Luxair LA-52-CAN-SS Operation instructions

GB Use and maintenance instructions
LA-52-CAN-SS
LA-74-CAN-SS
USE AND MAINTENANCE
INSTRUCTIONS

New 74cm & 52 Canopy Kitchen Hood with LED lights and massive extraction rates of 950 m³/hr
Canopy cooker hoods: Luxair's latest range of integrated canopy hoods, the CAN 52/74 with LED lights available in both
52cm and 74cm versions both in Stainless Steel. gone are the very poor canopy hoods with very poor extraction rates and
expensive halogen lights, also paper grease filters are now a thing of the past! quality canopy extractors by Luxair all carry
a full 7 years warranty
Most integrated hoods only offer up to 300 m³/hr but Luxairs new integrated range off a powerful 950 m³/hr motor. Fitted
with 2 LED lights, easy clean metal mesh grills and easy to use switch, this hood is powerful and quiet and delivers the
quality that Luxair are proud of at the most affordable prices.

LA-52/74-CAN-SS

LA-120-CAN-SS
438
258
258
286
1074
1145
252
144 108
150

1
2
3
4
5
6
Remove the outer cover plate by removing the
screws.

SLIDER CONTROL PANEL
:
A- Three-speed suction switch
B- Suction indicator light
C- Lighting switch
7
8
9
10
11
BA C
GB
Warning 5" 125mm ducting must be used on these cooker hoods, any less and your warranty will be void
Filters required if not ducted

SAFETY
A. Do not do flambé cook under the hood
B. Constantly check while using the fryers because overheated oil can catch fire
C. Prior to any cleaning operation, disconnect the unit from electrical power by pulling the plug or operating
the switch
D. If in the room the hood is simultaneously used with other appliances that give off fumes, not powered by
electricity, the room should be provided with ventilation
E. Avoid having free turned on stoves (not used)
F. Limit the use of the hood to its designed purpose: removal of cooking odours; do not use it for other
purposes
G. It is recommended to start the hood shortly before performing any cooking operation and to let it run after
cooking for at least 15 minutes and anyway until the odour has disappeared
H. This unit is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been instructed with regard to the use
of the device and are supervised by a person responsible for their safety. Children should be supervised in
order to make sure they do not play with the appliance.
I. The room must have sufficient ventilation when the hood is used simultaneously with other appliances that
use gas or other fuels
L. There is the possibility of fire if cleaning operations are not done according to the instructions
WARNING: accessible parts may become hot when using the hob.
M. Air should not be discharged into any duct used to discharge exhaust fumes produced by appliances
burning gas or other fuels.
N. Follow the laws applicable for external air evacuation.
O. If the power cable is damaged, it must be replaced by the manufacturer or an authorized technical service
center or by a qualified technician in order to avoid hazards.
TECNICAL SPECIFICATIONS
The technical data pertaining to the electric appliance The technical specifications of the appliance
are shown on the rating plates located inside the range hood.
INSTALLATION INSTRUCTIONS
This hood has been arranged to be installed above a cook top.
ASPIRATING TYPES: External exhaust - Minimum 5" Ducting Required
FILTERING TYPES: Internal re-cycling
We suggest to have installation carried out by qualified personnel, in compliance with all the current
regulations and in particular with the ones concerning air exhaust. The manufacturer cannot be held liable
for damages caused by improper installation or if it has not been carried out according to the state-of-the-
art.
Safety:
Do not connect the appliance dicharge to exhaust ducts of smokes produced by combustion that is not
supplied by electrical power.
The minimum safety distance between the cooking counter and the hood is 65 cm.
In the case in which both the hood and apparatuses emit fumes, do not operate electrical energy. A
sufficient aeration of the setting needs to be created.
GB

CLEANING
Use only a damp doth with neutral liquid detergent.
Do not use wet sponges or cloths, water jets, thinners, solvents, hydrochloric acid, bleach, alcohol or
abrasive substances.
MAINTENACE
Unplug the appliance or switch off the circuit breaker before carrying out maintenance operations.
Filters:
METAL ANTI-GREASE FILTERS
-The filters must be washed at least one a month with hot water and detergent.
-It can also be washed in the dishwasher.
Open by means of the handle.
ACTIVATED CARBON FILTERS
(Only filtering types)
-Carbon charcoal filters must be used when recirculating this cooker hood, these filters are filter type 5.
Lighting:
A B C
Please note that we make this version in four lighting types, this unit has LED lighting and
changing the bulbs is not an option, if the lights fail you will need to change the light unit,
please contact us for replacement light units for LED versions only.
