Powered Vehicle Mounting
Overview
Vehicle mounted brackets are specifically designed for vehicle mount applications. The vehicle mounted assembly restrains
the VX8 Kärv and isolates it from shock and vibration.
Overhead, dash and roof support pillar mounting is via a RAM Mount accessory which includes all the hardware required for
vehicle mounting.
In most cases, disconnect any power and peripheral cables from the VX8 before it is secured in the vehicle mounted assembly.
Never put the VX8 into the vehicle mounted assembly until the assembly is securely fastened to the vehicle.
Quick Start - Powered Vehicle Mounted Assembly
The powered vehicle mounted assembly should be secured to an area in the vehicle where it:
lDoes not obstruct the driver's vision or safe vehicle operation .
lWill be protected from rain or inclement weather.
lWill be protected from extremely high concentrations of dust or wind-blown debris.
lCan be easily accessed by a user seated in the driver's seat while the vehicle is not in operation.
Briefly ....
1. Attach the vehicle mounting assembly to the vehicle.
2. Attach the cradle assembly to the vehicle mounting assembly.
3. Secure the VX8 in the mounted vehicle cradle.
4. Adjust the VX8 to the best viewing angle.
5. Connect any external or remote mount antennas.
6. Connect peripheral cables.
7. Secure the 12 VDC power connector from the vehicle mounted power supply to the Power port.
8. Secure all cables in strain relief cable clamps.
The VX8 in the powered vehicle mounted assembly is ready for use.
E-EQ-VX8DKRG-B [ 1 ] VX8 Cradle Reference Guide

RAM Mount Options
RAM Mount Options
Several types of mounts are provided for the VX8. For a complete listing of mounting kits and the contents of each kit, please
refer to the VX8 & VX9 accessory catalog. Contact your LXE representative for catalog availability.
VX8 with single RAM ball option
If the VX8 is ordered with a single RAM ball, available mounting options include:
lTruck bracket with a single RAM ball (no keyboard mount provision)
lTruck bracket with a RAM ball for VX8 mount plus a RAM ball for keyboard mount
lRAM ball base with integrated keyboard bracket for back of VX8.
VX8 with dual RAM ball option
If the VX8 is ordered with dual RAM balls, available mounting options include:
lTruck bracket with a dual RAM balls (no keyboard mount provision)
lTruck bracket with dual RAM balls for VX8 mount plus a RAM ball for keyboard mount
Keyboard mounting options
They keyboard may be mounted using:
lIntegrated keyboard bracket included in some single RAM ball mounting kits
lA RAM mount using the keyboard ball on some truck brackets
lA stand alone keyboard mount using a RAM ball attached to the vehicle
Individual brackets
lMany individual mounting brackets are also available.
E-EQ-VX8DKRG-B [ 2 ] VX8 Cradle Reference Guide

Install Mounting Brackets
Install Mounting Brackets
Caution: This device is intended to transmit RF energy. For protection against RF exposure to humans and in accordance
with FCC rules and Industry Canada rules, this transmitter should be installed such that a minimum separation
distance of at least 20 cm (7.8 in.) is maintained between the antenna and the general population. This device is
not to be co-located with other transmitters.
The following RAM balls are used to mount the VX8:
D-sized (2.25”) balls and arms
lUsed to mount the VX8 when a single RAM ball is ordered on the back of the VX8. A D-sized ball is also used on the
truck.
C-sized (1.5”) balls and arms
lUsed to mount the VX8 when dual RAM balls are ordered on the back of the VX8. A pair of C-sized balls is also used on
the truck.
lKeyboard brackets also use C-sized ball. A corresponding C-sized ball is either included as part of the VX8 mounting
bracket or mounted independently on the truck for the keyboard assembly.
E-EQ-VX8DKRG-B [ 3 ] VX8 Cradle Reference Guide

Mounting Procedure
Mounting Procedure
Step 1 – Mount Vehicle RAM Ball(s)
Determine the position for mounting the RAM ball(s). Be sure to position the RAM ball(s) to allow access to the switches and
ports on the bottom of the VX8.
Depending on the options ordered with the VX8, the RAM ball may be:
lA single or dual RAM ball mounted directly to the truck
lA single or dual RAM ball mounted to a plate. The plate then mounts to the truck.
lA single RAM ball integrated with a mounting plate
lA single or dual RAM squeeze clamp style ball
lA single or dual RAM pipe clamp style ball
Additionally, some mounting plates contain a provision for another RAM ball which is used to mount the keyboard.
Sample mounting options:
Sample RAM Ball Mounting Options
E-EQ-VX8DKRG-B [ 4 ] VX8 Cradle Reference Guide

Step 2 – Prepare VX8
Step 2 – Prepare VX8
The VX8 is delivered with one or two RAM balls installed depending on the configuration ordered.
If an integrated keyboard bracket is to be mounted to the rear of the VX8, follow the procedure below. Otherwise, skip to the
next step.
1. The VX8 must be off and the power cord should not be attached during this procedure.
2. Place the VX8 face down on a stable surface.
3. Remove the RAM ball from the back of the VX8. The hardware attaching the RAM ball is not reused.
4.
Install the 2 M5x6 screws in the holes shown below.
Screw Installation, VX8
5. Install the 1.5” (C-size) RAM ball on the keyboard bracket using four M5 locking nuts.
E-EQ-VX8DKRG-B [ 5 ] VX8 Cradle Reference Guide

Step 2 – Prepare VX8
6.
Install the keyboard bracket and the 2.25” (D-Size) RAM ball (removed previously) onto the back of the VX8. Use three
M5x20 screws with three tapered washers.
Attach Keyboard Bracket
1. 1.5” RAM ball
2. Locking nut, M5
3. Integrated keyboard bracket
4. Screw, M5x20 (DO NOT reuse original screws)
5. Washer for RAM ball (DO NOT reuse original washers)
E-EQ-VX8DKRG-B [ 6 ] VX8 Cradle Reference Guide

Step 3 – Attach Keyboard to Bracket
Step 3 – Attach Keyboard to Bracket
LXE Keyboards
If using the optional integrated keyboard mount, attach the keyboard to keyboard mounting plate, using the appropriate screws:
lFor the 95 key keyboard, use four 8-32x5/8 screws
lFor the 60 key keyboard, use four 10-32x5/8 screws
Note: 95-key LXE keyboard shown.
Attach Keyboard to Mounting Plate
Note: Excess keyboard cable length can be looped around the hooks on the bottom of the keyboard mounting plate.
Other Keyboards
A generic keyboard plate is provided for non-LXE keyboards.
1. Attach the RAM ball to the keyboard mounting plate.
2. Attach the keyboard to the keyboard mounting plate. The mounting kit DOES NOT include hardware to attach the key-
board to the plate.
E-EQ-VX8DKRG-B [ 7 ] VX8 Cradle Reference Guide

Step 4 – Attach VX8 and Keyboard Assembly to RAM Base
Step 4 – Attach VX8 and Keyboard Assembly to RAM Base
Single RAM ball
1. Use a single D-sized RAM arm to attach the VX8 assembly to the RAM ball on the vehicle.
2. Use a single C-sized RAM arm to attach the keyboard assembly to the C-sized ball on either the VX8 keyboard bracket
or a C-sized ball on the vehicle.
Dual RAM balls
1. Use a pair of C-sized arms to attach the VX8 assembly to the RAM balls on the vehicle.
2. Use a C-sized arm to attach the keyboard assembly to a C-sized ball on the vehicle.
Completed Assembly
Samples of completed VX8 bracket assemblies are shown below
VX89A021KIT21 including RAM ball base and LXE
keyboard bracket
VX89A025KIT25 including RAM ball base and generic
keyboard bracket
Completed RAM Mount Assembly
E-EQ-VX8DKRG-B [ 8 ] VX8 Cradle Reference Guide

Removing the Port Lid
Removing the Port Lid
Before any cables can be attached to the VX8, the port lid must be removed. The port lid is held in place with eight (8) Torx 20
screws. Remove the screws and the port lid and set aside for reinstallation once all accessories are attached.
Removing the Port Lid
Reinstall the port lid after all cables are attached.
Connect Power Cable
Connect Power Cable to VX8
E-EQ-VX8DKRG-B [ 9 ] VX8 Cradle Reference Guide

DC to DC Power Supply Installation
For use with LXE power supplies:
lVX89301PWRSPLY – Power Supply, DC to DC, 9 to 36V
lVX89A302PSDC48V – Power Supply, DC to DC, 18 to 60V
lVX89303PWRSPLY – Power Supply, DC to DC, 60 to 110V
lVX89305PWRSPLY – Power Supply, DC/DC, 9 to 36V
lVX89306PWRSPLY – Power Supply, DC/DC, 18 to 60V
Connecting Electrical Cables to Power Sources
The DC to DC power supply is used to power the VX8.
Specifications for Electrical Supply
Input Voltage Always observe input voltage range specified on the DC to DC power supply and the optional screen
blackout box.
Output Voltage 12 VDC ± 10%: VX89301PWRSPLY, VX89A302PSDC48V, VX89303PWRSPLY
13.2 VDC ± 10%: VX89305PWRSPLY, VX89306PWRSPLY
Power 50 W: VX89301PWRSPLY, VX89A302PSDC48V, VX89303PWRSPLY
75 W: VX89305PWRSPLY, VX89306PWRSPLY
Fuse 5 A (slow blow fuse) 3 A (for optional screen blackout box). Fuses are USER SUPPLIED
Note: Refer to the Wiring Schematic for wiring colors and connections.
Caution: For proper and safe installation, the input power cable must be connected to a fused circuit on the vehicle. This
fused circuit requires a five Amp maximum time delay (slow blow) high interrupting rating fuse. If the supply
connection is made directly to the battery, the fuse should be installed in the positive lead within 5 inches of the
battery positive (+) terminal. Note: For North America, a UL Listed fuse is to be used.
Caution:
For installation by trained service personnel only.
Warning:
Risk of ignition or explosion. Explosive gas mixture may be vented from battery. Work only in well ventilated
area. Avoid creating arcs and sparks at battery terminals.
E-EQ-VX8DKRG-B [ 10 ] VX8 Cradle Reference Guide

Wiring Schematic
Wiring Schematic
VX8 without Backout Screen Box
VX8 with Backout Screen Box
How To Connect Vehicle Electrical Connection
1. The device must be powered off.
2. Begin by connecting the power cable to the VX8. Work from this connection with the last connection being to the vehi-
cle’s power source.
3. Route the cable from the VX8 to the DC to DC converter and, optionally for the VX8, the blackout screen box.
4. Cut the cable to length and strip the wire ends. For a VX8, if the blackout screen box is not used, do not strip the green
and yellow wires.
E-EQ-VX8DKRG-B [ 11 ] VX8 Cradle Reference Guide

How To Connect Vehicle Electrical Connection
Route the power cable the shortest way possible. The cable is rated for a maximum temperature of 105°C (221°F).
When routing this cable it should be protected from physical damage and from surfaces that might exceed this
temperature. Do not expose the cable to chemicals or oil that may cause the wiring insulation to deteriorate. If the
vehicle is equipped with a panel containing Silicon Controller Rectifiers (SCR’s), avoid routing the power cable in close
proximity to these devices.Always route the cable so that it does not interfere with safe operation and maintenance of
the vehicle.
5. If the DC to DCconverter is equipped with a lid, remove the converter lid screws. Put them in a safe place and remove
the lid from the DC to DC converter.
6. Attach the stripped wire ends to the output side of the DC to DC converter.
7. Attach the stripped wire ends to the input side of the DC to DC converter.
8. For power supply models VX89301PWRSPLY, VX89A302PSDC48V and VX89303PWRSPLY:
lAttach the stripped wire ends to the output side of the DC to DC converter. Attach stripped wire ends to the input side of
the DC to DC converter.
lThe input and output blocks each have two + and two – minus connectors. Either connector in the block can be used to
connect the matching polarity wire.
lUse the looms and wire ties to secure all wiring then reattach the lid with the screws.
4. For power supply models VX89305PWRSPLY and VX89306PWRSPLY
lAttach the stripped wire ends to the output side of the DC to DC converter. Attach stripped wire ends to the input side of
the DC to DC converter.
lThe input block has one +Vi and one –Vi connection to connect the matching polarity wire.
lThe output block has two +Vo and two –Vo connectors. Either connector in the block can be used to connect the match-
ing polarity wire.
lUse wire ties to secure all wiring, providing strain relief for the power supply connections.
5. If the blackout screen box is used for a VX8 installation, attach the stripped wire ends to the box. Refer to this illus-
tration
E-EQ-VX8DKRG-B [ 12 ] VX8 Cradle Reference Guide

External AC Power Supply, Optional
and the label on the blackout screen box for proper wiring connection.
6. Connect the DC to DC converter to the vehicle’s electrical system.
7. While observing the fuse requirements specified here, connect the power cable as close as possible to the actual bat-
tery terminals of the vehicle. When available, always connect to unswitched terminals in the vehicle fuse panel, after
providing proper fusing.
Note: ATTENTION: For uninterrupted power, electrical supply connections should not be made at any point after
the ignition switch of the vehicle.
8. If used, connect the wiring for the blackout screen box.
9. Use proper electrical and mechanical fastening means for terminating the cable. Properly sized “crimp” type electrical
terminals are an accepted method of termination. Please select electrical connectors sized for use with 18AWG (1mm2)
conductors.
10. Provide mechanical support for the cable by securing it to the vehicle structure at approximately one foot intervals, tak-
ing care not to over tighten and pinch conductors or penetrate outer cable jacket.
External AC Power Supply, Optional
Optional AC Power Supply
E-EQ-VX8DKRG-B [ 13 ] VX8 Cradle Reference Guide
