LX Blue Node User manual

Blue Node
Quick Start Guide
Copyright 2021 LX Corporation Pty Ltd. All rights reserved.
Apple and the Apple Logo are trademarks of Apple Inc., registered in
the U.S. and other countries. App Store is a service mark of Apple Inc.,
registered in the U.S. and other countries.
Google Play and the Google Play logo are trademarks of Google Inc.
For help visit incyt by LX
incyt.io/support

a platform is created for birds to stand on and access the antenna.
Alternatively, bird spikes can be installed.
LX recommends using an LX Range Tester to select an installation
location with suitable Base Station signal strength.
Install the Blue Node as per Figure 1.1, ensuring it is mounted as
high as practically possible with the antenna protruding above
the top of the pole/fixture to improve transmission.
Install the compatible Blue Node sensor according to its Quick
Start Guide. When instructed, align the white arrow on the
sensor cable with the white arrow on the
sensor connector. Push firmly until you hear
an audible click.
Once the Blue Node is plugged in, it will
connect to the Incyt platform for activation
and configuration. This process may take
several minutes. Once complete, data will
appear on the dashboard in the App.
If data does not appear within 5 minutes,
use the LX Range Tester to check network
connectivity.
Device setup
This Blue Node requires a Sensor and LX Base Station/Gateway to
function, which are available for purchase from Incyt.io.
Remove contents of box and check the component list above
to ensure the kit is complete.
Screw the Antenna clockwise onto the Antenna Connector by
hand. Do not over-tighten.
Installation and Mounting
Select a suitable location to install the Blue Node and coupled
sensor. Where possible, select an installation site that minimises
vegetation and obstructions between the Blue Node and the Base
Station/Gateway. Avoid installing the Blue Node in such a way that
Product Overview
4
5
IMPORTANT! Do not twist the connector.
This will damage the Blue Node.
As high as
practically
possible
Protect cables from animals by installing
sheathing from your local hardware store
Antenna
Bracket
Antenna connector
Sensor connector
1
2
3
4
1
3
2
4
1
2
3
Getting Started
Download the Incyt by LX
app from the App Store on
your phone. Create a new
account, or log in with an
existing account.
Figure 1.1
Bird Spikes
