BL
ACKCOMB
OWNER’S MANUAL
illuminating technologies for life
Operaon & Installaon Instrucons
NSF/ANSI Standard 55 Class A
C US
System Tested and Cered by
NSF Internaonal against CSA
B483.1 and NSF/ANSI 55
for Disinfecon** Performance, Class A
System Rated Flow System Rated Flow
LB6-02XA
1.6 gpm LBH6-05XA 2.2 gpm
LB6-03XA 2.2 gpm LBH6-10XA 4.1 gpm
LB6-06XA 3.4 gpm LBH6-15XA 5.4 gpm
LB6-10XA 6.3 gpm LBH6-25XA 7.9 gpm
LB6-15XA 7.9 gpm LBH6-40XA 18 gpm
NSF/ANSI Standard 55 Class B
C US
System Tested and Cered by
NSF Internaonal against CSA
B483.1 and NSF/ANSI 55
for Disinfecon** Performance, Class B
System Rated Flow System Rated Flow
LB5-02XB
LB6-02XB
2.9 gpm
LBH5-05XB
LBH6-05XB
5.4 gpm
LB5-03XB
LB6-03XB
5.2 gpm
LBH5-10XB
LBH6-10XB
7.6 gpm
LB5-06XB
LB6-06XB
7.6 gpm
LBH5-15XB
LBH6-15XB
13 gpm
LB5-10XB
LB6-10XB
13 gpm
LBH5-25XB
LBH6-25XB
22 gpm
LB5-15XB
LB6-15XB
22 gpm
LBH5-40XB
LBH6-40XB
28 gpm
LUMINOR - Standard Systems
System
Rated
Flow
System
Rated
Flow
LB4-02X
LB5-02X
LB6-02X
2
gpm
LBH4-05X
LBH5-05X
LBH6-05X
5 gpm
LB4-03X
LB5-03X
LB6-03X
3
gpm
LBH4-10X
LBH5-10X
LBH6-10X
10
gpm
LB4-06X
LB5-06X
LB6-06X
6
gpm
LBH4-15X
LBH5-15X
LBH6-15X
15
gpm
LB4-10X
LB5-10X
LB6-10X
11
gpm
LBH4-25X
LBH5-25X
LBH6-25X
25
gpm
LB4-15X
LB5-15X
LB6-15X
15
gpm
LBH4-40X
LBH5-40X
LBH6-40X
40
gpm
LB4-20X
LB5-20X
LB6-20X
21
gpm
LB4 Series LBH4 Series LB5 Series
LB6 Series
LBH5 Series
LBH6 Series

2|Page
Congratulaons on purchasing this LUMINOR UV system.

3|Page
TABLE OF CONTENTS
Safety Consideraons......................................................................................................... 4
Before You Begin ................................................................................................................ 4
Water Quality Parameters.................................................................................................. 5
Assembly ............................................................................................................................ 6
System Sizing ...................................................................................................................... 8
Locaon.............................................................................................................................. 8
Installaon ......................................................................................................................... 9
System Preparaon .......................................................................................................... 12
Cleaning the Quartz Sleeve .............................................................................................. 12
Cleaning the UV Sensor.................................................................................................... 13
Operaon ......................................................................................................................... 13
BLACKCOMB4.1 Controllers ..................................................................................... 14
BLACKCOMB5.1 & BLACKCOMB6.1 Controllers ......................................................... 14
BLACKCOMB5.1 & BLACKCOMB6.1 Power-up Sequence ........................................... 14
BLACKCOMB5.1 Operaonal Screens....................................................................... 15
BLACKCOMB6.1 Operaonal Screens....................................................................... 15
Lamp Countdown Sequence.................................................................................. 16
System Service Suggested...................................................................................... 17
Lamp Replacement (BLACKCOMB4.1 systems) ........................................................ 17
Lamp Replacement (BLACKCOMB5.1 & BLACKCOMB6.1 systems) ............................ 17
QR Codes ............................................................................................................... 17
System Troubleshoong......................................................................................... 18
Temperature Management Devices ................................................................................. 20
Expansion Modules .......................................................................................................... 20
BLACKCOMB Standard Output System Specicaons ...................................................... 22
BLACKCOMB-HO High Output System Specicaons ....................................................... 23
Performance Data Sheet (on all NSF/ANSI Standard 55, Class A Systems) ....................... 24
Performance Data Sheet (on all NSF/ANSI Standard 55, Class B Systems) ....................... 25
Limited Warranty Statement:........................................................................................... 26
Warranty Registraon ...................................................................................................... 27
Note: These instrucons are also available in so copy via email from Luminor Customer Service.

4|Page
Safety Consideraons
It is important that care is taken when operang and/or maintaining your system.
Please read the instrucons
• The appliance is not to be used by persons (including children) with reduced physical,
sensory or mental capabilies, or lack of experience and knowledge, unless they have been
given supervision or instrucon.
• Children should be supervised so that they do not to play with the appliance.
• WARNING: Do not operate the UV-C emier when it is removed from the appliance
enclosure.
• The appliance is to be supplied through a residual current device (RCD) having a rated
residual operang current not exceeding 30 mA.
• This appliance contains a UV-C emier.
• Unintended use of the appliance or damage to the housing may result in the escape of
dangerous UV-C radiaon. UV-C radiaon may, even in lile doses, cause harm to the eyes
and skin.
• The appliance must be disconnected from the supply before replacing the UV-C emier.
• The appliance is intended to be permanently connected to the water mains and not
connected by a hose-set.
• Maximum working voltage of built-in UV driver U-OUT=240V
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualied persons in order to avoid a hazard.
• Before servicing this equipment, disconnect the power cord from the electrical outlet.
• Energy given o by the UV lamp is harmful to your eyes and skin. NEVER look directly at
an illuminated UV lamp without adequate eye protecon and always protect your skin from
direct exposure to the UV light.
• For complete disinfecon**, use ONLY genuine replacement parts.
• Do not operate the unit if it has any damaged or missing components.
• To avoid possible electrical shock, use only with a properly grounded electrical outlet.
• Never perform any maintenance to the system unless you are comfortable in doing so.
Contact the manufacturer for service instrucons if required.
• Do not use this system for any purpose other than what it was intended for. Misuse of this
system could potenally cause harm to the user or others.
• Your system is intended to be installed indoors and away from leaking plumbing. DO NOT
plug the unit in if the system or any of the components are wet.

5|Page
• The system should be directly installed into a ground fault circuit interrupter (GFCI). If the
use of an extension cord is required, the cord must be manufactured with a minimum of 16
gauge wire and care should be taken to avoid potenal tripping hazards.
• We recommend that a licensed plumber or cered technician install the system.
This product is not to be used for general lighng / illuminaon.
Before You Begin
The following will be needed for installing the UV system:
Tools
• Pipe cuer, hacksaw or other specialized tools required to cut into your exisng plumbing
(e.g. if you have PEX piping)
• Soldering tools (torch, ux, emery cloth and solder)
• Wrench (for ghtening ngs)
Other Materials
• Inlet/outlet connecons
• Teon™ tape
Water Quality Parameters
Treated water should be tested for at the least the parameters listed below. If the water exceeds
the listed parameters LUMINOR strongly recommends that appropriate pretreatment equipment
be installed (equipment required will depend on parameters being treated):
Hardness: <7 gpg (120 mg/L) – if hardness level is 7 gpg or slightly below the
quartz sleeve must be cleaned periodically in order to ensure e-
cient UV penetraon; if above the water must be soened.
Iron (Fe): <0.3 ppm (0.3 mg/L)
Manganese (Mn): <0.05 ppm (0.05 mg/L)
Turbidity: < 1 NTU
Tannins (organics): <0.1 ppm (0.1 mg/L)
UVT (transmiance): >85% (Please contact LUMINOR if water has a UVT that is less than
80% for pre-treatment recommendaons)
You can have your water tested at a private analycal laboratory or by your local dealer. It
is always recommended to install pre-ltraon of at least 5 microns prior to a LUMINOR UV
disinfecon** system.
**LUMINOR’s systems are tested for reducon of the MS-2 coliphage challenge microorgan-
ism to demonstrate a log reducon greater than or equal to the reducon caused by a dose
of 40mJ/cm2.

6|Page
Assembly
Unpack the system and ensure all the components are included with the system. Your system is
shipped with the following components:
BLACKCOMB (Standard output lamp systems)
CONTROLLER
GLOW PLUG
(BLACKCOMB5.1 units only)
UV SENSOR
(BLACKCOMB6.1 units only)
4.1 SYSTEMS
RC-B4.01
5.1/6.1 SYSTEMS
RC-B56.01
300016 Complete Assembly
310026 Teon Plug
310040 O-Ring
390007 Brass Nut
RS-B2.5 LB5/LB6 -06, -10, -15 series
RS-B3.5 LB5-20, LB6-20 series
RS-B2.5V NSF Class A series
GLAND NUT
O-RING
SLEEVE SPRING
QUARTZ SLEEVE
REACTOR
UV LAMP
320006
300038
RL-210- “-02” series
RL-290 “-03” series
RL-470 “-06” series
RL-820 “-10” series
RL-850 “-20” series
RL-999 “-15” series
310039
RQ-210 “-02” series
RQ-290 “-03” series
RQ-470 “-06” series
RQ-820 “-10” series
RQ-850 “-20” series
RQ-999 “-15” series
300083 “-02” series
300050 “-03” series
300052 “-06” series
300054 “-10” series
300061 “-15” series
300068 “-20” series
LAMP KEY

7|Page
BLACKCOMB-HO (High output lamp systems)
CONTROLLER
GLOW PLUG
(BLACKCOMB5.1 units only)
UV SENSOR
(BLACKCOMB6.1 units only)
GLAND NUT
O-RING
SLEEVE SPRING
QUARTZ SLEEVE
REACTOR
UV LAMP
4.1 SYSTEMS
RCHO-B4.12
(ts all units)
5.1/6.1 SYSTEMS
RCHO-B56.12
(ts all units)
POWER CORD
300016 Complete Assembly
310026 Teon Plug
310040 O-Ring
390007 Brass Nut
RSHO-B3.5 Standard series
RSHO-B3.5V NSF Class A series
260004 North American
260005 Euro
260006 Australian/New Zealand
260008 Brish
320006
300038
RL-210HO “-05” series
RL-330HO “-10” series
RL-420HO “-15” series
RL-600HO “-25” series
RL-950HO “-40” series
310039
RQ-210 “-05” series
RQ-330 “-10” series
RQ-420 “-15” series
RQ-600 “-25” series
RQ-950 “-40” series
300062 “-05” series
300063 “-10” series
300064 “-15” series
300007 “-25” series
300009 “-40” series
LAMP KEY

8|Page
System Sizing
All LUMINOR UV systems are rated for a specic ow rate in water that meets the quality param-
eters on page 5. PLEASE NOTE that increasing the ow above this rang or disinfecng** water
that does not meet the quality parameters will decrease the dose and therefore compromise the
ecacy of the system.
If you need to determine your maximum ow rate, you can ll a 1 gallon bucket with water and
me how long it takes to ll up. It is always beer to oversize your system then to undersize. For
example, if your pump delivers 8 gpm it is recommended to install any of the BLACKCOMB 10
gpm systems.
Locaon
For Point of Entry (POE) systems, choose a locaon where the main cold water line is accessible.
The system must be installed aer other water treatment equipment (soener or lters), but
before any branches (See Figure 1). For Point of Use (POU) systems, install the unit just before
the faucet. LUMINOR recommends that a 5 micron lter be installed before the UV system for a
nal polishing step before the water is disinfected**.
Solenoid
module
OPTIONAL COMPONENT
BY-PASS ASSEMBLY
*
SEDIMENT
FILTER
CARBON
FILTER
WATER
METER
WATER SOFTENER
TO DRAIN
BY-PASS
ASSEMBLY
SOLENOID
VALVE
CONTROLLER
TO HOT AND COLD WATER PIPES
SOLENOID
MODULE
*
*
*
*
*
*
*
Figure 1. Recommended POE Installaon Locaon
To facilitate lamp removal, ensure there is enough space at the lamp connector end to safely
remove the UV lamp and/or quartz sleeve (See Figure 2). The controller will require a ground
fault circuit interrupter (GFCI or GFI) outlet and should be mounted beside or above the reactor.
PLEASE NOTE: All LUMINOR UV disinfecon** systems are intended for indoor use only as
they should not be exposed to the elements.

9|Page
Installaon
Step 1: The reactor can be installed either horizontally or
vercally using the clamps provided. Vercal installaon is the
preferred method with the inlet at the boom (lamp connecon
at the top) as it allows any air that may be in the lines to be easily
purged from the system.
Step 2: The use of a by-pass assembly is recommended as it will
allow you to isolate the UV reactor. This will allow for easier access
in case maintenance is required (See Figure 4).
Step 3: Fasten chamber clamps to wall with screws provided.
The screws must anchor securely into solid wood, concrete, or steel
structure for adequate strength. Do not aempt to secure screws
into drywall (Figure 3a). Install Chamber into clamps (Figure 3b).
Step 4: For water supplies where the maximum ow rate is
unknown, a ow restrictor is recommended so that the rated ow
of your parcular BLACKCOMB system is not exceeded. The ow
restrictor should be installed on the inlet port of the reactor.
Step 5: It is recommended to have a licensed plumber connect
the UV reactor to the water supply and may be a requirement
depending on where you are located.
leave at least
an addional
reactor length
to facilitate
lamp and
sleeve removal
Figure 2. Lamp
Removal Spacing
Figure 3a. Fasten
clamps to wall
Figure 3b. Install
chamber into clamps
Figure 4. By-pass
assembly
Note: Installaon of your BLACKCOMB disinfecon**
systems shall comply with applicable provincial/
state & local regulaons.

10|Page
Step 6: Once the system has been plumbed in, gently remove the
quartz sleeve from its packaging being careful not to touch the length
with your hands. The use of coon gloves is recommended for this pro-
cedure as oils from the hands can leave residue on the sleeve and lamp
which can ulmately block the UV light from geng to the water.
Carefully slide the sleeve into the reactor unl you can feel it hit the
opposite end of the reactor. Align the sleeve so it centered along the
length of the reactor, then gently push it in to lock it into the inter-
nal centering springs in the far side of the reactor. CAUTION: Pushing
too hard when the sleeve is not aligned can damage the centering
springs. Slide the o-ring onto the sleeve unl it is bued up against
the reactor.
Figure 5. Quartz
Sleeve Installaon
Step 7: Hand ghten the provided gland nut over the quartz sleeve onto the threaded end
of the reactor. It has a posive stop to prevent over-ghtening. A rm force may be required to
fully ghten the gland nut, but DO NOT USE TOOLS for this step. Insert the provided stainless
steel compression spring into the quartz sleeve. The spring works with the lamp and LUMI-Loc™
connector to create the proper lamp alignment. PLEASE NOTE: DO NOT install a UV lamp inside
the quartz sleeve without the sleeve spring in place.
Step 8: Install the UV sensor (BLACKCOMB6.1 systems only). Align the at poron so it faces
the gland nut end and matches up with the half metal lip on the sensor port (see Figure 6). Insert
the sensor so it is fully seated and hand ghten the sensor nut.
Figure 6. UV Sensor Installaon
Figure 7. Fasten
controller
Figure 8. IEP
Connecon
Step 9: The reactor is now ready for water ow. When all plumbing connecons have been com-
pleted, slowly turn on the water supply and check for leaks. Make sure the by-pass valves are func-
oning properly and that the water is owing through the reactor. The most common leak is from
the o-ring not making a proper seal on the reactor. For new installaons, review steps 5 and 6. For
older systems drain the reactor, remove the o-ring, dry it and reapply silicon grease. Reinstall the
o-ring ensuring that it is properly sealed against the reactor and check again for leaks.
Step 10: Fasten controller securely to wall with screws provided. Drywall anchors may be used.
Note that the controller must be mounted vercally for adequate airow across the aluminum
heat sink on back (see Figure 7). For monitored systems, insert the sensor connector into the
IEP located on the right side of the controller (Figure 8). For the sensor to be recognized by the
controller, the controller power must be plugged in last. Do not plug the controller power cord
in before the last step.

11|Page
Step 11: Always hold UV lamps by their ceramic ends, not by the lamp quartz. Remove the lamp
from its packaging. Again, the use of coon gloves is recommended. Remove the lamp key from
the lamp’s connector and set it aside for the next step. Be careful to not touch the key’s exposed
contacts. Insert the UV lamp into the reactor, being careful not to drop it.
Step 12: Install the lamp key into the controller (BLACKCOMB5.1, BLACKCOMB6.1 systems only).
The key always comes packaged with the lamp and sits on the connector. With the key removed
from the lamp, orient it so the label is upright and facing you. The key will plug into the lamp key
port on the right side of the controller (Figure 10).
Step 13: Plug the LUMI-Loc™ lamp connector into the lamp. Note the keying for proper align-
ment (see Figure 9a, 9b). Insert the lamp connector into the gland nut and turn the connector
approximately ¼ turn to lock the connector to the gland nut as in Figure 11.
Figure 10. Lamp Key Installaon Figure 11. LUMI-Loc™ Connector
Step 14: Tighten the capve ground screw to the ground lug on the UV reactor to ensure proper
grounding.
Figure 12. Ground Screw Connecon
Step 15: Your system is now ready to be plugged into the appropriate GFCI protected outlet.
Refer to the following secon before any water is allowed to ow through the system.
Figure 9a. Standard Output UV
Lamp Connecon
Figure 9b. High Output UV
Lamp Connecon

12|Page
System Preparaon
With a new installaon, or any me the UV system is shut down for service, without power, or
is inoperave for any other reason, the lines in the home or facility could be contaminated. Use
the following steps to prepare the lines throughout the enre home or facility.
Step 1: Check for and remove any “dead ends” in the lines throughout the home as these can
harbor dirt and debris. Plug in the UV system and wait unl it is ready for operaon.
Step 2: Remove the lter cartridge from the last sump and ll it with 1-2 cups of household
bleach (most are 5.25% chlorine). Replace the sump and slowly turn on the water supply.
Step 3: At a water outlet, run the water unl bleach can be smelled. Repeat this for all faucets,
toilets, shower heads, refrigerators, outdoor taps, the washing machine, dishwasher, etc. at the
home or facility. Once nished, wait a minimum of 30 minutes before connuing.
Step 4: Reinstall the lter cartridge into the sump and ush the chlorine soluon by opening
all faucets unl chlorine can no longer be detected. Your BLACKCOMB UV system is ready to use.
Cleaning the Quartz Sleeve
Depending on the water quality, the quartz sleeve may require periodic cleaning. At a minimum,
the quartz sleeve should be cleaned on an annual basis. The following steps outline a basic clean-
ing procedure.
Step 1: If a by-pass assembly is installed, shut the inlet valve o to prevent water ow through
the system. Otherwise, turn o main water inlet valve (and/or turn o the water pump).
Step 2: Disconnect power cord of UV system from electrical outlet.
Step 3: Release water pressure by opening a downstream faucet and then close the outlet
shut-o valve (if any). If there is no outlet shut-o valve, expect water to drain from the system
as the head pressure in the system will cause the water to ow back down.
Step 4: Remove the capve ground screw from the ground lug on the UV reactor.
Step 5: Remove the lamp connector from the reactor (gland nut) by pushing the LUMI-loc
connector in and turning it ¼ turn counter-clockwise. Disconnect the lamp connector from the
lamp. CAUTION: the lamp may be hot!
Step 6: Being careful to touch only the ceramic ends, remove the lamp out of the reactor.
Step 7: Unscrew the gland nut from the reactor exposing the end of the quartz sleeve.
Step 8: Remove the quartz sleeve and o-ring by gently twisng and pulling the quartz sleeve.
Step 9: Using a so, lint-free cloth or towel wipe the sleeve down using a commercial scale
cleaner (i.e. CLR® or LIME-A-WAY®). This removes scaling or iron deposits that may be on the
outside of the quartz sleeve. Be careful not to get any moisture or liquids inside of the sleeve.

13|Page
Step 10: Dry the sleeve with separate cloth.
Step 11: Replace the o-ring and slide the sleeve back into the reactor following steps 7 and 8
from the installaon secon of the manual.
Cleaning the UV Sensor
Depending on the water quality, the UV sensor may require periodic cleaning. At a minimum,
the UV sensor should be cleaned on an annual basis. The following steps outline a basic cleaning
procedure.
Step 1: If a by-pass assembly is installed, shut the inlet valve o to prevent water ow through
the system. Otherwise, turn o main water inlet valve (and/or turn o the water pump).
Step 2: Disconnect power cord of UV system from electrical outlet.
Step 3: Release water pressure by opening a downstream faucet and then close the outlet
shut-o valve (if any). If there is no outlet shut-o valve, expect water to drain from the system
as the head pressure in the system will cause the water to ow back down.
Step 4: Place something under the reactor to catch any water that may come out of the reac-
tor during the removal of the UV sensor.
Step 5: Unscrew (counterclockwise) sensor nut from the reactor and pull the sensor slowly out
of the sensor port.
Step 6: Holding the sensor in your hand wipe the at poron (sensor face) of the sensor with
isopropyl alcohol using a clean lint-free cloth.
Step 7: Replace sensor following step 9 from the installaon secon of the manual.
Operaon
BLACKCOMB systems come with a feature laden controller that incorporates both the lamp driv-
er (ballast) and control features in one water-ght case. Four main controllers are available for
the BLACKCOMB systems (depending on your model). All four models feature a power factor
corrected, constant current lamp driver with a universal power input.
Please Note: While the LED or display screen is red and the buzzer is sounding the water from
the system should NOT be consumed. If any water does pass through the system during this
period, please follow the disinfecon** procedure as outlined in this manual before the water
is consumed. For BLACKCOMB4.1 and BLACKCOMB5.1 systems, even though they have a visual
and audible warning built into the controller, a green LED or status screen does not necessarily
indicate that the water coming from this system is in fact potable (safe to drink). These systems
do not measure the level of disinfecon**; they simply measure the “on-o” status of the lamp.
Please have your water checked for microbiological contaminants on a regular basis.

14|Page
BLACKCOMB4.1 Controllers
LB4
Series
LBH4
Series
Simplisc in operaon, these systems feature a tri-colour
LED that indicang system status and a 4-digit display to in-
dicate lamp life remaining. Pressing the buon will change
the display to indicate total running me. When the UV lamp
is on and within its operang age, the LED will be green.
When the UV lamp is not on or the lamp life has expired,
the LED will be illuminated red and an audible buzzer will be
sounding. To remedy this condion, the UV lamp must be
replaced with a new genuine LUMINOR UV lamp.
BLACKCOMB5.1 & BLACKCOMB6.1 Controllers
LB5 / LB6
Series
LBH5 / LBH6
Series
A full colour LCD screen provides the user with a detailed
descripon of the system’s performance in addion to pro-
viding any applicable fault messages and system diagnoscs.
The controllers used in both the BLACKCOMB5.1 and BLACK-
COMB6.1 are idencal. The dierence is that the BLACK-
COMB6.1 series of products includes a UV intensity monitor.
All BLACKCOMB5.1 and BLACKCOMB6.1 controllers include an
“innite expandability port” located on the right side of the
controller. Simply plug in an oponal UV sensor module into
the expandability port of a BLACKCOMB5.1 controller and the
system will now monitor the UV intensity of the system!
BLACKCOMB5.1 & BLACKCOMB6.1 Power-up Sequence
On start up, the controller will run through a diagnosc start-up and the sequence will be dis-
played as follows on the colour LCD:
Next, the controller checks for and inializes any oponal modules that may be aached to the
system.
Oponal Modules Check
- UV Sensor
- Solenoid
- 4-20 mA
- WIFI
- Remote Alarm
- Flow Meter
OR

15|Page
A nal module screen is displayed showing which specic modules were inialized.
The controller then displays the lamp opmizaon screen for 60 seconds to allow the lamp to
reach its opmum output. Finally, a nal “start-up complete” screen is displayed. The system will
now be ready to disinfect** water ow.
all detected modules lamp reaching max output successful start-up
BLACKCOMB5.1 Operaonal Screens
On systems without the UV monitor, the default screen shows the LUMINOR Home Screen. At
any point during operaon the user is able to scroll through the LUMINOR Home Screen, Lamp
life remaining, QR Code, Contact Info and Maintenance Parts screens by pressing the buon
located on the front of the controller.
BLACKCOMB6.1 Operaonal Screens
On systems with the UV monitor, the system will display the same screens as on the BLACK-
COMB5.1 except the UV Intensity replaces the home screen. The UV Intensity screen displays
the level of UV light detected by the sensor. UV intensity can be aected by poor water quality,
scaling on the quartz sleeve and/or sensor, lamp failure or lamp expiring. The following screens
show the UV Intensity dropping.
Below 56%, the numbers and warning sign turn red and an audible chirp is given by the ballast
every 15 seconds. Below 51%, the screen is solid red and a constant audible alarm is given. This
alternates with a screen indicang “water may be unsafe for consumpon”. With the solenoid
module, the controller de-acvates the solenoid valve, shung o all water ow.

16|Page
audible chirp every
15 seconds
audible chirp every
15 seconds
constant audible
alarm
cycles with red low
UV screen
Lamp Countdown Sequence
The system counts down the number of days unl a lamp change is required.
BLACKCOMB6.1
BLACKCOMB5.1
BLACKCOMB4.1
At thirty days remaining, the LED or display screen will change to a yellow cauon indicator. At
seven days remaining, the system will addionally repeat an audible chirp. Past the zero day
threshold, the LED or display screen changes to solid red with a connuous buzzer.
BLACKCOMB6.1
BLACKCOMB5.1
BLACKCOMB4.1
At any point during this sequence, the audible chirp or alarm can be deferred for seven days
by holding the controller buon down for a period of ve seconds. The number of deferrals
used will be displayed as below. Once the deferral expires, the alarm will sound once again. The
deferral can be repeated up to three mes. PLEASE NOTE: At any point aer lamp expiraon,
the water may be unsafe for consumpon and should not be consumed without another form
of disinfecon**.

17|Page
System Service Suggested
BLACKCOMB 5.1 & 6.1 controllers will display the System Service Suggested
Screen every 6 months to remind consumers to maintain both their UV and
other preltraon. This will serve as a prompt only and will not put the
system into alarm. To clear this condion simply press the buon located
below the screen.
Lamp Replacement (BLACKCOMB4.1 systems)
Aer the lamp is expired, it must be replaced with the same part number as indicated by the
label on the reactor. Begin replacing the lamp by unplugging the power for the controller, then
refer to Installaon, starng with step 11 (page 11) for instrucons on installing the new lamp.
To reset the mer in the controller, rmly hold down the buon on the controller for 10 seconds.
The controller will read “rSt3”, “rSt2”, “rSt1” and then beep. The buon can now be released, the
lamp countdown mer has been reset.
Lamp Replacement (BLACKCOMB5.1 & BLACKCOMB6.1 systems)
Aer the lamp is expired, it must be replaced with the same part number as indicated on the
Maintenance Parts screen or on the label on the reactor. With the system powered down,
remove and discard the lamp key from the controller. The replacement lamp is packaged with a
lamp key on the connector at the end of the lamp. Remove the key from the lamp and place it in
the controller. Refer to Installaon, starng with step 11 (page 11) for instrucons on installing
the new lamp.
QR Codes
A QR code (Quick Response code) is a matrix barcode rst designed for the
automove industry. LUMINOR uses the QR code to store a link to a specic
page on our website. Users with a camera phone equipped with the correct
reader applicaon can scan the image of the QR code and over a wireless
network connect to a LUMINOR web page in the phone’s browser. LUMINOR’s
QR webpage has informaon on how to purchase replacement components
as well as a helpful video directory on system servicing (i.e. How to change
a UV lamp or quartz sleeve). To access the QR code on the BLACKCOMB
controller, press the control buon unl the QR code screen appears.

18|Page
System Troubleshoong
Hard Alarms: The following give a constant audible alarm. If present, the solenoid valve is closed,
and the 4-20, remote alarm and wi modules transmit the alarm.
System Display Problem Resoluon
The system has detected
a problem with the
lamp.
Reset lamp protecon circuit
-unplug unit for 10 seconds.
Replace the lamp with the
part as indicated on the
silver label on the reactor or
on the Maintenance parts
screen.
Although the lamp is
powered and visibly
illuminated, due to the
lamp’s age its UV output
is no longer sucient for
proper disinfecon**.
Replace the lamp with the
part as indicated on the
silver label on the reactor or
on the Maintenance parts
screen.
Low UV Intensity.
Remove and clean the
quartz sleeve and sensor.
Check water quality meets
requirements on page 5 and
add ltraon as required.
Replace lamp.
Wrong lamp or sensor
installed.
Replace component with
proper model as indicated.
The UV sensor is no
longer communicang
with the system.
Ensure all modules are
connected properly to the
system and to each other.
Modules can be tested indi-
vidually by plugging in one at
a me and cycling power to
the system.
Replace any module that is
not detected when plugged
directly into the controller.
A bad connecon has
been detected in the IEP
port.
Missing or incorrect
lamp key.
Ensure the lamp key
(packed with the lamp, on
the connector) is installed.
Unplug and reinstall the key.
Ensure the key part number
matches Lamp on Mainte-
nance Parts screen.

19|Page
So Alarms: The following remaining errors give a 15 second audible chirp only
System Display Problem Resoluon
The module
indicated is no longer
communicang to with
the system.
Ensure all modules are
connected properly to the
system and to each other.
Modules can be tested
individually by plugging in
one at a me and cycling
power to the system.
Replace any module that is
not detected when plugged
directly into the controller.
Refer to ow meter manual for detailed
troubleshoong
Warning: Aer any hard alarm, the home or facility should be disinfected**. Follow the steps
under the “System Preparaon” heading.
Boil Water Advisory: If any failure occurs on a BLACKCOMB UV system, the
water must not be used for human consumpon unl the system is returned to
normal operaonal mode. If the water is used for human consumpon during
this period, the water must be boiled (minimum 20 minutes at a full boil) prior
to consumpon.

20|Page
Temperature Management Devices
Your LUMINOR BLACKCOMB system is designed to run connuously to ensure opmal
disinfecon**. However, during periods when no water is drawn through the system, the energy
from the disinfecon** process can cause the temperature of the water inside the chamber to
rise. In extreme situaons elevated water temperature or the uctuaon in temperature can
lower the output of the UV lamp. In these cases, or if the elevated water temperature is a
nuisance, LUMINOR recommends one of the following forms of temperature management
devices.
Cooling Fan
Designed for use on the BLACKCOMB-HO systems, the “LUMI-coolTM” fan runs
connuously to cool the water by forced convecon. The long-life fan is powered
independently using a compact modular power adapter that operates from
100-240V/50-60Hz. ±10%. The cooling fan must only be supplied at SELV. Order
PN 130014.
Temperature Relief Valve (TRV)
On reaching a higher temperature, the TRV is designed to drain a small amount
of water to allow fresh, cooler water to enter the system. The TRV works without
power and comes complete with 10’ of drain line. Order PN 130031 for 1/2”
ports, PN 130032 for 3/4” ports, PN 130033 for 1” ports and PN 130034 for 1
1/2” ports.
Expansion Modules
BLACKCOMB5.1 and BLACKCOMB6.1 controllers incorporate an “Innite Expandability Port” (IEP)
which allows for expansion to the UV sensor and all other modules. Each module (including the
sensor) comes with both a male and female connecon. Connect any device to the controller
and all subsequent devices are then connected into the female end of last device added in a
“daisy chain” conguraon. The UV sensor must only be supplied at SELV.
The following oponal expansion modules are available for use on BLACKCOMB5.1 and BLACK-
COMB6.1 UV controllers. Contact your authorized distributor for purchasing informaon.
REMOTE ALARM CONNECTION MODULE: Allows
for a connecon to a remote device such as a buzzer,
light, alarm system, PLC, etc., via a pair of contacts.
In normal operaon the OK and COM contacts will
be connected, and in a fault condion (Low UV,
Lamp fail, Power Fail), the Fault and COM contacts
will be connected. Maximum contact rang is 30V
/ 1A (use 16-22 AWG). The remote alarm module
must only be supplied at SELV. Order PN MOD-RAM.
