LW Scientific M1-BHP4 User manual

Educational Microscopes
M1 PLUS Binoc
•Bearing mounted binocular head
•Coaxial coarse and fine focus
•Built-in mechanical stage
On the web: www.lwscientific.com - email: [email protected]
865 Marathon Parkway - Lawrenceville, Georgia 30045 - Ph: 770-270-1394 - Fx: 770-270-2389
The M1 Plus microscope looks equally at home
in a laboratory setting or an AP Biology classroom.
The seidentopf binocular head, built-in mechanical
stage, coaxial coarse and fine focus controls and
reverse nosepiece are premium features normally
found on much more expensive medical
microscopes. All these features have been
designed onto a large stable frame for durability
and years of use.
Construction
Heavy cast alloy
Acid and reagent resistant finish
All metal gearing
Head
Seidentopf binocular head
Bearing mounted, rotates 360°
30° inclined head
10X/18 wide field eyepieces
Locked-in eyepiece with pointer
Objectives
DIN achromatic
4X, 10X, 40XR, 100XR (oil)
Parfocal and parcentric
Color coded
Four-position reverse nosepiece with internal
click stops
Stage
Built-in mechanical stage
Stage size: 125mm x 130mm
Adjustment Controls
Coaxial coarse and fine focus
Adjustable stage stop
Illumination
NA 1.25 ABBE condenser on rack and pinion
Iris diaphragm
12V 20W Variable halogen light source
110V / 220V auto-switching
Mirror illuminator for field use
Accessories Included
Dust cover, mirror illuminator, blue and green
filters, two fuses, spare bulb, manual, and
warranty card
Warranty
Lifetime on materials and workmanship
One year on electronic components
Dimensions and Weight
Height: 15” (380mm)
Length: 9” (230mm)
Width: 6.63” (170mm)
Weight: 8.8 lbs. (3.99kg)
#traPdaeHsevitcejbO
4HB-P1M coniBliox001,x04,x01,x4
