M2M LOGIC io User manual

Technical Manual
Version 1.00
RTCU LX4 pro
Advanced Industrial M2M/IoT Gateway

RTCU LX4 pro Technical Manual V1.00
Advanced Industrial M2M/IoT Gateway
Logic IO ApS. Ph: ([phone]
Holmboes Allé 14 Fax: [phone]
8700 Horsens Page 2 of 39 Email: [e-mail]
Denmark www.logicio.com
Introduction
The RTCU LX4 pro is a powerful successor to the RTCU DX4i pro with significant improvements in
features, capacity, power, and security. In addition, the RTCU LX4 pro is based on the latest LX
hardware architecture, offering an unprecedented balance between price and performance.
The RTCU LX4 pro is positioned for a broad range of professional industrial Internet of Things
applications. With onboard M-Bus / Wireless M-Bus and pulse counting inputs (S0), it is a perfect
component in advanced Energy Management applications.
The device rests on the NX32L (NX32 for Linux) architecture that embraces many new technologies
and at the same time maintains full backward compatibility, which ensures already implemented and
tested NX32 applications can execute without changes.
The RTCU LX4 pro device has been designed to meet the ever-increasing security challenges. It offers
full TLS on all major protocols and includes a hardened protected execution environment with dual-
boot and automatic fallback and recovery.
The RTCU LX4 pro can also operate as a secure and intelligent industrial router/firewall for LAN side
clients connecting to the Internet over the cellular interface.
This manual contains technical documentation covering the installation and usage of the RTCU LX4
pro device. For detailed information on the product's programming and software configuration,
please refer to the RTCU IDE documentation.
For detailed information on the powerful RTCU M2M Platform, please refer to the
RTCU M2M Platform datasheet.

RTCU LX4 pro Technical Manual V1.00
Advanced Industrial M2M/IoT Gateway
Logic IO ApS. Ph: ([phone]
Holmboes Allé 14 Fax: [phone]
8700 Horsens Page 3 of 39 Email: [e-mail]
Denmark www.logicio.com
Table of contents
Introduction ......................................................................................................................................................................2
Important Information.....................................................................................................................................................4
Technical Highlights ........................................................................................................................................................5
RTCU LX4 pro Overview ................................................................................................................................................7
Signal Overview ....................................................................................................................................... 10
Mini USB-B Connector............................................................................................................................. 12
Ethernet / LAN.......................................................................................................................................... 12
Power Supply..................................................................................................................................................................12
Digital outputs ................................................................................................................................................................13
Digital Inputs / S0 inputs / Ignition Input...................................................................................................................14
S0 compliant inputs (IEC62053-31, Class A compatible).................................................................... 14
Analog Inputs .................................................................................................................................................................16
Analog Outputs ..............................................................................................................................................................17
RS232 port........................................................................................................................................................................18
RS485 Port........................................................................................................................................................................18
RS485 port 1............................................................................................................................................... 19
RS485 port 2............................................................................................................................................... 19
1-Wire bus .......................................................................................................................................................................19
Wired M-Bus ...................................................................................................................................................................20
Wireless M-Bus (optional).............................................................................................................................................20
User interface ..................................................................................................................................................................21
Graphical LCD display............................................................................................................................ 21
Keypad....................................................................................................................................................... 23
System Menu............................................................................................................................................. 23
LED Indicators ................................................................................................................................................................25
User LED A and B .................................................................................................................................... 25
System LED S1 and S2 ............................................................................................................................. 25
Switches ...........................................................................................................................................................................27
DIP-switch................................................................................................................................................. 27
System switch (RST)................................................................................................................................. 27
Rechargeable Li-Ion Backup Battery............................................................................................................................28
LTE Worldwide Cat. 4 Cellular Engine.......................................................................................................................29
SIM-Card .........................................................................................................................................................................29
Antennas..........................................................................................................................................................................29
Cellular Antenna ...................................................................................................................................... 29
Wireless M-Bus Antenna (optional) ...................................................................................................... 29
SD-CARD reader ............................................................................................................................................................30
Approved SD-CARDs.............................................................................................................................. 30
Product Identification Label with Barcode .................................................................................................................31
Power Consumption ......................................................................................................................................................32
Appendices......................................................................................................................................................................33
Appendix A –Device configuration guide........................................................................................... 33
Appendix B –Installing the SIM-Card.................................................................................................. 36
Appendix C - Open Source Disclaimer ................................................................................................. 37
RTCU LX4 pro Specifications .......................................................................................................................................38

RTCU LX4 pro Technical Manual V1.00
Advanced Industrial M2M/IoT Gateway
Logic IO ApS. Ph: ([phone]
Holmboes Allé 14 Fax: [phone]
8700 Horsens Page 4 of 39 Email: [e-mail]
Denmark www.logicio.com
Important Information
Thank you very much for using a product from Logic IO Aps. Our products are designed for
professional use, and therefore this manual assumes technical knowledge and practice working with
such products.
This documentation does not entail any guarantee on the part of Logic IO Aps with respect to
technical processes described in the manual or any product characteristics set out in the manual. We
do not accept any liability for any printing errors or other inaccuracies in the manual, unless it can be
proven, that we are aware of such errors or inaccuracies, or that we are unaware of these as a result of
gross negligence and Logic IO Aps has failed to eliminate these errors or inaccuracies for this reason.
This product is a complex and sensitive electronic product. Please act carefully and ensure
that only qualified personnel will handle and use the device. In the event of damage to the device
caused by failure to observe the information in this manual and on the device, Logic IO Aps shall not
be required to honor a warranty claim even during the warranty period and shall be exempted from
the statutory accident liability obligation. Any attempts to repair or modify the product also voids all
warranty claims. Do not open the product. There is no user-serviceable part inside.
Please contact Logic IO for any technical or commercial inquiries:
Logic IO Aps.
Holmboes Alle 14
8700 Horsens
Denmark
Phone: [phone]
Support: suppo[email protected]
URL: www.logicio.com

RTCU LX4 pro Technical Manual V1.00
Advanced Industrial M2M/IoT Gateway
Logic IO ApS. Ph: ([phone]
Holmboes Allé 14 Fax: [phone]
8700 Horsens Page 5 of 39 Email: [e-mail]
Denmark www.logicio.com
Technical Highlights
Platform:
➢Based on the RTCU M2M Platform.
➢NX32L (NX32 for Linux) execution architecture.
oRTCU IDE development tool.
oOperates under a full and highly optimized Linux variant.
oOpen and extendable with Platform SDK.
LX Hardware Core:
➢Cortex-A7 32-bit ARM processor operating at up to 1 GHz.
➢Cortex-M4 32-bit co-processor for advanced power management.
➢Hardware floating-point and DSP instructions.
➢128 MByte RAM.
➢512 MByte NAND Flash (system boot, persistent memory, and file-systems).
➢Real-time clock with a dedicated backup battery.
Security:
➢Embedded firewall.
➢Port forward and NAT services.
➢TLS/SSL support with full certificate management.
➢TLS/SSL supporting all significant TCP protocols, such as RCH, FTP, SMTP, MQTT, and sockets.
➢Hardware-assisted encryption/authentication: AES-128, AES-192, AES-256, DES, TripleDES, HASH,
RND and RSA signature.
Wireless Communication:
➢LTE Cat. 4 Worldwide Multi-Band Cellular Engine.
➢Internal SIM-card reader with support for eSIM.
➢Optional: Wireless M-Bus. EN 13757-4/7 OMS EU/CE.
Wired Communication:
➢100 Mbps Ethernet LAN interface.
➢Wired M-Bus interface with up to 20 slaves.
➢1-Wire bus for accessories such as ID-button reader, temperature sensors, etc.
➢1 x RS232 interface with handshake support.
➢2 x RS485 interface.
I/O Interfaces:
➢8 x digital inputs, up to 4 digital inputs configurable as IEC62053-31 CLASS A compliant.
➢8 x high-power solid-state digital outputs.
➢4 x analog inputs with 0..10 volt / 0..20 mA with 12 bit precision.
➢2 x analog outputs with 0..10 volt / 0..20 mA
➢Expandable I/O with standard Modbus modules.
Sensors:
➢Temperature sensor.

RTCU LX4 pro Technical Manual V1.00
Advanced Industrial M2M/IoT Gateway
Logic IO ApS. Ph: ([phone]
Holmboes Allé 14 Fax: [phone]
8700 Horsens Page 6 of 39 Email: [e-mail]
Denmark www.logicio.com
User Interaction:
➢Graphical 144x32 pixels display.
➢Keypad with 8 keys for sophisticated user interaction and control.
➢3 x bi-color, 1 x single color LED.
➢High-speed Mini-USB service-port connector.
Audio:
➢Fully digitized audio system.
➢Transfer, store, and play audio.
➢Digitized cellular audio.
➢DTMF support for Interactive Voice Response applications.
Storage:
➢Internal flash drive with up to 64 MByte capacity.
➢Persistent memory and circular datalogger.
➢Standard SD-Card reader.
Power and Battery:
➢Operating voltage from 8 to 36VDC.
➢On-board 2 Ah Li-Ion battery with intelligent charging.
Encapsulation:
➢Housed in an industry-standard M36 DIN compliant encapsulation.
➢Two-part pluggable connectors for easy installation and maintenance.
Regulatory Approvals:
➢Radio Equipment Directive, RED 2014/53/EU.
➢EMC Directive, 2014/30/EU.
➢2011/65/EU RoHS Directive.

RTCU LX4 pro Technical Manual V1.00
Advanced Industrial M2M/IoT Gateway
Logic IO ApS. Ph: ([phone]
Holmboes Allé 14 Fax: [phone]
8700 Horsens Page 7 of 39 Email: [e-mail]
Denmark www.logicio.com
RTCU LX4 pro Overview

RTCU LX4 pro Technical Manual V1.00
Advanced Industrial M2M/IoT Gateway
Logic IO ApS. Ph: ([phone]
Holmboes Allé 14 Fax: [phone]
8700 Horsens Page 8 of 39 Email: [e-mail]
Denmark www.logicio.com
The user interface can be found on the front and consists of a 144x32 easy-to-read graphical LCD, a
keypad with eight keys, four user-controlled LEDs, and three system LEDs.
The graphical LCD can show information to the user with both text and graphics fully supported. In
addition, the LCD also has icons for battery level/charging-in-progress and network status.
The keypad can let the user interact with the LX4 pro and access the system menu.
Front-side view
The pluggable screw terminals on the top and bottom sides of the LX4 pro are used to make
connections to external equipment.
All the connectors are available externally for easy access and maintenance.
The bottom side of the RTCU LX4 pro has connectors for the following communication interfaces:
Ethernet, 1-Wire, RS232, RS485 Port 1 and Port 2, and wired M-Bus. The analog inputs/outputs are
also found on this side.
Bottom-side view
Graphical LCD 144x32
Keypad
LEDs
Pin 5 . . . . . . . . . . . . . . Pin 26
Pin 27 . . . . . . . . . . . . . . Pin 49
Reset Button
Ethernet
Connector
Pin 5 . . . . . . . . . . . . . Pin 26
Screw
terminals
Screw
terminals

RTCU LX4 pro Technical Manual V1.00
Advanced Industrial M2M/IoT Gateway
Logic IO ApS. Ph: ([phone]
Holmboes Allé 14 Fax: [phone]
8700 Horsens Page 9 of 39 Email: [e-mail]
Denmark www.logicio.com
The top side of the RTCU LX4 pro has connectors for power, digital inputs, digital outputs, and an
SMA female connector for an external cellular antenna.
The SD-card reader, four DIP switches, and the mini-B USB connector used as a programming/service
interface are also found on this side.
Inside the encapsulation, the SIM card and various configuration/termination jumpers are located.
Pin 49 . . . . . . . . . . . . . . . . Pin 27
Cellular
Antenna
DIP 1-4
Mini USB-B
SD-Card

RTCU LX4 pro Technical Manual V1.00
Advanced Industrial M2M/IoT Gateway
Logic IO ApS. Ph: ([phone]
Holmboes Allé 14 Fax: [phone]
8700 Horsens Page 10 of 39 Email: [email protected]
Denmark www.logicio.com
Signal Overview
Ethernet
1
27
PGND
2
28
SUPP
P
3
29
SUPP
4
30
DOUT SUPP
SGND
5
31
DOUT1
1-Wire
6
32
DOUT2
1-Wire LED
7
33
DOUT3
SGND
8
34
DOUT4
RS485 RSA 1
9
35
DOUT5
RS485 RSB 1
10
36
DOUT6
SGND
11
37
DOUT7
RS485 RSA 2
12
38
DOUT8
RS485 RSB 2
13
39
DOUT GND
RS232 TXD
14
40
SGND
RS232 RDX
15
41
DIN1 / S0IN1
RS232 RTS
16
42
DIN2 / S0IN2
RS232 CTS
17
43
DIN3 / S0IN3
M-Bus +
18
44
DIN4 / S0IN4
M-Bus –
19
45
DIN5 / IGN
AOUT 1
20
46
DIN6
AOUT2
21
47
DIN7
AIN1
22
48
DIN8
AIN2
23
49
SGND
AIN3
24
50
Cellular
antenna
AIN4
25
51
AGND
26
52
Pin 5-26 overview
Pin
Name
Description
5
SGND
Signal ground
6
1-Wire
1-Wire bus for accessories such as ID-Button / temperature
sensor
7
1-Wire LED
1-Wire ID-Button LED
8
SGND
Signal ground
9
RSA 1
RS485 non-inverting signal for the RS485 port 1
10
RSB 1
RS485 inverting signal for the RS485 port 1
11
SGND
Signal ground
12
RSA 2
RS485 non-inverting signal for the RS485 port 2
