Lumineux Sutton Batten User manual

READ THESE INSTRUCTIONS
THOROUGHLY BEFORE
INSTALLATION KEEP THESE
INSTRUCTIONS FOR
FUTURE REFERENCE.
IMPORTANT:
This product must be installed
by a qualifi ed electrician or
competent person, and in
accordance with current building
and IET wiring regulations.
• Light Fitting
• Instruction Manual
Sutton
Batten
Single & Twin
19W, 27W & 38W Single / 38W, 50W & 60W Twin
IP20
Warranty
5 YR
BESA
Hours
50,000
Technical Helpline: +44 (0)1507 328031
www.lumineux.co.uk
1 2
5
3
6
on
off
4
Sutton
Batten
1. Route the correct 3-core or 4-core cable type
according to the location of the light tting
2. Secure the supplied wall plugs to the surface
where you want to mount (1)
3. Separate the body from the diffuser (2)
4. Secure the base of the ttting to the wall or ceiling
5. Feed the cable through the entry point and wire
into the terminal block (4)
6. Re- t the diffuser and screw in the remaining
retaining screws (6)
7. Switch the mains power on and check the light
tting illuminates
TOOLS REQUIRED
BOX CONTENTS
• Drill
• Screwdriver
• Cable
INSTALLATION INSTRUCTIONS
This lighting xture has been properly
packed to avoid damage during
transit. Before commencing with the
installation carefully inspect the
luminaire to con rm there is no
damage. DO NOT INSTALL if any
damage has occurred to the xture
or any of its components.
• Turn off the mains power before performing
inspections, installation, or removal
• Verify that the supply voltage is correct by
comparing it with the luminaire label information
• It is the installers responsibility to ensure installation
is suitable for the total load of the luminaire(s). The
supply cable, fuses/circuit brakers must be correctly
rated for the electrical load and considering for any
transient inrush currents that may occur
• Do not perform insulation strength or resistance
tests on installed luminarie(s) connected
PLEASE READ THESE INSTRUCTIONS
BEFORE INSTALLATION.
WARNING: Risk of electric shock! Isolate
the mains power before proceeding.
Manby Business Park, Manby, Lincolnshire
R1.0 16072019
NON– EMERGENCY FITTINGS
CLASS I PRODUCT
EARTH CONNECTION
REQUIRED.
LIVE = Brown
NEUTRAL = Blue
GND = Green/Yellow
Product Specification:
Unit Input Voltage Waage Length Width Height LF(mm)
4 Single 220-240VAC, 50/60Hz 19W 1220 64 62 1016
4 Twin 220-240VAC, 50/60Hz 38W 1220 64 62 1016
5 Single 220-240VAC, 50/60Hz 27W 1524 64 62 1320
5 Twin 220-240VAC, 50/60Hz 50W 1524 64 62 1320
6 Single 220-240VAC, 50/60Hz 38W 1829 64 62 1625
6 Twin 220-240VAC, 50/60Hz 60W 1829 64 62 1625
Manby Business Park, Manby, Lincolnshire
R1.0 16072019
NON– EMERGENCY FITTINGS
CLASS I PRODUCT
EARTH CONNECTION
REQUIRED.
LIVE = Brown
NEUTRAL = Blue
GND = Green/Yellow
Product Specification:
Unit Input Voltage Waage Length Width Height LF(mm)
4 Single 220-240VAC, 50/60Hz 19W 1220 64 62 1016
4 Twin 220-240VAC, 50/60Hz 38W 1220 64 62 1016
5 Single 220-240VAC, 50/60Hz 27W 1524 64 62 1320
5 Twin 220-240VAC, 50/60Hz 50W 1524 64 62 1320
6 Single 220-240VAC, 50/60Hz 38W 1829 64 62 1625
6 Twin 220-240VAC, 50/60Hz 60W 1829 64 62 1625
Manby Business Park, Manby, Lincolnshire
R1.0 16072019
NON– EMERGENCY FITTINGS
CLASS I PRODUCT
EARTH CONNECTION
REQUIRED.
LIVE = Brown
NEUTRAL = Blue
GND = Green/Yellow
Product Specification:
Unit Input Voltage Waage Length Width Height LF(mm)
4 Single 220-240VAC, 50/60Hz 19W 1220 64 62 1016
4 Twin 220-240VAC, 50/60Hz 38W 1220 64 62 1016
5 Single 220-240VAC, 50/60Hz 27W 1524 64 62 1320
5 Twin 220-240VAC, 50/60Hz 50W 1524 64 62 1320
6 Single 220-240VAC, 50/60Hz 38W 1829 64 62 1625
6 Twin 220-240VAC, 50/60Hz 60W 1829 64 62 1625
Manby Business Park, Manby, Lincolnshire
R1.0 16072019
NON– EMERGENCY FITTINGS
CLASS I PRODUCT
EARTH CONNECTION
REQUIRED.
LIVE = Brown
NEUTRAL = Blue
GND = Green/Yellow
Product Specification:
Unit Input Voltage Waage Length Width Height LF(mm)
4 Single 220-240VAC, 50/60Hz 19W 1220 64 62 1016
4 Twin 220-240VAC, 50/60Hz 38W 1220 64 62 1016
5 Single 220-240VAC, 50/60Hz 27W 1524 64 62 1320
5 Twin 220-240VAC, 50/60Hz 50W 1524 64 62 1320
6 Single 220-240VAC, 50/60Hz 38W 1829 64 62 1625
6 Twin 220-240VAC, 50/60Hz 60W 1829 64 62 1625
Manby Business Park, Manby, Lincolnshire
R1.0 16072019
NON– EMERGENCY FITTINGS
CLASS I PRODUCT
EARTH CONNECTION
REQUIRED.
LIVE = Brown
NEUTRAL = Blue
GND = Green/Yellow
Product Specification:
Unit Input Voltage Waage Length Width Height LF(mm)
4 Single 220-240VAC, 50/60Hz 19W 1220 64 62 1016
4 Twin 220-240VAC, 50/60Hz 38W 1220 64 62 1016
5 Single 220-240VAC, 50/60Hz 27W 1524 64 62 1320
5 Twin 220-240VAC, 50/60Hz 50W 1524 64 62 1320
6 Single 220-240VAC, 50/60Hz 38W 1829 64 62 1625
6 Twin 220-240VAC, 50/60Hz 60W 1829 64 62 1625
on
off
Manby Business Park, Manby, Lincolnshire, LN11 8UT
Lumineux is a B&T Associates Ltd company.
Electrical connection wiring
LIVE (SW) = Brown
NEUTRAL = Blue
EARTH = Green/Yellow
EE
A
G

ROUTINE TEST RECORD
Type Test Year 1 Year 2 Year 3 Year 4 Year 5
Signed Date Signed Date Signed Date Signed Date Signed Date
Functional 1
Functional 2
Functional 3
Functional 4
Functional 5
Functional 6
Functional 7
Functional 8
Functional 9
Functional 10
Functional 11
3hr Duration 12
Installation Engineers Contact Details: Luminaire Reference / Location
Name: Tel:
Luminaire Details: Full Recharge Duration 24 Hours Emergency Duration 3 Hours Lamp Type LED
Sutton Batten
This luminaire is warranted for a
period of 5 years from the date of
purchase. The backup battery
pack in the emergency version
is warranted for a period of 12
months. The warranty could be
invalidated should the light tting
not be installed according to these
instructions, outside the scope of
the specication or the product
has been altered or tampered with
in any way. Please see website for
terms and conditions.
Standard -20 to +40ºC
Emergency 0 to +25ºC
1. Connect incoming earth cable to ‘Earth’ terminal on connector block.
2. Connect incoming neutral cable to ‘Neutral’ terminal on connector block.
3. For the emergency unit to work correctly, please ensure that an
uninterrupted permanent live feed is present and is connected directly
to the ‘Permanent Live’ terminal of the mains terminal block. Please
ensure there are no switches, PIRs etc within the permanent live feed,
constant switching of the emergency pack could result in premature
battery failure.
4. Connect incoming switched live cable to the terminal marked
“Switched Live”
NOTE: If there is no switch live feed and the unit has a microwave sensor,
simply bridge across from the “Permanent Live” to the Switch Live” on the
mains terminal block.
5. There should be a loose ying lead connected to the battery. This needs
to be attached to the ying lead from the emergency control unit.
6. Following power up the green LED indicator should illuminate to indicate
charging. If power to the unit is disrupted or isolated, the unit indicating
green LED will switch off, triggering the emergency LEDs to illuminate.
7. Please allow 24 hours charge before rst emergency test.
The self-test version of emergency is tted with control gear that will carry out
periodic functional tests every 1 month and full duration test every 12 months.
Technical Helpline: +44 (0)1507 328031
Wiring instructions for units equipped
an with EMERGENCY function
Self-Test EMERGENCY function
DISPOSAL
WARRANTY
PRODUCT TEMP SPECIFICATION
Detection Range: This determines the effective
range of the motion. Note that reducing the
sensitivity will also narrow the detection range.
Hold Time Duration: This determines the
time the tting remains at 100% illumination
following motion detection.
Daylight Setting: This setting holds off the 100%
light output should there be sufcient daylight.
STANDARD ON/OFF SENSOR
MICROWAVE SENSOR SETTINGS
STEP DIM DRIVER SETTINGS
DETECTION AREA
1 2
ON ON 100%
OFF ON 75%
ON OFF 50%
OFF OFF 25%
OUTPUT CURRENT SETTING
Output Current (mA) S1 S2 S3
1200 ON ON ON
1050 ON ON -
900 ON - -
800 - - -
DAYLIGHT SENSOR
Daylight Sensor S1 S2 S3
Disable* ON ON ON
100Lux ON ON -
50Lux ON - ON
30Lux - ON ON
10Lux - - -
STAND-BY-PERIOD
Stand-by-Period S4 S5
1 Min ON ON
5 Min ON -
25 Min - ON
+∞ - -
SENSITIVITY
Sensitivity S1 S2
100% ON ON
75% ON -
50% - ON
25% - -
HOLD TIME
3 4 5
ON ON ON 5S
OFF ON ON 30S
ON OFF ON 90S
OFF OFF ON 5Min
ON ON OFF 20Min
OFF OFF OFF 30Min
DAYLIGHT
6 7 8
ON ON ON 2Lux
ON ON OFF 10Lux
OFF ON OFF 30Lux
ON OFF OFF 50Lux
OFF OFF OFF Disable
Part No. Description Watts L(mm) W (mm) H (mm) LF (mm) Weight
430039 / 430045
4ft Twin 38W
1220 64 62 1016
1.25Kg
430041 / 430047
5ft Twin 50W
1524 64 62 1320
1.55Kg
430043 / 430049
6ft Twin 60W
1829 64 69 1625
1.80Kg
430038 / 430044
4ft Single 19W
1220 64 62 1016
1.25Kg
430040 / 430046
5ft Single 27W
1524 64 62 1320
1.55Kg
430042 / 430048
6ft Single 38W
1829 64 69 1625
1.80Kg
SUTTON BATTEN DIMENSIONS
*Sensor is disabled and will not detect daylight
+∞ Lights remain constant at low level Set via detachable sensor
Emergency lighting luminaries must be installed and maintained in
accordance with the emergency lighting standard BS 5266-1
Revision 2 - February 2022
LENGTH
LF
W
H
Fault/Test/Status Reason
Battery fully charged
and operational Standard daily use
Battery Charging Initial charge /
battery topping up
Battery Failure Battery is disconnected or
damaged/faulty
Duration Test Failure Maintenance check required
by qualied engineer
Automatic Testing - Function
5 minute test (Every 30 days)
Self-testing in
operation
Automatic Testing -
Duration test is 3 hours
(every 12 months)
Self-testing in
operation
Charge Indicator Status
Battery Fully Charged
and Operational
Battery Charging
Auto Test 5 Min
(every 30 days)
Auto Test 3 Hours
(every 12 months)
Duration Test Failure
1 Sec ON
1 Sec OFF
3 Sec ON
3 Sec OFF
3 Sec ON
1 Sec OFF
0.5 Sec ON
0.5 Sec OFF
Battery
Disconnected/Faulty
The light source of this unit is not
replaceable; when the light source
reaches its end of life the whole
luminaire shall be replaced.
Disassemble instructions for end of
life disposal available on website.
Disposal of Electronic Equipment
WEEE Directive 2002/96/EC This
product falls within the scope of
the Waste Electrical & Electronic
Equipment Directive (WEEE), which
means the product should not be
disposed of as normal household
waste. Please recycle where
facilities exist or check with your
Local Authority. RoHS – All
components and materials used in
this product are RoHS 2002/95/EC
compliant.
Specications may change from time
to time. The information contained
in this leaet is for guidance only
and should not be considered as
always accurate and should be
treated as not representative.
** Please see our website for more detailed information on warranty.
This product contains a light source of energy efciency Class E.
EMERGENCY FITTINGS ONLY. EARTH CONNECTION REQUIRED.
L - LIVE (SW) = Brown
N - NEUTRAL = Blue
L1 - PERMANENT LIVE (PL) = Black
- EARTH = Green/Yellow
Other Lumineux Work Light manuals
Popular Work Light manuals by other brands

Ceotis
Ceotis COB-BEL-135-VG installation guide

Storch
Storch Power LED 30 W basic manual

Royal Sovereign
Royal Sovereign RFL-1300 owner's manual

Ape Labs
Ape Labs ApeCoin instruction manual

Federal Signal Corporation
Federal Signal Corporation RAYDIAN Installation and maintenance instructions

Würth
Würth HL 10-A Translation of the original operating instructions
