M2 Antenna Systems Eggbeater EB-310 User manual

M2 Antenna Systems, Inc. 4402 N. Selland Ave. Fresno, CA 93722
Tel: [phone] Fax: [phone] Web: www.m2inc.com
©2022 M2 Antenna Systems Incorporated 7/25/12
Rev.01
Model ........................................EB-310
Frequency Range.......................225 To 405 MHz
Gain, Overhead 90° ...................5.5 dBic Typical
Impedance .................................50 Ohms
VSWR ........................................< 2.0:1
Pattern........................................Omni Directional
Polarity .......................................RH Circular Overhead
Polarity .......................................Horizontal @ Horizon
Power Handling.......................... 1kW
Mounting .................................... To 3/8-24 Male Thread
Connector................................... “N” Female
Size ............................................ 20” H x 20” W
Wind Survival ............................. 100 MPH
Weight / Ship Wt. ....................... 4 Lbs. / 5 Lbs.
M2 Antenna Systems, Inc.
Model No: EB-310
Eggbeater Satellite Antenna
FEATURES:
The M2 EB-310 EGGBEATER antenna offers performance characteristics for specialized fixed and mobile
operations within the 225-405 MHz frequency. The EGGBEATER produces a smooth, horizontally polarized
omnidirectional pattern at the horizon. Above the horizon, the hemispheric pattern transforms to RIGHT HAND
CIRCULAR polarization, making it a natural for aviation, ELINT, MILSATCOM, or other specialized use. No rotation or
steering is required, producing instantaneous communications in all directions. The EGGBEATER’s rugged, weatherproof
construction suits mobile and marine applications as well as fixed, land based installations in hostile environments.
Operations with little room or budget for larger antennas will experience a new standard of performance with the EB-310.
SPECIFICATIONS:
Peak= 5.62 dBi Total Field
Circular Omni Antenna
ElevaƟon

EB-310
SHOWN WITH
OPTIONAL
RADIAL KIT
GENERAL INSTALLATION GUIDELINES:
1. If lightning is prevalent in your area, an Eggbeater used in
a fixed installation should have the case or mast grounded.
2. Feedline should be good quality RG-58 or RG-213 type 50
ohm coax cable. Belden 8214 or 9913 are excellent low-loss
foam types and RG-8X is also good. Connect the male "N" to the
Balun case connector and, if a mast is used, secure the cable to
the mast with tape or nylon ties, beginning 4-6 inches below the
connector and repeating every 12” down the mast. Be sure to
leave a little slack where the cable passes the spring.
3. The Eggbeater produces an omnidirectional, circularly
polarized pattern overhead and a linear polarized pattern at the
horizon.
This completes the assembly.
TOOLS: 7/16” & 9/16” open ended wrenches
MAY BE SHIPPED ASSEMBLED AT THE FACTORY’S DISCRETION
1. Unpack the two loop elements. Insert each loop through the crossed
holes of the insulator located at the top of the can assembly. Pull the
loops all the way through until the insulator lies at their midpoints.
2. Align the ends of the elements carefully with the four mounting
terminals on top of the can assembly case. Install the four screws with a
screwdriver and tighten.
3. (OPTIONAL) Locate the radial plate and six 1/4 x 12-3/8” radials.
Insert all six radials into the radial plate and tighten the six 8-32 x 1/4” set
screws.
4. Attach the mast bracket and radial assembly to the can assembly
using the supplied 3/8-24 x 1” bolt and lockwasher.
5. Lastly, assemble the 4 saddle clamps and attach them to the mounting
bracket.
MAST BRACKET
2" SADDLES (4)
2 x .125 x 72" STR 6061-T6
MAST
RADIAL PLATE
CAN ASSEMBLY
OPTIONAL GROUND PLANE
HARDWARE DETAIL
DESCRIPTION QTY
CAN ASSEMBLY .................................................... 1
LOOP ELEMENT, 3/8 TUBE................................... 2
SCREW, 10-32 X 3/4, SS .......................................4
SADDLE CLAMP, 2” ............................................... 4
MAST BRACKET, 4 x 4” ......................................... 1
ASSEMBLY MANUAL.............................................1
RADIAL KIT (OPTIONAL)
RADIAL, 1/4 x 12-3/8” AL ROD............................... 8
RADIAL PLATE, 1/2 x 2.5” HEX, AL .......................1
HARDWARE BAG
DESCRIPTION QTY
BOLT, 5/16-18 x 3”, SS .......................................... 4
5/16-18 LOCKNUT, SS .......................................... 4
BOLT, 3/8-24 X 1" SS............................................. 1
LOCKWASHER, 3/8” SS ........................................ 1
8-32 X 1/4" SETSCREW ........................................ 8
5/64 ALLEN WRENCH ........................................... 1
EB-310 PARTS LIST
4402 N. Selland Ave, Fresno CA 93722 [phone] FAX [phone]
http: www.m2inc.com Email: [email protected]
EB-310 ASSEMBLY MANUAL

Model ........................................ EB-310
Frequency Range ...................... 250 To 405 MHz
Usable Frequency Range.......... 225 To 405 MHz
Impedance................................. 50 OHMS
Gain ........................................... 5.5 dBic Typical,
Straight Overhead
VSWR........................................ < 2.0:1
Pattern. ...................................... Omni Directional
Polarity Horizontal @
Horizon & RH Circular
Overhead
Power Handling ......................... 1kW
Mounting.................................... To 3/8-24 Male
Thread
Connector .................................. “N” Female
Size............................................ 20” H x 20” W
Wind Survival............................. 100 MPH
Weight / Ship Wt........................ 4 Lbs. / 8 Lbs.
