luxvision HE-3000 User manual

Notication
Dear Users,
Thank you for your purchase of HE 3000 Hand Edger Manual. Please take time to
read our user’s manual carefully before use.
This guarantees you to make full use of this unit and prolongs the operation life of
this unit.
Precautions
If you have detected abnormal heat, smoke, noise or smell, immediately stop using
the product.
In the event of an abnormality, turn off the power and disconnect the power plug from
the power socket. Continuing to use the product may result in electric shock or re.
Observe the instructions given below regarding the power cable:
• Be sure to use the supplied or specied power cable.
• Do not modify, forcibly bend, kink or pull the power cable.
• When disconnecting the power cable from the AC outlet, be sure to hold the cable
by the plug.
Pulling the cable may cause wire breakage or shot circuit, resulting in re or electric
shock.
• Do not connect or disconnect the plug of the power cable to/from the AC outlet
using wet hands.
Doing so may result in electric shock.
• Do not touch the product with wet hands while the power cable is connected
to the AC outlet.
Doing so may result in electric shock.
• If the product will not be used for a long period, disconnect the power cable
from the power source. Leaving the cable connected to the power socket for
a prolonged period will consume electricity and may result in heating.

Content
1. Name of Parts ................................................................................................4
2. Accessories ....................................................................................................4
3. Operation .......................................................................................................5
4. Precaution .....................................................................................................5
5. Common trouble Shooting .............................................................................5
6. Specications .................................................................................................6

1. Name of Parts
1. Water can
2. Water valve
3. Adjustable valve of water level
4. Three-in-one combinative grinding wheel
5. Sponge
2. Accesories
1. one hose
2. one lamp
3. one piece of sponge
4. one oilstone stick
7
6
8
9
1
2
3
4
5
10
6. Tools table
7. Working lamp
8. Motor switch
9. Lamp switch
10. Low hose adaptor
4

3. Operation
Open the carton and take out the foamed plastic cover. Then take the machine out
carefully and place it on a big enough and quite stable desk. Please check the
accessories, connect the exhaust hose, pour clean water into water can, adjust the
adjustable valve of water level, open the water valve, turn on the working lamp and
the motor switch. Then you can use it. This machine has one set “Three-in-one
combinative diamond grinding wheel”, i.e. the left is rough grinding (180#), the middle
is ne grinding (280#) and the right is V-ne grinding (400#). To get the best grinding
result, you can select the different grinding wheel according to your requirements.
4. Precaution
To avoid blocking up the exhaust hose, please pour clean water into the water can.
When the electric power can’t reach the intensity demanded (voltage and frequency),
don’t use the machine. Don’t use the machine for any other purposes except
hand-grinding the edge of lenses.
5. Common Trouble Shooting
Problem
1. Motor doesn’ t rotate and the
working lamp doesn’t light up.
2. No water supply
3. Grinding fatigue
4. Water supply is available, but
no water from the exhaust hose.
Solution
Check the power supply and see
if the plug is connected with the
socket and the voltage is stable.
check the working lamp and see
if it’s useful.
Check the water level of the water
can and see if the water valve is
opened.
Use the oilstone stick to condition
the wheel reqularly.
Open the machine, clear the
waste thorough.
5

6. Specications
Dimensions (L*W*H) Net.Weight
395*245*295mm 7.8kg
Timer Power RequirementSpecication
1-5min AC KXM20V/60HZ
AC 200-240V/50Hz
6
