M-Audio MIDISport UNO User manual

USER’S GUIDE

English • 4
Introduction
Thank you for purchasing the M-Audio Uno. Uno is a class-compliant 1x1 MIDI interface for USB-equipped PC and Macintosh computers. Uno’s
high-speed Universal Serial Bus connection assures reliable and speedy transfer of MIDI data to and from the computer. Uno is self-powered and
can be conveniently attached to your computer’s USB port without the need for tools or computer disassembly. The Uno comes with integrated
USB and MIDI cable connectors as part of its sturdy construction. Follow the installation instructions in this manual and you will be up and running
in no time. Expansion also is easy—if you need additional MIDI ports, simply install more Unos.
PLEASE DO NOT connect the Uno to your computer until you have reviewed the installation instructions for your operating system.
Features
Uno USB/MIDI Interface offers the following features:
• 1-in/1-out MIDI via USB connection (16 x 16 MIDI channels)
• Class-compliant installation in Windows XP and OS X
• High-speed connection to PC or Apple computers with USB port
• MIDI input and output LED indicators
• Bus-powered—requires no external power supply
• Compatible with Mac OS 9.2.2 and Mac OS X (OMS required in OS 9.2.2)
• Compatible with Windows 98SE and higher—true plug-and-play installation requires no IRQ, I/O address or DMA channel setup
• Extremely compact size
Package Contents
The Uno package includes:
• Uno interface
• Driver disk for Windows and Macintosh
• This manual
Before You Connect Your Uno
Please read through the installation information that pertains to your operating system
Feature View
å USB cable and connector—used to connect Uno to the host computer’s USB port
ç USB LED—when pulsing, indicates that Uno is powered and functioning
é MIDI in and MIDI out LEDs—indicate MIDI input or output activity
è MIDI out cable and connector—sends MIDI signals from the computer to a receiving device
ê MIDI in cable and connector—receives MIDI signals from a sending device for input into the computer via USB
English
é
MIDI output signal indicator
å
USB connector
é MIDI input signal indicator
ç
USB active connection indicator è
MIDI connector (to “MIDI out”)
ê
MIDI connector (to “MIDI in”)

English • 5
Overview
Uno provides one MIDI input port and one MIDI output port, each supporting 16 MIDI channels. MIDI is the acronym for Musical Instrument Digital
Interface and is the protocol used by MIDI keyboards and devices (devices that record and play back the MIDI information, such as computer or
hardware sequencers)to communicate with each other.
Windows XP & Mac OS X
If you are using Windows XP or Mac OS X, simply plug in the Uno as shown by the diagram on page 4. Because the UNO is class-compliant under
Windows XP and Mac OS X, it will work without any further driver installations in those operating systems.
Installing Drivers For Windows 98/ME
PLEASE DO NOT plug in the Uno yet.
1. Power up your PC.
2. Insert the UNO Installer CD-ROM. The installer should begin to run automatically. If it does not, select “Run” from the start menu and type
“d:\autorun” (minus the quotes), if “d” is your CD-ROM drive, then press ENTER. If your CD-ROM drive is identified by a letter than “d,” be
sure to type the correct one in the RUN command line.
3. Click on “install driver.”
4. Follow the on-screen instructions.
5. When the installation has finished, exit setup.
6. Plug the Uno into a free USB port on your computer.
Windows will continue with the installation of a USB driver and a MIDI driver to support your Uno, after which.Windows may prompt you to restart
your computer. If so, please restart and then you may begin using your Uno.
Installing Drivers For Windows 2000
PLEASE DO NOT plug in the Uno yet.
1. Power up your PC.
2. Insert the Uno Installer CD-ROM. The installer should begin to run automatically. If not, select “run” from the start menu and type “d:\
autorun” (minus the quotes), if ‘d’ is your CD-ROM drive, then press ENTER. If your CD-ROM drive is identified by a letter other than “d,” be
sure to type the correct one in the RUN command line.
3. Click on “install drivers.”
4. Follow the on-screen instructions.
5. When the installation has finished, exit setup.
6. Plug the Uno into a free USB port on your computer. Windows will automatically recognize the Uno and ask for the Uno Installer
CD-ROM.
7. Select the CD-ROM drive and click “OK.” Windows will then ask you to select the CD-ROM drive again for the MIDI driver.
8. Windows will report the drivers have not been digitally signed. click on “Continue Installation.”
9. Select the “d” drive once more.
10. Click “OK” and finish installation.
Installing Drivers For Apple Mac OS 9.x
If you do not have OMS installed, please run the OMS installer first; OMS is included on your Uno Installer CD-ROM. If OMS is installed on your
computer, skip this section and proceed to “Installing the UNO OMS Driver.”
< To install OMS:
Make sure that all programs are shut down before you launch the installer.
Also make sure you have removed any dongles or copy-protection devices that you may be using.
1. Insert the Uno Installer CD-ROM.
2. Double-click on the Uno Installer CD icon on your desktop
3. Double-click on the OS 9 folder.
4. Double-click on Install OMS 2.3.8
5. Follow the on-screen instructions
6. The Uno Installer CD-ROM will now take a few moments to install OMS. When it has finished it will ask you to restart the computer.
Click “Restart.”

English • 6
< Installing the Uno OMS Driver
1. Click and drag the USB Drivers Installer from the OS 9 window it is currently in, to the desktop.
2. Double-click on the icon. If a window appears, click “Open.”
3. Double-click on the newly-created USB Drivers Installer on your desktop.
4. Click “Install.” The installer automatically places the drivers in the correct system folders.
5. Once the installer has finished installing the drivers, click “Restart.”
6. Plug the Uno into a free USB port on your computer.
< OMS Setup
You should now run the OMS Setup program:
1. Open the Hard Drive, then locate and open the “Opcode” folder, followed by the “OMS Applications folder,” and then run “OMS Setup.”
2. If you get a message to switch AppleTalk on or off, choose either option. (This will make no difference to the OMS Setup.)
3. In the next window, click “OK.”
4. Click “Search.”
5. Click “OK.”
6. Then click “OK” again.
7. Click “Save.”
8. If OMS prompts you about replacing your current setup, click “Replace.”
You should now have a final window showing your current Studio Setup. If “QuickTime Music” is crossed out, you should double-click on it, then
click in the “on” circle to enable it. Then click “OK.” Now you’re ready to go. Just make sure your Uno is selected as the default MIDI input device
in your music software.
Setting Up Your MIDI Studio
A typical MIDI system setup might include your Uno, a computer, MIDI sequencing software, a MIDI controller keyboard and, perhaps, a MIDI-
compatible sound module. This type of setup can be constructed as follows:
1. Connect Uno via the USB cable to the computer’s USB port connector.
2. Connect the “To MIDI out” cable from Uno to the MIDI out jack of your controller keyboard.
3. Connect the other cable, labeled “To MIDI in,” to the MIDI in jack of your sound module.
In the set-up below, Uno is being used as a MIDI interface, inputting and outputting MIDI data between the controller keyboard, the sound module
(from which sound will be produced) and the computer running its application software.
About the MIDI In Port
The MIDI in port is used to connect a standard MIDI device to your computer, via the USB port. Data received from this device will be transmitted
via the UNO to the computer.
About the MIDI Out Port
Connecting a MIDI device to the Uno’s MIDI out port allows data to be sent from the computer to that MIDI device. Make sure the Uno is selected
as the default MIDI output device in your MIDI application software.
• Important note: The Uno is not a MIDI THRU device and as such, MIDI data received at the Uno’s MIDI in port can never be sent directly to
the Uno’s MIDI out plug. However, data received at the MIDI in can be transmitted from the computer to the MIDI out of the Uno to achieve
this.
•
Caution: Electrostatic discharges, electrical fast transients and conducted RF interference may cause the unit to malfunction. In such cases,
unplug the unit for a moment and then plug it in again to restore normal operation.
UNO USB MIDI INTERFACE
MIDI
to MIDI in
MIDI Sound Module MIDI Keyboard
Computer
USB
to MIDI out

English • 7
Contact
Warranty Terms & Registration
Warranty Terms
M-Audio warrants products to be free from defects in materials and workmanship, under normal use and provided that the product is owned by
the original, registered user. Visit www.m-audio.com/warranty for terms and limitations applying to your specific product.
Warranty Registration
Thank you for registering your new M-Audio product. Doing so immediately both entitles you to full warranty coverage and helps M-Audio develop
and manufacture the finest quality products available. Register online at www.m-audio.com/register to receive FREE product updates and for the
chance to win FREE M-Audio gear.
For additional help, technical support is available on our website at www.m-audio.com, where you can fill out our technical support form.
Alternatively, you can email us at [email protected], or contact us by phone at: [phone]
Technical support is available by telephone from 7am - 7pm PST.
M-AUDIO U.S. - 5795 Martin Road, Irwindale, CA 91706-6211, U.S.A. M-AUDIO Deutschland (Germany) - Kuhallmand 34, D-74613 Ohringen, Germany
Sales Information: 626-633-9050
Sales Information (email): [e-mail]
Tech Support: 626-633-9055
Tech Support (email): [e-mail]
Fax: [phone]
Internet Home Page: http://www.m-audio.com
Sales Information: 49 7941 98 7000
Sales Information (email): [e-mail]
Technical Support: 49 7941 98 70030
Technical Support (email): [e-mail]
Fax: [phone]
Internet Home Page: http://www.m-audio.de
M-AUDIO U.K. - Floor 6, Gresham House, 53 Clarendon Road, Watford WD17 1LA M-AUDIO Canada - 1400 St-Jean Baptiste Ave. #150, Quebec City, QC G2E 5B7, Canada
Tel: [phone] Fax: [phone]
Sales Information (phone): 44 (0) 1442 416590
Sales Information (fax): 44 (0) 1442 246832
Sales Information (email): [e-mail]
Technical Support (PC): 44 (0) 1309 671301
Technical Support (Mac): 44 (0) 1765 650072
Technical Support (email): [e-mail]
Internet Home Page: http://www.maudio.co.uk
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Internet Home Page: http://www.m-audio.ca
M-AUDIO France - Floor 6, Gresham House, 53 Clarendon Road, Watford WD17 1LA M-Audio Japan - Annex Buliding 6F, 2-18-10 Marunouchi, Naka-Ku, Nagoya 460-0002, Japan
Tel: [phone] Fax: [phone]
Informations Commerciales: 0810 001 105
Informations Commerciales (email): [e-mail]
Assistance Technique: 0820 000 731 (PC) ou
0820 391 191 (Mac at général)
Assistance Technique (email): [e-mail] ou [e-mail]
Fax: [phone]
Site Internet: http://www.m-audio.fr
Tel: [phone]
Fax: [phone]
Technical Support: 08 200 0731
Email: [e-mail]
Internet Home Page: http://www.m-audio.co.jp
Uno
Tested to comply with
FCC standards
FOR HOME OR STUDIO USE

UNO_UG_041129_01
