LuxaFlex PowerView User manual

PowerView™Motorisation
Smart shades that simplify your life
Quickstart guide
Scene

A brilliant evolution
in The Art of Window Styling.

3
COMPONENTS
This guide will help you get started with your Powerview™
purchase.
STEP 1 INSTALL YOUR SHADES
Make sure you have properly installed your shades and that
they are connected to a power source (battery pack or power
supply).
STEP 2 YOUR POWERVIEW™
COMPONENTS
Packed with your purchased product you will find one or more
remotes, repeaters and a Hub (which is optional and only
required when you want to control your shades using a tablet
or smartphone). Remotes come in different shapes and colours.
Please locate them all before you start.
Pebble™ Remote
Wall Surface
Repeater (optional)
Hub (optional), required for controlling your shades
with a tablet or smartphone.

4
PAIRING REMOTES
The Scene Controller (as shown on the top right of this page),
will be explained in the chapter ‘Additional Actions’on page 15
of this guide.
STEP 3 PAIRING REMOTES
If you only have one remote, please proceed to Step 4.
By pairing PowerView™ remotes you make all your remotes
part of the same PowerView™ Network. This is important for
seamless installation of the PowerView™ system.
For this instruction you use the STOP button on your
Remote.
3.1 TAKE TWO REMOTES, NAME
THEM ‘REMOTE 1’, ‘REMOTE 2’ AND
FOLLOW THE INSTRUCTIONS
BELOW
Repeat these steps if you have more than two remotes.
Scene
Controller
Stop

5
REMOTE 2:
3.2 REMOVE BACK COVER
(Keep batteries in place).
REMOTE 2:
3.3 PRESS THE RESET BUTTON FOR SIX
SECONDS
The group button will flash on the press of the Reset
button, then again at six seconds.
PAIRING REMOTES

REMOTE 2:
3.4 CLOSE THE COVER
REMOTE 1:
3.5 PRESS STOP FOR 6 SECONDS
(Keep pressing until the remote lights start blinking).
REMOTE 2:
3.6 PRESS STOP AND HOLD
REMOTE 1:
3.7 PRESS STOP AND HOLD
3.8 RELEASE STOP ON BOTH REMOTE 1 AND REMOTE 2
(As confirmation remote 2 will flash the group buttons).
3.9 IF THE BUTTONS ON REMOTE 2 ARE STILL FLASHING PRESS
STOP FOR 6 SECONDS
(Keep pressing until the flashing stops).
Do you have a third or fourth remote? Take one of the above Remotes and name it Remote 1. Take your third
Remote and name it Remote 2. Go to step 3.2 and proceed from there.
PAIRING REMOTES
6

STEP 4 ADDING A SHADE TO
A REMOTE
A Remote can control 6 individual groups of shades (which are
the buttons 1 to 6).
The instructions below assign a shade to group 1. Depending
on your preference you can choose your own group.
This instruction will make use of the OPEN, GROUP 1, and
STOP buttons on your remote.
Find the shade button on your shade.
Different shade types have different shade buttons. Consult
the shade documentation for the exact location of the shade
button.
Open
Group 1
Stop
ADDING A SHADE TO A REMOTE
7
Shade button

4.1 PRESS STOP FOR 6 SECONDS
(Keep pressing until the remote lights start blinking).
4.2 PRESS GROUP1
(This will activate the group 1 on the remote).
4.3 PRESS AND HOLD THE SHADE BUTTON
4.4 PRESS THE OPEN BUTTON
(You will see the shade move up and down shortly).
4.5 RELEASE THE SHADE BUTTON
4.6 IF YOUR REMOTE IS STILL FLASHING: PRESS STOP
FOR 6 SECONDS AND HOLD
(Keep pressing until the flashing stops).
ADDING A SHADE TO A REMOTE
8

STEP 5 INSTALL REPEATERS
Installation of a repeater is necessary when your shade is
not responding to a command from your remote control.
Preferably put the repeater halfway between the unresponsive
shade and the remote control location.
This instruction will make use of the STOP button on your
remote and the button on the repeater.
INSTALL REPEATERS
Stop
Repeater button/light
9

INSTALL REPEATERS
10
5.1 PLACE THE REPEATER IN THE USB
CHARGER AND PLUG IT IN AN
OUTLET
(The repeater light illuminates green).
5.2 PRESS STOP FOR 6 SECONDS
AND HOLD
(Keep pressing until the Remote lights start blinking).
5.3 HOLD THE REMOTE WITHIN 20 CM
FROM THE REPEATER
5.4 PRESS STOP
(The repeater light will turn off. The repeater is now part of
your personal Powerview™ Network).

CONNECT AND SETUP THE HUB
11
STEP 6 CONNECT AND SETUP
THE HUB
If you have not purchased a Hub please proceed to ‘Additional
Actions’on page 15 to proceed with your installation.
6.1 CONNECT THE HUB TO YOUR
HOME NETWORK ROUTER
6.2 CHECK THE RANGE OF THE HUB
Your Hub should be able to reach each shade in the
house. Use your remote from the same location as your
Hub to operate your shades. If some shades do not
respond, add or relocate a repeater and check again.
6.3 CONNECT THE HUB TO YOUR
POWER OUTLET

CONNECT AND SETUP THE HUB
12
6.4 WAIT APPROX. 2 MINUTES AND
OBSERVE THE HUB LIGHT
- Blue/Red blinking:
All ok. Proceed with the installation.
- Red Blinking:
Hub is downloading updates. Please wait
(approx. 5-15 minutes).
- Continuous blue:
Hub is already connected to a network. If you have
previously setup your hub you can continue. If not you
can clear the data on the hub. Go to Erase hub data in
the Additional actions chapter.

CONNECT THE POWERVIEW™ APP TO THE HUB
13
STEP 7 CONNECT THE POWERVIEW™
APP TO THE HUB
Take your remote control.
7.1 DOWNLOAD THE POWERVIEW™
APP FROM THE APP STORE OR PLAY
STORE
7. 2 START THE APP
(The app will start looking for an available Hub).
7. 3 WAIT FOR THE NEXT SCREEN TO
APPEAR AND CLICK SET UP
7. 4 GIVE YOUR HUB A NAME AND
CLICK SUBMIT
PowerView™
MOTORISATION
New Hub found
SET UP
Name Your Hub
Cancel
Control your window treatments from your phone or tablet
Submit
PV Hub

CONNECT THE POWERVIEW™ APP TO THE HUB
14
7. 5 PRESS OK
7. 6 WAIT FOR THE NEXT SCREEN AND
SELECT NEXT STEP
7. 7 FOLLOW THE ON SCREEN
INSTRUCTIONS TO ADD THE HUB
TO YOUR EXISTING POWERVIEW™
NETWORK
7. 8 YOU CAN NOW START WITH
THE APP
(For further instructions please go to
www.luxaflex.co.uk/powerview-installation).
P
owerView
™
MOTORISATION
Name Your Hub
OK
Hub succesfully named PV Hub.
PowerView™
MOTORISATION
PowerView™Network
Next StepI don’t have a remote
Please locate the PowerView Remote that has been paired with
your window treatments and place it next to the Hub.

ADDITIONAL ACTIONS
15
ADDITIONAL ACTIONS
Your PowerView™ Network is now setup and ready to be
further adjusted to your preferences. Follow the steps in this
chapter or go to www.luxaflex.co.uk/powerview-installation for
more information.
OPERATE A SHADE
This instruction will make use of the OPEN, GROUP 1,
STOP, ALL and CLOSE buttons on your Remote.
1PRESS GROUP 1
(Group 1 will light up).
2PRESS OPEN
(Shades assigned to group 1 will open).
3PRESS STOP
(Shades assigned to group 1 will stop).
4PRESS CLOSE
(Shades assigned to group 1 will close).
Open
Group 1
Stop
All
Close
Pressing all instead of group 1 will move all shades from
all 6 groups on the remote.

ADDITIONAL ACTIONS
16
SET A FAVOURITE POSITION
This instruction will make use of the STOP and
FAVOURITE buttons on your remote.
Find the shade button on your shade.
(Different shade types have different shade buttons. Consult
the shade documentation for the exact location of the shade
button).
Stop
Favourite
Shade button

ADDITIONAL ACTIONS
17
1MOVE YOUR SHADE TO THE DESIRED FAVORITE POSITION
(Use your OPEN, CLOSE and STOP buttons to move the shade).
2PRESS STOP FOR 6 SECONDS
(Keep pressing until the Remote lights start blinking).
3PRESS AND HOLD THE SHADE BUTTON
4PRESS THE FAVOURITE BUTTON
(You will see the shade move up and down briefly).
5RELEASE THE SHADE BUTTON
6IF YOUR REMOTE IS STILL FLASHING PRESS STOP FOR 6 SECONDS
(Keep pressing until the flashing stops).

ADDITIONAL ACTIONS
18
MOVE A SHADE TO A FAVOURITE
POSITION
This instruction will make use of the GROUP 1, FAVOURITE
and ALL button on the Remote.
Move shades assigned to group 1 to their favourite
position.
1PRESS GROUP 1
(Group 1 will light up).
2PRESS FAVOURITE
(Shades assigned to group 1 will move to their favourite
position).
Pressing all instead of group 1 will move all shades from all
6 groups to their favorite position.
Group 1
Favourite
All

ADDITIONAL ACTIONS
19
REMOVE A SHADE FROM A GROUP
This will remove a shade from a group on your remote control.
It will not remove the shade from the Powerview™ network.
This instruction will make use of the GROUP 1, STOP and
CLOSE buttons on the Remote.
Find the shade button on your shade.
(Different shade types have different shade buttons. Consult
the shade documentation for the exact location of the shade
button).
Group 1
Stop
Close
Shade button

The following instruction removes a product from group 1.
1PRESS STOP FOR 6 SECONDS
(Keep pressing until the remote lights start blinking).
2BRIEFLY PRESS ON GROUP 1
(This will activate the group 1 on the remote).
3PRESS AND HOLD THE SHADE BUTTON
4BRIEFLY PRESS ON CLOSE
(You will see the shade move up and down shortly).
5RELEASE THE SHADE BUTTON
6IF YOUR REMOTE IS STILL FLASHING PRESS STOP FOR 6 SECONDS
(Keep pressing until the flashing stops).
ADDITIONAL ACTIONS
