M2 Antenna Systems 6-30LP11 User manual

M2 Antenna Systems, Inc. 4402 N. Selland Ave. Fresno, CA 93722
Tel: [phone] Fax: [phone] Web: www.m2inc.com
©2015 M2 Antenna Systems Incoporated 06/09/15
Rev.01
Model .........................................6-30LP11
Frequency Range.......................6 To 30 MHz
*Gain ..........................................5 To 6.2 dBi
Front to back ..............................10 To 20 dB Typical
Feed Impedance........................50 Ohms Unbalanced
Maximum VSWR........................1.8:1 Max, Under 1.5
I
Input Connector..........................“N” Female
Power Handling..........................3 Kw, Higher Optional
Boom Length / Type...................80’ / Steel Tower
Turning Radius:..........................65’
Wind area / Survival...................125 MPH
Weight / Ship Wt.........................1,228 Lbs.
M2 Antenna Systems, Inc.
Model No: 6-30LP11
FEATURES:
The 6-30lp11 log periodic is a modern design both mechanically and electrically. Top quality materials combined
with many CNC machined parts will keep it trouble free for years or operation. Performance is excellent and specific path
gain can be as much as 12 dB with ground gain factored in. The 6-30LP11 is available individually or in a turnkey system,
complete with support tower, rotation mechanism and controller. Many options exist within the turnkey system such as
height and type of tower, rotator mechanism, and controller type. As pictured above and originally supplied to NASA at
Edwards air Force Base in Edwards California, the tower was a special, massive, motorized, self supporting 72 foot tower
supplied by US tower Corp to M2specifications. The 6-30LP11 is the latest Log to join the M2Family of high quality broad
band antennas.
SPECIFICATIONS:
*Subtract 2.14 from dBi for dBd

BEFORE YOU BEGIN: Look over the ELEMENT ASSEMBLY sheets to get familiar with the various
parts of the log periodic. These written instructions attempt to give some order and efficiency to the
overall assembly and make you aware of critical areas. TWO CUPS OF ZINC PASTE HAS BEEN
PROVIDED AND SHOULD BE USED AT EACH JOINT WHERE MACHINED PARTS JOIN
ALUMINUM RODS OR TUBES AND GENERALLY AT EACH ELECTRICAL CONNECTION POINT.
WE ALSO STRONGLY RECOMMEND THAT EACH BOLT AND SCREW USED, BE TOUCHED IN
THIS PASTE WITH THE FIRST FEW THREADS. THIS WILL PREVENT GAULING AND BETTER
TIGHTENING OF THE STAINLESS HARDWARE.
THIS IS A VERY LARGE ANTENNA WHEN COMPLETELY ASSEMBLED. WE SUGGEST YOU
ASSEMBLE THE ELEMENTS FIRST AND WHEN DOING THE LARGER ELEMENTS, ASSEMBLE
THE TIP SECTIONS UP TO THE 1-1/2” SECTIONS, MARK AND SET ASIDE UNTIL THE BOOM IS
ASSEMBLED AND THE INNER SECTIONS 2” DIAMETER AND LARGER ARE MOUNTED ON
THE BOOM.
THE LONGEST 3 ELEMENTS ARE BOXED INDIVIDUALLY TO MAKE IT EASIER TO IDENTIFY
AND ASSEMBLE THE CORRECT ELEMENT SECTIONS.
BEGIN ASSEMBLING THE SMALLEST ELEMENTS FIRST TO ESTABLISH A “ROUTINE”
REFER TO THE ELEMENT 4 THOUGH 11 ASSEMBLY SHEET
1. Locate five (5) 7/8 x 30” FIBERGLASS RODS and (10) POLY DISCS with 7/8” holes. Press a
disc onto the end of a rod and slide it down until it is about 3/4” inside the INNER two 1/4” holes.
Then slide another poly disc on from the other end of the rod and position it about 3/4” inside the
other 1/4” hole. Repeat this for all five of the 7/8” FIBERGLASS RODS. Slight repositioning of the
poly discs may be required when the element is mounted below the boom.
ELEMENT #11 (Smallest)
2. Install a PHASE LINE CLAMP with 1” hole at the butt of the 1” x 60.75” element half with the two
grooves facing the butt. Secure the clamp block temporarily using an 8-32 x 1-1/2” screw and
locknut. Add a PHASING LINE CLAMP CAP to the PHASE LINE CLAMP using a 1/4-20 x 1” flat
head bolt and locknut, but finger tighten only at this time. Repeat for the other #11 element half.
Now slide each element half onto a previously prepared 7/8” FIBERGLASS ROD and align the
holes. Secure with 1/4-20 x 1-1/2" bolt and locknut. Finally, align the grooved side of the clamp
block assembly on each side with the NUT SIDE of the bolt holding each element half onto the
rod. Position the clamp blocks about 1/2” from the end of the element butts and tighten the 8-32 x
1-1/2” screws and locknuts securing the clamp blocks. Use a marking pen to identify the element
as #11. Element #11 is now complete and ready to be installed on the boom at a later time.
ELEMENTS #10, #9, #8, & #7
3. These are very similar to #11. Follow the same procedure as in step #2. Follow the ELEMENT
ASSEMBLY SHEET for the element information and the hardware needed. Don’t forget to use
PENETROX (ZINC) PASTE on all aluminum joints and on the threads of the screws and bolts.
Element #7 has a 1-1/8” outer sleeve but it still uses a 7/8” FIBERGLASS ROD and a PHASE
LINE CLAMP with 1” hole for the phasing lines.
6-30LP11 ASSEMBLY MANUAL

4. Element #6 is similar as well but has internal sleeves to strengthen the element. It has a 1-1/4”
diameter element butt and needs a 1” FIBERGLASS ROD, POLY DISCS with 1” hole and
PHASE LINE CLAMPS with 1-1/4” hole.
5. ELEMENT #5 is 1-1/2” diameter at the butt and needs a 1-1/4” FIBERGLASS ROD, POLY
DISCS with 1-1/4” hole and PHASE LINE CLAMPS with 1-1/2” hole.
6. ELEMENT #4 is similar to #5 but requires a 1-5/8” OUTSIDE SLEEVE over the butt section to
maintain element strength to survive 125 mph winds. ELEMENT #4 is unique because at #4
there is transition in phasing line diameter. Both PHASE LINE CLAMPS AND 3/8” CLAMP
BLOCK PAIRS are required at the butt of this element. The 3/8” diameter phasing lines go back
to element #3.
THIS COMPLETES ELEMENT ASSEMBLY FOR ELEMENTS #11
DOWN THROUGH ELEMENT #4
ELEMENTS #3, #2 AND #1 ARE NEXT AND WE RECOMMEND YOU ASSEMBLE THE OUTER
SECTIONS BEGINNING WITH THE 1-1/2” SECTIONS, MARK THEM AND SET THEM ASIDE FOR
LATER CONNECTION TO THEIR INNER SECTIONS.
6-30LP11 ASSEMBLY MANUAL

7. Assemble the three inner section of ELEMENT #3. NOTE that the PHASE LINE CLAMPS and
PHASING LINE CLAMP CAPS have been replaced with pairs of 3/8” CLAMP BLOCKS held in
place with the same bolt that keeps the element on the 2” FIBERGLASS ROD. These 3/8”
CLAMP BLOCKS clamp the 3/8” diameter phasing lines installed later in the assembly. The
POLY DISCS have 2” diameter holes to fit over the 2” center support insulator and may have
been factory installed as have the machined coupling rings. If POLY DISCS have not been fac-
tory installed on CENTER SUPPORT INSULATOR you will have to remove two rings off one
side, slide POLY DISCS on and re-install rings. NOTE: These POLY DISCS provide a long
barrier between the “hot” element and the grounded tower boom. They provide arc and flashover
protection in the event the insulator is contaminated with salt spray, bird doo or other foreign
substances that could conduct under the right condition.
8. Assembling ELEMENT #2 & #1 is similar to #3 except ELEMENT #2 & #1 each use (2)
ELEMENT SIDE SUPPORT BRACKETS that are attached to the 2” sections just inside the
SWAGED (necked down) section. Use a 2” U-bolt and cradle and stainless nuts and lock
washers. Attach (3) HPTG 1200 Philistran insulated cables to each of the three holes in ELE-
MENT SIDE SUPPORT BRACKET. Use a 3/16” cable eye in each hole. String two 1/8” cable
clips on one end of each cable and thread the cable end through each hole and around each
cable eye. Thread the cable end back through the cable clips about 3”. Space the clips about 1”
inch apart. Push one clip tight against the cable eye and begin tightening that clip. Strighten the
cable between the clips and begin tightening the second clip. Alternate back and forth on the
tightening of each clip until each is tight and the clips are secure. The other ends of these cable
will be attached to the TOWER BOOM and ELEMENT VERTICAL SUPPORT MAST later in the
assembly procedure.
6-30LP11 ASSEMBLY MANUAL

1. Use 1/2-13 X 2” (grade 5) galvanized bolts, 1/2-13 galvanized nut & 1/2-13 galvanized pal nut
for all tower boom section joints.
2. Shims (as shown) are supplied with tower sections to help align. Use as needed.
6-30LP11 BOOM TOWERASSEMBLY

6-30LP11 ELEMENT ASSEMBLY #4-11

6-30LP11 ELEMENT ASSEMBLY #3

6-30LP11 ELEMENT ASSEMBLY #2

6-30LP11 ELEMENT ASSEMBLY #1

1. Begin by installing element #11, the smallest element. Locate the bag of twenty (20) HD CRA-
DLES with 7/8” radius to fit the 7/8” fiberglass rods. These cradles have clearance holes for 5/16”
diameter bolts. Drop four (4) 5/16-24 x 4” bolts down through the element #11 mounting plate.
Hold the center of element #11 up near the plate and place two saddles on the center of 7/8” fi-
berglass rod. Raise the element up and feed the bolts down through the cradles. Place another
cradle under each upper cradle and add locknuts. Tighten up the nuts until the element is almost
secure. Then center the element through the cradles and rotate the element until the bolts at the
element butt are up and their corresponding nuts are down. Tighten the cradle bolts evenly and
completely. Now orient the PHASE LINE CLAMP ASSEMBLIES on the element butts so the
PHASING LINE CLAMP CAP are DOWN and square with the boom.
2. Continue mounting element #10, #9, #8, and #7 in order as described above.
3. Element #6 is different only as it has a 1” fiberglass rod and (4) HD CRADLES with 1” radius, fit-
ting the fiberglasss rod perfectly. Use (4) 5/16-24 x 4” bolts and locknuts to secure the element.
4. Element #5 and #4 both use 1-1/4” fiberglass rods and (4) HD CRADLES with 1-1/4” radius.
Use 5/16-24 x 4-1/2” bolts and locknuts.
5. Because of their size and weight we have suggested that just the INNER SECTIONS of element
#3, #2, and #1 be mounted before the whole element is assembled. Element #3 and #2 use 2”
fiberglass rods and (4) HD CRADLE with 2” radius. These cradles require 3/8-24 x 5” bolts and
locknuts. Before tightening cradles completely be sure to rotate the element so the 3/8” PHASE
LINE CLAMP CAPS are down and their bolts are perfectly perpendicular with the TOWER
BOOM legs. Doing this will facilitate the installation of the phasing lines in the subsequent as-
sembly steps.
6. Element #1 uses a 2” fiberglass rod and (8) HD CRADLES with 2” radius. These cradles require
(8) 3/8-24 x 5” bolts and locknuts. Again center and rotate the element in the cradles so the 3/8”
PHASE LINE CLAMP CAPS are down and their bolts perpendicular to the TOWER BOOM legs.
7. OPTIONAL: THE TIP SECTION OF ELEMENTS #3, #2, AND #1 CAN NOW BE INSTALLED.
You may also elect to do the element tip installation just prior to the antenna being place on a
tower. If you do it now or later, refer again to the appropriate element assembly sheet for the
hardware required to attach the tip sections.
8. Now do the final check and tightening of the all elements forward to the Element #11. TIGHTEN
each bottom cradle EVENLY AND SECURELY.
6-30LP11 ELEMENT INSTALLATION

1. INSTALLING THE ELEMENT VERTICAL SUPPORT BRACKETS AND ELEMENT VERTICAL
SUPPORT MASTS ON ELEMENT #2 AND #1. Set the bracket over element #2 as shown. Mount
the VERTICAL ELEMENT SUPPORT MAST using 1-1/2” U-bolts and rotate the mast so the holes
in the top flag are over the element. Adjust the bracket location so the flag holes are centered
over the element center line. Install four (4) 1-1/2” stainless U-bolts in the appropriate holes and
tighten all U-bolts.
2. Route the HPTG 1200 insulating cables, previously installed on these inner element sections, in
toward the boom from each side. Open the 5/16” hook and eye turnbuckles until just one thread
shows INSIDE the body. Hook the turnbuckle as shown and install cable eyes in the turnbuckle
eyes. Slide two 1/8” cable clips on the cable and route the cable through the turnbuckle eye and
over the cable eye. Push the cable end back through the clips, pull all the slack out of the cable
and then push one clip close against the cable eye and begin tightening the nuts on the clip.
Slide the second clip to about 1” away from the first clip and begin tightening both clips until se-
cure. Using a 5/16” nut driver is the easiest way to tighten the clips.
3. Route the side guy cables in toward the
two TOWER BOOM TABS on each side of
the element. Install cable eyes in each tab
hole. String two cable clips on each cable
end and route the cable through the tab
hole and over the cable eye. Pull all the
slack out of the cable and slide the clip up
and tighten as before. Repeat this proce-
dure for element #1. Trim off excess cable
as required.
4. Once the element tips are installed, the
overhead cable turnbuckles should be ad-
justed to lift the element until the center ele-
ment sections are level. Be sure to safety
wire the turnbuckles so they will not loosen
after installation.
6-30LP11 OVERHEAD SUPPORT

1. Mount the 4:1 BALUN MOUNTING PLATE assembly to the TOWER BOOM just behind element
#11 as shown above. Route the balun leads to the 1/4-20 x 1-1/2 bolts through the element butts
and tighten securely.
2. Locate the shortest pair of 3/16” rod phasing lines and slide
a 3/16” PHASE LINE INSULATOR onto the rods and feed
the front ends into the grooves in the PHASE LINE
CLAMPS. Hanging below the element butts. Slide the rods
far enough through to insert the other ends into the PHASE
LINE CLAMPS on element #10. Center and align the rods
so the bends are flat and parallel. Now tighten the front
PHASE LINE CLAMPS only.
3. Continue by adding the next set of phasing lines between
element #10 and #9. Center align the phasing rods and
tighten the PHASE LINE CLAMPS on element #10. Contin-
ue installing phasing lines and 3/16” PHASE LINE SPAC-
ERS to element #8.
4. The phasing lines between element #8 and #7 and beyond require (4) 3/16” PHASE LINE SUP-
PORT INSULATORS between each element. String on the 3/16” PHASE LINE SPACER and
then two 3/16” PHASE LINE SUPPORT INSULATORS from each end of the phasing lines. Posi-
tion the assembly under the boom and add the PHASE LINE SUPPORT CAPS. Use 1/4-20 x 1-
1/2” bolts that thread into 3/16” PHASE LINE SUPPORT INSULATORS. Tighten the bolts until no
rotation of the 3/16” PHASE LINE SUPPORT INSULATOR is possible. DO NOT OVERTIGHT-
EN.
6-30LP11 BALUN & PHASE LINE

6. Two pairs of 3/8” CLAMP BLOCKS should be attached to the butts of element #4. If they are not
there, mount them now loosely on the 1/4-20 x 2-1/2” bolts through each butt.
THE DRIVE MAST BRACKET (OPTIONAL) IS MOUNTED LATER IN BETWEEN ELEMENT #4
AND #3. “SPECIAL” OFFSET BEND PHASE LINES ARE REQUIRED HERE TO CLEAR THE
DRIVE MAST BRACKET.
7. Slide a 3/8” PHASE LINE SPACER onto the shortest set of 3/8” diameter phase lines. Now add
(8) 3/8” PHASE LINE SUPPORT INSULATORS. NOTE: THIS SET OF LINES ARE NOT BENT
SYMETRICALLY. CONNECT THE SHORT, STRAIGHT SECTIONS TO ELEMENT #4 and the
longer straight sections to element #3. Center and align these phase lines and tighten the 3/8”
CLAMP BLOCKS at element #4.
8. Element #3 should have two pairs of 3/8” PHASE LINE CLAMP CAPS on the element butts. If
not, then add them now loosely. Continue installing this phase line set using eight (8) 3/8”
PHASE LINE SUPPORT INSULATORS. Center and align the phasing lines and tighten 3/8”
PHASE LINE CLAMP CAPS on element #3.
9. The phasing lines between element #2 and #1 require (8) 3/8” PHASE LINE SUPPORT INSULA-
TORS, two on each line on each side of the crossover. Element #1 should have two pairs of 3/8”
PHASE LINE CLAMP CAPS. Install now if not already on the element butts. Center and align the
phase lies as before and tighten the 3/8” PHASE LINE CLAMP CAPS on both element #2 and
#1. This completes the phasing line installation.
5. Continue adding these 3/16” rod phasing line assemblies until you reach and finish Element #4.
Tighten the 3/16” PHASE LINE CLAMPS on element #4. Note: 3/8” tube phasing lines are used
between element #4 through element #1.
6-30LP11 BALUN & PHASE LINE

1. The physical balance point of the antenna is about 30” to the rear of the center TOWER BOOM
joint as shown below. The DRIVE MAST BRACKET (sold separate), will mount just below the
MAST PLATE “L” & “R” that bolt on to the OVERHEAD MAST BRACKET (shown below).
2. Place the MAST PLATE “L” & ‘”R” and OVERHEAD MAST BRACKET in position and add the
CRADLES with 1/2” radius and use 3/8-24 x 4” BOLTS and locknuts as shown. Then insert the
MAIN MAST OVERHEAD SUPPORT and carefully align the welded top tabs with the boom.
3. Install the 1/2” FORGED TURNBUCKLES in the top holes in the welded tabs and extend the
turnbuckle until just one thread shows inside the body. Install 3/8” cable eyes in the turnbuckle
eyes and also into the welded tabs on the tower/boom itself. Slide two 3/8” cable clips on a cable
end and route the cable through the turnbuckle, over the cable eye and back through the two
clips. Slide one clip against the cable eye and begin tightening. Then position the second clip
about 2” from the first and begin tightening it. Alternate back and forth until the clips are very tight
and have compressed into the cable jacket. Repeat this for the other turnbuckle. Now go to the
outer ends of the boom and repeat the process but be sure to pull all the slack out of the cables
before tightening the clips.
4. Now begin tensioning the cables by tightening the turnbuckles. If possible use a forklift or equiv-
alent to lift the whole antenna at the OVERHEAD MAST BRACKET point to determine that the
cable tension is adequate to maintain a straight boom. Adjust as required. Final adjustment can
be done once the antenna is installed on the tower.
6-30LP11 BOOM OVERHEAD SUPPORT

ELEMENT #1
12-18-08
DESCRIPTION QTY
ELE 1 SEC 1, 3” X .125 X 120” SOE, 6061-T6 2
ELE 1 SEC 2, 2-1/2 X .125 X 116”, SOE 6061-T6 2
ELE 1 SEC 3, 2” X .125 X 110” SOE, 6061-T6 2
ELE 1 SEC 4, 1-1/2” X .058 X 60” SOE 6063-T832 2
SLEEVE, 1-3/8 X .058 X 56.00 6063-T832 2
SLEEVE, 1-1/4 X .058 X 40.00 6063-T832 2
ELE 1 SEC 5, 1-1/4 X .058 X 45” SOE 6063-T832 2
SLEEVE, 1-1/8 X .058 X 37.00 6063-T832 2
ELE 1 SEC 6, 1” X .058 X 45” 6063-T832 2
SLEEVE, 7/8” X .058 X 66.0” 6063-T832 2
ELE 1 SEC 7, 3/4 X .049 X 60” SOE 6063-T832 2
ELE 1 SEC 8, 1/2 X .049 X 60” 6063-T832 2
CENTER SUPPORT INSUL, 2” X 36” W/ COUPLING RINGS 1
POLY DISC INSULATOR, 2” I.D. 2
CRADLE, 2” HD (MACH. ALUM.) 8
ELEMENT VERTICAL SUPPORT MAST 1-1/2” X 48” (WELDED) 1
ELEMENT VERTICAL SUPPORT BRACKET (STEEL, WELDED) 1
ELEMENT SIDE SUPPORT BRACKET (ALUMINUM, WELDED) 2
3/8” PHASE LINE CLAMP CAP 4
2” U-BOLT AND CRADLE 2
1-1/2” U BOLT AND CRADLE 7
TURNBUCKLE, 5/16, HOOK & EYE SS 2
HPTG 1200 PHILISTRAN, 28 FT 6
HARDWARE
CABLE CLIPS, SMALL, 24
CABLE EYE, 1/8” 12
BOLT, 3/8-24 X 5“, GRADE 5 8
LOCKNUT, 3/8-24 ZINC 8
BOLT, 3/8-16 X 4” SS 2
BOLT, 3/8-16 X 3-1/2”, SS 2
LOCKNUT, 3/8-16, SS 4
NUT, 5-16-18, SS 18
LOCKWASHERS, 5/16” SPLIT RING, SS 18
BOLT, 1/4-20 X 3-1/4”, SS 4
BOLT, 1/4-20 X 2-3/4”, SS 4
BOLT, 1/4-20 X 2 1/4”, SS 4
LOCKNUT, 1/4-20, SS 16
SCREW, 8-32 X 1-3/4”, SS 4
SCREW, 8-32 X 1-1/2”, SS 8
SCREW, 8-32 X 1-1/4”, SS 4
SCREW, 8-32 X 1”, SS 4
LOCKNUT, 8-32, SS 20
PENTROX,CUP 1
6-30LP11 PARTS & HARDWARE

ELEMENT #2
12-18-08
DESCRIPTION QTY
ELE 2 SEC 1, 3” X .125 X 74” SOE, 6061-T6 2
ELE 2 SEC 2, 2-1/2 X .125 X 79”, SOE 6061-T6 2
ELE 2 SEC 3, 2” X .125 X 64” SOE 6061-T6 2
ELE 2 SEC 4, 1-1/2 X .058 X 63” SOE 6063-T832 2
SLEEVE, 1-3/8 X .058 X 56.00 6063-T832 2
SLEEVE, 1-1/4 X .058 X 40.00 6063-T832 2
ELE S SEC 5, 1-1/4 X .058 X 44” SOE 6063-T832 2
SLEEVE, 1-1/8 X .058 X 37.00 6063-T832 2
ELE 2 SEC 6, 1” X ..058 X 44” 6063-T832 2
SLEEVE, 7/8” X .058 X 71” 6063-T832 2
ELE 2 SEC 7, 3/4 X .049 X 66” SOE 6063-T832 2
ELE 2 SEC 8, 1/2 X .049 X 60” 6063-T832 2
CENTER SUPPORT INSUL. 2” X 36” W/ COUPLING RINGS 1
POLY DISC INSULATOR, 2” I.D. 2
CRADLE, 2” HD (MACH. ALUM.) 4
ELEMENT VERTICAL SUPPORT MAST 1-1/2 X 48” (WELDED) 1
ELEMENT VERTICAL SUPPORT BRACKET (STEEL, WELDED) 1
ELEMENT SIDE SUPPORT BRACKET (WELDED) 2
3/8” PHASE LINE CLAMP CAP 4
2” U-BOLT AND CRADLE 2
1-1/2” U BOLT AND CRADLE 7
TURNBUCKLE, 5/16, HOOK & EYE SS 2
HPTG 1200 PHILISTRAN, 20 FT 2
HARDWARE
CABLE CLIPS, SMALL, 24
CABLE EYE, 1/8” 12
BOLT, 3/8-24 X 5“, GRADE 5 4
LOCKNUT, 3/8-24 ZINC 4
BOLT, 3/8-16 X 4” SS 2
BOLT, 3/8-16 X 3-1/2”, SS 2
LOCKNUT, 3/8-16, SS 4
NUT, 5/16-18, SS 18
LOCKWASHERS, 5/16” SPLIT RING, SS 18
BOLT, 1/4-20 X 3-1/4”, SS 4
BOLT, 1/4-20 X 2-3/4”, SS 4
BOLT, 1/4-20 X 2-1/4”, SS 4
LOCKNUT, 1/4-20, SS 16
SCREW, 8-32 X 1-3/4”, SS 4
SCREW, 8-32 X 1-1/2”, SS 8
SCREW, 8-32 X 1-1/4”, SS 4
SCREW, 8-32 X 1”, SS 4
LOCKNUT, 8-32, SS 20
PENETROX CUP 1
6-30LP11 PARTS & HARDWARE

ELEMENT #3
12-18-08
DESCRIPTION QTY
ELE 3 SEC 1, 3” X .125 X 36” SOE, 6061-T6 2
ELE 3 SEC 2, 2-1/2 X .125 X 41”, SOE 6061-T6 2
ELE 3 SEC 3, 2” X .125 X 49” SOE 6061-T6 2
ELE 3 SEC 4, 1-1/2 X .058 X 63” SOE 6063-T832 2
SLEEVE, 1-3/8 X .058 X 56.00 6063-T832 2
SLEEVE, 1-1/4 X .058 X 40.00 6063-T832 2
ELE 3 SEC 5, 1-1/4 X .058 X 43” SOE 6063-T832 2
SLEEVE, 1-1/8 X .058 X 37.00 6063-T832 2
ELE 3 SEC 6,1” X .058 X 28” 6063-T832 2
SLEEVE, 7/8” X .058 X 71.875” 6063-T832 2
ELE 3 SEC 7, 3/4 X .049 X 81” SOE 6063-T832 2
ELE 3 SEC 8, 1/2 X .049 X 63” 6063-T832 2
CENTER SUPPORT INSUL. 2” X 36” W/ COUPLING RINGS 1
POLY DISC INSULATOR, 2” I.D. 2
CRADLE, 2” HD (MACH. ALUM.) 4
3/8” PHASE LINE CLAMP CAP 4
HARDWARE
BOLT, 3/8-24 X 5“, GRADE 5 4
LOCKNUT, 3/8-24 ZINC 4
BOLT, 3/8-16 X 4” SS 2
BOLT, 3/8-16 X 3-1/2”, SS 2
LOCKNUT, 3/8-16, SS 4
BOLT, 1/4-20 X 3-1/4”, SS 4
BOLT, 1/4-20 X 2-3/4”, SS 4
BOLT, 1/4-20 X 2-1/4”, SS 4
LOCKNUT, 1/4-20, SS 16
SCREW, 8-32 X 1-3/4”, SS 4
SCREW, 8-32 X 1-1/2”, SS 8
SCREW, 8-32 X 1-1/4”, SS 4
SCREW, 8-32 X 1”, SS 4
LOCKNUT, 8-32, SS 20
PENETROX CUP 1
6-30LP11 PARTS & HARDWARE

6-30LP11 BOOM
12-18-08
DESCRIPTION QTY
BOOM TOWER SECTION #1 1
BOOM TOWER SECTION #2 1
BOOM TOWER SECTION #3 1
BOOM TOWER SECTION #4 1
DRIVE MAST WELDMENT, ZINC 1 OPTIONAL
MAST PLATE, WELDMENT, ZINC 1
MAST PLATE “L” 1
MAST PLATE “R” 1
MAIN MAST OVERHEAD SUPPORT MAST 1
(2” X .180 X 96” GALV)
GUY CABLE, HPTG 6700 PHILISTRAN X 70 FT. 1
TURNBUCKLE, 1/2 X 12 FORGED GALV. 2
CRADLE, 1 1/2” MACHINED ALUM. (13/32 HOLES) 16
TOWER SHIM (THICK) 12
TOWER SHIM (THIN) 12
HARDWARE
BOLT, 1/2-13 X 2” GRADE 5, GALV. (TOWER BOLTS) 40
NUT, 1/2-13 GALV. 40
PAL NUT 1/2-13, GALV. 40
BOLT, 3/8-24 X 4” GRADE 5 8
BOLT, 3/8-24 X 3 1/2”, GRADE 5 8
BOLT, 3/8-12 X 1 1/2”, GRADE 5 8
NUT, 3/8-24, LOCKING, ZINC 24
CABLEEYES,3/8” 4
CABLE CLIPS, 3/8” 8
6-30LP11 PARTS & HARDWARE

PHASING LINE SYSTEM & FEED
12-18-08
DESCRIPTION QTY
3/8” X 204” TUBE, BENT, 6063-T832 2
3/8” X 172” TUBE, BENT, 6063-T832 2
3/8” X 137” TUBE, BENT, 6063-T832 2
3/16” X ROD, BENT, 6061-T6 2
3/16” X ROD, BENT, 6061-T6 2
3/16” X ROD, BENT, 6061-T6 2
3/16” X ROD, BENT, 6061-T6 2
3/16” X ROD, BENT, 6061-T6 2
3/16” X ROD, BENT, 6061-T6 2
3/16” X ROD, BENT, 6061-T6 2
PHASE LINE SUPPORT INSULATOR, FOR 3/8” TUBE 24
PHASE LINE SUPPORT INSULATOR, FOR 3/16 ROD 20
PHASE LINE SUPPORT CAP (DELRIN) 44
.375 PHASE LINE SPACER, 3/4 X 2 X 2 ” DELRIN 3
.188 PHASE LINE SPACER, 1/2 X 1-3/8 X 3/4” DELRIN. 7
BALUN, 4:1 W/ “N” CONN 1
BALUN MOUNTING PLATE, 1/4 X 1 1/2 X 12 ALUM 1
1 1/2 U-BOLT AND CRADLE 2
2 1/2 U-BOLT AND CRADLE 1
HARDWARE
NUT, 5/16-18 SS 6
LOCK WASHER, 5/16 SS 6
BOLT, 1/4-20 X 1-3/4”,SS 88
LOCK WASHER, 1/4” SPLIT RING, SS 88
6-30LP11 PARTS & HARDWARE

ELEMENT #4 TO #11
12-18-08
DESCRIPTION QTY
SLEEVE, 1-5/8” X .058 X 56” 2
ELE 4 SEC 1A, 1-1/2” X .058 X 60” SOE ( 1/4 HOLE, TO FIT SELF) 2
ELE 4 SEC 2B, 1-1/2” X .058 X 60” SOE (TO EXCEPT 1 1/4) 2
ELE 5 SEC 1, 1-1/2” X .058 X 60” SOE (1/4 HOLE) 2
SLEEVE, 1-3/8” X .058 X 56” (1/4 HOLE) 4
SLEEVE, 1-3/8” X .058 X 55” (1/4 HOLE) 2
SLEEVE, 1-3/8” X .058 X 53” 2
ELE 6 SEC 1, 1-1/4” X .058 X 60” SOE (1/4”HOLE) 2
ELE 4 SEC 3, 1-1/4” X .058 X 60” SOE (2 HOLES ) 4
SLEEVE, 1-1/4” X .058 X 37” ( 3 HOLES) 2
SLEEVE, 1-1/8” X ,058 X 30” (1/4 HOLE) 2
SLEEVE, 1-1/8 X .058 X 30.00 (2 HOLES) 4
SLEEVE, 1-1/8 X .058 X 12” ( 1/4 HOLE) 2
ELE 11, SEC 1, 1” X .058 X 60.75” STR 2
ELE 7, SEC 1, 1” X .058 X 60” SOE, (1/4 HOLE ) 8
ELE 6, SEC 2, 1” X .058 X 60” SOE (2 HOLES ) 2
ELE 4, SEC 4, 1” X .058 X 39” SOE 4
SLEEVE, 7/8” X .058 X 15” 2
ELE 8, SEC 2, 3/4 X .049 X 63” STR 2
ELE 9, SEC 2, 3/4 X .049 X 39.25” STR 2
ELE 4, SEC 5, 3/4 X .049 X 39” SOE 8
ELE 10, SEC 2, 3/4 X .049 X 19.75” STR 2
ELE 7, SEC 3, 1/2 X .049 X 63” 2
ELE 4 SEC 6, 1/2 X .049 X 56” 4
ELE 6, SEC 4, 1/2 X .049 X 43” 2
FIBERGLASS ROD, 1-1/4” X 24” 2
FIBERGLASS ROD, 1” X 24” 1
FIBERGLASS ROD, 7/8 X 30” 5
POLY DISC INSULATOR, 1-1/4” ID. 4
POLY DISC INSULATOR, 1” ID. 2
POLY DISC INSULATOR, 7/8” ID. 10
PHASE LINE CLAMP, 1-1/2” 4
PHASE LINE CLAMP, 1-1/4” 2
PHASE LINE CLAMP, 1” 10
PHASE LINE CLAMP CAP, FOR 3/16” PHASE LINES 16
CRADLE, 1-1/4” HD (MACH. ALUM ) 8
CRADLE, 1” HD (MACH. ALUM) 4
CRADLE, 7/8” HD (MACH. ALUM) 20
3/8” CLAMP BLOCK (SINGLE 1/4 HOLE) 4
HARDWARE, NEXT PAGE
6-30LP11 PARTS & HARDWARE
