LZ Models 35405 User manual

Keep safety rules when working with resin.
For safety reasons, and due to the complexity of construction,
this kit is recommended only for advanced modellers.
The kit contains small parts, keep it out of the reach of children.
Glue and paints not included
No.35405
39
27
wire needed for assembly
Decals for 2 tractors (Russian and German service)
resin parts
PE parts
instructions and references on CD
Made in EU
keep safety rules for work with resin
WWW.LZmodels.com
contains 1 highly detailed and accurate set
1/35 S-65 Stalinetz Engine Upgrade Set
glue and paints not included
suitable for advanced modellers
Reel assembly for weasels, jeeps, other vehicles and diorama

A1
A2
A3
A4
A5
A6
A12
A13
A14
A15
A16
A17
A18
A19
A20 A21 A22 A24
A23

A7 A8
A9
A10
A11
A25 A26
A27
A28 A29
A30 A31 A32 A33
4x
4x

A1
A2
Fit the front
corners
A7
A8

The middle gap meets the edge
of the engine block
A5

A3
Fit the opposite bolt heads and
secure with C/A glue
A23

A22
A16
A17
Mind correct position

A11
A9
0.6mm wire
Rods A9 are slightly longer to avoid possible resin and mold shrinkage, cut the tops to the
length required, glue them one by one on the top, set them exactly vertically and glue the base
A11 should have 4 tiny holes about 0,3mm for wiring that can be done to get nice detail - check the
link at last page to find a great walkaround, which provides perfect reference for ultra detailing

A10
A14
A12
A12 - dry fit the engine in its place, put the front on B6 beam , then the edge marked with arrow
should be about 0,5mm lower than top of the kit part E2 - set engine perfectly vertically with E2,
put A12 in place and glue it to the engine block A1
B6
A1
glue
A29

A6
Mind correct position
