LUXTON HOME VV-2828 User manual

Page 1of 5
Women's Memory Foam Massage Table
VV-2828
USER’S MANUAL

Page 2of 5
Precautionary Instructions
1. Maintain the table periodically. Make sure all screws are secure and the cable has not
deteriorated or frayed. Make sure there are no cracks on the wooden structure.
2. Do not overload the table beyond the recommended weight limit. This could result in serious injury
to the user. This product is tested to hold a max working load of 551 lbs (250kgs). Don’t apply
loads over 44 lbs (20kgs) on the position of breast holes and on headrest cradle as well.
3. Be cautious not to tangle the cables with legs or support beams.
4. Do not use alcohol based cleaners or harsh cloth when cleaning the vinyl. This could cause
damage to the vinyl material. For PU leather, use dry soft cloth to clean it or use PU leather
friendly cleaning agent to clean and dry it quickly.
5. Make sure when using the table that all four legs are at the same level. Using the legs at different
levels can cause the table to be unstable and cause injury.
6. Do not allow children to assemble or disassemble the massage table for you unless under
supervision.
7. Be careful when using sharp objects as they can pierce the covering. Keep the table’s covering
away from being contacted by the sharp items.
1. Handle 2. Support Beam 3.Armrest Outlet 4. Hanged Rod for Towel
5. Cable 6. Headrest Cradle with Cushion 7. Hanged Armrest 8. Side Armrests
9. Breast Hole 10. Oil Pocket 11. Table Cover 12. Wheels for carry bag
1. Handle
2. Support Beam
3.Armrest Outlet
4. Hanged Rod
for Towel
5. Cable
6. Headrest Cradle
with cushion
7. Hanged Armrest
8. Side Armrests
9. Breast Hole
10. Oil Pocket
11. Table Cover
12. Wheels for carry bag

Page 3of 5
Setting Up Your Table
1. Release the buckle.
2. Lay the table on its side with four rubber stands on the floor, open up the table with four legs extends
as full as possible.
3. Take out all accessories.
4. Lift the table up until all legs are on the floor, to ensure the cables have all been fully extended, be
cautious not to tangle the cables with the legs.
5. Put accessories into the corresponding outlets, put on the hanged armrest or sling on the headrest
cradle.
6. Release the side handle and press it in once the headrest is adjusted to the required position.
Remarks: If the headrest is too loose to be locked, press the opposite side of side handle and rotate
the handle in clockwise direction to make it firmer and press it in.
7. Now the table is ready for your use. You can also put on table cover if you need.
Re: The height of table is adjustable by turning off the knobs on the leg and take out the movable leg
to adjust the height by choosing the holes on the movable leg, put back onto the leg and fasten the
knobs firmly. Four legs should be done in the same way one by one and make sure all legs are
adjusted into same height level. Don’t overload weight of 44 lbs (20kgs) on the position around breast
holes.
Remarks: There are 4 wheels for carry bag to be assembled by DIY, follow the guide of assembly
as in separate page.

Page 4of 5
Instructions for Installing Wheels of Carry Bag
Parts Included: a. 2 pcs of universal wheels c. 9 pcs of screws
b. 2 pcs of directional wheels d. 1 pc of wrench
Assemble all wheels on the bottom of the carry bag. Both Universal wheels should be installed on the
same side of the carry bag that has the handle.
To install wheels, place the wheels on the bottom of the carry bag and align the screw with the hole in
the bottom of the carry bag. Tighten the screw with a wrench.
Note: Each wheel is to be tightened with two screws.
Note: Avoid using the wheeled carry bag on roads with tough conditions or uneven surfaces.
carry bag with a handle
.
(
Handle
)
(
U
niversal wheels
)
(
D
irectional wheels
)

Page 5of 5
Fold Up and Carry Along
1. Take out all accessories.
2. Lay the table on its side with four rubber feet on the ground.
3. Put all accessories under the elastic strap under the top veneer.
4. Fold the legs on each end at angle towards inside by pressing the corresponding support beams.
5. Fold the table up and lock the buckle.
6. Put table inside the carry bag and zipper up. Carry the table with carry bag with shoulder belt.
Warning: If the frame/legs/table structure is damaged in anyway, then you should not use this table.
Using this table when damaged may cause harm or serious injury to you or your patient. You should seek
repair immediately.
