Lynx NGT-9000 Series User manual

Lynx ®NGT-9000
MultiLink Surveillance System
Part Number: 9029000-( )
Installation Manual
This manual contains installation instructions and
recommended flightline maintenance information
for the Lynx NGT-9000 MultLink Surveillance
System, Configuration Module, and Directional
Antenna. Guidelines for external equipment
necessary for installation are included. This
information is supplemented and kept current by
revisions, service letters and service bulletins.
0040-17001-01 (Revision A)
January 15, 2015

Foreword
This manual provides information intended for use by persons who, in accordance with current regulatory
requirements, are qualified to install this equipment. Installation requirements may vary, depending on the
particularities of each aircraft, and this manual is intended as a guideline for that purpose. This manual
assumes familiarity with the setup and operation of the aircraft systems that interface with the NGT-9000.
If further information is required, please contact:
L-3 Avionics Systems
Attn: Field Service Engineering
5353 52nd Street, S.E.
Grand Rapids, MI USA 49512-9704
Telephone: [phone] or [phone]
Fax: [phone]
Email: [e-mail]
Web: http:///www.L-3avionics.com
This manual is distributed with permission by:
L-3 Avionics Systems
5353 52nd Street, S.E.
Grand Rapids, MI USA 49512-9704
Telephone: [phone] or [phone]
Fax: [phone]
Email: [e-mail]
We welcome your comments concerning this manual. Although every effort has been made to keep it free
of errors, some may occur. When reporting a specific problem, please describe it briefly and include the
manual part number, the paragraph/figure/table number, and the page number. Send your comments to the
address or email above:
WARNING
INFORMATION SUBJECT TO EXPORT CONTROL LAWS
This technical data is controlled under the Export Administration
Regulations (EAR) and may not be exported without proper authorization
by the U.S. Department of Commerce.
Copyright 2015
ACSS
Trademarks
Lynx®is a trademark of L-3 Avionics Systems
Patent Pending
Page A 0040-17001-01
January 15, 2015 Revision A

Lynx NGT-9000s
Installation Manual
About This Manual
SECTION 1 – GENERAL INFORMATION
This section provides the following information: unit configurations, unit functionality, items
required but not supplied with the unit, equipment specifications, installation approval/limitations
and TSO approvals.
SECTION 2 - INSTALLATION
This section contains instructions to locate, assemble and install the Lynx NGT-9000s MultLink
Surveillance System as well as information for unpacking equipment, and inspection procedure for
in-shipment damage.
SECTION 3 – INSTALLATION CHECKOUT
This section contains instructions for post installation setup, post installation and return to service
checkout.
SECTION 4 – MAINTENANCE
This section contains general flightline maintenance procedures. It includes periodic maintenance,
troubleshooting and instructions for the return of defective components.
APPENDIX A – SIGNAL AND CABLE CHARACTERISTICS
This appendix defines the electrical characteristics of all input and output signals.
APPENDIX B – ENVIRONMENTAL QUALIFICATION FORM
This appendix provides the environmental qualification test data.
APPENDIX C – CONFIGURATION AND CHECKOUT LOG
This appendix provides the installer a way to record configuration options.
References
PUBLICATION DESCRIPTION
0040-17000-01 Pilot’s Guide for the NGT-9000
0040-17001-01 Page i
Revision A January 15, 2015

Lynx NGT-9000s
Installation Manual
List of Effective Pages
Dates of original and changed pages are: Revision A ..............................January 15, 2015
Total number of pages in this publication consists of the following:
Title page
Page A
i thru xvi
1-1 thru 1-40
2-1 thru 2-30
3-1 thru 3-34
4-1 thru 4-32
A-1 thru A-24
B-1 thru B-4
C-1 thru C-2
Disclaimer
This Installation Manual contains information that is considered relevant only at the time of distribution
with the Avionics Systems product for which it is shipped. Information in this manual is subject to change
without notice and will not be updated after distribution.
Avionics Systems does provide a listing of all publications and directives with their current revision and
change levels to insure up-to-date information. See www.as.l-3com.com, Customer Care Section,
Technical Publications Page for the Publications Index to get an up-to-date listing of all Avionics Systems
technical publications and directives. Contact Avionics Systems Customer Service [1-800-453-0288] to
determine availability of technical publications and directives.
Revision A Highlights
Original release.
Page ii 0040-17001-01
January 15, 2015 Revision A

Lynx NGT-9000s
Installation Manual
This page intentionally left blank.
0040-17001-01 Page iii
Revision A January 15, 2015

Lynx NGT-9000s
Installation Manual
Table of Contents
Paragraph Page
Foreword.......................................................................................................................................................A
About This Manual......................................................................................................................................... i
References..................................................................................................................................................... i
List of Effective Pages....................................................................................................................................ii
Revision A Highlights .....................................................................................................................................ii
Table of Contents..........................................................................................................................................iv
List of Illustrations .......................................................................................................................................viii
List of Tables................................................................................................................................................. x
Abbreviations, Acronyms, and Symbols .......................................................................................................xi
Section 1
General Information
1.1 Introduction.................................................................................................................................1-1
1.2 Functional Description................................................................................................................1-2
1.2.1 GPS Functional Overview ..........................................................................................................1-2
1.2.2 ADS-B System Overview............................................................................................................1-3
1.2.3 ADS-R System Overview ...........................................................................................................1-3
1.2.4 TIS-B System Overview .............................................................................................................1-3
1.2.5 FIS-B System Overview .............................................................................................................1-4
1.2.6 Traffic Awareness System (option) Overview ............................................................................1-4
1.2.7 Discrete Inputs and Outputs.......................................................................................................1-4
1.3 Equipment Descriptions..............................................................................................................1-6
1.3.1 Model Options ............................................................................................................................1-6
1.3.2 Detachable Configuration Module (DCM) ..................................................................................1-6
1.3.3 System Unlock Code..................................................................................................................1-7
1.4 INterfaces ...................................................................................................................................1-7
1.4.1 ADS-B Out Fail...........................................................................................................................1-8
1.4.2 AHRS Input.................................................................................................................................1-8
1.4.3 Altitude Encoder Input................................................................................................................1-8
1.4.4 Audio Out....................................................................................................................................1-9
1.4.5 RF Suppression Input/output......................................................................................................1-9
1.4.6 TAS Alert ....................................................................................................................................1-9
1.4.7 TIS-B Not In Coverage...............................................................................................................1-9
1.4.8 WiFi Interface .............................................................................................................................1-9
1.4.9 WOW Input.................................................................................................................................1-9
1.4.10 Maintenance Interface................................................................................................................1-9
1.4.11 GPS Antenna..............................................................................................................................1-9
1.4.12 L-Band (UAT/1090) Antenna....................................................................................................1-10
1.4.13 Directional Antenna ..................................................................................................................1-10
1.4.14 Traffic Display...........................................................................................................................1-10
1.4.15 Weather Display.......................................................................................................................1-10
1.5 Installation Considerations .......................................................................................................1-11
1.6 Specifications ...........................................................................................................................1-12
1.7 TSO Information .......................................................................................................................1-15
1.7.1 TSO Markings...........................................................................................................................1-16
1.7.2 TSO Deviations from Minimum Performance Standards .........................................................1-17
1.7.3 Non-TSO Functions..................................................................................................................1-18
1.8 Modifications.............................................................................................................................1-19
1.9 Software Versions ....................................................................................................................1-19
1.10 Equipment Required Not Supplied...........................................................................................1-20
1.10.1 Installation Kits .........................................................................................................................1-23
1.10.2 Antenna Cables........................................................................................................................1-24
Page iv 0040-17001-01
January 15, 2015 Revision A

Lynx NGT-9000s
Installation Manual
Table of Contents (continued)
Paragraph Page
1.11 Equipment Interfaces................................................................................................................1-27
1.11.1 GPS Antenna............................................................................................................................1-27
1.11.2 L-Band Antenna........................................................................................................................1-27
1.11.3 Directional Antenna ..................................................................................................................1-28
1.11.4 Traffic Displays.........................................................................................................................1-30
1.11.5 Weather Display.......................................................................................................................1-30
1.11.6 WIFI Accessory ........................................................................................................................1-30
1.11.7 Personal Electronic Device (PED) Apps ..................................................................................1-31
1.12 Software Updates.....................................................................................................................1-31
1.12.1 Website Download....................................................................................................................1-31
1.12.2 Compact Disc ...........................................................................................................................1-33
1.12.3 Installation Procedure for LynxMMS USB Driver .....................................................................1-34
1.13 Installation Approval and Limitations........................................................................................1-38
Section 2
Installation
2.1 Introduction.................................................................................................................................2-1
2.2 Unpacking and Inspecting..........................................................................................................2-1
2.2.1 Transport and Storage Considerations ......................................................................................2-1
2.3 Installation Procedures...............................................................................................................2-2
2.3.1 Location......................................................................................................................................2-3
2.3.2 Electrical Connections................................................................................................................2-6
2.3.3 Panel Installation......................................................................................................................2-19
2.3.4 Installation ................................................................................................................................2-21
2.3.5 Antenna Installation Guidelines................................................................................................2-21
2.3.6 Remove and Replacement Procedures ...................................................................................2-29
Section 3
Installation Checkout
3.1 Introduction.................................................................................................................................3-1
3.2 Basic Operation..........................................................................................................................3-1
3.2.1 Power On....................................................................................................................................3-2
3.3 Maintenance PC.........................................................................................................................3-3
3.4 Maintenance Mode.....................................................................................................................3-6
3.5 Configure WIFI Accessory..........................................................................................................3-7
3.6 Verify Software Version..............................................................................................................3-8
3.7 Select Configuration Options......................................................................................................3-9
3.7.1 Aircraft Specific Options...........................................................................................................3-10
3.7.2 I/O Options – AHRS and Altitude.............................................................................................3-13
3.7.3 I/O Options – Misc....................................................................................................................3-14
3.7.4 Backup......................................................................................................................................3-16
3.8 Calibration Setup......................................................................................................................3-17
3.8.1 Audio Calibration and Test.......................................................................................................3-17
3.8.2 Screen Calibration....................................................................................................................3-17
3.8.3 TAS Antenna Calibration..........................................................................................................3-18
3.8.4 Clear Fault Log.........................................................................................................................3-18
3.9 Interface Check ........................................................................................................................3-19
3.9.1 Live Data - Discrete Inputs, Altitude, and Heading ..................................................................3-19
3.9.2 Live Data - GPS........................................................................................................................3-20
3.9.3 Live Data – ADS-B ...................................................................................................................3-21
3.9.4 Live Data – Simulate ................................................................................................................3-22
3.9.5 Configuration Check Complete ................................................................................................3-22
0040-17001-01 Page v
Revision A January 15, 2015

Lynx NGT-9000s
Installation Manual
Table of Contents (continued)
Paragraph Page
3.10 Installation Checkout................................................................................................................3-23
3.10.1 Functional Checks....................................................................................................................3-23
3.10.2 Ground Checks.........................................................................................................................3-28
3.10.3 Electromagnetic Interference (E.M.I.) Check ...........................................................................3-31
3.10.4 Display Check...........................................................................................................................3-33
3.10.5 Flight Test.................................................................................................................................3-33
3.10.6 Installation Checkout Complete................................................................................................3-33
Section 4
Maintenance
4.1 Introduction.................................................................................................................................4-1
4.2 Continued Airworthiness.............................................................................................................4-1
4.3 Periodic Maintenance.................................................................................................................4-1
4.3.1 Screen Calibration......................................................................................................................4-2
4.3.2 Directional Antenna (NY156 and NY164)...................................................................................4-3
4.4 Fault Isolation .............................................................................................................................4-3
4.4.1 System Status Messages.........................................................................................................4-10
4.5 Using the Maintenance PC.......................................................................................................4-16
4.5.1 Load Software ..........................................................................................................................4-16
4.5.2 Load Databases .......................................................................................................................4-17
4.5.3 View or Retrieve Data...............................................................................................................4-18
4.5.4 Configuration Restore...............................................................................................................4-28
4.5.5 Service......................................................................................................................................4-29
4.6 Return to Service......................................................................................................................4-30
4.6.1 Lynx NGT-9000s ......................................................................................................................4-30
4.6.2 Detachable Configuration Module............................................................................................4-31
4.6.3 Directional Antenna (NY156 and NY164).................................................................................4-32
4.6.4 L-Band (UAT/1090) Antenna....................................................................................................4-32
4.6.5 GPS Antenna............................................................................................................................4-32
4.7 Disposition of Failed Items .......................................................................................................4-33
Appendix A
Interface Signal Name & Cable Characteristics
A.1 Introduction.................................................................................................................................A-1
A.2 Input and Output Interfaces........................................................................................................A-1
A.2.1 Input Power ................................................................................................................................A-1
A.2.2 RF Suppression Bus...................................................................................................................A-1
A.2.3 Audio Output...............................................................................................................................A-1
A.2.4 Gilham Input (Altitude Input).......................................................................................................A-1
A.2.5 RS-232 Interface ........................................................................................................................A-2
A.2.6 RS-422 Interface ........................................................................................................................A-3
A.2.7 ARINC 429 Input ........................................................................................................................A-4
A.2.8 ARINC 429 Output......................................................................................................................A-5
A.2.9 Discrete Input .............................................................................................................................A-6
A.2.10 Discrete Output...........................................................................................................................A-6
A.2.11 I2C Serial Bus (Detachable Configuration Module) ....................................................................A-7
A.2.12 Antenna Connections..................................................................................................................A7
A.3 Pin Definition Summary..............................................................................................................A-8
A.4 [J1 connector].............................................................................................................................A-9
Page vi 0040-17001-01
January 15, 2015 Revision A

Lynx NGT-9000s
Installation Manual
Table of Contents (continued)
Paragraph Page
Appendix B
Environmental Qualification Form
B.1 Introduction.................................................................................................................................B-1
B.2 NGT-9000 Environmental Qualification Form ............................................................................B-1
B.3 NY156 and NY164 Environmental Qualification Form...............................................................B-4
APPENDIX C
CONFIGURATION AND CHECKOUT LOG
0040-17001-01 Page vii
Revision A January 15, 2015

Lynx NGT-9000s
Installation Manual
List of Illustrations
Figure Page
1-1: Lynx NGT-9000s..............................................................................................................................1-1
1-2: Example of Own Aircraft UAT, 1090ES, and TAS Traffic................................................................1-5
1-3: System Block Diagram.....................................................................................................................1-8
2-1: Outline Dimensions for Panel Mount NGT-9000 .............................................................................2-4
2-2: Outline Dimensions for Mounting Rack ...........................................................................................2-5
2-3: Interconnect Wiring Diagram .........................................................................................................2-10
2-4: Mating Connector (P1) and Pin Assignments................................................................................2-13
2-5: P1 Mating Connector Assembly ....................................................................................................2-14
2-6: Outline Dimensions for the Data Configuration Module (9230-17003-01) ....................................2-15
2-7: Example of Assembled RF Cable..................................................................................................2-16
2-8: Coax Cable Preparation.................................................................................................................2-17
2-9: Straight Coax Contact Shield Termination ....................................................................................2-18
2-10: Right Angle Coax Contact Installation.........................................................................................2-18
2-11: Connector Assembly....................................................................................................................2-19
2-12: Panel Assembly ...........................................................................................................................2-20
2-13: Example of Antenna Mounting Locations....................................................................................2-21
2-14: Directional Antenna Mounting Location.......................................................................................2-25
2-15: NY156 / NY164 Directional Antenna Outline Dimensions...........................................................2-26
2-16: Antenna Mounting Holes .............................................................................................................2-28
2-17: Directional Antenna Installation...................................................................................................2-28
3-1: Transponder/Traffic Screens ...........................................................................................................3-1
3-2: Maintenance Application Tool – Main Page ....................................................................................3-4
3-3: Lynx MAT – Main Screen ................................................................................................................3-4
3-4: Lynx MAT – Restart Unit..................................................................................................................3-5
3-5: Activate Maintenance Mode Window...............................................................................................3-6
3-6: Maintenance Mode Screens............................................................................................................3-6
3-7: Lynx MAT – WiFi Accessory............................................................................................................3-7
3-8: Lynx MAT –Check Versions ..........................................................................................................3-8
3-9: Lynx MAT –Aircraft Specific Options.............................................................................................3-10
3-10: Lynx MAT – I/O Options – AHRS and Altitude ............................................................................3-13
3-11: Lynx MAT – I/O Options – Misc...................................................................................................3-14
3-12: Lynx MAT – Configuration - Backup............................................................................................3-16
3-13: Lynx MAT – Setup - Calibration...................................................................................................3-17
3-14: Lynx MAT – Info – Fault Log........................................................................................................3-18
3-15: Lynx MAT – Live Data - Inputs ....................................................................................................3-19
3-16: Lynx MAT – Live Data - GPS.......................................................................................................3-20
3-17: Lynx MAT – Live Data - GPS.......................................................................................................3-21
3-18: Lynx MAT – Live Data - Simulate................................................................................................3-22
3-19: Examples of Start-up Screens.....................................................................................................3-24
3-20: Example of Normal Operation .....................................................................................................3-24
3-21: Example of Flight ID Input Screen...............................................................................................3-24
3-22: Example of System Test Results.................................................................................................3-25
3-23: Options Screen….........................................................................................................................3-26
3-24: Lynx MAT – Ground Test.............................................................................................................3-28
Page viii 0040-17001-01
January 15, 2015 Revision A

Lynx NGT-9000s
Installation Manual
List of Illustrations
Figure Page
4-1: Activate Maintenance Mode Window...............................................................................................4-2
4-2: Maintenance Mode Screens............................................................................................................4-2
4-3: Lynx MAT – Update Software........................................................................................................4-15
4-4: Lynx MAT – Update Database.......................................................................................................4-16
4-5: Lynx MAT – Information.................................................................................................................4-17
4-6: Lynx MAT – Version.......................................................................................................................4-17
4-7: Lynx MAT –Configuration - Restore ..............................................................................................4-27
4-8: Lynx MAT – Service.......................................................................................................................4-28
A-1: RN370M Interconnect Option for RS-232 to WiFi Converter......................................................... A-2
0040-17001-01 Page ix
Revision A January 15, 2015

Lynx NGT-9000s
Installation Manual
List of Tables
Table Page
1-1: System Components........................................................................................................................1-1
1-2: Built-in Interfaces .............................................................................................................................1-7
1-3: Specifications for Lynx NGT-9000s...............................................................................................1-12
1-4: Specifications for Detachable configuration module......................................................................1-14
1-5: Applicable TSO’s ...........................................................................................................................1-15
1-6: TSO Markings................................................................................................................................1-16
1-7: TSO Deviations..............................................................................................................................1-17
1-8: Failure Classification......................................................................................................................1-19
1-9: Hardware Modifications .................................................................................................................1-19
1-10: Software Revisions ......................................................................................................................1-20
1-11: Equipment List.............................................................................................................................1-21
1-12: Installation Kit P/N 9060-17000-01 for Straight RF Connector....................................................1-24
1-13: Installation Kit P/N 9060-17000-02 for Right Angle RF Connector .............................................1-24
1-14: Coaxial Cable Specifications .......................................................................................................1-25
1-15: Directional Antenna SIGMA and DELTA Port Cable Vendors ....................................................1-26
1-16: Cable to Connector Reference ....................................................................................................1-27
1-17: GPS Antennas .............................................................................................................................1-28
1-18: L-Band Antennas.........................................................................................................................1-28
1-19: Directional Antenna Model Options and Specifications...............................................................1-29
1-20: Directional Antenna Installation Kit 817-10009-xxx.....................................................................1-30
1-21: Airframe Installation Kits..............................................................................................................1-30
1-22: Traffic Displays ............................................................................................................................1-31
1-23: FIS-B WX Displays ......................................................................................................................1-31
1-24: RS-232 to WiFi Accessories........................................................................................................1-31
1-25: APPS for PED..............................................................................................................................1-32
1-26: List of Service Notices .................................................................................................................1-34
1-27: System Software CD Part Numbers and Contents......................................................................1-35
4-1: Troubleshooting...............................................................................................................................4-3
4-2: System Status Messages ................................................................................................................4-9
4-3: List of Fault Log Messages............................................................................................................4-18
A-1: Connector (P1) Pin Assignments ................................................................................................... A-8
Page x 0040-17001-01
January 15, 2015 Revision A

Lynx NGT-9000s
Installation Manual
Abbreviations, Acronyms, and Symbols
ITEM
DEFINITION
°Degrees
°C Degrees Celsius
°F Degrees Fahrenheit
1090ES 1090 megahertz extended squitter
AC Advisory Circular
ACSS Aviation Communication and Surveillance Systems
ADS-B Automatic Dependent Surveillance-Broadcast
ADS-R Automatic Dependent Surveillance - Rebroadcast
AHRS Attitude & Heading Reference System
AIRB Basic Airborne Situation Awareness
ARINC Aeronautical Radio, Incorporated
ASA Aircraft Surveillance Applications
ASSAP Airborne Surveillance and Separation Assurance Processing
ATC Air Traffic Control
ATCRBS Air Traffic Control Radar Beacon System
ATM Air Traffic Management
AWG American Wire Gauge
BIT Built In Test
Cal Calibration
CCW Counter Clock Wise
CDTI Cockpit Display of Traffic Information
CFR Code of Federal Regulations
CONUS Continental United States
CW Clock Wise
dB Decibel
dBm Decibels referenced to one Milli-watt
dc Direct Current
DCM Detachable Configuration Module
DL Data Loading
DME Distance Measuring Equipment
DO- RTCA Document Number Prefix (i.e., DO-160)
DTIF Display Traffic Information File
EMI Electro-Magnetic Interference
EVAcq Enhanced Visual Acquisition Application
FAA Federal Aviation Administration
FAR Federal Aviation Regulations
FCC Federal Communications Commission
FIS-B Flight Information Services - Broadcast
FPGA Field Programmable Gate-Array
FSS Flight Service Station
0040-17001-01 Page xi
Revision A January 15, 2015

Lynx NGT-9000s
Installation Manual
Abbreviations, Acronyms, and Symbols
ITEM
DEFINITION
Ft feet
FW Firmware
g Gravitational Acceleration
GPS Global Positioning System
H/W Hardware
hPa Hectopascal
Hz
Hertz
i.e. That is
IAW In Accordance With
ID Identification
in Hg Inches of Mercury
Kg Kilogram
kHz
Kilohertz
Kts Knots
L-3 AS L-3 Communications Avionics Systems
LLC Limited Liability Company
LRU Line Replaceable Unit
Lynx MAT Maintenance Application Tool
m Meter
Max Maximum
MSG Message
MHz Megahertz
mm Millimeter
MPC Maintenance Personal Computer
MSS
MultiLink Surveillance System
N/A Not Applicable
NACp Navigation Accuracy Category for position
NAR Non Altitude Reporting
NAS National Airspace System
NC Not Connected
NEXRAD
Next Generation Radar Reflectivity
NGT Not an abbreviation
NIC Navigation Integrity Category
No. Number
NOTAM Notice to Airmen
NVM Non-Volatile Memory
Orig Original
P/N Part Number
PBIT Periodic Built-In Test
PED Personal Electronic Device
PFD Primary Flight Display
Page xii 0040-17001-01
January 15, 2015 Revision A

Lynx NGT-9000s
Installation Manual
Abbreviations, Acronyms, and Symbols
ITEM
DEFINITION
RAIM Receiver Autonomous Integrity Monitoring
RBA Risk-Based Authentication
RF Radio Frequency
RTCA RTCA, Inc.
S/N Serial Number
S/W Software
SBAS
Satellite Based Augmentation systems
SPI Special Position Identification
STC Supplemental Type Certification
STIF Standard TCAS Intruder File
SUA Special Use airspace
SURF Basic Surface application
TAF
Terminal Area Forecasts
TAS Traffic Advisory System
TCAS Traffic Alert and Collision Avoidance System
TFR Temporary Flight Restrictions
TIS-B Traffic Information Service – Broadcast
TSAA Traffic and Situational Awareness Alerts
TSO Technical Standard Order
UAT Universal Access Transceiver
USB Universal Serial Bus
UTC Coordinated Universal Time
Vdc Volts Direct Current
VFR Visual Flight Rules
VHF Very High Frequency
VOR VHF Omni-directional
W Watts
WAAS Wide Area Augmentation System
WiFi Wireless Fidelity
WOW Weight On Wheels
Wx Weather
0040-17001-01 Page xiii
Revision A January 15, 2015

Lynx NGT-9000s
Installation Manual
This page intentionally blank
Page xiv 0040-17001-01
January 15, 2015 Revision A

Lynx NGT-9000s
Installation Manual
Section
1
General Information
1.1 INTRODUCTION
This section includes descriptions, specifications, TSO information, equipment required but not supplied,
and installation approval and limitations for the Lynx®MultLink Surveillance System Lynx NGT-9000s
family (Release 1) See Figure 1-1. Available models of the Lynx NGT-9000s are detailed in Table 1-1.
Included at the end of this section is a list of compatible equipment and equipment required but not
supplied with the system.
Table 1-1: System Components
COMPONENT MODELS H/W PART NO. S/W PART NO.
MultiLink Surveillance System NGT-9000+ (1)
NGT-9000D (1) 9029000-20000 9020010-001 (2)
Detachable Configuration Module DCM 9230-17003-01 - -
GPS Antenna See Table 1-17 - - - -
L-Band Antenna See Table 1-18 - - - -
Directional Antenna (optional) See Table 1-19 - - - -
Notes:
(1) The NGT-9000D and NGT-9000+ require an unlock code that is set up during installation. See paragraph1.3.3.
(2) Details on software releases are located in paragraph 1.9.
(3) The “+” at the end of the model number indicates TAS functionality. The “D” at the end of the model number
indicates Diversity functionality.
Figure 1-1: Lynx NGT-9000s
0040-17001-01 General Information Page 1-1
Revision A January 15, 2015

Lynx NGT-9000s
Installation Manual
1.2 FUNCTIONAL DESCRIPTION
The Lynx MultiLink Surveillance System (also referred to in this manual as the Lynx NGT-9000s) is a
Mode S Level 2 dens Class 1 Transponder with an integrated GPS receiver providing Automatic
Dependent Surveillance-Broadcast (ADS-B) output using a 1090ES (Extended Squitter). The unit also
receives ADS-B data via 1090ES and UAT (978 MHz Universal Access Transceiver). Some models
support optional Active Traffic Awareness System (TAS) or antenna Diversity functionality.
The unit replies to Mode A, Mode C and Mode S interrogations receiving interrogations at 1030 MHz and
transmitting responses at 1090 MHz. The unit is equipped with IDENT capability that activates the
Special Identification (SPI) pulse for 18 seconds.
Ground stations can interrogate Mode S Transponders individually using a 24-bit ICAO Mode S address,
which is unique to the particular aircraft. In addition, ground stations may interrogate the unit for its
transponder data capability and the aircraft's Flight ID.
The ADS-B provides own aircraft data with Enhanced Visual Acquisition (EVAcq) traffic information
that improves situational awareness and flight safety by providing aircraft position, velocity, and heading
information that is automatically transmitted to other aircraft and ground stations providing immediate
surveillance of air-to-air traffic.
The 1090ES and UAT ADS-B datalink have the following capabilities:
•1090ES In - Receive ADS-B, ADS-R and TIS-B
•1090ES Out - Transmit ADS-B
•UAT In - Receives ADS-B, ADS-R and TIS-B, FIS-B, NOTAMS, and TFR’s
The unit also provides TAS traffic advisories when TAS configuration is enabled. A voice or tone audio
output announces traffic alerts. The unit has multiple transmit/receive ARINC 429, RS-422 and RS-232
data ports used to transmit data to traffic, weather, and PED displays.
The unit provides the transponder code, reply symbol and mode of operation to the display.
Maintenance and configuration setup can be accomplished via the USB port located on the front of the
unit or by an optional WiFi connection.
Models are available that provide Active Traffic Awareness System (TAS) function and antenna
Diversity. Both models require additional equipment to be installed.
1.2.1 GPS Functional Overview
The GPS function utilizes signals from Global Positioning System (GPS) satellite constellation and
Satellite-Based Augmentation Systems (SBAS) such as the USA Wide Area Augmentation System
(WAAS), European EGNOS, Indian GAGAN and the Japanese MSAS. Currently it supports WAAS and
WAAS compatible SBAS systems.
The internal GPS function provides position, velocity, time, and integrity (NIC, NAC etc.) information to
the ADS-B functions and is ADS-B rule compliant with the requirements of AC20-165A.
Page 1-2 General Information 0040-17001-01
January 15, 2015 Revision A

Lynx NGT-9000s
Installation Manual
1.2.2 ADS-B System Overview
The Automatic Dependent Surveillance-Broadcast (ADS-B) improves situational awareness and flight
safety by providing real time traffic information. The ADS-B In function is used to receive ground station
supported TIS-B and ADS-R traffic, and direct communication with nearby like equipped aircraft (with
Mode S or UAT). The ADS-B Out (1090ES) function is used to periodically broadcast (without
interrogation) information about the aircraft that includes aircraft identification, position, altitude, velocity
and other aircraft status information.
•The traffic display shows the relative position of ADS-B or standard traffic using text, shapes, and
colors. ADS-B also provides similar information on ADS-B equipped ground vehicles.
•The effective surveillance range is 60 nmi. The passive-mode surveillance range is 160 nmi and
maintains report messages for a minimum of 200 1090ES ADS-B participants and 300 UAT ADS-B
participants simultaneously. To reduce display clutter a set number of other aircraft of the highest
priority other aircraft are displayed at a time. See Figure 1-2 for an example of own aircraft traffic
(UAT, 1090ES, TIS-B, and TAS).
•The Lynx NGT-9000 is equipped with a dual-link receiver. ADS-R service is unnecessary to provide
a complete picture of traffic in the area.
1.2.3 ADS-R System Overview
The Automatic Dependent Surveillance – Re-broadcast (ADS-R) is a ground based broadcast service that
repeats ADS-B messages from one link (1090ES or UAT) to the other link for aircraft with ADS-B In.
•ADS-R transmissions are updated at least every 2 seconds on the surface, 5 seconds in the terminal
area, and 10 seconds in the en-route airspace.
•An aircraft on the ground receiving ADS-R is provided both ground aircraft and vehicles as well as
airborne other aircraft within 5nm and 2,000 ft above ground level of the airport reference point.
•Other aircraft are provided by the ground station if within a 15 nm horizontal range and +/-5,000 ft
of altitude of the receiving aircraft. ADS-B equipped ground aircraft and vehicles are not displayed
to airborne aircraft. See Figure 1-2 for an example of own aircraft traffic (UAT, 1090ES, TIS-B, and
TAS).
1.2.4 TIS-B System Overview
Traffic Information Service Broadcast (TIS-B) is a ground based broadcast service that provides
secondary surveillance radar (SSR) derived traffic data (aircraft not equipped with ADS-B Out capability)
to ADS-B In equipped aircraft.
•The actual availability of services depends upon the availability of ground-based radar to support
TIS-B source data.
•Receiving aircraft must be in both radar coverage and ground based transceiver (GBT) coverage in a
given area to receive TIS-B service in that area. When ownship is above 24,000 ft, the ground station
will no longer provide TIS-B service. To reduce display clutter, the TIS-B service provides traffic
information on other aircraft within 15 nmi and +/- 3500 ft of ownship.
•Other aircraft are provided by the ground station if within a 15nm horizontal range and +/-3,500 ft of
altitude of the receiving aircraft. ADS-B equipped ground aircraft and vehicles are not displayed to
airborne aircraft. See Figure 1-2 for an example of own aircraft traffic (UAT, 1090ES, TIS-B, and
TAS).
0040-17001-01 General Information Page 1-3
Revision A January 15, 2015

Lynx NGT-9000s
Installation Manual
1.2.5 FIS-B System Overview
The Flight Information Services - Broadcast (FIS-B) function provides pilots with a cockpit display of
certain aviation weather and aeronautical information for awareness of own aircraft location with respect
to reported weather, including hazardous meteorological conditions (CONUS/ NEXRAD /AIRMETS/
SIGMETS/ NOTAMS/ METARS, etc) and SUA status and TAF (FIS-B products).
NOTE
CONUS and Regional NEXRAD may not always contain complete data.
The data is refreshed every 15 minutes and it is likely to be updated in a
future cycle.
FIS-B is advisory information only and is intended to enhance pilot decision-making during strategic
flight planning. FIS-B augments traditional sources of this information such as ATC and Flight Service
Station (FSS). FIS-B information is provided over the ADS-B Services network on the 978 MHz UAT
link when in ground station coverage.
1.2.6 Traffic Awareness System (option) Overview
The TAS option is an active system that operates as an aircraft-to-aircraft interrogation device. The unit
interrogates transponders in the surrounding airspace similar to ground based radar. When replies to these
active interrogations are received, the responding aircraft’s range, altitude, and closure rates are computed
to plot traffic location and predict collision threats. The unit alerts the flight crew to nearby transponder
equipped aircraft and assists the pilot in the visual acquisition of aircraft that may represent a danger.
Traffic information, out to a selected range, is graphically displayed on the unit or alternate display. See
Figure 1-2 for an example of own aircraft traffic (UAT, 1090ES, TIS-B, and TAS).
•The system display shows the relative position of traffic using text, shapes (i.e., Traffic Advisory =
solid circle; Other Traffic = open diamond) and colors.
•The effective active-mode surveillance range is 35 nmi and track 35 ATCRBS intruders
simultaneously with the target bearing relative to the nose of own aircraft.
•The tracking of targets is in a cylindrical volume centered on own aircraft that has, at a minimum, a
radius of 35 nmi and extends 10,000 ft above and 10,000 ft below own aircraft.
1.2.7 Discrete Inputs and Outputs
The Lynx NGT-9000s have discrete inputs and outputs available that can be interfaced to indicator lamps
and cockpit switches. These are optional installations and are not required.
•The WOW input discrete signals the On Ground status to the unit via a squat switch, airspeed
monitor, or a collective switch.
•The IDENT switch activates the IDENT pulse which highlights the aircraft’s symbol on the ATC’s
radar screen and is identified on the NGT-9000 when active.
•The Audio Mute switch is used to signal the unit to suppress all audio output. The discrete is set to
GND/Open. The active position indicates Audio Muted. When grounded this input mutes all audio
from the NGT-9000. This input is typically only used if the aircraft equipped with TAWS or other
aircraft alerting systems.
•The TAS Alert lamp is used to indicate Traffic Alert (TA). The discrete is set to GND/Open. The
GND (active) position indicates Traffic Alert. The GND (active) position illuminates the lamp.
•The TIS-B Not In Coverage lamp is used to indicate that the unit is not receiving a ground station
signal. The discrete is set to GND/Open. The GND (active) position illuminates the lamp.
•The ADS-B Out Fail lamp is used to indicate that ADS-B out is not operating. The discrete is set to
GND/Open. The GND (active) position illuminates the lamp. Depending on the situation the lamp
has the following functions: flashes while the GPS is initializing and stays illuminated when the
ADS-B Out has failed.
Page 1-4 General Information 0040-17001-01
January 15, 2015 Revision A
