Lvneng LX05 User manual

USER’S MANUAL
LX05
（EEC L1E-B）

USER INSTRUCTIONS DESCRIPTION OF COMPONENTS AND PARTS
Safety Instructions
Installation of Mirrors
Welcome to the family of LX05 owners! We will guide you to know each function for the right and safe use of Electric scooters. To ensure your
safety, please read this manual carefully before riding and make sure you are always following the requirements below:
Please contact the Local Customer Service Center if you have any questions about this bike. We are at our service at any time. Wish you safe and pleasant riding experience!
Fully understand the information in this manual, including but not limited to the relevant instructions, precautions and warnings.
Fully understand the operation and contingency measures of electric scooters.
Be fully aware of warning labels of LX05 electric scooters.
We will not take any responsibility resulting from the unauthorized modification, failure to use original spare parts, or installation of components
that affect the performance and safety of the scooter.
Take out the Left and Right mirrors,Insert the hole and rotate the
mirror clockwise to the correct position.
Use the spanner to fasten the nut,make sure the left and right mirror
is on the same line and suitable for the driver’s view.
To ensure the safety of you and others, please make sure to observe the following matters:
Do not ride after you take medications which may affect your riding ability, drink alcohol, or when you are unwell.
Observe traffic regulations and traffc signs and confirm the surrounding road conditions and scooter conditions at any time, so as to actively avoid danger.
Wear safety equipment, such as helmet, and appropriate protective clothing if necessary, such as gloves and boots.
Perform a basic check each time before riding, so as to confirm the light, brake, tread and tire pressure and check other parts for looseness or abnormal noise, and
regularly go to Local Service Center for maintenance.
In order to ensure the safety of you and others, please DO NOT use high beam in good lighting conditions. The continuous use of high beam will cause the visual
disturbance to vehicles and pedestrians on the opposite side, thus affecting normal driving.
Please do not make or answer any call during riding, which is likely to cause traffc accidents.
1
2
1 2

Info of Elements DIAGRAM OF INSTRUMENT PANEL
3 4
DESCRIPTION OF COMPONENTS AND PARTSDESCRIPTION OF COMPONENTS AND PARTS
Speed display - Display current speed.
1
Driving time - Display Single driving time.
2
ODO/TRIP Total ODO - Distance/ TRIP distance.
3
Power display bar - Display current battery level.
4
Gear display - Display current gear.
5
Failure warning - Display current Failure (Motor,Controller,Brake, Accelerator)
6
Left Winker indicator - Flashing in synchronization with the Left winker.
READY light - Ready for driving.
Under-voltage of Battery - The charge indicating lamp lights up When
less than 10% electricity remains.
Right Winker indicator
Flashing in synchronization with the Right winker.
ON/OFF - Switch Light of Side stand Light on when side stand working.
Charging of the scooter - The charge indicating lamp lights up When
charging the battery on the scooter.
Position light - The lamp lights up When the daytime driving.
High beam indicator, Indicating high beam on.
7
8
9
10
11
12
13
14
Electric engine
Main stand
Side stand
Battery Controller
Windglass
Direction indicator lamp
Converter
Horn
Headlamp
Front position lamp
Back foot-rest
Rear fender
Front fender
Rear registration plate lamp
Direction indicator lamp
Stop lamp/rear position lamp
Speedometer
Mirrors
6
11
2
5
3
9
4
7
14
8101213
1

Dial to the left side to turn on the Left winker.
Dial to the right side to turn on the Right winker.
Details Of Instrument Panel Left Start Button Right Start Button
High/Low beam switch button
Winker button
5 6
OPERATION GUIDEOPERATION GUIDE
Press up to turn on the high beam.
Press down to turn on the low beam.
1
2
Press to make a sound and release to stop.
Horn button
3
Dial up to turn on the headlamp.Turn downward to AUTO to automatically
turn on the headlights. The headlights turn on automatically according to
the brightness of the environment.
Dail down to to turn off the headlamp.
Gear shift button
Headlamp button
The bike has three(3) Gear modes,1 "Eco", 2 "Cruise", and 3 "Sport".
Dial rightwards for "Eco", Middle for "normal"and left for "sport".
1
2
Parking button has two modes: press to park the bike and parking indicator P
goes on; and press again to exit the parking status.
Parking button
3
When the scooter have failure warning on the motor/Controller/Brake/Accelerator,
always press this button, slow driving to nearby service center for repairs.
Recover button
4

With the advanced Smart Remote Controller, you can
easily lock or unlock your electric scooter by simply
pressing the button within 50 meters.
1
2
3
4
Unlock
Press the unlock button, and the start button stays on. The scooter enters
into the [Unlocked State].
Lock
When the scooter is in the [Static State], press the lock button, and the start
button flashes. The scooter enters the [Locked State].
Remote keyless entry
After unlock the scooter,press this button twice within two(2) seconds, and
the scooter will be in the “Powered” state without key.
Search key
Press this witch within 50m, “Bi Bi” sounds searching the scooter.
How To Operate The Smart Remote Contol Guide of ignition key
7 8
OPERATION GUIDE OPERATION GUIDE
1
2
43

As the protection switch for the main power of electric scooter, the air switch will automatically disconnect to ensure safety when
the scooter circuit is abnormal or the current caused by short circuit exceeds the set safe value.
Before open the key, please turn ON this Air switch in advance.
Open the small cap on the top of battery case,plug the battery cable
inside the socket,connecting the battery with scooter.
Unlock and Remove the battery case
Open the saddle,rotate the plug,unplug the power cable connecting with battery,
then pull up the battery case with one hand.
Whether the handlebar is stable and flexible when turning.
Whether the switches on the right and left handlebars can work normally.
Whether the speed accelerator can work normally.
Make sure the tire pressure is normal. The suggested tire pressure is 26-29psi for front wheel and 29-32 psi for rear wheel.
Check tire surface for cracks, damage, wear, and foreign matter puncture or attachment
Whether the tread depth is suffcient (>0.8 mm).
Whether any fault warning light on the instrument panel goes on after being powered.
Whether the battery is fully charged.
Whether the head and tail lights, brake lights and winkers can work normally.
Whether the horn can work normally.
Whether the rear mirrors are clean. Adjust them to the appropriate angle.
Whether the brake oil is suffcient, and whether the handlebars and brake system can work normally.
For any abnormality or operational concern, please contact local Customer Service Center.
NOTES：In order to protect your safety, please turn off the air switch when
cleaning, storing the scooter for a long time, or re- moving the battery pack.
1
2
3
Air switch ON/OFF
Operation of Air switch Checks Before Riding
910
OPERATION GUIDE RIDING GUIDE
1
2
3
4
5
6
7
8
9
10
11
12
Make sure to check the following items before riding a Electric Scooter, which will guarantee your safety on the road.

Make sure to check the following items before riding, which will guarantee your safety on the road.
Insert the key and turn leftwards, Open the saddle, Turn On the Air switch.
TIPS:
1
2
3
Insert the key and turn rightwards, “Powered” state is started,the instrument
is opened,and the “READY” light is ON,scooter is ready for driving now.
4
Press the "P" button with three(3) seconds, to exit the Parking
state,and the “P” indicator goes off,then you can start driving.Gently
turn the handlebar to ride on the road.
Before riding,make sure the electronic side stand retracted and
rotate the handlebar to ensure that the handlebar lock is closed.If
the Parking button is pressed when riding, the bike will be dis-
energized. So DO NOT press it when riding for avoiding danger
caused by the sudden loss of power.
If the electronic side stand is extended when riding, the bike will be
dis- energized. So DO NOT extend the electronic side stand when
riding for avoiding danger caused by the sudden loss of power.
The scooter must be fully stopped before starting. In case of
abnormality during riding, please ride carefully or push it to a safe
place. DO NOT try restarting the bike during riding or on the lane so
as to avoid danger.
Insert the main charger plug into the charging port of the scooter.
Insert the chargers AC power plug into the home power socket, and the battery starts charging when the charger indicator turns red. The battery is fully charged
if the charger indicator turns from red to green.
How to Charge the Battery
11 12
CHECKS BEFORE RIDING BATTERY USE INSTRUCTIONS
1
Put on the helmet, and retract the electronic side stand.
VIEW I
Charge Socket
1
3
2
P
P
READY
M
RREADY

How to Charge the Battery
Pull up the battery from scooter,Insert the main charger plug into the charging socket of the battery. Insert the chargers AC power plug into the home power
socket, and the battery starts charging when the charger indicator turns red.The battery is fully charged if the charger indicator turns from red to green.
2
TIPS:
Short circuit of the cathode and the anode at the battery's input.
Keep it away from children, fire and heat source. It is strictly forbidden
to throw it into the fire;Violent movements, shock and extrusion are
prohibited;
Only the specified charger can be used, and other chargers are
prohibited to charge the battery;
This product has been subject to strict inspection before leaving
factory, and it is strictly prohibited to dismantle it. Please contact our
company's after-sales department for any question.
Please charge the battery to half-saturation state when storing or transporting it (after the battery is discharged, charge it for 3 hours).
Place it in a dry and ventilated place;
Battery and charger should be kept in a clean,dry,and ventilated place. Keep them away from corrosive materials,power source and heat source;
Storage conditions: ambient temperature -20-35 °C, humidity <65% RH;
When storing the charger, please disconnect it from the battery.
Regular maintenance can enhance the service life and driving safety of the electric scooter. Please refer to the following suggestions and take care of your
scooter.
TIPS:
Do not expose the battery to water, and prevent it from being
damped by water or rained.
Charge temperature: 0-45 °C, discharge temperature: -20-45 °C;
Battery capacity will be reduced when placed in a low-temperature
environment;
Charge the battery when you use it, but make sure to charge it before
the capacity is lower than 20%. When it is not used
for a long time, please remove it from the scooter.
Storage, Maintenance and Transportation
13 14
BATTERY USE INSTRUCTIONS BATTERY USE INSTRUCTIONS

Routine Cleaning and Maintenance
Regular Inspection and Maintenance
Cleaning：Please use clean water and neutral detergent to clean it, and use soft cloths and sponges to clean the surface;
It is prohibited to use metal brushes, sandpaper or the like to clean it, in order not to scratch the parts surface. After cleaning, dry it with soft cloths.
The scooter has no electricity,
and the READY lamp does not
shine.
When turning the speed
regulating steering handle-bar,
the motor does not turn after
being powered.
Speed is slow or mileage is
short.
Battery can not be charged.
Battery is poorly connected.
Air switch is not turned on.
Low battery volume.
Side stand is not retracted.
Brake handle does not reach the right position.
Steering handlebar failure.
The controller plug is loose.
Controller failure.
Low battery.
Under-inflated tire.
Heavily overloaded.
Brake pads interference.
Battery aging or normal scrap.
Poor contact of the main plug of the charger.
Do not use the wrong charger.
Battery aging or normal scrap.
Battery low-voltage protection.
Charge the battery.
Inflate the tire, and check the tire pressure before riding.
Foster a good habit, and keep the appropriate load Change
the brake pads and check the brake system before riding.
Change battery.
Check whether the main plug is in a right place Use the
special charger.
Contact of the main plug again.
Contact with local service office of battery.
Charge the battery.
Put away the side stand.
Close the parking key.
Place the brake handle at the right position.
Change handlebar.
Re-plug controller.
Change controller.
Connect the battery properly at its main plug.
Turn on the air switch.
TIPS:
TIPS:
Please disconnect the air switch before cleaning.
Do not use strong water jet to directly wash it, so as to avoid the default of mechanical parts caused by water invasion.
Storage: try to park it in a dry and cool room to reduce the exposure to sun and rain and avoid the reduction of service life due to corrosion of parts.
When left unused for a long time, please turn off the air switch and disconnect the power supply circuitto prevent over discharging.
After long-term storage, please fully charge it before use.
The new scooter must be subject to the first inspection and maintenance in the Service Center when it reaches 1,000 km or two months (whichever comes first).
The scooter is recommended to be subject to regular inspection and maintenance in the Service Center at every 3,000 km or six months (whichever comes first).
Please disconnect the air switch before cleaning.
Do not use strong water jet to directly wash it, so as to avoid the fault of mechanical parts caused by being damped.
Regular maintenance can improve the service life and driving safety of the electric scooters.
Please refer to the fol-lowing suggestions and take care of your scooter.
15 16
ROUTINE CLEANING AND MAINTENANCE ROUTINE CLEANING AND MAINTENANCE
Failure Causes Solutions

17
ROUTINE CLEANING AND MAINTENANCE
Ha
Hb
Hc
HA
HC
+5V
A
D
B
C
HB
DE5
12V
+5V
+
-
60V `'
12V/40 W
1.5Hz
120 W
250V/10A
battery pack2 Air switch1
The power lock
Fuse converter
The charging plug 60V low voltage
Signal ground
signal of speed handle bar
speed handle bar
V
Power switch
ariable speed switch
Brushless controller
Alarm signal
Wheel moved test
The power off braker
Speed
indicator
Reverse gear
Speed indicator
Meter cathode
Power capacity indicator
Meter lighting
High beam instruction
Turn right instruction
Turn left instruction
Anti-theft
alarm device
flasher
Turn switch
The negative control
antenna
strong power
orange
grey
Light blue
The headlight switch
blackbrown pink
Rear turn left light
Front turn left light
Rear turn right light
Front turn right light
Front headlight
Blue Pink White
Turn
High
light Headlight
Horn
Left Right
Horn switch
Left
Right
brake switch
meter board assembly
black
License lamp
Y
-+
battery pack1
Air switch1
orange grey
12V
Left Power indicator
Gear display
Speed dial
Right
