Lumiscope LUMINEB II 5710 User manual

Model 5710
LUMINEB II
Compressor Nebulizer
Operation Instructions
5710-INS-LAB-RevB14

5710-INS-LAB-RevB14 2
TABLE OF CONTENTS:
INTRODUCTION.......................................3
WARNINGS..........................................4
PARTSIDENTIFICATION.................................5
USING YOUR LUMINEB II COMPRESSOR NEBULIZER . . . . . . . . . 6 – 8
CLEANING & DISINFECTING YOUR LUMINEB II . . . . . . . . . . . . . . . . . 8
CHANGINGTHEFILTER .................................9
REPLACEMENT PARTS & OPTIONAL ACCESSORIES . . . . . . . . . . . . . 9
SPECIFICATIONS.....................................10
FIVE-YEARLIMITEDWARRANTY...........................11
INSTRUCCIONESENESPAÑOL...........................13
GF Health Products, Inc. is not responsible for typographical errors. For the most updated and
current information on packaging, warranties, products and specifications, including the most
current version of these instructions, please visit our website at
Graham-Field, Lumiscope, and Lumiscope For The Quality of Life are registered
trademarks of GF Health Products, Inc.

5710-INS-LAB-RevB14 3
INTRODUCTION:
Congratulations on purchasing your new LUMINEB II Compressor Nebulizer. It
is a compact medical device designed to efficiently deliver physician prescribed
medication to the bronchial lung passages. With proper care and use, it will provide
you with many years of reliable treatment.
This product has been developed for the treatment of asthma, allergies and other
respiratory disorders. It creates a stream of air that travels through clear tubing to
the nebulizer. When air enters the nebulizer, it converts the prescribed medication
into aerosol mist for easy inhalation.
Your LUMINEB II should be used under the supervision of a licensed physician and/
or respiratory therapist. We encourage you to thoroughly read these instructions
to learn about the features and proper use of this product. Any use of this product
other than its intended use will void all warranties and should be avoided.
CAUTION: USA FEDERAL LAW RESTRICTS THIS DEVICE TO
SALE BY OR ON THE ORDER OF A PHYSICIAN.

5710-INS-LAB-RevB14 4
WARNINGS:
• The5710containshigh-precisionassemblies.Therefore,avoid
extreme temperatures, humidity, direct sunlight and strong static
electricity or electromagnetic waves.
• Toavoidelectricalshock,keeptheunitawayfromwater,donot
immerse the power cord or unit in liquid, do not use while bathing, do
not reach for a unit that has fallen into water – immediately unplug it.
• Notforusebychildrenwithoutadultsupervision.
• Notforuseforotherthanmedicalnebulizationtreatment.
• Donotattempttoxorrepairthemachineunderanycircumstances.
 
• Disconnecttheunitfromtheelectricalsourcebeforecleaning,lling
the nebulizer and after each use.
• Ensurethepowercordisfully inserted into the socket to prevent
electrical malfunction.
• Cleantheunitandaccessoriescarefullywithaslightlydamp,soft
cloth. Do not apply excess pressure. Do not use solvents or cleaners
on either the unit or accessories.
• OnlyusetheincludedLumiscopeACadapterforACpowering.Donot
leave the unit plugged in while unattended.
• Neverblocktheairopeningsoftheunitoroperateitwheretheair
openings may be obstructed.
• WARNING:NoticeforCaliforniaCustomers-CaliforniaProposition65
 WARNING:ThisproductcontainsachemicalknowntotheStateof
California to cause cancer and reproductive or developmental harm.

5710-INS-LAB-RevB14 5
1
2
3
4
5
6
10
7
9
8
11
1. Nebulizer Compressor 4. Tube Connector 7.PowerCord 10. Power Cord Plug
2. Air Tube 5. Standard
Mouthpiece 8. Air Vents 11. Filters
3. Filter Compartment 6. Nebulizer 9. On/Off Switch
PARTS IDENTIFICATION:
OPTIONAL ACCESSORIES AVAILABLE
Adult Mask (item 5704)

5710-INS-LAB-RevB14 6
USING YOUR LUMINEB II COMPRESSOR NEBULIZER:
Note:Priortoinitialoperation,thenebulizershouldbethoroughlycleaned.
1. Place your LUMINEB II on a flat and stable surface. Be sure that you can easily
reach the controls while you are seated.
2. Gently twist the top part of the nebulizer
assembly counter-clockwise to
disassemble the nebulizer. (fig.1)
3. Fill the bottom section of the nebulizer with the
medication prescribed by your physician. Be sure
that the nebulizer cone is put inside the bottom
section. (fig. 2)
4. Replace the top part of the nebulizer and gently twist
clockwise to reassemble the nebulizer. Make sure both
sections are connected properly. (fig. 3)
Figure 1
Figure 2
Figure 3

5710-INS-LAB-RevB14 7
5. Attach one end of the air tube to the base of the nebulizer. (fig. 4)
6. Attach the other end of the air tube to the air outlet on the top of the LUMINEB II.
(fig.4)
7. Attachthestandardmouthpiecetothetop
of nebulizer assembly. (fig. 5) If using an
optional mask, attach the mask to the top
of nebulizer assembly. (fig. 6)
8. Make sure the On/Off switch is in the Off
position, then plug the power cord into an
electrical outlet.
9. Flip On/Off switch to On position to begin
your prescribed treatment.
10. When your treatment is finished, shut off
the LUMINEB II and unplug it from the
electrical outlet.
Figure 4
Figure 5 Figure 6

5710-INS-LAB-RevB14 8
IMPORTANT:
The compressor motor has a thermal protector which will shut off the unit before
itoverheats.Whenthethermalprotectorshutstheunitoff:
1. Switch off the LUMINEB II.
2. Unplug the unit from the electrical outlet.
3. Wait 30 minutes for the motor to cool down before another treatment.
4. Make sure the air openings are not obstructed.
CLEANING YOUR LUMINEB II
It is recommended that the nebulizer, mouthpiece and mask are thoroughly
cleaned with hot water after each use and cleaned with mild detergent after the
last treatment of the day. If your physician or respiratory therapist specifies a
different cleaning procedure, follow their instructions.
Before cleaning, make sure the power cord is disconnected from the electrical
outlet and the unit.
 TocleanyourLUMINEBII:
1. Disconnect the air tube, nebulizer and mouthpiece.
2. Gently twist the nebulizer to open it.
3. Rinse the nebulizer and mouthpiece or mask with water.
4. Dry with a clean soft towel or allow to air dry.
5. Reassemble the nebulizer when completely dry.
6. Wipe the compressor with a damp cloth and allow to air dry.
 7. Neverusepowderedcleanersorsoappadsonthecompressor,asitmay
damage the finish of the unit.
DISINFECTING YOUR LUMINEB II
It is suggested that your LUMINEB II be disinfected after the last treatment of
eachday.Unlessindicatedotherwisebyyourphysician,disinfectyourLUMINEBII:

5710-INS-LAB-RevB14 9
1. Use one part white vinegar to three parts distilled water. Make
sure the mixed solution is enough to submerge the nebulizer and
mouthpiece.
2. Wash the nebulizer, mouthpiece and/or mask in warm water with a
mild detergent, then rinse the detergent solution out with hot tap
water.
3. Submerge the cleaned components in the water and vinegar solution
for thirty minutes.
CHANGING THE FILTER
1. Use only Lumiscope nebulizer filters.
2. Do not substitute cotton or any other materials. Do not wash, clean
or re-use a filter.
3. Never operate your LUMINEB II without a filter.
4. Change the filter every 30 days or when it turns gray.
Tochangethelter:
1. Remove the filter cover on the top of the compressor unit.
(see page 5)
2. Replace the old filter with a new one.
3. Replace the filter cover.
REPLACEMENT PARTS
Replacement parts are available - please contact our Customer Service
OPTIONAL ACCESSORIES
 AdultMask(item5704)

5710-INS-LAB-RevB14 10
SPECIFICATIONS:
Protection against electric shock
 • ClassIIEquipment
 • TypeBFappliedparts:Mouthpieceandmask
Protection Against Harmful Ingress of Water
 • IPX0(Ordinary)
 • Degreeofsafetyinthepresenceofammableanestheticsoroxygen
 • NoAP/APG(Notsuitableforuseinthepresenceofammableanesthetics
or oxygen)
 • ModeofOperation:Continuous
Method of Nebulization Piston Driven
Power AC 120V, 60Hz
Power Consumption 70Watts
Medication Capacity 5 ml
Particle Size 4 µm
Sound Level ~ 60dba
Maximum Medication Capacity 13ml (cc)
Average Nebulization Rate 0.2ml/min
Compressor Pressure Range 30 - 36 Psi (210 - 250 KPa / 2.1 - 2.5 bar)
Operating Pressure Range 8 - 16 Psi (50 - 100 KPa / 0.5 - 1.0 bar)
Liter Flow Range 6 ~ 8 lpm
Operating Temperature Range 50°F - 104°F (10°C - 40°C)
Operating Humidity Range 10 - 95% RH
Storage Temperature Range -4°F-158°F(-20°C-70°C)
Storage Humidity Range 10 - 95% RH
Dimensions (LxWxH) 8.5”x7.75”x6”(210mmx195mmx150mm)
Weight 3.3 lb (1.5kg)
Standard Accessories Power Cord, Nebulizer, Air Tube, Mouthpiece and Filters (x5)
Optional Accessories Adult Mask

5710-INS-LAB-RevB14 11
FIVE-YEAR LIMITED WARRANTY:
SCOPE OF WARRANTY
GF Health Products, Inc. (“GF”) warrants to the original purchaser (“Customer”)
only, that it will replace or repair components, at GF’s sole discretion, that are
defective in material or workmanship under normal use for a period of five years
after the purchase date unless there is an expiration date on the component in
which case the warranty shall expire on the earlier of the warranty period or the
expiration date. The warranty does not extend to non-durable parts and does
not include labor or costs of shipping. This limited warranty is not transferable.
All warranties are conditioned upon the proper use of the product strictly in
accordance with good commercial practice and applicable GF instructions and
manuals, including proper use and maintenance. The warranty is void if the
defect is caused by any other reason not related to defects in materials or
workmanship.
OBTAINING WARRANTY SERVICE
GF’s customer service team must be notified of any warranty claim within the
applicablewarrantyperiod.       There is a $15 fee for return shipping and handling.
Please make checks payable to GF Health Products, Inc. Failure to follow the
specific
directions provided by the GF customer service team will result in denial
of the
warranty claim.
ENTIRE WARRANTY, EXCLUSIVE REMEDY AND CONSEQUENTIAL
DAMAGES DISCLAIMER
THIS WARRANTY IS GF’S ONLY WARRANTY AND IS IN LIEU OF ALL OTHER
WARRANTIES,EXPRESSORIMPLIED.GFMAKESNOIMPLIEDWARRANTIES
OF ANY KIND INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE. IF ANY MODEL OR SAMPLE WAS
SHOWN TO THE CUSTOMER, SUCH MODEL OR SAMPLE WAS USED MERELY
TO ILLUSTRATE THE GENERAL TYPE AND QUALITY OF THE PRODUCT AND NOT
TO REPRESENT THAT THE PRODUCT WOULD NECESSARILY CONFORM TO THE
MODEL OR SAMPLE IN ALL RESPECTS.
GF’S TOTAL LIABILITY FOR ANY PRODUCT OR SERVICE PROVIDED IS LIMITED
TO THE COST OF THE PRODUCT GIVING RISE TO THE CLAIM. IN NO EVENT
WHETHER IN CONTRACT, INDEMNITY, WARRANTY, NEGLIGENCE, STRICT
LIABILITY OR OTHERWISE WILL GF BE LIABLE FOR ANY DIRECT, SPECIAL,
INDIRECT,INCIDENTAL,EXEMPLARYORCONSEQUENTIALDAMAGES,INCLUDING,
BUTNOTLIMITEDTO:DAMAGESFORLOSSOFPROFITSORINCOME,LOSS
OF USE, DOWNTIME, COVER, OR EMPLOYEE OR INDEPENDENT CONTRACTOR
WAGES, PAYMENTS AND BENEFITS.
This warranty gives you specific legal rights. You may have additional rights which
vary from state to state.
