LumiSource BOOMCHAIR B51 Racer User manual

OWNER’S MANUAL
,UM3OURCE¸
BOOMCHAIR™
B51 Racer
Multimedia Chair with Built-In SPEAKERS

Congratulations!
You are now the proud owner of a BOOMCHAIR™. Prepare to experience your entertainment on a whole new level.
BOOMCHAIR™ allows you to HEAR the sound and FEEL the excitement. You’ll experience every crash, bang, and boom while
enjoying your favorite game, music, or movie. BOOMCHAIR™ is also a great game seat built to endure the rigors of today’s
gaming environment. Take a moment to review your owner’s manual before connecting your BOOMCHAIR™. Assembly and
operation of the BOOMCHAIR™ is simple.
If you need further assistance visit us at www.BoomChair.com or www.LumiSource.com
BOOMCHAIR™, a LumiSource®product.
LumiSource, Inc.
2950 Old Higgins Road, Elk Grove Village, IL 60007
PATENTS PENDING
BoomChair™, BoomChair 2.0™, BoomCube™ and BoomChair ™ are trademarks of LumiSource, Inc. Other trademarks are properties of their respective owners.
©2006 LumiSource, Inc. All rights reserved. www.BoomChair.com & www.LumiSource.com
2
Multimedia Chair with Built-In SPEAKERS
BOOMCHAIR™
B51 Racer

READ BEFORE USE
• DO NOT wash or soak with water. If BOOMCHAIR™ gets wet, disconnect power immediately and
do not use until completely dry.
• Switch power off (0) and unplug BOOMCHAIR™ when not in use.
• Children under 5 years old should not use this product without parental supervision.
• For INDOOR use only/ DO NOT expose to direct sunlight, moisture, or extreme temperatures.
• DO NOT use on slippery or uneven ooring.
• Excessive exposure to audio equipment at high volume may lead to hearing loss.
• DO NOT open the BOOMCHAIR™ (see warning below).
Internal
• DO NOT OPEN
Caution: To reduce the risk of electric shock and re, do not open the BOOMCHAIR™. There are no user serviceable parts inside.
Refer to your warranty for service information
#!54)/.
FCC CERTIFICATIONS
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
Power rating: 12 Volts at 1000/mA
3

SET-UP GUIDE
The BOOMCHAIR™ comes with the following: PARTS LIST:
Dimensions: 25” L x 16” W x 34” H
Weight: 28 lbs.
2 - 3” coaxial mid-high speakers @ 5W 4 Ohms
1 - 12v AC/DC UL listed power adapter
SYSTEM SPECIFICATIONS
1) BOOMCHAIR™
2) AC/DC POWER SUPPLY
3a) RCA CORD
(headphone jack to audio left & right channel connectors)
3b) RCA CORD
(audio left & right channel connectors)
3c) RCA AUDIO COUPLER
4) RECEPTACLE
5) HOOK & LOOP FASTENER (on back)
6) STORAGE POCKET (on back)
7) ADJUSTABLE RECLINE STOPPERS (on back)
8) DASHBOARD CONTROL PANEL
9) SPEAKERS
4
3b
3a
1
3c
2
5
7
8
9
4
6

DASHBOARD CONTROL PANEL
5
VOLUME
POWER
INPUT
R L
+
™
(A) POWER SWITCH / VOLUME CONTROL
(B) LED POWER INDICATOR
(C) RCA AUDIO INPUTS

Step 1: Lift seatback to the upright position.
Step 2: Refer to diagram on far right for directions on
securing upright position.
Step 3: Insert receptacle (4) into adapter cord(2).
Step 4: Plug adapter (2) into outlet.
Step 5: Turn Power/Volume Control (A) clockwise.
Step 6: Refer to pages 7 & 8 for connection to media devices.
6
4
Fold fabric down.
Secure ap with use of
hook & loop fastener.
Flap maintains the seat’s
upright position.
STEP 2
A.
B.
STEP 1
2
STEP 3

VOLUME
POWER
INPUT
R L
+
™
CONNECTING TO GAME CONSOLES
7
Step 1:
Step 2:
Plug yellow composite video cable from game
console into video input of TV. (Fig. 1)
Plug Red/White RCA cord from game console into
RCA INPUT (C) of BoomChair™. (Fig. 2)
Step 1:
Step 2:
Step 3:
Connect Audio Coupler (3c) to Red/
White RCA cord from game console.
Connect one end of RCA cord (3b) into
other end of Audio Coupler (3c).
Connect other end of RCA cord (3b) into
RCA INPUT (C) of BoomChair™ .
IN
Note: All game consoles are supplied with a custom connector with
yellow video out and RCA red/white audio out.
3c 3b
GAME CONSOLE TV BOOMCHAIR™
Fig. 1
Fig. 2
Cable supplied with game console
Fig. 3
Alternate Connection:
Connect directly from the TV Audio Out to the BoomChair™
Audio Input using the RCA audio cords provided.
Note: It may be necessary to extend your BoomChair™
further away from your TV or console. Here’s how. (Fig.3)
AUDIO COUPLER (3c)

Plug the single end of the RCA cord (3a)
into the headphone jack of your device.
Plug the pair of RCA cords into RCA
INPUT (C) on the BoomChair™.
3a = headphone jack to audio left & right
channel connectors.
CONNECTING TO HAND-HELD GAMES, MP3 PLAYERS & CD/DVD PLAYERS
8
VOLUME
POWER
INPUT
R L
+
™
COMPUTER
HAND-HELD GAMES
MP3 PLAYERS
CD/DVD PLAYERS
3a
Step 1:
Step 2:

DAISY CHAINING CHAIRS TOGETHER : up to 4 chairs
9
Step 1:
Step 2:
Step 3:
Step 4:
Connect single end of rst “Y” adapter to RED RCA plug coming from media device. (Fig.1)
Connect single end of second “Y” adapter to WHITE RCA plug coming from media device. (Fig.2)
Cord A (Fig.3): Connect RED plug to RED “Y” adapter and WHITE plug to WHITE “Y” adapter. Seperate
cords as necessary. Connect opposite end of cord to INPUT of rst BoomChair™.
Cord B (Fig.4): Connect RED plug to RED “Y” adapter and WHITE plug to WHITE “Y” adapter. Seperate
cords as necessary. Connect opposite end of cord to INPUT of second BoomChair™.
Media Device or TV IN
IN
RCA “Y” ADAPTER
(sold seperately)
RCA CORD (3b)
3b
FIRST CHAIR
SECOND CHAIR
Fig. 1
Fig. 2
Fig. 3
3b Fig. 4
Note: You will need two RCA “Y” adapters (sold seperately) and two RCA cords (3b) to connect two BoomChairs
Audio OUT

CLEANING/CARE INSTRUCTIONS
Fabric: Use a clean cloth to dab lightly with soap and water. DO NOT rub.
DO NOT immerse in water. DO NOT use detergent.
TROUBLESHOOTING BOOMCHAIR™
If a problem occurs while using this product, please contact us. DO NOT open unit or attempt to repair on your own. It may result in
serious injury from electric shock and void your product warranty.
MAINTENANCE AND REPAIR
Q: Why isn’t there sound coming from any of my speakers?
A: Ensure your BoomChair™ is connected as described in the Setup Guide. Check that the power to the unit is on and the volume is
turned up. Also, make sure your audio device is not set to “MUTE” and volume is turned up.
Q: Why isn’t there sound coming from one of the speakers?
A: Ensure the audio cord to the BoomChair™ is securely connected as described in the Setup Guide.
Make sure that both the left and right channel audio inputs and outputs are securely connected to the BoomChair™ and audio device.
Q: Where can I get more information?
A: Visit us at www.BoomChair.com or www.LumiSource.com
Contact information: LumiSource, Inc. 2950 Old Higgins Road, Elk Grove Village, IL 60007
E-mail: [email protected]
NOTE: PLEASE DO NOT USE ON HARDWOOD FLOORS, IT MAY CAUSE SCRATCHING.
10

LIMITED WARRANTY: LumiSource, Inc. (“LumiSource”) warrants this product against defects in materials and workmanship for a period of ninety (90) days from the
date of original consumer purchase. If a covered warranty claim is timely made, LumiSource®will, at its sole discretion: (a) repair the product, using new and/or
refurbished replacement parts or (b) replace the product with an identical (or comparable) product, without charge to you other than the initial shipping cost to return the
product. LumiSource®will only pay return shipping charges for destinations within the 48 continguous U.S.A., if the returned product is covered by the limited warranty.
WHAT THIS WARRANTY DOES NOT COVER: This warranty does not cover defects resulting from accidents, alterations, unauthorized repair, failure to follow
instructions, misuse, commercial use, re, ood, or acts of God.
WHAT WE ASK YOU TO DO: If there is a covered defect, please write or email us within 90 days of the date of purchase at the address noted on page 8 to obtain
instructions and authorization to return the product to LumiSource®. You will need to pack the product securely in packaging providing at least the degree of protection
of the original carton and packing materials and ship it to us at your expense. You will also need to include with the product (a) a copy of your original proof of purchase
(retail receipt) showing the date of purchase and (b) a detailed explanation of the problem(s) requiring service.
TO THE EXTENT PERMITTED BY LAW, THIS LIMITED WARRANTY AND THE REMEDIES SET FORTH
ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, REMEDIES AND CONDITIONS,
ORAL OR WRITTEN, EXPRESS OR IMPLIED. TO THE EXTENT PERMITTED BY LAW, LUMISOURCE®
HEREBY DISCLAIMS ANY IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION, WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT APPLICABLE
STATE LAW EXCLUDES SUCH DISCLAIMERS, THEN TO THE EXTENT ALLOWED BY LAW, THE TIME
FOR ANY CLAIMS FOR SUCH IMPLIED WARRANTIES SHALL EXPIRE 90 DAYS FROM THE DATE OF
ORIGINAL CONSUMER PURCHASE. TO THE EXTENT PERMITTED BY LAW, LUMISOURCE®IS NOT
RESPONSIBLE FOR DIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING BUT
NOT LIMITED TO LOSS OF TIME, INCONVENIENCE, LOSS OF USE OF YOUR PRODUCT, OR PERSONAL
INJURY OR PROPERTY DAMAGE, CAUSED BY YOUR PRODUCT OR ITS FAILURE TO WORK.
This limited warranty gives you specic legal rights. Some states do not allow the exclusion or limitation of incidental or consequential damages, and applicable law
may not permit the exclusion of certain implied warranties. You may also have their rights, which vary, from state to state.
LUMISOURCE, INC. LIMITED WARRANTY
11

www.BoomChair.com or www.LumiSource.com
,UM3OURCE¸
Check out our other BOOM afliated products:
BOOMCUBE™ BOOMCHAIR™ 2.0 BOOMCHAIR™ 1.0
05-2006
