LUMIEN N4B3 User manual

Lumien Lighting | Website: www.lumienlighting.com | E-mail: [e-mail]
INSTRUCTION MANUAL
(INTEGRATED LED)
MODELS
CORE
N4B3
WW PRO
N7B3
RGBW PRO
N8B3
Shroud Options (Ordered Separately):
WARNING –To reduce the risk of FIRE OR INJURY TO PERSON:
• Turn off/unplug the fixture and allow to cool before handling; making any adjustments or repairs or replacing the
integrated light module.
• Integrated light module gets HOT quickly. Only touch the switch/plug when turning on.
• Do not touch the lens, guard, or enclosure when hot.
• Keep integrated light module away from materials that could ignite/ combust/ burn.
• Do not touch the integrated light module chip at any time. Use a soft cloth. The oils from skin could damage LED.
CORE
PRO
Wattage
3W
WW: 3W
RGBW: 3W
Voltage Range
10-15V
10-15V
Lumen Output
15°: 175 Lumens
30°: 275 Lumens
WW: 110 Lumens
RGBW: 40 Lumens
Color Temp
2700K/3000K
WW/RGBW
CRI
80+
80+
Lifespan
50,000 Hrs.
50,000 Hrs.
Finishes
Antique
Antique
Housing
Material
Brass
Brass
Wet Rated?
IP68
IP68
Light Source
Integrated LED
Integrated LED

Lumien Lighting | Website: www.lumienlighting.com | E-mail: [e-mail]
WARNING –Risk of Electric Shock:
•Install in accordance with all local codes and ordinances.
•A fixture shall not use tungsten halogen lamps unless the luminaire is marked for such lamps.
IMPORTANT
TRANSFORMER
•Install in accordance with all local codes and ordinances.
•Only use a UL1838 transformer for safety reasons and to ensure full lifespan of the fixture.
•Ensure that the transformer is plugged in to a GFCI protected circuit.
FIXTURE
DO NOT EXCEED 15 VOLTS INPUT
•Install in accordance with all local codes and ordinances.
•This fixture functions best when the incoming voltage is between 10–15 volts. Voltages outside of this range
could damage the fixture, shorten the life, and cause unsatisfactory performance. The use of improper voltage
voids the product warranty.
LOW VOLTAGE CABLE
•Install in accordance with all local codes and ordinances.
•Be protected by routing near the luminaire, or next to a building structure such as a house or deck.
•Not be buried except for a maximum of 6 inches (15.2 cm) to connect to the main low voltage cable.
•Have the length cut off so that it is connected to a connector within 6 inches (15.2 cm) from a building structure,
a luminaire, or fitting.
It is not recommended to use Quick Clip style connectors because they are not waterproof and can rot creating resistance
and shorts. Only use outdoor rated waterproof wire connectors. Install in accordance with all local codes and ordinances.
LED LIFE
• For maximum light output, adjust lighting circuits to provide between 10-15 volts.
• Voltage can be regulated by adjusting circuit load/run.
• To determine circuit voltage, use a digital voltmeter at the fixture.

Lumien Lighting | Website: www.lumienlighting.com | E-mail: [e-mail]
INSTALLATION
Full Fixture Assembly:
Other Installation Methods:
Using Standard Spike –LAP-002
Using Quick Connect Spike
Surface Mount (Using J-Box)
Recessed
A - Shroud B –Module/Knuckle C- O-Ring D - Female Connector E- Set Screw
F-Lock Nut J- Spike I-Waterproof Wire Nuts

Lumien Lighting | Website: www.lumienlighting.com | E-mail: [e-mail]
LIMITED WARRANTY
WHAT IS COVERED
The manufacturer warrants this lighting fixture to be free from defects in materials and workmanship from date of
purchase for a period of ten (10) years for Aluminum and Lifetime for Brass. This warranty applies only to the original
consumer purchaser and only to products used in normal use and service. If this product is found to be defective, the
manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the product at the
manufacturer’s discretion, provided that the product has not been damaged through misuse, abuse, accident,
modification, alteration, neglect, or mishandling.
WHAT IS NOT COVERED
This warranty shall not apply to any product that is found to have been improperly installed, set-up, or used in any way
not in accordance with the instructions supplied with the product. This warranty shall not apply to a failure of the product
because of an accident, misuse, abuse, negligence, alteration, faulty installation, or any other failure not relating to faulty
material or workmanship. This warranty shall not apply to the finish on any portion of the product, such as surface and/or
weathering, finish defects or fusing of the metals are considered normal wear and tear due to proximity to harsh
environments; this includes but is not limited to coastal areas, ground water (minerals and impurities) and chemicals used
in the landscape. The manufacturer does not warrant andespecially disclaims any warranty, whether expressed or implied,
of fitness for a purpose, other than the warranty contained herein. The manufacturer specifically disclaims any liability
and shall not be liable for any consequential or incidental loss or damage, including but not limited to any labor/expense
costs involved in the replacement or repair of said product.
