replacement or repair of said product.
