MSpa®ELITE
Owner’s Manual
EN
DO NOT RETURN MERCHANDISE TO YOUR DEALER STORE DIRECTLY. CALL MSPA AFTER
SALES SERVICE CENTER FOR PRODUCT QUESTIONS OR CONTACT MSPA AT
[email protected]
Due to MSpa continuous product improvement, MSpa reserves the right to change
specifications and product appearance, which may result in updates to the instruction
manual without notice.
Where Luxury Is Affordable
www.the-mspa.com
E-BA04 BAIKAL
E-RE04 REVE
E-BL06 BLISS

2
ENTER THE WORLD OF MSPA
ThankyouforchoosingMSpaandforyourconfidenceinourbrand.Webelievethatyouwillenjoymanybenefits
of using MSpa products for years to come.
Toguide you inyour initial MSpaexperience, we arepleased to presentyou with thisinstruction manual. Please
carefully and thoroughly read this manual entirety before using the product for the first time.
We are delighted to welcome you to the MSpa family, and look forward to sharing with you the full spectrum of
our expertise.
Enjoy your MSpa!
Scan the QR code to enter the MSpa official website
CONTENT
Safety precautions………………………………………………………………......................................................
Specifications and product overview…………………………………………………..............………....................
First use and set-up preparation………………………………………………….........................……………........
Spa set-up……………………………………............................…………………………......….............................
Control panel operation…………………………………………........................…................................................
Water maintenance and chemicals………………….......................................………..………………..…...........
Drainage, cleaning and storage………………………...................................………………..………..……..........
Disposal and environmental protection…………………………....................................…..................................
Troubleshooting…………………………………………….......……………………….…...…...…..........................
MSpa limited warranty policy …………………………............………................................………………...........
3
8
10
12
16
18
20
21
22
24
Welcome,

3
SAFETY PRECAUTIONS
For your own safety and that of your product, make sure to follow the safety
precautions below. Fail to follow the instruction may result in serious injury,
property damage or death. Improper installation or operation will void the warranty.
READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS
! DANGER
Risk of Accidental Drowning. Extreme caution must be exercised to prevent
unauthorized access by children.
Risk of drowning. Inspect the spa cover regularly for leak, premature wear and
tear, damage or signs of deterioration. Never use a worn or damaged cover: it
will not provide the level of protection required to prevent unsupervised access
to the spa by a child.
Risk of drowning. Always lock the spa cover after each use.
Risk of injury. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to avoid a
hazard.
Risk of Electric Shock. Do not permit any electrical appliances, such as a light,
telephone, radio or television within 1.5m (5 feet) of a spa tub.
Risk of Electric Shock. Do not use the spa when it is raining, thundering or
lightning.
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
To reduce the risk of electric shock, do not use an extension cord, timers, plug
adaptors or converter plugs to connect the unit to electric supply; provide a
properly located outlet.
The spa must be connected to a grounded mains supply with a supply cord
fitted with a plug and PRCD with a tripping current of 10mA.
Parts containing live parts, except parts supplied with safety extra-low voltage
not exceeding 12V, must be inaccessible to occupants in the spa.
Parts incorporating electrical components, except remote control devices, must
be located or fixed so that they cannot fall into the spa.
Ɣ
Ɣ
Ɣ
Ɣ
! WARNING

4
Residential electrical connection box must be located safely with a distance of
at least 2m away from the spa.
Electric installation should fulfill the local requirement or standards.
Do not press down or uplift the control panel or put any heavy items on the
control panel after installations.
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
To reduce the risk or injury, do not permit children use this product unless they
are closely supervised all times.
To reduce the risk of child drowning, supervise children all times. Attach and
lock spa cover after each use.
Make sure the floor is capable of supporting the expected load, which you can
find from the spec sheet, calculate the expected load of water capacity plus total
weight.
Adequate draining system must be provided around the spa to deal with
overflow water.
To reduce the risk of injury:
a) Lower water temperatures are recommended for young children and when
spa use exceeds 10 minutes. In order to avoid the possibility of hyperthermia
(heat stress) occurring it is recommended that the average temperature of
spa-pool water should not exceed 40°C(104°F).
b) Since excessive water temperatures have a high potential for causing fetal
damage during the early months of pregnancy, pregnant or possibly pregnant
women should limit spa water temperatures to 38°C(100°F).
c) Before entering a spa or hot tub the user should measure the water
temperature with an accurate thermometer since the tolerance of water
temperature regulating devices varies.
d) The use of alcohol, drugs or medication before or during spa use may lead to
unconsciousness with the possibility or drowning.
e) The use of alcohol, drugs, or medication can greatly increase the risk of fatal
hyperthermia in spas.
f) The causes and symptoms of hyperthermia may be described as follows:
Hyperthermia occurs when the internal temperature of body reaches a level
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ

5
several degrees above the normal body temperature 37°C(98.6°F). The
symptoms of hyperthermia include an increase in the internal temperature of
body, dizziness, lethargy, drowsiness, and fainting. The effect of hyperemia
include failure to perceive heat; failure to recognize the need to exit spa;
unawareness of impending hazard; fetal damage in pregnant women;
physical inability to exit the spa; and unconsciousness resulting in the danger
of drowning.
g) Obese persons or persons with a history of heart disease, low or high blood
pressure, circulatory system problem, or diabetes should consult a physician
before using a spa.
h) Persons using medication should consult a physician before using a spa
since some medication may induce drowsiness while other medication may
affect heart rate, blood pressure, and circulation.
i) Check with doctor before use if pregnant, diabetic, in poor health, or under
medical care.
People with infectious disease should not use a spa or hot tub.
To avoid injury exercise care when entering or existing the spa or hot tub.
Water temperature in excess of 42°C(108°F) may be injurious to your health.
Never use a spa or hot tub alone or allow others to use the spa alone.
Do not use a spa or hot tub immediately following strenuous exercise.
Spa heat in conjunction with alcohol, drugs, or medication can cause
unconsciousness.
Exit immediately if uncomfortable, dizzy, or sleepy. Spa heat can cause
hyperthermia and unconsciousness.
Do not put the spa under 0°C(32°F) environment in order to avoid freezing if
there is still water in the pool.
It’s helpful to put temp barrier mat in between the spa pool and the ground.
Similar mat which is made of foam material or other materials with heat barrier
function can also be used. Do not turn on the spa when the water is frozen.
Never pour water with a temperature higher than 40°C(104°F) into the spa
directly.
Always unplug this product from the electrical outlet before removing, cleaning,
servicing or making any adjustment to the product.
Never jump or dive into a spa or any shallow body of water.
No part of the electric appliance is to be located above the bath during use.
Do not bury the electrical cord. Locate the cord where it will not be damaged by
lawn mowers, hedge trimmers and other equipment.
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ

6
Do not attempt to plug in or unplug this product while standing in water or when
your hands are wet.
Do not use the spa if damaged in delivery and/or malfunctioning in any way.
Contact the MSpa service center for further direction.
Keep all pets away from the spa to avoid any damage.
Do not add bath oil or bath salt to the spa water.
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Always add chemicals to water, never add water to chemicals. Adding water to
chemicals may cause strong fumes or violent reactions and hazardous chemical
spray.
For water already used, discharge it in time or use water chemicals for cleaning.
Usually,change water every 3-5 days.
Use Mspa chemical kit for disinfection in accordance with manufacture’s
instructions.
Do not leave or set up the spa in temperature lower than 4°C(39°F) if heater is
not operating.
Always enter and exit the spa or hot tub slowly and cautiously. Caution of wet
floor.
To avoid damage to the pump, never turn on the spa or hot tubs unless it is
filled with water to the minimum water line.
Place the spa or hot tub only on a properly prepared site that can withstand the
floor loading requirement of the spa.
Do not leave the spa empty for extended period of time. Drain away water
inside the pool thoroughly for long time disuse. Do not expose the spa under
direct sunshine. Check regularly before each use. Put away the spa or fence it
up in time after using.
Open the spa top lid when the Bubble function is on.
In order to avoid a hazard due to inadvertent resetting of the thermal cut-out,
this appliance must not be supplied through an external switching device, such
as a timer, or connected to a circuit that is regularly switched on and off by the
utility.
Refer to relevant chapter for details concerning cleaning and other
maintenance.
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
! CAUTION

7
Zone 2 Zone 2
h
h
Zone 1
Zone 0
Zone 0
2.5 m
2.5 m
1.5 m 1.5 m2.0 m 2.0 m
Warning: Water protection levels of appliance at different product zones are
different see the following scheme. ( Installation regulations comply to IEC
60364-7-702)
NOTE-The measured zone dimensions are limited by walls and fixed partitions.
Zones
Zone 0
Zone 1
Zone 2
Description of the zones
Zone 0 is the interion of the basin including any recesses in their
walls or floors.
Zone 1 is limited by
• Zone 0
• A vertical plane 2m from the rim of the basin.
• The floor or the surface expected th be occupied by persons
• The horizontal plane 2.5m above the floor or the surface
Zone 2 is limited by
• A vertical plane external th zone 1 and parallel plane 1.5m
from the former.
• By the floor or surface intended to be occupied by persons.

JET & BUBBLE SPA
Control System
Total Power
Heater
Massage Air Blower
Filter Pump
Integrated Ozone Generator
Top Lid
Spa Material
Spa Liner Material
ESPECIFICACIONES
8
E-BA04 / Baikal
E-RE04 / Rêve
E-BL06 / Bliss
Round
Round
Square
4
4
4 + 2
700Ltr.
(184Gal)
700Ltr.
(184Gal)
930Ltr.
(245Gal)
ijP
(71”)
ijP
(71”)
1.85 x 1.85m
(73”)
1.40m
(55”)
1.40m
(55”)
1.45 x 1.45m
(57”)
0.70m
(28”)
0.70m
(28”)
0.68m
(27”)
35.5kg
(78.2lbs)
35kg
(77.2lbs)
41kg
(90.4lbs)
Control System Specs E-BA04 / E-RE04 / E-BL06
AC 220-240V / 50Hz
2300W
1500W
220-240V / 150W (E-BA04 / E-RE04) / 225W (E-BL06)
(E-BA04 / E-RE04: 75W x 2sets, jet pressure: above 0.5 bar, 4 high efficiency hydro-jets)
(E-BL06: 75W x 3sets, jet pressure: above 0.5 bar, 6 high efficiency hydro-jets)
720W - 3 levels (L1: 300W, L2: 500W, L3: 720W)
12V / 60W
5.5W, 30-50Mg/Hr
Rhino-Tech™ reinforced PVC
Premium Rhino-Tech™ reinforced PVC
with Micro Mspassima Fabric
Premium PVC material
Jet
Model No.
/ Code Shape Seating
Capacity Water Capacity Outside Dimensions Inside Dimensions Height Weight

9
PRODUCT OVERVIEW
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
A. B. C.
D.
H.
M. N.
I. J. K.
E. F/G.
FG
®
®
®
®
* round or square
* E-BL06 is a square shape spa
* Buckle spa cover and ground mat for E-BL06
®
Packaging content
L.

10
REF. NO. PARTS DESCRIPTION QTY.
Spa cover with aluminum foil inside
Spa tub
Control panel with air pipe
Heat preservation bubble mat
Digital lock(except for square spa)
Inflation hose
Manometer
Filter cartridge set (twin pack)
Spa cover inflatable bladder
Spa drain valve adaptor
Wrench
Buckle spa cover and ground mat set
Instruction DVD
Repair kit
NOTE: When ordering parts, be sure to quote the model number and part numbers.
FIRST USE AND SET-UP PREPARATION
The spa can be installed indoor and outdoor. For household use only.
The spa must be set up on a flat, smooth and supporting surface that is capable of supporting the
maximum load of the filled spa with listed maximum occupants.
Make sure the area is free of sharp objects under or around the spa. Uneven of unsound surfaces can
damage the spa and void your warranty. Level the surface before filling spa with water.
Provide adequate drainage system around the spa to deal with overflow water and splashes.
Make sure there is enough clearance around the spa for full access to the spa equipment for maintenance
and/or service.
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
Site preparation and requirements
Verify the supporting floor can support the filled weight of spa with maximum number of occupants. Check
with a qualified contractor or structural engineer to verify the requirement.
Make sure the floor is water resistant and provides non-slip surface. Do not install the spa on a carpet of
any other material that could damaged by the moisture.
Humidity is a naturally side effect of indoor spa installation. The room shall be properly ventilated to allow
moisture to escape. Install a ventilating system to prevent excess condensation moisture in the room.
Additional requirements for indoor installation
1
1
1
1
1
1
1
1
1
1
1
1
1
1
A
B
C
D
E
F
G
H
I
J
K
L
M
N

11
LOAD
LINE
TEST BEFORE USE
TEST
RESET
TEST
RESET
ONOFF
RED BLACK
1. 2.
REINICIO
3.
PRUEBA
LOAD
LINE
TEST BEFORE USE
TEST
RESET
TEST
RESET
ONOFF
RED BLACK
Make sure to set up the spa on a firm, level and smooth surface that is strong enough to support the full
weight of the filled spa and maximum occupants.
Do not set up the spa on grass or dirt, as this increases the amount of debris entering the spa, and
damage the spa floor.
Do not leave the spa tub exposed to direct sun light for extend period of time.
It is possible to install and leave the spa outside at a temperature not lower than 4°C (39°F) and the water
inside the circulation system, pump, pipe are not frozen. Put a Heat Preservation Mat or the Electric
Heating Mat (*Optional) in between the spa bottom and the ground to prevent heat loss from the bottom of
the spa and to provide better heat retention.
Ɣ
Ɣ
Ɣ
Ɣ
Additional requirements for outdoor installation
Plug the machine into the mains.
Press the RESET button on the PRCD. The indicator turns red.
Press the TEST button on the PRCD. The PRCD indicator should shut off. If the PRCD indicator does not
turn off, the PRCD is faulty.
Do not use the spa. Contact a qualified electrician to correct the fault.
Press the RESET button on the PRCD again. The indicator should turn red. If yes, the spa is ready for use.
1.
2.
3.
4.
PRCD Testing
Risk of electric shock: This product is provided with a PRCD located at the end of the power cord. The
PRCD must tested before each use. Do not use the spa if the PRCD does not function properly. Disconnect
the power cord until the fault has been identified and corrected. Contact a licensed electrician to correct the
fault. There are no serviceable parts in side the PRCD. Opening the PRCD will void the warranty.
! WARNING
Spa Control Unit Connected
External Equipotential Bonding
Conductors
A qualified electrician shall wire the spa control
unit to the household equipotential terminal using
a minimum 1.5mm² solid copper conductor as
follow.

12
23
4
5
1
SPA SET-UP
Move the entire package to the selected site. Open the carton carefully as it can be used to store the spa
during long term storage or when not in use.
Lay out all the parts on the ground and make sure all parts are accounted for. Make sure the spa tub is
right side up. (*For missing or damaged part, contact the MSpa Service Center)
Spread the Heat Preservation Ground Mat over a cleared area. Spread out the spa liner over the ground
mat. Heat Preservation Mat prevents heat loss from the bottom of the unit.
1.
2.
3.
Connect the digital cable. Find the digital
cable, loose the cap on the end, and plug
into the cable port on the control panel.
Once the cable is connected properly, the
backlight of the buttons area will light up on
the panel.
4.
Connect the control panel to the spa tub. Fasten and
secure the rings to the pipe adapter on the spa tub.
(Fig.5) Make sure the rubber O-rings are properly placed
on the air pipes.
CAUTION: Lost of the O-rings may result spa and the
bubbling function working improperly, and also cause the
air pump rusted.
NOTE: For spa models have PVC leather covers, make
sure the spa cover is onto the spa tub properly before
connecting the control panel. The two holes on the
leather cover must be positioned correctly to the pipes of
control panel air pipes.
5.
NOTE:
Bliss E-BL06: Spread out
the square ground mat and
place it to the selected site.
Make sure the buckle of
cover and mat is attached
when spa not in use.
Ɣ
this side
face down
O-rings
Air pipe

13
11
6.1 6.2 6.3
(b) (b)
(c)
6.4 6.5
(a)
(a)
7
(a)
(b)
(c)
6.1 Unscrew the air valve cap (a) on the control panel to reveal the air blower inflation outlet and connect
one end of the inflation hose (b) to the outlet. See Figure 6.1
6.2 Unscrew the air valve cap on the spa pool and reveal the stem for inflation.
6.3 Connect the other end of the inflation hose (b) to the manometer (c) first and then insert to the air
valve.
6. Spa Inflation
6.6 When inflation is completed. Press Bubble button for more than 3 seconds to turn off the
function. Disconnect the inflation hose on both ends. Replace the air valve cap back.
NOTE:
Ɣ7KHFDSLVGHVLJQHGWREHVFUHZHGRQDQGRII1HYHUH[HUWIRUFHDVWKLVFRXOGFDXVHWKHFRPSOHWH
internal inflation system of the valve to come loose.
Ɣ,IRYHULQIODWHGUHPRYHWKHLQIODWLRQKRVHIURPWKHVSDDLUYDOYHVLGHVFUHZWKHYDOYHFDSWR
release some air and stop until the manometer points to the right color section.
6.4 Press the Bubble button to inflate the spa tub until it is firm to touch.
CAUTION: Do not over inflate. Over inflation may cause spa leakage and void the warranty.
6.5 Pay attention to the Manometer. The Yellow section appears when the spa is properly inflated. The
Green section shows when water filling is completed. Repeat previous steps if more air is necessary.
CAUTION: The Red section shows when the spa is over inflated. Press the black button (a) on the
manometer to release some air until it points the green section.
IMPORTANT: During spa use, the manometer shall only shows the Green section at all times.
Green
Yellow
Over Inflation
Red
Button
Spa Bladder Inflation.
7.1 Open the air valve (a) on the bladder. Insert the inflation
hose (b) into the valve
7.2 Press the Bubble button to inflate until it is firm
to touch but not hard.
7.3 Press the Bubble button for more than 3
seconds to turn off the function. Disconnect the inflation
hose from the air blower outlet and the valve
7.4 Replace the air valve cap (c) back on the control panel. Close and recess the inflation valve (a)
7.

14
8
®
® ®
8.4
NOTE: Deflation Instruction
Spa Deflation
1. Unscrew the air valve cap on the spa pool to deflate the spa.
2. Once the deflation is completed, replace the cap back.
Spa Bladder Deflation
1. Pull the valve cap out and squeeze the valve at its base until deflated.
2. Close and recess the valve back.
8.5 Turn on the Heater on the spa control panel, refer to the “Control Panel Operation” section.
Maximum heating temperature is 42°C(108°F). Hourly heating rate is about 1.5°C-2°C(2.5°F-3.5°F)
for 4 persons and 1.2°C-1.8°C(2°F-3°F) for 6 persons.
Water level must reach the Minimum water line but not exceed the Maximum line to
avoid pump failure.
Never pour water with a temperature higher than 40°C(104°F) into the spa directly.
To avoid control system failure, do not operate the spa until water reaches the Minimum
line.
Ɣ
Ɣ
Ɣ
Water Filling
8.1 Check the spa liner is at the selected area and
point the drain valve toward a suitable draining
area before inflation.
8.2 Fill the spa tub with fresh water to a level between
Minimum and Maximum line marked on the inside
of the spa wall.
Do not over fill the spa. It is recommended to fill the spa with lukewarm water for quick heating and
energy saving.
WARNING:
8.3 After water filling, check the spa pool air pressure to make sure the manometer points out
the Green section.
8.4 Place the inflated air bladder and the zipper spa cover over the spa tub, and make sure the spa
cover zipper are closed and lock the cover by the digital lock in the accessory pack.
IMPORTANT:
Ɣ,QVSHFWWKHVSDSUHVVXUHUHJXODUO\IRUOHDNSUHPDWXUHZHDURUGHWHULRUDWLRQ
Ɣ&KHFNDQGZD[WKH]LSSHUUHJXODUO\WRPDNHLWVPRRWKIRURSHUDWLRQDQGDYRLGVSOLWV
8.
Zipper and Buckle Operation
9.1 Digital Lock Operation
Original password is “000”. Following the steps below to change the password:
9.

15
® ®
®
(a)
(b)
(c)
9.1.(1) 9.1.(2) 9.1.(3)
10.1
(a) (a)
(a
)
E-RE04/E-BA04 - 4 jets E-BL06 - 6 jets
Ɣ3XVKWKHEXWWRQDLQWKHGLUHFWLRQRI)LJWRXQORFNWKHGLJLWDOORFN
Ɣ6HW\RXUSUHIHUUHGSDVVZRUGLQGLJLWVE\WXUQLQJWKHQXPEHUZKHHOEVHH)LJ
Ɣ,QVHUWEDFNWKHFDEOHF7KHQHZSDVVZRUGLVVHW
10. JET Button Operation
10.1 Adjust the jet nozzles (a) in the proper direction for your needs.
10.2 Turn the jet control knob (b) clockwise or anticlockwise to change the water stream power. The
maximum power combo is air and hydro-jet together. The minimum power is hydro-jet on only.
There are two (2) jet control knobs for E-RE04/BA04 and three (3) jet control knobs for E-BL06.
(b)
Control knobs open or close.
c
l
o
s
e
o
p
e
n
9.2 Square Spa Buckle Lock Operation
Lock the Buckle
Ɣ,QVHUWWKHEXFNOHRQWKH*URXQG
Mat into the Spa cover buckle,
until you hear a “Click” sound.
Unlock the Buckle
Ɣ3LQFKERWKVLGHVRIWKHORFNHG
buckle, and press down the round dot in center in the same time.
Press down the center button and release the lock.
Lock Unlock
9.2
10.2

16
CONTROL PANEL OPERATION
1. ON/OFF Button
2. Jet Button
3. Bubble Button - Adjust the bubble
level by pressing the button
(L1:300W, L2: 500W, L3:720W)
4. Filter Button
5. Heater Button
6. Temperature UP & DOWN Button
7. Celsius/Fahrenheit Toggle Button
8. Ozonator Button
ON/OFF Button: To activate the control panel.
LCD displays the current temperature and backlight is white when the power is on, all
functions can be opened.
Jet Button: To activate the water jet massage function.
NOTE: The Bubble button can only be adjusted between L1(300W) and L2 (500W) while the
Jet function is on. JET function will shut down automatically after one-hour continuous
operation.
Bubble Button: Can adjust among 3 levels of bubbling power. The default bubbling
massage power is level 2 (500W) . Press the BUBBLE button again, switching to level 3
(720W) . Press again made to level 1 (300W) . To shut down the function, press
the BUBBLE button for 3 seconds.
NOTE: The bubbling massage function will be shut down automatically after every 20
minutes operation for safety concern. It can not be operated within 10 minutes after shut
down. The bubbling massage function will be filtered automatically after 4-hour.
Filter Button: Activate the filter pump. The Filter icon shows when the filtration system is
activated.
NOTE: Filtration cannot be turned off when heating is activated. When the Heating function
is turned off, Filtration will be stopped after 30 seconds. Filtration function can be then
activated separately.
NOTE: Auto-filtration system every 4 hours.
Heater Button: Use this button to activate the HEATING and FILTRATION function at the
same time. The heater will heat the spa water until the water temperature reaches the pre-set
temperature. After the current water temperature drops below the set temperature, the
heating system will restart automatically. The Heater icon shows when the heating system is
activated. When the Heater icon is flashing, the heating system is at rest and the water is at
set temperature.
NOTE: If you want to open the HEATING and FILTRATION functions, just press the
HEATER button.
Temperature Adjustment Buttons: To adjust the current temperature, press the UP or
Down button, and the LCD screen flashes to display the set temperature. The temperature
interval is one degree. The LCD displays the current temperature if no further operation more
than 3 seconds.

17
LCD READING CAUSE SOLUTION
Water temperature is lower than zero
degree or exceed 55°C(131°F)
Temperature sensor failure
Water pressure switch failure
Filter failure
Water level is not at minimum water line
Detecting function failure
No water in the spa tub
Contact the MSpa Service Center.
Contact the MSpa Service Center.
Add more water to the minimum line.
Add more water to the minimum line.
System self-checking
Step 1: Fill water to the water line, and make
sure that there is no bather or
object in the spa tub.
Step 2: Connect the power supply, press
RESET button on the PRCD.
Step 3: If E3 shows, contact the MSpa
Service Center. If E3 is flashing,
press ON/OFF, C/F,TEMP+ buttons
once insequence, enter to the
self-checking system. If no error
code shows, failure is not detected.
It is OK to use the spa. If error code
shows after self-checking, contact
the MSpa Service Center.
Contact the MSpa Service Center.
Change the water or contact the MSpa
Service Center.
ERROR CODE CHART
Celsius/Fahrenheit Toggle Button: The temperature can be displayed in either Celsius
or Fahrenheit. The system's default is Celsius.
Ozonator Button: Activate the Ozone. The Ozone icon shows when the Ozone function is
activated. For bathers' safety concern, the ozonator cannot be operated at the same time
when the Bubble or Jet function is on. The Ozonator will be off automatically after opearting
for 2 hours. Ozone output is 30-50mg/Hr.
NOTE: Please do not soak in the spa when the Ozone is on. The Ozonator will not work
when the spa has no water or when the JET or Bubble Button is on.
IMPORTANT：The following conditions will lead to slow water heating
Ɣ7KHDPELHQWWHPSHUDWXUHLVORZHUWKDQ&)
Ɣ2XWGRRUZLQGVSHHGLVDERYHPVPSK
Ɣ7KHDLUEXEEOHIXQFWLRQLVDFWLYDWHGZKHQKHDWHULVRQ
Ɣ7KHVSDLVQRWSURSHUO\FRYHUHGZLWKWKHVSDFRYHUZKHQKHDWHULVRQ
Heating failure
System failureE3
E4
E0
E1
E2
NOTE: The default temperature is 38°C(100°F).
NOTE: Temperature adjustment ranges from 20°C(68°F) to 42°C(108°F).

18
1.1 1.2 1.3
5
WATER MAINTAINCE AND CHEMICALS
Water Sanitation
The spa owner must regularly check and keep the spa water sanitized with scheduled maintenance (daily, if
necessary). Adding sanitizer or other chemical will control bacteria and viruses present in the spa water. The
maintenance of a proper water balance through appropriate use of sanitizers is the most important factor in
maximizing the life and appearance of the spa as well as ensuring clean, healthy and safe water.
Proper technique is important for water testing and treating the spa water. See your spa professional for
chemical, sanitizer, test kit and testing procedures questions.
CAUTION:
Ɣ$OZD\VIROORZWKHFKHPLFDOPDQXIDFWXUHU¶VGLUHFWLRQDQGWKHKHDOWKDQGKD]DUGZDUQLQJ
Ɣ'RQRWDGGFKHPLFDOVLIWKHVSDLVRFFXSLHG7KLVFDQFDXVHVNLQRUH\HLUULWDWLRQ
Ɣ&RQFHQWUDWHGFKORULQHVROXWLRQVFDQGDPDJHWKHVSDWXE,PSURSHUFKHPLFDOXVHZLOOYRLGWKHZDUUDQW\
Maintenance of Spa Water and Cartridge
Protect all the spa occupants from possible water related illness by keeping the spa water clean and sanitized.
Always practice good hygiene. To ensure proper spa water quality by following these procedures:
1. Inspect and clean the filter cartridge after each use, and change the filter cartridge after it works
continuously for 72 hours.
ƔUnscrew the cartridge assembly from the spa tub wall and remove the cartridge by turning it
counter clockwise (Fig. 1.1)
ƔUse a garden hose to rinse off the cartridge. If the cartridge remains soiled and discolored it should be
replaced. Keep spare cartridges on hand.(Fig.1.2). There are two filter cartridges from the original
package, one is for use, one is spare.
ƔReinstall the clean or spare cartridge back onto the spa tub wall but turning it on clockwise. (Fig.1.3)
2. Change the spa water every 3-5 days depends on the spa use. See “Cleaning, draining and storage”
section for instruction.
3. Use spa chemicals to maintain proper water chemistry. Spa damage resulting from misuse of chemicals
and mismanagement of spa water is not covered by the warranty. Consult with your local spa or pool
retailer for more information on chemical use.
4. All occupants must shower before entering the spa.
5. When spa inlet or outlet is stuck with dirt. Use the
Wrench to check the problem and clean the inlet
or outlet.

19
Water Balance
Maintain the spa water pH level between 7.2 and 7.8, total alkalinity between 80 and 120ppm and free chlorine
level between 3 to 5ppm. Use the *optional Test Strips to test the spa water chemistry before each use of the
spa and continue to test the water no less than once a week.
The Test Strips can test the “Free Chlorine”, “pH”, and “Total Alkalinity” level at the same time:
1. Dip the entire strip into the water and remove immediately
2. Hold the strip level for 15 seconds. Do not shake excess water from the strip
3. Compare the strip pad to the color chart on the packaging label. If necessary, adjust the chemical level in
the pool water
NOTE:
Ɣ/RZS+ZLOOGDPDJHWKHVSDWXEDQGSXPS'DPDJHUHVXOWLQJIURPWKHFKHPLFDOLPEDODQFHZLOOYRLGWKH
warranty.
Ɣ+LJKS+KDUGZDWHUZLOOUHVXOWLQZKLWHFRDJXODWLRQVLQVLGHWKHILOWHUSXPSZKLFKPD\OHDGWRSXPS
damage.
IMPORTANT:
Ɣ3UHVVWKH%XEEOHEXWWRQRQWKHspa control panel to turn on the bubble air blower and help to
dissolve the chemicals into the water.
Ɣ1HYHUPL[FKHPLFDOVWRJHWKHU$GGWKHFKHPLFDOVWRWKHVSDZDWHUVHSDUDWHO\7KRURXJKO\GLVVROYHHDFK
chemical before adding one to the water.
WATER TREATMENT:
Ɣ%URPHRUFKORUHLVKLJKO\UHFRPPHQGHGIRUJRRGZDWHUTXDOLW\
Ɣ3OHDVHQRWHWKDWFKORULQHDQGEURPLQHSURGXFWVVKRXOGQHYHUEHPL[HG7KLVLVH[WUHPHO\GDQJHURXV,I\RX
usually use chlorine-based products and you want to switch to bromine-based products, or vice versa, it is
mandatory to completely change the spa water before any product changes.
Ɣ'RQRWRYHUXVHWKHFKHPLFDOVRWKHUZLVHWKHUHZLOOEHVWURQJFKHPLFDORGRUDQGSRWHQWLDOKD]DUGWR\RXU
skin.

20
1
4 5 6
2 3
17
garden hose
®
15
minutes
DRAINAGE, CLEANING AND STORAGE
Spa Drainage
1. Turn off all the buttons (heater, filter and bubble) on the control panel unit.
2. Connect the drain valve adapter to a garden hose and point the other end of the garden hose to a
suitable draining area with local environmental regulations (Fig.1)
3. Remove the drain valve cap from the outside of the spa tub and attach the drain valve adapter with the
garden hose to the drain valve (Fig.2)
4. From the inside of the spa tub, open the drain valve cap, water will start to flow out through the garden
hose (Fig.3)
5. When the water stops draining, lift the spa tub wall from the opposite to the drain, leading any
remaining water to the drain and empty the spa water completely. (Fig.4)
Spa Tub Cleaning
Ifdirt is visible inthewater or water becomescloudyand proper water chemistrydoesnot clear it up,changethe
water and clean the spa tub.
Whilespa water is empty,removethe cartridge from theinsideof the spa tubwall,clean and /or replacethefilter
cartridge.Useaspongeandmildsoapsolutiontowipeawayanysoilorstainsontheinsideofthespawall.Rinse
thoroughly before refilling with clean water.
IMPROTANT: Do not use steel wool, hard brushes or abrasive cleaners.
Spa Tub and Air Bladder Repair
Use the enclosed repair patch to repair any puncture:
1. Clean and dry the area to be repaired thoroughly
2. Apply the glue to the PVC patch and quickly attach it onto the damaged surface. (Glue is not included)
3. Smooth the surface to remove any air bubbles and allow it dry for 5-10 minutes
6. Press Bubble button to dry out any water in the piping system. Operate the bubbling function
for 15 minutes to blow out all the remaining water. (Fig.5)
7. When the water stops draining, use a clean towel to wipe up any remaining water and moisture on the
spa tub and spa control panel. (Fig.6)
