MINN KOTA VANTAGE User manual

VANTAGE
TRANSOM-MOUNT TROLLING MOTOR
USER MANUAL

NOTE: Do not return your Minn Kota motor to your retailer. Your retailer is not authorized to repair or replace this unit. You may obtain service
by: calling Minn Kota; returning your motor to the Minn Kota Factory Service Center; sending or taking your motor to any Minn Kota
authorized service center. A list of authorized service centers is available on our website. Please include proof of purchase, serial number and
purchase date for warranty service with any of the above options.
Please thoroughly read this user manual. Follow all instructions and heed all safety and cautionary notices below. Use of this motor is only
permitted for persons that have read and understood these user instructions. Minors may use this motor only under adult supervision.
ATTENTION: Never run the motor out of the water, as this may result in injuries from the rotating propeller. The motor should be disconnected from
the power source when it is not in use or is off the water. When connecting the power-supply cables of the motor to the battery, ensure that they are
not kinked or subject to chafe and route them in such a way that persons cannot trip over them. Before using the motor make sure that the insulation
of the power cables is not damaged. Disregarding these safety precautions may result in electric shorts of battery(s) and/or motor. Always disconnect
motor from battery(s) before cleaning or checking the propeller. Avoid submerging the complete motor as water may enter the lower unit through
control head and shaft. If the motor is used while water is present in the lower unit considerable damage to the motor can occur. This damage will not
be covered by warranty.
CAUTION: Take care that neither you nor other persons approach the turning propeller too closely, neither with body parts nor with objects. The
motor is powerful and may endanger or injure you or others. While the motor is running watch out for persons swimming and for floating objects.
Persons whose ability to run the motor or whose reactions are impaired by alcohol, drugs, medication, or other substances are not permitted to use
this motor. This motor is not suitable for use in strong currents. The constant noise pressure level of the motor during use is less than 70dB(A). The
overall vibration level does not exceed 2,5m/sec2.
LOCATING YOUR SERIAL NUMBER
Your Minn Kota 11-character serial number is very important. It helps to determine the specific model and year of manufacture. When contacting
Consumer Service or registering your product, you will need to know your product’s serial number. We recommend that you write the serial number
down in the space provided below so that you have it available for future reference.
CE MASTER USER MANUAL (FOR CE/C-TICK CERTIFIED MODELS)
Conforms to 89/336/EEC (EMC) under standards EN 55022A, EN 50082-2 since 1996 LN V9677264
THANK YOU
Thank you for choosing Minn Kota. We believe that you should spend more time fishing and less time positioning your boat.
That’s why we build the smartest, toughest, most intuitive trolling motors on the water. Every aspect of a Minn Kota trolling motor
is thought out and rethought until it’s good enough to bear our name. Countless hours of research and testing provide you the
Minn Kota advantage that can truly take you “Anywhere. Anytime.” We don’t believe in shortcuts. We are Minn Kota. And we
are never done helping you catch more fish.
REMEMBER TO KEEP YOUR RECEIPT AND IMMEDIATELY REGISTER YOUR TROLLING MOTOR.
The serial number on your Vantage is located on
the inside of the main transom bracket
Made by Minn Kota
Johnson Outdoors
Vantage 80 36”
MODEL 1352625
SER NO M365 MK12345
EXAMPLE

WARRANTY ON MINN KOTA FRESHWATER TROLLING MOTORS
Johnson Outdoors Marine Electronics, Inc. (“JOME”) extends the following limited warranty to the original retail purchaser only. Warranty coverage is not
transferable.
MINN KOTA LIMITED TWO-YEAR WARRANTY ON THE ENTIRE PRODUCT
JOME warrants to the original retail purchaser only that the purchaser’s new Minn Kota freshwater trolling motor will be materially free from defects in materials
and workmanship appearing within two (2) years after the date of purchase. JOME will (at its option) either repair or replace, free of charge, any parts found by
JOME to be defective during the term of this warranty. Such repair, or replacement shall be the sole and exclusive liability of JOME and the sole and exclusive
remedy of the purchaser for breach of this warranty.
MINN KOTA LIMITED LIFETIME WARRANTY ON COMPOSITE SHAFT
JOME warrants to the original retail purchaser only that the composite shaft of the purchaser’s Minn Kota trolling motor will be materially free from defects in
materials and workmanship appearing within the original purchaser’s lifetime. JOME will provide a new composite shaft, free of charge, to replace any composite
shaft found by JOME to be defective during the term of this warranty. Providing a new composite shaft shall be the sole and exclusive liability of JOME and the
sole and exclusive remedy of the purchaser for breach of this warranty; and purchaser shall be responsible for installing, or for the cost of labor to
install, any new composite shaft provided by JOME.
EXCLUSIONS & LIMITATIONS
This limited warranty does not apply to products that have been used in saltwater or brackish water, commercially or for rental purposes. This limited warranty
does not cover normal wear and tear, blemishes that do not affect the operation of the product, or damage caused by accidents, abuse, alteration, modification,
shipping damages, acts of God, negligence of the user or misuse, improper or insufficient care or maintenance. DAMAGE CAUSED BY THE USE OF
OTHER REPLACEMENT PARTS NOT MEETING THE DESIGN SPECIFICATIONS OF THE ORIGINAL PARTS WILL NOT BE COVERED BY
THIS LIMITED WARRANTY. The cost of normal maintenance or replacement parts which are not in breach of the limited warranty are the responsibility
of the purchaser. Prior to using products, the purchaser shall determine the suitability of the products for the intended use and assumes all related risk and
liability. Any assistance JOME provides to or procures for the purchaser outside the terms, limitations or exclusions of this limited warranty will not constitute
a waiver of the terms, limitations or exclusions, nor will such assistance extend or revive the warranty. JOME will not reimburse the purchaser for any expenses
incurred by the purchaser in repairing, correcting or replacing any defective products or parts, except those incurred with JOME’s prior written permission.
JOME’S AGGREGATE LIABILITY WITH RESPECT TO COVERED PRODUCTS IS LIMITED TO AN AMOUNT EQUAL TO THE PURCHASER’S
ORIGINAL PURCHASE PRICE PAID FOR SUCH PRODUCT.
MINN KOTA SERVICE INFORMATION
To obtain warranty service in the U.S., the product believed to be defective, and proof of original purchase (including the date of purchase), must be presented
to a Minn Kota Authorized Service Center or to Minn Kota’s factory service center in Mankato, MN. Any charges incurred for service calls, transportation or
shipping/freight to/from the Minn Kota Authorized Service Center or factory, labor to haul out, remove, re-install or re-rig products removed for warranty service,
or any other similar items are the sole and exclusive responsibility of the purchaser. Products purchased outside of the U.S. must be returned prepaid with
proof of purchase (including the date of purchase and serial number) to any Authorized Minn Kota Service Center in the country of purchase. Warranty service
can be arranged by contacting a Minn Kota Authorized Service Center or by contacting the factory at 1-800-227-6433 or email [e-mail].
Products repaired or replaced will be warranted for the remainder of the original warranty period [or for 90 days from the date of repair
or replacement, whichever is longer]. For any product that is returned for warranty service that JOME finds to be not covered by or not
in breach of this limited warranty, there will be a billing for services rendered at the prevailing posted labor rate and for a minimum of at
least one hour.
NOTE: Do not return your Minn Kota product to your retailer. Your retailer is not authorized to repair or replace products.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THESE LIMITED WARRANTIES. IN NO EVENT SHALL ANY IMPLIED
WARRANTIES INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE, EXTEND
BEYOND THE DURATION OF THE RELEVANT EXPRESS LIMITED WARRANTY. IN NO EVENT SHALL JOME BE LIABLE FOR PUNITIVE,
INDIRECT, INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES. Without limiting the foregoing, JOME assumes no responsibility for
loss of use of product, loss of time, inconvenience or other damage.
Some states do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damages, so the above
limitations and/or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other legal rights which vary from state
to state.
FEATURES
Specifications subject to change without notice.
*This diagram is for reference only and may differ from your actual motor.
Cool, Quiet Power Motor
Bracket Tension and
Angle Adjustment Screw
Clamp Screws
4:1 Articulated Steering
Direction Indicator
Speed Control Power Trim
On/Off Tilt/Extend Tiller Handle
Digital Maximizer
Breakaway Mounting Bracket
Weedless Wedge 2 Propeller

INSTALLATION
MOTOR INSTALLATION
With its variable shaft length, the Vantage will fit on most transoms between 14 and 28 inches high.
1. Trailer the boat and park it on a level surface.
2. Locate the Vantage on the boat transom where it will be mounted. The location
choice is important. The Vantage motor lower unit rotates 400°. It must,
therefore, be positioned far enough to the side of the outboard engine along the
transom so that during rotation it will not strike the outboard engine. With the 36V
101 version, you should install the transom extrusion (provided) before you secure
the Vantage to the transom.
TRANSOM EXTRUSION INSTALLATION (101 MODELS ONLY)
a. Set Vantage on transom with clamp screws backed out.
b. Slide extrusion between inside of transom and the clamp screw washers and tighten clamp screws.
c. Attach extrusion to transom with two screws provided. This will require drilling
two appropriate sized pilot holes for the self tapping screws.
3. Set the angle adjustment/tensioning screws (located on the sides of transom
bracket) so the motor is perpendicular to the ground. Hand tighten the screws.
4. Measure from the ground to the bottom of the hull. Measure from ground to the
bottom of the Vantage skeg. Secure the unit so the bottom of the skeg is at one
inch above the bottom of the hull, directly in front of the Vantage (accounting
for the v-shape of the boat hull). Use a 1/2 inch open-end wrench to loosen the
four transom bracket nuts/bolts between the body of Vantage and the transom
bracket. Adjust the body of Vantage to a one-inch level above the transom and
secure. This will position the Vantage lower unit and prop so that, when retracted,
they will clear the bottom of the boat. It may take several attempts to achieve
correct placement.
5. Adjust the handle to a comfortable position.
NOTE: When mounted properly, the Vantage motor lower unit will be out of the water when the boat is on plane. If lower unit
creates water spray when on plane, slightly re-adjust it higher until there is no more water spray.
CAUTION:
• Never operate your motor when it is out of the water.
• Over-tightening the clamp screws can damage the bracket.
WARNING: When raising/lowering motor or operating the tilt mechanism, keep fingers clear of all hinge and
pivot points and all moving parts.
Measure from a level surface
Transom Extrusion

BOAT RIGGING & PRODUCT INSTALLATION
For safety and compliance reasons, we recommend that you follow American Boat and Yacht Council (ABYC) standards when
rigging your boat. Altering boat wiring should be completed by a qualified marine technician. The following specifications are for
general guidelines only:
CAUTION: These guidelines apply to general rigging to support your Minn Kota motor. Powering multiple motors or additional
electrical devices from the same power circuit may impact the recommended conductor gauge and circuit breaker size. If you are
using wire longer than that provided with your unit, follow the conductor gauge and circuit breaker sizing table below. If your wire
extension length is more than 25 feet, we recommend that you contact a qualified marine technician.
An over-current protection device (circuit breaker or fuse) must be used. Coast Guard requirements dictate that
each ungrounded current-carrying conductor must be protected by a manually reset, trip-free circuit breaker or fuse. The type
(voltage and current rating) of the fuse or circuit breaker must be sized accordingly to the trolling motor used. The table below gives
recommended guidelines for circuit breaker sizing.
Reference:
United States Code of Federal Regulations: 33 CFR 183 – Boats and Associated Equipment
ABYC E-11: AC and DC Electrical Systems on Boats
CONDUCTOR GAUGE AND CIRCUIT BREAKER SIZING TABLE
Motor Thrust /
Model Max Amp Draw Circuit Breaker Wire Extension Length *
5 feet 10 feet 15 feet 20 feet 25 feet
30 lb. 30 50 Amp @ 12 VDC 10 AWG 10 AWG 8 AWG 6 AWG 4 AWG
40 lb., 45 lb. 42 10 AWG 8 AWG 6 AWG 4 AWG 4 AWG
50 lb., 55 lb. 50 60 Amp @ 12 VDC 8 AWG 6 AWG 4 AWG 4 AWG 2 AWG
70 lb. 42 50 Amp @ 24 VDC 10 AWG 10 AWG 8 AWG 8 AWG 6 AWG
80 lb. 56 60 Amp @ 24 VDC 8 AWG 8 AWG 8 AWG 6 AWG 6 AWG
101 lb. 46 50 Amp @ 36 VDC 8 AWG 8 AWG 8 AWG 8 AWG 8 AWG
Engine Mount 101 50 60 Amp @ 36 VDC 8 AWG 6 AWG 4 AWG 4 AWG 2 AWG
112 lb. 52 60 Amp @ 36 VDC 8 AWG 8 AWG 8 AWG 8 AWG 8 AWG
Engine Mount 160 116 (2) x 60 Amp @ 24 VDC 2 AWG 2 AWG 2 AWG 2 AWG 2 AWG
E-Drive 40 50 Amp @ 48 VDC 10 AWG 10 AWG 10 AWG 10 AWG 10 AWG
This conductor and circuit breaker sizing table is only valid for the following assumptions:
1. No more than 3 conductors are bundled together inside of a sheath or conduit outside of engine spaces.
2. Each conductor has 105° C temp rated insulation.
3. No more than 5% voltage drop allowed at full motor power based on published product power requirements.
*Wire Extension Length refers to the distance from the batteries to the trolling motor leads.
BATTERY WIRING & INSTALLATION

SELECTING THE CORRECT BATTERIES
The motor will operate with any lead acid, deep cycle marine 12 volt battery/batteries. For best results, use a deep cycle, marine battery
with at least a 105 ampere hour rating. Maintain battery at full charge. Proper care will ensure having battery power when you need
it, and will significantly improve the battery life. Failure to recharge lead-acid batteries (within 12-24 hours) is the leading cause of
premature battery failure. Use a multi-stage charger to avoid overcharging. We offer a wide selection of chargers to fit your charging
needs. If you are using a crank battery to start a gasoline outboard, we recommend that you use a separate deep cycle marine battery/
batteries for your Minn Kota trolling motor.
Advice Regarding Batteries:
• Never connect the (+) and the (–) terminals of the battery together. Take care that no metal object can fall onto the battery and short
the terminals. This would immediately lead to a short and extreme fire danger.
• It is highly recommended that a circuit breaker or fuse be used with this trolling motor. Refer to “Conductor Gauge and Circuit Breaker
Sizing Table” in the previous section to find the appropriate circuit breaker or fuse for your motor. For motors requiring a 60-amp
breaker, the Minn Kota MKR-19 60-amp circuit breaker is recommended.
CONNECTING THE BATTERIES IN SERIES (IF REQUIRED FOR YOUR MOTOR)
24 VOLT SYSTEMS:
1. Make sure that the motor is switched off (speed selector on “0”).
2. Two 12 volt batteries are required.
3. The batteries must be wired in series, only as directed in wiring
diagram, to provide 24 volts.
a. Connect the connector cable supplied with the
motor to positive (+) terminal of battery 1 and
to negative (–) terminal of battery 2.
b. Connect positive (+) red lead to positive
(+) terminal on battery 2.
c. Connect the yellow (+) lead to positive
(+) terminal on battery 1.
d. Connect negative (–) black lead to
negative (–) terminal of battery 1.
4. For safety reasons do not switch the motor on until the propeller is in the water. If installing a leadwire plug, observe proper polarity
and follow instructions in your boat owner’s manual. See wiring diagram on following pages.
36 VOLT SYSTEMS:
1. Make sure that the motor is switched off (speed selector on “0”).
2. Three 12 volt batteries are required.
3. The batteries must be wired in series, only as
directed in wiring diagram, to provide 36 volts.
a. Connect the connector cable supplied with
the motor to positive (+) terminal of battery
1 and to negative (–) terminal of battery 2.
b. Connect positive (+) red lead to
positive (+) terminal on battery 3.
c. Connect the yellow (+) lead to
positive (+) terminal on battery 1.
d. Connect negative (–) black lead to
negative (–) terminal of battery 1.
4. For safety reasons do not switch the motor on
until the propeller is in the water. If installing a leadwire plug, observe proper polarity and follow instructions in your boat owner’s
manual. See wiring diagram on following pages.
CAUTION
• Improper wiring of 24/36 volt systems could cause battery explosion!
• Keep leadwire wing nut connection tight and solid to battery terminals.
• Locate battery in a ventilated compartment.
• For safety reasons, disconnect the motor from the battery or batteries when the motor is not in use or while
the battery/batteries are being charged.
To trolling motor negative
24 Volt Connection
Battery #1 (Low Side)
Neg - Neg -Pos + Pos +
Battery #2 (High Side)
+24 Volts to trolling motor
positive (or circuit breaker)
24 Volt Series Connection
Yellow Lead
To trolling motor negative
24 Volt Connection 36 Volt Connection
Battery #1 (Low Side)
Neg - Neg - Neg -Pos + Pos + Pos +
Battery #2 Battery #3 (High Side)
+36 Volts to trolling motor
positive (or circuit breaker)
36 Volt Series Connection
Yellow Lead
BATTERY WIRING & INSTALLATION

24 VOLT SYSTEM
MOTOR WIRING DIAGRAM
BATTERY 1 BATTERY 2
Red Motor+ Black Motor-
Red Battery+
Black Battery-
White Lift Lead
Lift Lift
Black Lift Lead
Lift Motor
Control Board
On/Off Light
Deploy Light
Coil Cord Leads
Jumper
Yellow Lead
MOTOR
Coil Cord

36 VOLT SYSTEM
MOTOR WIRING DIAGRAM
BATTERY 1 BATTERY 2 BATTERY 3
Red Motor+ Black Motor-
Red Battery+
Black Battery -
White Lift Lead
Lift Lift
Black Lift Lead
Lift Motor
Control Board
On/Off Light
Deploy Light
Coil Cord Leads
Jumper Jumper
Yellow Lead
MOTOR
Coil Cord

USING & ADJUSTING THE MOTOR
ADJUSTING THE DEPTH OF THE MOTOR
To position the lower unit, press and release the DOWN button on the tiller to
automatically lower the motor into the water. To adjust for shallow water, deploy
the motor and hit the DOWN button a second time and the motor will stop at that
point. Use the UP button to adjust depth if still necessary. When the DOWN button
is pushed, the motor down LED will illuminate and stay lit until the motor is retracted
back to its stowed position. The motor is only designed to deploy a certain distance.
Pushing the DOWN button when the motor is fully deployed or UP button when the
motor is fully stowed may result in lift motor damage.
NOTE: If the UP button is pushed while the lower unit is running, the power will shut
off to protect the lift system.
CAUTION: Never operate your motor when it is out of the water.
CONTROLLING SPEED AND DIRECTION WITH THE TILLER
Locate the ON/OFF switch located at the end of the control handle. Push the switch in to
power on, and push the switch again to power off. The LED indicator will illuminate when
power is on. This motor offers a choice of infinitely variable speeds. Turn the control button
on the tiller counterclockwise to decrease speed and clockwise to increase speed.
ARTICULATED STEERING
The tiller has a 4-to-1 steering ration which enables you to rotate the lower unit 180° by moving the tiller just 45°.
ON/OFF Switch
UP/DOWN Button
Extendable Tiller
Speed Control
45º
180º
45º
180º
Increase Speed
Decrease Speed

USING & ADJUSTING THE MOTOR
BACKTROLLING
The orientation of the lower unit can be changed for backtrolling. Set your speed to 0 and trim the lower unit down to the fully
deployed position. Slide the latch knob to the front and hold. Align the directional indicator with the tiller handle and slightly twist
the indicator knob left or right while pulling up with slight force until the alignment is achieved and the indicator knob is free. Lift
and turn the indicator knob counterclockwise 180°, then align the indicator in its new position with the tiller handle and press
down to re-seat it. Release the latch knob..
ADJUSTING THE TILLER
Pull the tiller handle to extend the tiller an additional 7 inches.
The handle can be positioned at an angle using the large clamp screw.
Loosen the screw located at the base of the handle, adjust the handle
to a comfortable position then hand-tighten the screw.
CAUTION: Over-tightening the clamp screw, or adjusting
the handle angle without loosening clamp screw, can
damage the bracket.
NOTE: Always loosen clamp before adjusting angle and
retighten when desired angle is achieved.
Clamp Screw
Latch Knob (shown in forward position)
Indicator Knob

Propeller
Slot End
Drive Pin
Prop Nut
Washer
PROPELLER REPLACEMENT
TOOLS AND RESOURCES REQUIRED:
• Box End Wrench
- 1/2” for motors with 70 lbs thrust or lower.
- 9/16” for motors with 80 lbs thrust or higher.
• Screwdriver (optional)
CAUTION:
Disconnect the motor from the battery
before beginning any prop work or
maintenance.
NOTE: The propeller on your motor may differ from
the one pictured.
1. Disconnect the motor from all sources of power prior to changing the propeller.
2. Hold the propeller and loosen the prop nut with pliers or a wrench.
3. Remove the prop nut and washer. If the drive pin is sheared or broken, you will need to hold the shaft stationary with a blade
screwdriver pressed into the slot on the end of the shaft.
4. Turn the old prop to horizontal (as illustrated) and pull it straight off. If drive pin falls out, push it back in.
5. Align the new propeller with the drive pin.
6. Install the prop washer and prop nut.
7. Tighten the prop nut 1/4 turn past snug [25-35 inch lbs.] Do not over tighten as this can damage the prop.
GENERAL MAINTENANCE
1. After use, the entire motor should be rinsed with freshwater, then wiped down with a cloth dampened with an aqueous based
silicone spray. This series of motors is not equipped for saltwater exposure.
2. The propeller must be inspected and cleaned from weeds and fishing line after every use.
Fishing line and weeds can get behind the prop, damage the seals and allow water to enter the motor.
3. Verify the prop nut is secure each time the motor is used.
4. To prevent accidental damage during transportation or storage, disconnect the battery whenever the motor is off of the water.
For prolonged storage, lightly coat all metal parts with an aqueous based silicone spray.
5. For maximum battery life recharge the battery(s) as soon as possible after use. For maximum motor performance restore
battery to full charge prior to use.
6. Keep battery terminals clean with fine sandpaper or emery cloth.
7. The propeller is designed to provide weed free operation with very high efficiency. To maintain this top performance, the
leading edge of the blades must be kept smooth. If they are rough or nicked from use, restore to smooth by sanding with fine
sandpaper.
SERVICE & MAINTENANCE

1. Motor fails to run or lacks power:
• Check battery connections for proper polarity.
• Make sure terminals are clean and corrosion free. Use fine sandpaper or emery cloth to clean terminals.
• Check battery water level. Add water if needed.
2. Motor loses power after a short running time:
• Check battery charge. If low, restore to full charge.
3. You experience prop vibration during normal operation:
• Remove and rotate the prop 180°. See removal instructions in the Propeller Replacement section.
4. The lower unit does not fully deploy:
• Check for shallow water or underwater obstructions.
5. The deployed lower unit does not fully retract:
• Press the DOWN button so the lower unit returns to full deploy. Then press and hold the UP button until the unit is fully
retracted.
6. Experiencing interference with your fishfinder:
•You may, in some applications, experience interference in your depth finder display. We recommend that you use a
seperate deep cycle marine battery for your trolling motor and that you power the depth finder from the starting/cranking
battery. If problems still persist, call our service department.
ATTENTION: The lift system of the Vantage motor can be aff ected by cold temperatures. At temperatures below 32 degrees
Farenheit., (0 degrees Celsius.), the lubricant in the lift system can become viscous preventing stow/deploy. Also, if this motor is
being used in open water areas at freezing temperatures, ice can form on the telescoping portion of the motor shaft preventing
stow/deploy. In either case, placing the motor in a warm, heated area will restore the lift system to normal operation.
NOTE: For all other malfunctions, visit an Authorized Service Center. You can search for an Authorized Service Center in your
area by visiting our Authorized Service Center page, found online or by calling our customer service.
TROUBLESHOOTING & REPAIR

PARTS DIAGRAM
28
26
29
30
1
11
12
13R
13B
18
18
7
8
9
10
19
16
20
21
27
25
22
24
23
31
151
37
46
47
48
49
42
39
40
43
45
54
52
53
51
55
33
74
38
44
65
134
135
117
116
113
110
111
128
66
71
72
57
56
70
69
78
145
146
147
148
144
161
64
112
113
66
118
67
81
63
83
32
84
82
105
109
108
85
86
92
93
94
87
90
91
119
120 89
123
127
126
125
124
122
130
129
132
131
133
95
88
101
102
143
142
149
97
100 98 99
107
150
106
35
36
34
114
41
79A
79
61
140
103
104
141
106
50
80
139
62
138
73
68
60
59
58
15
17
137
162
152
153
154
6
4
5
This page provides Minn Kota® WEEE compliance disassembly instructions.
For more information about where you should dispose of your waste equipment for recycling and recovery and/
or your European Union member state requirements, please contact your dealer or distributor from which your
product was purchased.
Tools required, but not limited to: flat head screw driver, Phillips screw driver, socket set, pliers, wire cutters.
VANTAGE 80
80 LBS THRU - 24 VOLT
VANTAGE 101
101 LBS THRU - 36 VOLT
2054908 rev M ECN 35975

PARTS LIST
VANTAGE 80/101
80/101 LBS THRU - 24/36 VOLT
ITEM QTY PART
NUMBER DESCRIPTION
1 1 421-276 PIN END HOUSING SY
4 1 990-045 THRU SPACER
5 2 992-010 SPRING WHER
6 1 140-010 BALL BEARING
7 1 2-100-214 ARMATURE SEMBLY 80
12-100-216 ARMATURE SEMBLY 101
8 1 788-040 RAINING RING
9 1 990-051 WHER-THRU, EEL
10 1990-052 WHER- NYTRON
n12-600-144 BRUSH/WIRE/PTE SEMBLY(11-13)
*11 1738-004 BRUSH PTE
*12 2975-041 SPRING -TORSION
13 2188-094 BRUSH
15 2973-025 SPACER -BRUSH PTE
16 2830-027 SCREW - 10-32 X 2.2”
17 12-200-160 CENTER HSING SY 80
12-200-110 CENTER HSING SY 101
*18 2701-043 O-RING
19 1144-017 BEARING -FNGE
20 12-300-160 BRUSH END HOUSING SY
*21 2880-025 SEAL
*22 2701-009 O-RING -THRU BOLT
n12889460 SEAL & ORING KIT(18, 21, & 22)
23 2830-094 THRU BOLT 80
2830-096 THRU BOLT 101
24 12316271 MOTOR SEMBLY 80
12316261 MOTOR SEMBLY 101
25 1979-015 RAIN RELIEF - BODY
26 19950339 P - RAIN RELIEF
27 12382900 GROMMENT- RAIN RELIEF
28 12331160 PROPELLER (W.WEDGE 2)
29 12093101 NUT-PROP NYLOC (RGE)
30 12091701 WHER-PROP (RGE)
31 12772010 TUBE-MOTOR
1 3/4” KIT W/TEMPTE
32 12991822 TRANSOM BRCKT SY
33 12056505 HOUSING EXTRUSION
34 42053511 BOLT-RRIAGE 5/16-18 1”
35 42151726 WHER-5/16 D (S/S)
36 42053103 NUT, 5/16-18 NYLOC
37 12770420 LOWER SUPPORT GE SEMBLY
38 12057302 BEARING-UPPER, LI SCREW
n12881510 YOKE/BEARING RACE KIT (39,40,42)
*39 12051510 YOKE-LI SCREW
*40 12056200 BEARING RACE-YOKE
ITEM QTY PART
NUMBER DESCRIPTION
41 22053401 SCREW-10 X 1/2,TYPE 25
*42 12353401 SCREW-10-16 X 1/2 ALGD
43 12053400 SCREW-LI, 1/2-10 ACME
44 12052707 SPRING-COIL,SO OP
45 12770429 COIL SPRING/WHER KIT
46 42053413 SCREW-10-16X1’
N 1 2883200 WIRE CMP KIT (47,48,49)
*47 12053200 WIRE CMP, LEHAND
*48 12053205 WIRE CMP, RIGHTHAND
*49 12053417 SCREW-10-16X3/4
50 12770400 TAPE SPRING SY (51-55)
51 12052705 SPRING, CONANT FORCE
52 12052610 PIN-PIVOT 7/16” O.D.
53 12051920 BRACK-SPRING
54 12052305 WIRE GUIDE
55 12053418 SCREW-#4-40X1/4
56 12050225 WIRE SHIELD
n12770405 TOP PTE SEMBLY (57,60,61,68)
*57 12051927 TOP PTE
58 22053414 SCREW-#8-32 X 1/2
59 22051717 WHER-#8 SAE FT
*60 12057306 BEARING-BALL
*61 12057302 BEARING-UPPER
LI SCREW
*62 12052630 PIN, CLUER GEAR
63 12053415 SCREW-#8-32 X 3/8
64 12051716 WHER-FENDER #10
65 12052001 SHA-EERING
66 22051706 WHER-SPRING SUPPORT
67 12052205 GEAR, EERING TUBE MACHINED
*68 12052616 PIN-DRIV-LOK 1/8 X 1 1/8
69 12052510 BLE CMP, 3/16’
70 12053415 SCREW-#8-32 X 3/8
71 12777812 MOTOR-LI (12,24,36V)
72 12058411 TENSIONER-BELT
73 32053422 SCREW - 3MM
74 42053413 SCREW-10-16X1
n12882201 CLUER GEAR / FNGE PULLEY KIT (75, 76, 77)
*75 12770427 PULLEY/PINION GEAR SY
*76 12058405 FNGE-PULLEY
*77 22053418 SCREW 4-40 X 1/4 PPH
78 12050800 BELT-DRIVE
79 12051705 WHER-NYLON
79A 12051703 WHER-THRU
n12882200 GEAR LI/PIN KIT (80,62)

PARTS LIST
ITEM QTY PART
NUMBER DESCRIPTION
*80 12990426 LI GEAR SEMBLY
81 12052620 PIN-DRIV-LOK 1/8 X 5/8”
82 12056520 P-LOWER, GEAR HOUSING
83 12383500 BOLT-3/8-16 X 1.25
84 32053402 SCREW-10-24 X 1”
85 12054600 O-RING, GEAR HOUSING
86 12056510 UPPER P GEAR HOUSING
87 12057200  T C H
88 12052711 SPRING, TCH RURN
89 12050102 KNOB-TCH
90 12353401 SCREW-10-16 X 1/2 ALGD
91 12051716 WHER-FENDER #10
92 12151730 WHER-CUP
(HINGE BRACK)
93 12051737 WHER - FT (ZINC)
94 12053107 NUT-3/8-16, TOPLOCK
96 12990921 HANDLE SEMBLY
n12884106 HANDLE RL BOARD/GRIP KIT (97,149)
*97 12994005 RL BOARD SY-HANDLE
98 12055115 BUTTON SWITCH AUATOR
n12883701 PLUNGER/GRIP KIT (99,149)
*99 12053700 PLUNGER, ON/OFF
100 12050111 KNOB-SPEED CONTROL
101 22012100 SCREW-8-18 X 5/8” THD CUT
102 22053412 SCREW 8 X 1.5”
n12880921 HANDLE TENSION KNOB KIT (103-105, 141)
*103 12051736 WHER-URHANE
*104 12053115 NUT-WHER, HANDLE SY
*105 12050015 RACH-DISK, HANDLE SY
n12880920 BRACK TENSION HANDLE KIT (106, 107, 150)
*106 12051737 WHER-FT
*107 22050922 HANDLE, TENSION, SHORT
108 12052510 BLE CMP, 3/16”
109 12053415 SCREW-#8-32 X 3/8”
*110 12774041 CNTRL BRD SY 24/36V W/PAD INCL.111
*111 12315105 INSUTING PAD
112 22261712 SHOULDER WHER
113 32053407 SCREW-#8-32 X .75 PPH
114 12051220 LEADWIRE,24/36V CONDU
116 12052512 BLE CMP, 1/2”
117 12053415 SCREW-#8-32 X 3/8”
118 12052210 ROLLER-EERING SHA
n12880102 CONTROL HEAD COVER TCH KIT (89,90,91,119)
119 12050200 COVER-CONTROL HEAD
120 32053415 SCREW-#8-32 X 3/8”
nTHIS ITEM IS PART OF AN SEMBLY.
*THIS ITEM IS PART OF A KIT AND ONLY LIED FOR
VIEWING PURPOS.
ITEM QTY PART
NUMBER DESCRIPTION
121 22012100 SCREW-8-18 X 5/8”
122 12050211 SHROUD-CONTROL HEAD
123 22055612 DEL-SHROUD
124 12055604 DEL-COVER, 24V
12055602 DEL-COVER, 36V
125 12055610 DEL-COVER, LED
126 12051712 WHER- .152 ID, .50 OD, .06
127 12302100 SCREW-6-20 X 1/2”
128 42012100 SCREW-8-18 X 5/8”
129 12050110 KNOB-POINTER, VANTAGE
130 12051717 WHER- #8
131 12332101 SCREW-8-32 X 1/2” SS
132 12371715 LOCKWHER-AR #8 ZINC
133 12056700 PLUG, POINTER
134 12050220 SHIELD-EXTRUSION
135 22053414 SCREW-#8-32 X 1/2”
136 22055611 DEL-SHIELD - VANTAGE
137 22998200 CIRCUIT BRKR ASSEMBLY 36V
138 12051732 WHER .315 X .562
139 12053420 S SCREW #8-32
140 32051710 LOCKWHER 3MM
141 12050921 HANDLE TENSION - LONG
n12880910 HANDLE L/R KIT (100,101,102,142,143,150)
*142 12050916 HANDLE SIDE L
*143 12050911 HANDLE SIDE R
n22880925 HANDLE/CMP SCREW KIT (144-148)
*144 12051300 SCREW-CMP 5/8X4
*145 12050925 HANDLE-CMP SCREW
*146 12052625 PIN-COILED SPRING
*147 12011710 WHER-CMP SCREW
*148 12263402 SCREW- 1/4-20X3/4”
149 12880424 GRIP KIT
*150 12053105 NUT- HEX
151 12881500 TUBE/SLEEVE/BUSHING KIT
152 12990950 HANDLE/RL BOARD SY
153 12262658 PROP PIN
154 22340610 CONNEOR BLE
n12994844 TRANSOM EXTRUSION KIT (161, 162) - 101 ONLY
161 22053421 BOLT - 14-1/4X1 - 101 ONLY
162 12058415 TRANSOM EXTRUSION
KIT - 101 ONLY
VANTAGE 80/101
80/101 LBS THRU - 24/36 VOLT

ENVIRONMENTAL COMPLIANCE STATEMENT:
It is the intention of JOME to be a responsible corporate citizen, operating in compliance with known and applicable
environmental regulations, and a good neighbor in the communities where we make or sell our products.
WEEE DIRECTIVE:
EU Directive 2002/96/EC “Waste of Electrical and Electronic Equipment Directive (WEEE)” impacts most distributors, sellers,
and manufacturers of consumer electronics in the European Union. The WEEE Directive requires the producer of consumer
electronics to take responsibility for the management of waste from their products to achieve environmentally responsible
disposal during the product life cycle.
WEEE compliance may not be required in your location for electrical & electronic equipment (EEE), nor may it be required
for EEE designed and intended as fixed or temporary installation in transportation vehicles such as
automobiles, aircraft, and boats. In some European Union member states, these vehicles are considered
outside of the scope of the Directive, and EEE for those applications can be considered excluded from the
WEEE Directive requirement.
This symbol (WEEE wheelie bin) on product indicates the product must not be disposed of with other
household refuse. It must be disposed of and collected for recycling and recovery of waste EEE. Johnson
Outdoors Inc. will mark all EEE products in accordance with the WEEE Directive. It is our goal to comply
in the collection, treatment, recovery, and environmentally sound disposal of those products; however, these requirement do
vary within European Union member states. For more information about where you should dispose of your waste equipment for
recycling and recovery and/or your European Union member state requirements, please contact your dealer or distributor from
which your product was purchased.
DISPOSAL:
Minn Kota motors are not subject to the disposal regulations EAG-VO (electric devices directive) that implements the WEEE
directive. Nevertheless never dispose of your Minn Kota motor in a garbage bin but at the proper place of collection of your local
town council.
Never dispose of battery in a garbage bin. Comply with the disposal directions of the manufacturer or his representative and
dispose of them at the proper place of collection of your local town council.
WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects
or other reproductive harm.
COMPLIANCE STATEMENTS

• 60-Amp Circuit Breaker
• Mounting Brackets
• Stabilizer Kits
• Extension Handles
• Battery Connectors
• Battery Boxes
• Quick Connect Plugs
RECOMMENDED ACCESSORIES
ON-BOARD & PORTABLE BATTERY CHARGERS
Stop buying new batteries and start taking care of the ones you’ve got. Many chargers can actually damage your battery
over time – creating shorter run times and shorter overall life. Digitally controlled Minn Kota chargers are designed to provide the
fastest charge that protect and extend battery life.
TALON SHALLOW WATER ANCHOR
Talon deploys faster, holds stronger and runs quieter than any other shallow water anchor. Available in depths up to 12’ and bold color
options, it boasts an arsenal of features and innovations that no other anchor can touch:
MINN KOTA ACCESSORIES
We offer a wide variety of trolling motor accessories, including:
MK210DMK345PC MK110P
• Vertical, multi-stage deployment
• User-Selectable Anchoring Modes
• 2x Anchoring Force
• Fast Deploy
• Auto Up/Down
• Triple Debris shields*
• Built-In Wave Absorption
• Noise Dissipation
• Versatile Adjustments
*available on 10’ and 12’ models only
