Lutz MDxL Series User manual

0698-825 MD1xL / MD2xL - 06/2021
Operating instructions
COMPRESSED AIR MOTORS 3-16
Manuel d’utilisation
MOTEURS PNEUMATIQUES 17-30
Manual de instrucciones
MOTORES DE AIRE COMPRIMIDO 31-43
Type/Tipo
MD1xL
MD2xL
en
fr
Read this manual before start up!
Avant la mise en service de la pompe, lisez ce mode d‘emploi!
Lea las instrucciones antes de la puesta en marcha.
To be retained for future reference.
Document de référence à conserver!
Conservar para una futura referencia.
es

2
0698-825 MD1xL / MD2xL - 06/2021
en
Fig. / Dessin 2 Fig. / Dessin 4 Fig. / Dessin 5

3
0698-825 MD1xL / MD2xL - 06/2021
en
Table of Contents
1. Concerning this manual.................................................................................................................... 4
1.1 Terms.......................................................................................................................................... 4
1.2 Target groups ............................................................................................................................. 4
1.3 Associated applicable documents .............................................................................................. 4
1.4 Warnings and symbols............................................................................................................... 4
1.5 Latest version ............................................................................................................................. 4
1.6 Copyright .................................................................................................................................. 4
2. Safety ................................................................................................................................................ 5
2.1 General safety information......................................................................................................... 5
2.2 Proper use .................................................................................................................................. 6
 2.3 Specicdanger........................................................................................................................... 7
 2.4 Identication.............................................................................................................................. 8
3. Transport and storage....................................................................................................................... 8
3.1 Transport .................................................................................................................................... 8
3.2 Storage ....................................................................................................................................... 8
4. Starting up ........................................................................................................................................ 9
4.1 Compressed air connection........................................................................................................ 9
4.2 Assembly of pump tube to the motor....................................................................................... 10
5. Operation........................................................................................................................................ 11
5.1 Controlling compressed air motor MD1xL ............................................................................... 11
5.2 Controlling compressed air MD2xL .......................................................................................... 11
6. Maintenance and servicing............................................................................................................. 11
7. Repairs ............................................................................................................................................ 12
8. Disposal .......................................................................................................................................... 12
9. Instructions for the explosion protection........................................................................................ 12
9.1 Marking.................................................................................................................................... 12
9.2 Explosion protection regulations.............................................................................................. 12
 9.3 Identiedignitionhazardsandtheimplementedprotectivemeasures.................................. 12
9.4 Equipotential bonding and earthing........................................................................................ 13
9.5 Traceability ............................................................................................................................... 14
10.Product warranty ............................................................................................................................ 14
Annex.................................................................................................................................................... 15

4
0698-825 MD1xL / MD2xL - 06/2021
en
1. Concerning this manual
This manual
• is part of this product
• is valid for all mentioned series
• describes the safe and proper use in all operating
stages
1.1 Terms
User: Single person or organisation who is using
the products e.g. customer, user, assistant
Children:Young persons up to and including the
age of 14 years.
1.2 Target groups
Target group Task
User ►Retain these operating
instructions at the product’s
place of use for future
reference.
►Demandthestatoreadand
observe these instructions
and the additional valid
documents, in particular
the safety information and
warnings.
►Observe additional
regulations and instructions
concerning the plant.
Qualied
personnel,
installer
►Read, observe and follow
these instructions and the
additional valid documents, in
particular the safety informa-
tion and warnings.
Tab. 1: Target groups and their tasks
1.3 Associated applicable
documents
Document Purpose
Operating instructions
pump tube
Safe and proper use of
the pump tube
Supplementary
operating instructions
for additional delivered
components
Tab. 2: Associated applicable documents and purpose
1.4 Warnings and symbols
Warning Level of
risk
Consequences
in case of non-
compliance
DANGER direct
danger
death or serious
injury
WARNING possible
direct
danger
death or serious
injury
CAUTION possible
dangerous
situation
light injury
NOTICE possible
dangerous
situation
damage of
property
Tab. 3: Warnings and consequences in case of non-
compliance
Symbol Meaning
Safety information
►Comply with all measures that
are marked with a safety sign to
prevent injuries or death.
iInformation / Recommendation
►What to do
→Cross reference
3Requirement
Tab. 4: Symbols and meaning
1.5 Latest version
Pleasendthelatestversionofthisoperating
instruction manual online at
www.lutzpumpsamerica.com.
1.6 Copyright
The content of this operating instruction and the
images contained in them are subject to the copy-
right protection of Lutz Pumpen GmbH.

5
0698-825 MD1xL / MD2xL - 06/2021
en
2. Safety
The manufacturer will not be held responsible for
any damages resulting from non-compliance of
the overall documentation, in particular for dam-
ages in case of non-compliance of the operating
instructions.
2.1 General safety information
Observe following regulations before accomplish-
ing all activities.
Product safety
The motor is constructed in conformity with the
state of the art and approved safety-related stand-
ards. Danger however can occur during use for life
and health of the user or third parties or damage
of the motor and other material assets. Therefore:
• Operate the motor only in a technically sound
state, for its proper use, and conscious of safety
and hazards taking into account these instruc-
tions.
• Ensure that these instructions and all associated
applicable documents are complete, legible, and
stored in a place that personnel can access at all
times.
• Refrain from any manner of working that endan-
gers personnel or uninvolved third parties.
• In the case of a safety-relevant malfunction, stop
the motor immediately and enlist a responsible
person to rectify the malfunction.
• In addition to the overall documentation, ob-
serve the statutory or other safety and accident
prevention regulations, as well as the valid stand-
ards and guidelines of the respective operating
country.
Modications
Unless the manufacturer has provided its consent
in writing, the manufacturer is not liable for
interventionsperformedbytheuser(modications)
on the product, such as conversion, alteration,
newdesign,etc.Modicationsnotagreedwith
themanufacturermayhavethefollowingeects,
among others:
• Functional impairments on the appliance or plant
• Damage to the appliance and other property
damage
• Environmental damage
• Personal injuries right through to death
Duties of the operator
Safety-conscious working
• Operate the motor only in a technically sound
state, for its proper use, and conscious of safety
and hazards taking into account these instruc-
tions.
• Ensure observance and monitoring of:
- Proper use
- Statutory or other safety and accident preven-
tion regulations
- Safety provisions in handling hazardous sub-
stances
- Valid standards and guidelines in the respec-
tive country of operation
• Provide protective equipment.

6
0698-825 MD1xL / MD2xL - 06/2021
en
Personnel qualication
• This device must not be used by children. It may
be used by persons of reduced physical, senso-
ry or mental capacity or by persons lacking in
experience or knowledge provided that they are
supervised or have been instructed in the safe
use of the device and understand the associated
hazards. Cleaning or user maintenance must not
be performed by children.
• Ensure that personnel tasked with work on
the motor have read and understood these
instructions and all associated applicable
documents, particularly safety, maintenance and
servicing information, before they start work.
• Clarify responsibilities, competencies and mon-
itoring of the personnel.
• Ensure that all work is carried out by technical
qualiedpersonnelonly:
- Assembly, servicing, maintenance work
- Work on the electrics
• Personnel to be trained must only work on the
motor under the supervision of technical person-
nel.
• Personnel holding the motor in their hands
during operation will be subjected to vibrations.
Statutory warranty
• During the guarantee period, obtain the manu-
facturer'spermissionformodications,mainte-
nance work or alteration.
• Use only original parts.
Duties of the personnel
• Observe the notices on the motor and maintain
them in a legible state.
• Use protective equipment where necessary.
• Only perform work on the motor during down-
time.
• Disconnect the motor from the compressed air
during all assembly and maintenance work.
• After completing all the work on the motor,
remount the safety devices in accordance with
specications.
2.2 Proper use
A compressed air driven drum and container pump
comprises motor and pump tube to suit the particu-
lar application. Application of the compressed air
motors MD1xL and MD2xL in explosive hazard areas
orforpumpingammableliquidsisonlyallowed
in combination with a pump tube approved for
category 1/2 G.
• Motor may only be operated with pump tube.
• The motor must not be immersed in the liquid
being pumped.
• The motor can be used in the following environ-
ment:
- temporarily outdoors without protection from
weathereects
- on roofed surfaces
- in open and closed rooms
- in explosive hazard areas
• Observe following technical data:
Type MD1xL MD2xL
Power output 1.34 hp / 1000 W
Max. operating
pressure 87 psi / 6 bar 4)
Air consumption1) 53 SCFM / 1.5 Nm³/min
Ambient
temperature
-4°F up to 140°F /
-20°C up to +60°C
Marking2) II 2G Ex h IIB T6 Gb
II 2D Ex h IIIC T80°C Db
Sound pressure
level3) <85dB(A)
Sound power level <96dB(A)
Weight 2.2 lb /
1.0 kg
3.0 lb /
1.4 kg
Order No. 0004-725 0004-735
1) In standard condition (Characteristics of the air consump-
tion →Annex)
2) Drum pumps are approved for explosion groups IIA and
IIB and temperature class T4. As a result hereof, the
combination motor/pump tube is also approved only for
matters(liquidtobepumpedand/orenvironment)ofthis
classication.
3) Measuredat87psi(6bar)operatingpressurewithfully
throttled pump tube
4) 72,5psi(5bar)foroperationinhazardousareasorwhen
pumpingammableliquids.

7
0698-825 MD1xL / MD2xL - 06/2021
en
If the product and supplied accessories are used for
other purposes than the intended purpose, it is the
responsibility of the user to check the suitability and
admissibility.Productusenotconrmedinwriting
by the manufacturer absolves the manufacturer of
any liability.
The manufacturer is not liable for consequences of
incorrect treatment, use, maintenance, servicing
and operation of the appliance, as well as normal
wear and tear. The same applies if faults arise from
modicationsorcongurationsonthepartofthe
user not authorized by the manufacturer.
Prevention of obvious
misapplication (examples)
• Motor may only be operated with correctly
mounted pump tube.
• Motor may only be used in permissible explo-
sion hazard area
• Use suitable compressed air supply
• Do not connect the compressed air supply
while the engine is switched on
• Do not immerse the motor in the liquid being
pumped
• Do not drive inadmissible devices with the
motor
• Do not allow the motor to be operated by
children or people in need of protection
• Do not use improper accessories
• Do not use improper or inadmissible spare
parts
• Observe maintenance intervals
2.3 Specic danger
Explosion hazard area
!DANGER
Danger of explosion from use in an explosion
hazard area!
Whenpumpingammableliquids,theoperational
safety regulation and the following points have to
be observed:
• Compressed air motors are non-electrical oper-
atingappliancesnotrequiringocialapproval
when used in zone 1.
• The motors are therefore suitable for driving
explosion proof Lutz drum- and container pumps
Class I, Group D and C.
• Application restrictions are depending on the
respective pump tube (→operating instructions
pumptube).
• Only authorized for mobile use.
• Connect equipotential bonding (→chapter9).
• Useconductivepressurehosesonly(→operating
instructionspumptube).
• The pump motor must remain outside the drum
or container.
• Operating pressure must not exceed 72,5 psi
(5bar).
• The temperature of the compressed air supplied
must not exceed the max. permissible ambient
temperature.
• Motor and pump tube operation must be con-
trolled.
• Donotoperatethemotorwithammablegases.
• Prescribed inspection periods: Grooved ball
bearing and vane, both have to be exchanged
at latest after 1.000 operating hours.
• The presence of strong charge-generating
processes, in particular the arrangement within
transported dust and within a distance of 1 m
from high-voltage electrodes, must be excluded.
→Chapter 9: Instructions for the explosion
protection

8
0698-825 MD1xL / MD2xL - 06/2021
en
2.4 Identication
Rating plate
1Type
2Serial number of the motor
3Marking of explosion protection
4 Yearofconstructionofthemotor(lasttwodigitsoftheserialnumbere.g.-18for2018)
3. Transport and storage
3.1 Transport
Unpacking and checking condition of delivery
►Unpack the motor on receipt and check for transport damages.
►Report transport damages to the manufacturer immediately.
►Check that the consignment is complete as ordered.
3.2 Storage
►Storemotordry,protectedagainstweathereectsandUV-rays.

9
0698-825 MD1xL / MD2xL - 06/2021
en
4. Starting up
4.1 Compressed air connection
!WARNING
Danger of injury due to uncontrolled restarting of the motor!
►Switchingothemotorbeforeconnectingthecompressedair.
Fig. 1
Function and service life largely depend on the condition and pressure of the compressed air supplied.
Excessive moisture or dirt particles in the compressed air will destroy the motor. A high percentage of
condensateinthecompressedairwillcauseaslightrustdepositinthemotorandtheairoutletmuer
will get covered by ice during air expansion.
Therefore, when starting the compressed air motor, observe the following items (→Fig.1):
• Before connecting the motor to the compressed air supply, clean the compressed air line and the hose
by blowing out with low pressure to remove any dirt particles from the line. Wear safety goggles, hold
thelinetightanddonotstandintheareaoftheairow.
• Mainairlines(6)requireaslightinclinationofatleast1%inthedirectionofowsothatcondensation
watermaybedrainedthroughavalve(7)atthelowestpoint(manuallyorautomatically).
• Branchpipesshouldbeconnectedpointingupwards(5)inthecaseofahorizontalmainline(6)-and
inthecaseofaverticalmainline(4)notatthelowestpoint.Thus,anycondensationwatercollectedin
themainlinewillbepreventedfromowingintothebranch.

10
0698-825 MD1xL / MD2xL - 06/2021
en
• Usemaintenanceunits(3)consistingofairlter
and oiler. The oiler is not necessary for motors
MD1xL and MD2xL, but is recommended for
longerservicelife.Themotorpoweris10-20%
lower with non lubricated air than with lubricated
air.
• Install the maintenance unit with an air connec-
tion of at least G 1/4 in the immediate vicinity of
thecompressedairmotor(1).Usearesin-free
and acid-free mineral oil with a viscosity of 20 to
30cSt(20to30mm²/s)intheoiler(3).Theoil
consumption should be 1 drop per minute as a
minimum.
• Theair lter(3)requiresregularmaintenance
during which the trapped condensation water
isdrainedandthelteriscleaned.
• The compressed air motor will achieve maximum
performanceat87psi(6bar).Thepressurein
thepneumaticsystemexceeding87psi(6bar),
apressureregulator(3)mustbeinstalled.Ad-
justmentofthepressureregulator(3)mustbe
eectedwiththemotorrunning.
• Installanairhose(2)of1/2”(13mm)inside
diameter between maintenance unit and com-
pressed air motor to minimize the pressure
losses.
• Use a stop valve in the pressure line in order
to connect and disconnect the motor without
pressure.
• Note the resulting pressure loss when using
quick-action couplings.
Recommendation for compressed air supply
• Theclassicationofthecompressedairquality
can be taken from ISO 8573-1: 2010.
• Standard values of compressed air quality are
e.g. to be found in VDMA 15390-1: 2014-12.
• For lubricated air, a minimum compressed air
quality by ISO 8573-1: 2010 [-: 4: 4] is recom-
mended.
• For non lubricated air, a minimum compressed
air quality by ISO 8573-1: 2010 [6 3: 3] is recom-
mended.
• Excessive water contentin the compressedair can
cause freezing of the water particles. This may be
the cause for damaging the vanes or clogging the
muer,whichmayaecttheperformanceofthe
motor.
4.2 Assembly of pump tube to the
motor
3Motorisswitchedo
►Connect the motor with the pump tube.
►Turn the motor slightly to ensure that the
driver (→Fig.2,Item1)engagesinthe
coupling
(→Fig.2,Item2).
►Firmly connect the motor and pump tube by
meansofthehandwheel(right-handthread)
(→Fig.2).

11
0698-825 MD1xL / MD2xL - 06/2021
en
5. Operation
!WARNING
Danger of rolling-up and pulling-in of objects!
►Do not put any objects in the opening for the
coupling control (→Fig.4).
►Donotworkonthemotorwiththinandloose-t-
ting gloves.
!WARNING
Danger of injury due to uncontrolled restarting
of the motor!
►The pump must not be left unattended while in
operation.
►If the power supply fails, the motor must be
switchedo.
5.1 Controlling compressed air
motor MD1xL
►Forswitching-on/othemotor,insertacheck
valve in the compressed air line (e.g. ball valve
fromLutzaccessories).
5.2 Controlling compressed air
MD2xL
►On: Moveswitchfromtheo-position
(→Fig.5,item1)totherequiredspeed
(→Fig.5,item2).
O: TurnbacktheswitchtoO-position.
6. Maintenance and servicing
If the compressed air motor is missing the required
power, check the following points:
Fault Cause Remedy
Air pressure
notsucient
(87 psi /
6bar)
• Compressed
air line is
leaky
• Pressure
losses
• Seal or
replace the
compressed
air line
• Enlarge
the cross-
section of the
compressed
air line
Air pressure
uctuating
• Compressed
air line is
leaky
• Compressed
air line,
muerorair
lterblocked
• Error during
generation of
compressed
air
• Seal or
replace the
compressed
air line
• Clean com-
pressed air
line,muer
orairlter
• Check air
compressor
Airlteron
maintenance
unit is dirty or
blocked
• Impurities in
compressed
air
• Cleaning the
airlter
Lack of oil in
the com-
pressed air
system
• Oiler impure
or damaged
• Clean, repair
or replace
oiler
Muer
blocked
• Impurities in
compressed
air
• Dust in the
environment
•Cleanmuer
If none of the above defects is detected, the com-
pressed air motor must be repaired.

12
0698-825 MD1xL / MD2xL - 06/2021
en
7. Repairs
►Repairs should only be made by the manufactur-
er or authorized repair shops.
►Only use original Lutz Pumpen spare parts. If
other spare parts are used, liability on the part
of Lutz Pumpen is obsolete.
8. Disposal
Dispose of the motor according to the locally appli-
cable regulations.
9. Instructions for the explosion
protection
9.1 Marking
II 2G Ex h IIB T6 Gb
II 2D Ex h IIIC T80°C Db
9.2 Explosion protection regula-
tions
►Following standards were used for the com-
pressed air motors:
- EN 1127-1:2011 Explosive atmospheres —
Explosion prevention and protection — Part
1: Basic concepts and methodology
- EN ISO 80079-36:2016 Explosive atmospheres
— Part 36: Non-electrical equipment for
explosive atmospheres — Basic method and
requirements
- EN ISO 80079-37:2016 Explosive atmospheres
— Part 37: Non-electrical equipment for ex-
plosive atmospheres — Non- electrical type of
protection constructional safety ‘'c’', control of
ignition sources ‘'b’', liquid immersion ‘'k’'
►National rules and regulations have to be ob-
served.
9.3 Identied ignition hazards
and the implemented protective
measures
Identied
ignition
hazard
Implemented protective
measures
Hot surface Cooling by adiabatic expansion
of the compressed air
Heat dissipation materially
given
Preventing heating of the
bearingsduetospecied
replacement interval
Mechanically
generated
sparks
Use of suitable materials
Discharge
of static
electricity
Connecting the conductive
housing parts to the
equipotential bonding
Constructive limitation of the
electrostatic charge in plastic
parts

13
0698-825 MD1xL / MD2xL - 06/2021
en
9.4 Equipotential bonding and earthing
!WARNING
Explosion hazard by electrostatic discharge!
Risk of injury due to burns.
Pressure wave:  ying parts can kill.
►Whenusingadrumpumptollcans,drumsorotherportableorxedcontainerswithammableor
combustible liquids, both the container being pumped from and the container being pumped to must
beeectivelyBONDEDandGROUNDEDtopreventdischargeofstaticelectricityorsparkswhichcould
cause explosion and death.
BONDINGistheelectricalinterconnectionbetweencontainers(suchasdrumandareceivingcan).Bonding
must be completed before pumping begins.
GROUNDINGistheelectricalconnectionbetweenacontaineranda„constantground”.A„constantground“
wouldbeametalpipe(waterpipe)orrodincontactwiththeearth.Anundergroundtankandpiping
connected to it would be inherently grounded by nature of the installation.
BothBONDINGandGROUNDINGofcontainersofammableliquidsarerequiredunderU.S.Government
OSHA regulations and National Fire Protection Association Code 77, static electricity.
►Before starting up, an equipotential bonding must be established between the pump, the container to
beemptiedandthecontainertobelled(→Fig.6).
►Clamptheequipotentialbondingcable(orderno.0204-994)tocreateanequipotentialbondingbetween
the pump and the container to be emptied. For better conductivity, remove the paint and dirt from the
clamping points.
►Equipotentialbondbetweenthecontainerstobeemptiedandtobelledviaaconductivesubstrate
(e.g.aconductivegrating).
►Ensure that a conductive transition between container and earthing potential is available.
Legend:
(1)Equipotentialbondingwire,(2)groundwire,
(3)conductivehose,(4)conductiveconnection
fromhosetohoseconnector,(5)Metalpump
tube with marking II 1/2 G IIB T4 in Stain-
lesssteelorHastelloy“C”,(6)explosion-proof
compressedairmotorforzone1,(7)nozzle,
(8)maintenanceunit,(9)earthpotential
Fig. 6

14
en
0698-825 MD1xL / MD2xL - 06/2021
9.5 Traceability
Productsforpotentiallyexplosiveatmospheresareidentiedbyanindividualserialnumber.
Lutz Pumpen ensures the traceability of this device up to the initial point of delivery.
All who deliver the device are obliged to guarantee its traceability to enable subsequent recall actions.
10. Product warranty
We warrant that we shall repair or replace, without additional charge, or refund the purchase price of,
anypumpwhichfailstodelivertheowandpressurecapacitiesspeciedinourproposalorisotherwise
defectiveinmaterialandworkmanship;providedBuyernotiesuspromptlyinwriting.Theoptionof
repair, replacement or refund shall be at our discretion.
Although we shall pay all transportation charges relative to our repairing or replacing a pump, we shall
not be responsible for costs of removal, loading, installation, or other similar related expense.
Thiswarrantyextendstotwelve(12)monthsafterinitialinstallationofthepumporforeighteen(18)
months after its shipment from our factory, whichever period is shorter.
This warranty shall not apply to failures resulting from 1. normal wear and tear 2. alteration, misuse or abuse
by Buyer or a third party or 3. improper installation and/or maintenance by Buyer or a third party. We also
warrantthatweshallre-performanyrepairservicesperformedbyuswhicharedecientinworkmanship
within one year from completion of same.
The foregoing obligations are in lieu of all other obligations and liabilities and all warranties of merchant-
ability,tnessforaparticularpurpose,orotherwiseexpressorimpliedbyfactorbylaw,andstatebuyer’s
exclusive remedies for our breach of this warranty.

15
0698-825 MD1xL / MD2xL - 06/2021
en
Annex
Purity classes of the compressed air according to ISO 8573-1:2010
Class Particles per m² Moisture content and
water Complete oil [10]
0.1..–0,5μm
[1.6, 9]
0.5..–1μm
[1.6, 9]
1..–5μm
[1.6, 9]
0Accordingtodenition
and better than class 1
Accordingtodenition
and better than class 1
Accordingtodenition
and better than class 1
1≤20.000 ≤400 ≤10 ≤-70°C
[2,5]
≤0,01 mg/m³ [1,3]
2≤400.000 ≤6.000 ≤100 ≤-40°C ≤0,1 mg/m³
3 --- ≤90.000 ≤1.000 ≤-20°C ≤1 mg/m³ [1,4]
4 --- --- ≤10.000 ≤+3°C ≤5 mg/m³
5 --- --- ≤100.000 ≤+7°C
6≤5 mg/m³ [1,7] ≤+10°C
7 5 – 10 mg/m³ [1,7] ≤0,5 g/m³
[1,8]
8 0.5.. – 5 g/m³
9 5.. – 10 g/m³
X > 10 mg/m³ [1,7] > 10 g/m³ > 5 mg/m³ [1,4]
[1] –referenceconditions1bar(a)and20°Cat0%relativehumidity
[2] –unless otherwise agreed or stated, reference conditions 7 bar and 20°C
[3] –measured according to ISO 8573-2 and ISO 8573-5
[4] –measured according to ISO 8573-2 ; measurement according to ISO 8573-5 optional
[5] –measured according to ISO 8573-3 and, if required, ISO 8573-9
[6] –measured according to ISO 8573-4
[7] –measured according to ISO 8573-8
[8] –measured according to ISO 8573-9
[9] –if particles greater than 5 µm have been measured, class 0-5 cannot be applied
[10] – liquid, aerosol and vapour oil content

16
0698-825 MD1xL / MD2xL - 06/2021
en
Luftverbrauchskennlinie/
Characteristics of the air consumption
Art.-Nr. / Bezeichnung /
Order No. Description
Motor / Motor: 0004-725 Motor MD1xL / motor MD1xL
0004-726 Motor MD1xL USA / motor MD1xL USA
0004-735 Motor MD2xL / motor MD2xL
0004-736 Motor MD2xL USA / motor MD2xL USA
Änderungen vorbehalten / Subject to change Techn. Stand / State of art 05/20
The values given are subject to measuring and product tolerances and are to be considered as standard values.
Lutz Pumpen GmbH · Erlenstr. 5-7 · 97877 Wertheim · Telefon [phone] · Telefax 09342/87 94 04
Internet: http://www.lutz-pumpen.de · e-mail: [e-mail]
Die angegebenen Werte unterliegen Meß- und Produkttoleranzen und sind als Richtwerte anzusehen. /
2 bar
3 bar
4 bar
5 bar
6 bar
0
10
20
30
40
50
60
70
80
90
0
200
400
600
800
1000
1200
1400
1600
02000 4000 6000 8000 10000 12000 14000 16000
Luftverbrauch / Air consumption in [Nm³/h]
Luftverbrauch / Air consumption in [Nl/min]
n in [1/min]
Characteristics of the air consumption
Air consumption in [Nl/min] Air consumption in [Nm³/h]
n in [1/min]

17
0698-825 MD1xL / MD2xL - 06/2021
fr
Table des matières
1. Concernant ce manuel .................................................................................................................... 18
1.1 Termes...................................................................................................................................... 18
1.2 Les groupes cibles.................................................................................................................... 18
1.3 Documents applicables associés .............................................................................................. 18
1.4 Mises en garde et symboles..................................................................................................... 18
1.5 Dernière version....................................................................................................................... 18
1.6 Droit d‘auteur ........................................................................................................................... 18
2. Sécurité .......................................................................................................................................... 19
2.1 Remarques générales en matière de sécurité.......................................................................... 19
2.2 Utilisation conforme................................................................................................................. 20
2.3 Dangers spéciaux ..................................................................................................................... 21
 2.4 Identication............................................................................................................................ 22
3. Transport et stockage...................................................................................................................... 22
3.1 Transport .................................................................................................................................. 22
3.2 Stockage................................................................................................................................... 22
4. Démarrage...................................................................................................................................... 23
4.1 Le accordement d’air comprimé............................................................................................... 23
4.2 Montage du corps de pompe sur le moteur............................................................................. 24
5. Fonctionnement.............................................................................................................................. 25
5.1 Contrôler le moteur à air comprimé MD1xL............................................................................. 25
5.2 Contrôler le moteur à air comprimé MD2xL............................................................................. 25
6. Maintenance et réparation ............................................................................................................. 25
7. Réparations..................................................................................................................................... 26
8. Conteneur d’ordures ....................................................................................................................... 26
9. Consignes sur la protection d’explosion ......................................................................................... 26
9.1 Marquage ................................................................................................................................ 26
9.2 Réglementations pour la protection contre les explosions...................................................... 26
 9.3 Dangersd’inammationidentiésetmesuresdeprotectionréalisées................................... 26
9.4 Equilibrage des potentiels et mise à la terre............................................................................ 27
9.5 Traçabilité ................................................................................................................................ 28
10.Garantie .......................................................................................................................................... 28
Annexe.................................................................................................................................................. 29

18
0698-825 MD1xL / MD2xL - 06/2021
fr
1. Concernant ce manuel
Ce manuel
• fait partie de ce produit
• est valable pour toutes les séries mentionnées
• décrit l’utilisation sûre et appropriée à tous les
stades d’exploitation
1.1 Termes
Utilisateur: Personne ou organisation unique qui
utilise les produits par exemple client, utilisateur,
assistant
Enfants: Jeunes enfants jusqu’à 14 ans révolus.
1.2 Les groupes cibles
Groupes
cibles
Tâches
Utilisateur ►Conserver ces instructions de
service sur le lieu d'utilisation
pour pouvoir s’y référer
ultérieurement.
►Exiger du personnel de lire
et respecter ces instructions
de service et les documents
valides supplémentaires, en
particulier les consignes de
sécurité et avertissements.
►Respecter les réglementa-
tions et les instructions rela-
tives au site de l'installation.
Personnel
qualié,
installateur
►Lire, observer et suivre les
instructions et les documents
valides supplémentaires, en
particulier les consignes de
sécurité et avertissements.
Tab. 1: Les groupes cibles et leurs tâches
1.3 Documents applicables associés
Documents But
Mode d`emploi
corps de pompe
Utilisation sûre et appro-
priée du corps de pompe
Instructions
complémentaires
Pour d'autres composants
livrés
Tab. 2: Documents applicables associés et but
1.4 Mises en garde et symboles
Avertissement Niveau
de risque
Conséquences
en cas de non-
respect
DANGER Danger
direct
Danger de mort
ou blessures
sérieuses
AVERTISSE-
MENT
Danger
direct
possible
Danger de mort
ou blessures
sérieuses
ATTENTION Situation
de danger
possible
Blessure légère
AVIS Situation
de danger
possible
Dégâts de
propriété
Tab. 3: Informations sur la sécurité et conséquences en
cas de non-conformité
Symbole Signication
Information de sécurité
►Observer toutes les mesures
qui sont marquées avec
un signe de sécurité pour
empêcher des blessures ou la
mort.
iInformation / Recommandation
►Quoi faire
→Renvoi
3Besoin
Tab.4:Symbolesetsignications
1.5 Dernière version
Nous vous prions de bien vouloir trouver la dernière
version de cette notice d’instructions sur le site
www.lutzpumpsamerica.com.
1.6 Droit d‘auteur
Le contenu de ce mode d’emploi et les images sont
soumis aux droits d’auteur de Lutz Pumpen GmbH.

19
0698-825 MD1xL / MD2xL - 06/2021
fr
2. Sécurité
Le fabricant ne sera pas tenu pour responsable
des dommages résultant de la non-conformité de
la documentation générale, en particulier pour les
dommages en cas de non-respect des instructions
d’utilisation.
2.1 Remarques générales en
matière de sécurité
Respecter les consignes suivantes avant d’accomplir
toutes les activités.
La sécurité des produits
Le moteur est construit techniquement selon des
règles de sécurité reconnues. Lors de l’utilisation,
le danger peut cependant se produire pour la santé
voire la vie de l’utilisateur ou des tiers, ou l’endom-
magement du moteur et d’autres biens matériels.
Par conséquent:
• Utiliser le moteur en bon état technique, pour
l’usage pour lequel il est conçu et dans le respect
des instructions de sécurité et de prévention des
risques.
• S’assurer que les instructions et tous les docu-
ments pertinents associés sont complets, lisibles
et stockés dans un endroit facilement accessible
pour le personnel utilisateur.
• S’abstenir de toute forme de travail qui mettrait
en danger le personnel ou des tiers non impli-
qués.
• Dans le cas d’un dysfonctionnement des sécu-
rités, arrêter le moteur immédiatement et faire
appel à unepersonne responsable pourremédier
à la panne.
• En plus de la documentation générale, observer
la sécurité élémentaire et les préventions des
risques d’accidents selon les dispositions légales
ou autres, ainsi que les normes et les lignes
directrices respectives propres à chaque pays
d’exploitation.
Modications
Sauf avis favorable écrit du fabricant, celui-ci ne
peut être tenu pour responsable des interventions
eectuéesparl’utilisateur(modications)surle
produit,tellesquelaconversion,lamodication,
lanouvelleconception,etc…Desmodications
nonagréesparlefabricantpeuventavoirleseets
suivants, entre autres:
• Troubles fonctionnels de l’appareil ou de
l’installation
• Dommages sur l’appareil et autres dommages à
la propriété
• Dommages environnementaux
• Blessures pouvant entrainer la mort
Obligations de l’exploitant
Travail soucieux de la sécurité
• Utiliser le moteur en bon état technique, pour
l’usage pour lequel il est conçu et dans le respect
des instructions de sécurité et de prévention des
risques.
• Veiller au respect et à la surveillance de:
- Utilisation conforme
- La réglementation statutaire ou autre sécurité
et de prévention des accidents
- Dispositions de sécurité dans la manipulation
des substances dangereuses
- Les normes et les lignes directrices respectives
propres à chaque pays d’utilisation
• Fournir des équipements de protection.

20
0698-825 MD1xL / MD2xL - 06/2021
Qualication du personnel
• Ce matériel ne doit pas être utilisé par de jeunes
enfants. Matériel pouvant être utilisé par des
personnes ayant des capacités physiques, sonso-
rielles ou mentales réduites ou sans expérience
sous réserve qu’elles soient surveillées ou ins-
truites de l’utilisation du matériel et des dangers
potentiels inhérents. Nettoyage et maintenance
non réalisables par des enfants.
• S’assurer que le personnel, chargé des travaux
sur le moteur a lu et compris ces instructions
et tous les documents pertinents associés,
notamment la sécurité, la maintenance et les
services d’information, avant de commencer leur
travail.
• Clarierlesresponsabilités,lescompétenceset
la surveillance du personnel.
• S’assurerquetoutletravailesteectuéparun
personneltechniquequalié:
- Assemblage, service, travaux d’entretien
- Travaux sur le système électrique
• Le personnel en cours de formation ne peut
intervenir sur le moteur que sous la supervision
d’un responsable technique.
• L’utilisateur est soumis à des vibrations, quand il
tient en main le moteur en train de fonctionner.
Garantie légale
• Au cours de la période de garantie, obtenir l’au-
torisationdufabricantpourdesmodications,
des travaux d’entretien ou de reconstruction.
• Utilisez uniquement des pièces d’origine.
Obligations du personnel
• Respectez les consignes sur le moteur et les
maintenir dans un état lisible.
• Utilisez un équipement de protection si néces-
saire.
• Les interventions de maintenance du moteur
doiventêtreeectuéesaumoteuràl’arrêt.
• Déconnectez le moteur de l’air comprimé pen-
dant tous les travaux d’installation et de main-
tenance.
• Après maintenance du moteur, effectuer le
remontage en respectant scrupuleusement les
consignes de sécurité.
2.2 Utilisation conforme
Une pompe vide-fûts et vide-réservoirs pneuma-
tiquerenfermentmoteurettubedepompeande
satisfaire aux exigences de l’application envisagée.
L’application des moteurs à air comprimé MD1xL
et MD2xL dans des zones à risque d’explosion ou
pour le pompage de liquides inflammables est
uniquement autorisée en combinaison avec un
tube de pompe approuvé pour la catégorie 1/2 G.
• Ne faire fonctionner le moteur qu’avec un corps
de pompe.
• Le moteur ne doit pas être immergé dans le
liquide à pomper.
• Le moteur peut être utilisé dans l’environnement
suivant:
- temporairement à l’extérieur sans protection
contre les intempéries
- sur les surfaces couvertes
- dans des pièces ouvertes et fermées
- dans les zones à risque d’explosion
fr
