LXE MX2 User manual

MX2 Docking Station
User’s Guide
Copyright © March 2005 by LXE Inc.
All Rights Reserved
MX2A137OPGDWW
E-EQ-MX2DKOG-B

Notices
Notice:
LXE Inc. reserves the right to make improvements or changes in the products described in this manual at any time
without notice. While reasonable efforts have been made in the preparation of this document to assure its accuracy,
LXE assumes no liability resulting from any errors or omissions in this document, or from the use of the
information contained herein.
Copyright Notice:
This manual is copyrighted. All rights are reserved. This document may not, in whole or in part, be copied,
photocopied, reproduced, translated or reduced to any electronic medium or machine-readable form without prior
consent, in writing, from LXE Inc.
Copyright © 2005 by LXE Inc. An EMS Technologies Company.
125 Technology Parkway, Norcross, GA 30092 U.S.A. [phone]
LXE is a registered trademark of LXE Inc. All other brand or product names are trademarks or registered
trademarks of their respective companies or organizations. When this manual is in PDF format: "Acrobat ® Reader
Copyright © 1987-2005 Adobe Systems Incorporated. All rights reserved. Adobe, the Adobe logo, Acrobat, and the
Acrobat logo are trademarks of Adobe Systems Incorporated." applies.
Note: The original equipment’s User Manual is copyrighted by PSC® Inc. This manual has been amended by
LXE® Inc., for the MX2 and Docking Station with PSC’s express permission.
The user is strongly encouraged to read Appendix A, "Regulatory
Notices and Safety Information". Important safety cautions, warnings
and regulatory information is contained in Appendix A.
Revision Notice
MX2 Docking Station User's Guide
Upgrade From Revision A to Revision B
B – Feb 2002 Regulatory
Notices
Add RF Safety Notice. Add Adobe copyright statement. Move Regulatory
Notices to Appendix A "Regulatory Notices and Safety Information."
B – Feb 2002 Accessories Change 1250mAh battery to 1650mAh. Part number does not change.
B – Feb 2002 Contacting
LXE
Remove "Contacting LXE" section. The information is available on the LXE
Manuals CD, in the file titled "Contacting LXE".
Add section titled "Getting Help."
B – Feb 2002 Whole
manual
Change manual style for on-line viewing. Edit figures for on-line viewing.
Change DocID number, remove Revision indicator from footer on each page.
B – Mar 2005 Whole
manual
Replaced the word “Operator’s” with “User’s”. Removed old LXE logo and
replaced it with new LXE logo. Changed release date, but not revision level.

E-EQ-MX2DKOG-B MX2 Docking Station User’s Guide
Table of Contents
Introduction ............................................................................................................... 1
Features.....................................................................................................................................1
Document Conventions ............................................................................................................1
Single Dock ............................................................................................................... 2
Indicators ..................................................................................................................................2
Using the Single Dock..............................................................................................................3
Attaching the Single Dock to a Computer................................................................................3
Troubleshooting and Maintenance.......................................................................... 4
Getting Help..............................................................................................................................4
Accessories............................................................................................................... 4
Appendix A Regulatory Notices and Safety Information...................................... 5
Illustrations
Figure 1 Charging/Communication Dock for One MX2 .....................................................................................2
Figure 2 Back Panel of the Single Dock ..............................................................................................................3

ii Table of Contents
MX2 Docking Station User’s Guide E-EQ-MX2DKOG-B

Introduction 1
E-EQ-MX2DKOG-B MX2 Docking Station User’s Guide
Introduction
LXE offers one docking station for the MX2 – a stationary single dock that holds one MX2. The
stationary single dock powered docking station has two primary uses:
• Recharge the MX2 NiMH battery pack and lithium backup batteries.
• Provide a connection for serial communications between the MX2 and the host computer or
another serial device, such as a printer or modem.
The powered docking station requires an AC/DC power source.
Note: Do not use the MX2 docking station with any other unit.
Note: The MX2 is not designed to use alkaline batteries.
The “MX2 Reference Guide” contains MX2 technical information and advanced functions.
Please refer to this manual when preparing to dock the MX2 or communicate with the host.
Please refer to the “MX2 Installation and Operator’s Guide” when using the MX2 with a
Docking Station.
Features
The LXE stationary powered dock features:
• Recharge the NiMH battery pack and backup battery.
• Provide a connection for serial communications between the MX2 and the host computer or
another serial device, such as a printer or modem.
• Power supplies are available that meet either 110V - 120V or 200V - 240V.
Document Conventions
This reference guide uses the following document conventions:
Convention Meaning
"Quotes" Indicates the title of a book, chapter or a section within a chapter (for
example, "Document Conventions").
< > Indicates a key on the keypad (for example, <CTRL> ).
Indicates a reference to other documentation.
Note: Keyword that indicates immediately relevant information.
CAUTION
Keyword that indicates a cautionary warning to follow.
ATTENTION Keyword that indicates vital or pivotal information to follow.

2 Single Dock
MX2 Docking Station User’s Guide E-EQ-MX2DKOG-B
Single Dock
Figure 1 Charging/Communication Dock for One MX2
1 Serial 25-pin Connector
2 Power Input Jack
3 MX2 Receptacle
4 Battery Charging / Communication Pads
5 Infrared Window
6 Power Indicator
7 Ready Indicator
Indicators
Indicator Function
POWER Red when receiving power from power adapter connected to the dock.
READY Red when charging the main and backup batteries in the MX2.
Green when the both batteries in the MX2 are fully charged.

Single Dock 3
E-EQ-MX2DKOG-B MX2 Docking Station User’s Guide
Using the Single Dock
Note: The Power LED on the dock is illuminated when the dock is receiving AC power. MX2
batteries will not charge unless the Power LED is on.
Place the MX2 in the dock with the keypad facing out (on the same side as the indicators).
The dock will begin charging the batteries. The MX2 can begin communicating with the host (if
the dock is cabled to the host).
Please refer to the “MX2 Reference Guide” for instructions on sending data to and from the host.
Attaching the Single Dock to a Computer
Complete the following steps:
1. Attach the 25-pin end of the cable to the Cable Connector on the back of the Single Dock.
2. Attach the other end of the cable to a serial port on your computer.
3. If you ordered the optional power adapter, attach it to the Power Input Jack on the Single
Dock .
Figure 2 Back Panel of the Single Dock
1 Power input jack
2 Cable connector

4 Troubleshooting and Maintenance
MX2 Docking Station User’s Guide E-EQ-MX2DKOG-B
Troubleshooting and Maintenance
If the READY light on a powered dock does not come on, make sure the POWER light is on and
the MX2 is fully inserted into the dock, with the keypad facing out. If it still doesn’t work, make
sure the Power Adapter is securely attached to the MX2 and that the contacts in the dock and on
the MX2 are clean.
With normal use, the docking station should require no maintenance.
Getting Help
All LXE manuals are now available on one CD and they can also be viewed/downloaded
from the LXE website. Contact your LXE representative to obtain the LXE Manuals CD (Product
No. 9000A426LXEMANUALS).
You can also get help from LXE by calling the telephone numbers listed on the LXE Manuals
CD, in the file titled "Contacting LXE". This information is also available on the LXE website
www.lxe.com.
Accessories
Cables
Dock Serial Cable (9 Pin and 25 Pin) [dock to PC or dock to
printer]
2325A052CBLDOCK925
Cable, Serial RJ-DB9 (MX2 to PC cable) 2325A051CBLRJDB9
Batteries, Battery Chargers and Power Supplies
Battery, 1650 mAh, NiMH, MX2 2325A376BATTNMH850
Dock, Single, Power Supply, External AC, US 2325A301PSDOCK110
Dock, Single, Power Supply, External AC, Int'l 2325A302PSDOCK220
Battery Charger, 110V Single-slot 2325A377CHGR1US
Battery Charger, 220V Single w/Euro connector 2325A378CHGR1EU
Battery Charger, 220V Single w/IEC 320 connector 2325A379CHGR1IEC
Battery Charger, 110V Four-slot w/pwr supply US 2325A380CHGR4US
Battery Charger, 220V Four-slot w/pwr supply Euro 2325A381CHGR4EU

Appendix A Regulatory Notices and Safety Information 5
E-EQ-MX2DKOG-B MX2 Docking Station User’s Guide
Appendix A Regulatory Notices and Safety Information
FCC Information:
This device complies with FCC Rules, part 15. Operation is subject to the following conditions:
1. This device may not cause harmful interference
and
2. This device must accept any interference that may be received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Warning: Changes or modifications to this device not expressly approved by LXE, Inc., could void the
user’s authority to operate this equipment.
Product Label Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Shielded cables must be used with this unit to ensure compliance with the FCC Class A limits.
EMC Directive Requirements:
This is a Class A product. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.
Industry Canada:
This Class A digital apparatus meets all requirements of the Canadian Interference Causing Equipment
Regulations. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouiller
du Canada. Le present appareil numérique n’emet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numeriques de le Classe A préscrites dans le Reglement sur le brouillage
radioélectrique édits par le ministere des Communications du Canada.
Approvals: EMI / EMC Standards:
FCC Part 15 Subpart B,
EN 50022 Class A,
EN50082-1

6 Appendix A Regulatory Notices and Safety Information
MX2 Docking Station User’s Guide E-EQ-MX2DKOG-B
