Lumintrek TrailBlazer TB-3000 User manual

Lumintrek TrailBlazer
LED Bicycle Light User Manual
Model: TB-3000

1
1. Please Read Before Use
Please read this user manual to completely familiarize you with this product. Make sure you
understand all functions before hitting the trails.
Cycling in the dark is inherently dangerous. Always make sure the light is firmly secured and the
battery is fully charged before you go for a ride. Like all other electronic devices, the light can
fail at any unexpected time. It is advised to always keep a backup light and battery pack with you
whenever you go on an extended ride. Please note that your Lumintrek light is very bright, never
aim it directly at any oncoming motorists/cyclists.
Your Lumintrek bicycle light is equipped with a high capacity Lithium-ion battery pack. Please
completely charge the battery before first use of the light. While the battery pack is double
protected, you should always observe the following:
While charging the batteries, never leave it unattended for a long time.
Only use the Lumintrek charger to charge the batteries. Using other chargers to charge
Lumintrek batteries may cause battery failure and/or other serious damage.
Your Lumintrek bicycle light uses high power LEDs which, especially in turbo/high mode,
generate a significant amount of heat. The aluminum light-head is designed to draw most of the
excess heat away. The light head may get extremely hot during this process if sufficient air flow
is not provided. Please use with caution.
2. Charging the battery pack
The battery pack is shipped half charged. You need to fully charge it before first use.
Connect the battery to the charger- the charger LED will turn Green.
Plug the charger into the power outlet –the charger LED will turn Red indicating that
the battery is charging. A full charge from empty will take approximately 4 hours.
Once fully charged the LED will turn Green. Unplug the charger and disconnect the
battery.

2
3. Handle Bar Mounting
Insert the O-ring into the hook on the front of the light head. You must stretch the
O-ring slightly which makes it thinner and then it slips into place easily.
Place the light head on the handlebars and stretch the O-ring around the bottom of
the handle bar. Clip it onto the hook at the rear of the light head. Various O-ring
sizes are provided; Use the one which provides the best fit depending on the size of
your handle bars.
Find the most suitable place for mounting the battery. If you have a long enough stem, this
is the best place to put it; otherwise you can mount it to your bike frame or handlebars
(Opposite side to where the light is).
Estimate how much cable length you will require and then fold up the excess cable.
Wrap the Velcro strap around the stem/frame/handle bars, at the same time stuffing the
excess cable into the pouch.
Plug the light cable into the battery cable.
4. Helmet mounting
Attach the helmet bracket to your helmet by feeding the Velcro straps through your helmets
air vents. You can cut the straps shorter if needed.
Insert the O –ring into the hook on the front of the light head.
Place the light head on the helmet mount bracket and stretch the O-ring around the
underneath. Clip it onto the clip at the rear of the light head.
Guide the cable through one of your helmet straps or Velcro it to the back of your helmet in
order to ensure that the cable doesn’t snag on a low hanging branch or dangle down in front
of your face while you are riding.
Place the battery in a convenient location. Here are some suggestions:
--in your shirt pocket
--Inside your hydration pack

3
--Attached to the shoulder strap of your hydration pack
Plug the light cable into the battery cable.
5. Operating Lumintrek TB-3000 Trailblazer light
The switch is illuminated while plugged in which makes it easy to locate in the dark.
The light starts in the OFF mode.
Push the switch button for High, Medium, Low
Push and hold the switch button for two seconds (from any setting) to turn the light OFF.
Push and hold the switch button for two seconds (from off) to enter into the STROBE mode.
6. Battery Level Indicator
The Lumintrek TB-3000 Trailblazer comes with a 4 stage power meter. As the battery depletes,
the backlit switch button will change color from Green-Blue -Red-Flashing Red.
Green 100%-75%
Blue 75%-30%
Red 30%-5%
Flashing Red < 5%
7. Battery Storage
Disconnect the battery pack from the light head when not using. Store the battery pack fully
charged and re-charge it before using the lighting system again. If not used for an extended
period of time, please store the battery pack in a cool dry place to avoid excessive discharge.
8. Troubleshooting
Failure
Caused
Solution
No light
Battery is over discharged
Charge the battery
Battery is not plugged in
correctly
Make sure all parts are firmly
connected
Running time too short
Battery is not fully charged
Charge the battery
New battery
Charge the battery
Very old battery
Replace the battery

4
Cold temperature
Keep the battery warm
Defective charger
Replace the charger
Flicker
Cables not secured
Make sure all parts are firmly
connected
9. Technical Data
LED: 3 CREE XML-U2
LED lifespan：above 50,000 hours
Max output: 3000 lumens
Lens: High transparent acrylic lens
Modes: 3-level adjustable brightness, flashing and over-heat protection functions
Output levels: Max: 3000 lumens Medium: 1450 lumens Low: 650 lumens
Runtime: Max: 3 hours Medium: 6 hours Low : 12 hours
Power indicator: 3-color/4-modes LED indicator to display battery capacity
Battery capacity/Voltage: 16.8V (4X26650 waterproof designed)
Charge time: 4 hours
Shell material: 6061-T6 Aluminum alloy
Waterproof grade: IP65
Weight : 130g without battery pack, 585g with battery pack
Package Includes: light head, battery pack, charger, helmet mount, extension cable, O-rings
