Lush Projects LushOne Echo Manual

LushOne EchoSynthModule
BuildInstructions

2 LushOne Echosynthmodule– buildinstructions
Gettingstarted
•IfyoucanbuildtheLushOne basemodulethenthen
buildingtheEchoshouldbeeasy
•Remember:
–Accuracyandneatnessismoreimportantthanspeed
•Getitworkingfirsttime
–TheseinstructionswillguideyoubutIassumeyouare
familiarwithbasictechniquesandequipment
•Allcomponentsexceptthepower‐inaremountedon
thecircuitboard–noslow,fiddlypointtopointwiring!

3 LushOne Echosynthmodule– buildinstructions
Buildorder
Buildinanyorderyoulike,butIsuggest:
•Patchsockets
•ICs
•Resistors,capacitors
•Transistor,diodes
•Powerleads
•Internal/Externalfeedbackswitch
•Variableresistors

4 LushOne Echosynthmodule– buildinstructions
Front
Thefollowingcomponentsaremountedfromthefront:
•Patchsockets
•Variableresistors

5 LushOne Echosynthmodule– buildinstructions
Back
Thefollowingcomponentsaremountedfromtheback:
•Everythingnotonthefront!

6 LushOne Echosynthmodule– buildinstructions
Patchsockets
•9smallsilverpatchsocketsfitfrom
frontofboard
•Fitinthelarge,labelledcircles
–Notthefourmountingholesinthe
extremecorners
•Solderroundrimonback
•Suggestyoufitfirstsoyoucan
makethemsitnicelyflushwiththe
board

7 LushOne Echosynthmodule– buildinstructions
ICs
•AllICsaremountedfromtheback
•ICsareprovidedunsocketed
–Youcanaddsocketsifyoulike!
•Positionsandorientationsaremarkedonthesilk‐screen
–Pin1alsohasasquarepad
•Thevoltageregulatorhasthesamecaseasthetransistors–checkthe
labels!
–Orientationisshownonsilk‐screen
Designation Type Comment
U201,U202 LM324 14Pin
U301 LM13700 16Pin
U401 78L05 3Pintransistor‐stylecase
U402 PT2399 16 Pin

8 LushOne Echosynthmodule– buildinstructions
Resistors •Allresistorsaremountedfromtheback
•Resistorsareallmountedvertically
•Labelsarenotinasetpositionrelativetothesymbol–
lookfortheclosestlabel
•Theroundsilk‐screensymbolshowninthephotoshows
theresistorlocations
•Resistorcoloursareonnextpage
Value Resistors
220R R413
470R R205,R304,R306,R317,R319
1k R307,R320
1.5k R421
2.2k R207,R310,R323,R328,R334,
R411,R418
2.7k R401
4.7k R303,R316,R417,R422
5.6k R209
8.2k R305,R318
10k R206,R208,R313,R326,R403,
R404,R407,R416
15k R402,R405,R406,R408
22k R201,R203,R204
27k R312,R325
33k R309,R322
47k R202,R332,R335,R419
68k R415
100k R327,R329,R330,R331,R333,
R336,R410,R412,R414
180k R409
330k R301,R302,R308,R311,R314,
R315,R321,R324
1M R420

9 LushOne Echosynthmodule– buildinstructions
Resistorcolours
Value Colours
220R Red,Red,Brown,Gold
470R Yellow,Purple,Brown,Gold
1k Brown,Black, Red,Gold
1.5k Brown,Green,Red,Gold
2.2k Red,Red,Red,Gold
2.7k Red,Purple,Red, Gold
4.7k Yellow,Purple,Red,Gold
5.6k Green,Blue,Red,Gold
8.2k Grey, Red,Red,Gold
10k Brown, Black,Orange,Gold
15k Brown,Green,Orange,Gold
22k Red, Red,Orange,Gold
27k Red,Purple,Orange,Gold
33k Orange,Orange,Orange,Gold
47k Yellow,Purple,Orange, Gold
68k Blue,Grey,Orange,Gold
100k Brown,Black,Yellow,Gold
180k Brown,Grey,Yellow,Gold
330k Orange,Orange,Yellow,Gold
1M Brown, Black,Green,Gold

10 LushOne Echosynthmodule– buildinstructions
Capacitors
•Allcapacitorsaremountedfromtheback
•Capacitorsaremarkedwithoneofthesymbolsshown
above
•Forelectrolyticcapacitorsthe“+”lead(longerlead)is
labelledandindicatedbythesquarepad.
•Somecapacitorsmaycomewitheitherwideornarrowleg
spacing.Connectasshownbelow.
Value Capacitors Type
22p C302,C308,C316,
C317,C422 Ceramic
100p C423 Ceramic
560p C410,C414 Ceramic
1n C402,C417 Ceramic
4.7n C403,C418 Ceramic
10n C401 Ceramic
100n
C204,C205,C306,
C307,C406,C408,
C409,C412,C415,
C416,C419,C420
Ceramic
1u
C201,C202,C203,
C303,C309,C312,
C314,C315,C404,
C413
Ceramic
(Multi‐
Layer)
10u
C301,C304,C305,
C310,C311,C313,
C407
Electrolytic
47u C405,C411,C421,
C424 Electrolytic
Connectnarrowlegstothesepads
Connectwidelegstothesepads

11 LushOne Echosynthmodule– buildinstructions
Capacitormarkings
Value Marking
22p 220
100p 101
560p 561
1n 102
4.7n 472
10n 103
100n 104
1u 105or1u

12 LushOne Echosynthmodule– buildinstructions
Transistors,diodes
•AllTransistorsanddiodesaremounted
fromtheback.
•Transistorsaremarkedshowingthe
packageorientation.Checkyouhavethe
transistorsandnotthevoltageregulator!
•TherearebothNPNandPNPtransistors–
checkyouhavetherightone
•Diodesareallverticallymountedand
shownwiththesquaresymbol.
–Thediode’sstripeshouldbetowardsthe
printedsquare/squarepad
–Smalllinecomingoutofsquareonsilk
screenshowsdirectionofthelead.
D201,
D202,
D301,
D302,
D401
1N4148
Q401,
Q402
2N3904
NPN
Q403 2N2906
NPN

13 LushOne Echosynthmodule– buildinstructions
Powerleads
•TheLushOne Echocanbe
connectedtotheLushOne base
moduleforpower
•Connectthreeleadstothe
LushOne Echo“PowerIn”
connectors
•Suggest:
–Red=+9V
–Black=0V
–Blue=‐9V
•Connectotherendofpowerleads
tothespareterminalsnexttothe
PowerInontheLushOne base
•Ifyouhavemorethantwo
modulesinyoursystemseenext
slide

14 LushOne Echosynthmodule– buildinstructions
PowerwithmorethantwoLushOne modules
•Toconnectmorethan
oneLushOne moduletoa
LushOne baseitis
desirabletousea“star”
powerconnectionpoint
•Asimpleterminalblockis
aneasychoice
•Connectasshowninthe
diagram
–Switchedoutputof
LushOne basegoestostar
point
–Eachadditionalmodule
connectstothestarpoint
foritspower
LushOne
Base
egLushOne
Contour
egLushOne
Echo
Distribution
starpoint
9V
9V
+9V
0V
‐9V

15 LushOne Echosynthmodule– buildinstructions
Internal/Externalswitch
•ConnecttheInternet/External
feedbackswitchtothefrontof
theboardwhereindicated
•Theswitchcangoineitherway
round

16 LushOne Echosynthmodule– buildinstructions
Variableresistors
•Eightvariableresistorsare
mountedwhereshownonfront
ofboard
•Youmayneedtobendthepins
slightlytomakethemsit
properly
RV301,
RV302,
RV303,
RV304,
RV305,
RV306,
RV401,
RV402
10k

17 LushOne Echosynthmodule– buildinstructions
Checkingtime
•Congratulations– buildingshouldnow
becomplete!
–Takeabreak
•Timetocheck:
–Nopartsleft‐over
–Allparts(particularlyICs)intherightway
–Nobadsolderjointsorunsolderedjoints
–Powerconnectorsoncorrectly(very
important!)
–Nosolderbridgesorotherproblems
•Goodluck

18 LushOne Echosynthmodule– buildinstructions
Testing
Followthequickreferenceguideorthetutorials
totestthefunctionsoftheLushOne Echo
…nowgoplay
