M3 SL10K Series User manual

1
User Manual
Version 2.0 © 2020

2
Cautions When Using This Manual
Thank you for purchasing M3 SL10K. This device provides high performance data collection and
mobile communications that meet industrial standards.
This user manual enables users to know the characteristics of M3 SL10K series and how to use it.
Caution
⚫ Please carefully read this manual before using the device to ensure safe and proper use,
as well as to prevent accidents that may occur when the device is used.
⚫ This manual is created based on current status. The details on this manual may be
changed without prior notice.
⚫ The descriptions of this manual are based on the device’s default settings.
⚫ Images and screenshots are described with the latest software version.
⚫ This manual is created under the assumption that the device has all options. For detailed
information on available options, contact the local distributor or refer to our Web site
(http://www.m3mobile.net).
⚫ M3 Mobile does not have any legal responsibility for any performance problem that may
occur when a user uses an application that is supplied by a third party.
⚫ M3 Mobile does not have any legal responsibility for any performance degradation or
compatibility problem that may occur because of the user’s mistake or negligence.
⚫ M3 Mobile does not have any legal responsibility for copyright or patent breach by the
user.
⚫ M3 Mobile can request all or part of the applications developed by a user or a third
party. The request is for the improvement of user environment or device performance.
⚫ Higher OS version may be released after you purchase the device with the existing OS. If
you want to receive information on the latest OS, please contact your local distributor.
⚫ This device can be operated in at least one Member State without infringing applicable
requirements on the use of radio spectrum.
⚫ This manual may include technical or editing errors.

3
Copyright
Copyright © 2019 M3 Mobile Co., Ltd.
This manual is protected under international copyright laws. No part of this manual may be
reproduced, distributed, translated, or transmitted in any form or by any means, electronic or
mechanical, including photocopying, recording, or storing in any information storage and retrieval
system, without the prior written permission of M3 Mobile.
Trademarks
⚫ M3 Mobile and M3 logos are registered as trademarks of M3 Mobile.
⚫ M3 SL10K is a registered trademark of M3 Mobile Co., Ltd.
⚫ Google, Android, Google Play, YouTube and other marks are Trademarks of Google LLC;
Oreo i s a t ra dem a rk o f M o n del ez I n t ern a t i o n a l , In c . gr o u p . A ll o t h er t ra dem a rk s a re t h e
property of their respective owners.
Instructional Icons
Before using this manual, please carefully read and understand the following icons:
Warning –Situations that may cause injury to yourself or others
Caution –Situations that may cause damage to your device or other
equipment
Note –Notes, usage tips, or additional information

4
Safety Rules
⚫ Do not use the device while driving.
✓ Traffic accidents mayoccur.
✓ Observe the rules on device use while driving.
⚫ Do not touch the power plug with wet hands.
✓ You may be electrocuted.
⚫ Be carefulwhen using the battery.
✓ Avoid causing a strong impact on the battery or breaking a hole through it with a sharp
thing.
✓ Do not put water on the battery or submerge it in water.
✓ Do not let the charging terminal of the battery come into contact with a metal material.
⚫ Keep the device, battery, or charger away from direct heat sources.
✓ Heat may cause the device to become deformed, or an explosion or fire may occur.
✓ If the device is placed inside a vehicle, the battery may explode due to increase in
temperature.
⚫ Do not use the device when there is thunder or lightning.
✓ Lightning or fire may cause the device to break down or you may be electrocuted.
⚫ Turn off power of the device when device use is prohibited.
✓ Hazardous or wave-related problem may occur.
✓ Turn off power of the device when you board a plane. The electromagnetic waves
generated from the device may affect the plane’s electronic equipment.
✓ Turn off power of the device when you are in a hospital. Observe the device rules while in a
hospital. The electromagnetic waves generated from the device may affect the medical
equipment in the hospital.
⚫ Turn off power of the device in hazardous areas where explosions may occur.
✓ Observethe regulations, instructions, or signs of a hazardous area where explosions may
occur.
✓ Turn off power of the device while refueling.

5
⚫ Be careful when a headset is used.
✓ Avoid long-term exposure to loud sounds to prevent damage to your hearing.
✓ Loud sounds while walking or driving distract your attention and may cause traffic
accidents.
Revision
Release date of version 1.0: July 2019
⚫ Initial distributio n
Release date of version 2.0: Feb. 2020
⚫ Update of Specificaion

6
Table of Contents
CautionsWhenUsingThisManual ............................................................................... 2
Caution ........................................................................................................ 2
Copyright ...................................................................................................... 3
Trademarks .................................................................................................... 3
Instructional Icons .............................................................................................. 3
Safety Rules ..................................................................................................... 4
Revision ......................................................................................................... 5
Table ofContents ................................................................................................. 6
1. GettingStarted ......................................................................................... 9
1.1 Package Contents ....................................................................................................... 9
1.1.1 Device and Accessories .............................................................................................. 9
1.2 Battery ......................................................................................................................... 10
1.2.1 How to Use .................................................................................................................. 10
1.2.2 Charging the Battery ................................................................................................. 11
1.3 Turning the Device On/Off ........................................................................................ 13
1.3.1 Turning the Device On ............................................................................................... 13
1.3.2 Turning the Device Off ............................................................................................... 14
1.3.3 Standby Mode............................................................................................................ 14
1.4 Memory Card ............................................................................................................. 15
1.4.1 Inserting an External Memory Card .......................................................................... 15
1.4.2 Checking Data........................................................................................................... 16
2. Basic Use ............................................................................................................................................. 18
2.1 Features....................................................................................................................... 18
2.2 Key............................................................................................................................... 19
2.2.1 Button .......................................................................................................................... 19
2.3 Home Screen.............................................................................................................. 19
2.3.1 Status Bar..................................................................................................................... 20
2.3.2 Notification Bar........................................................................................................... 20

7
2.3.3 Home Screen.............................................................................................................. 21
2.3.4 Dock Bar...................................................................................................................... 21
2.4 Data Input................................................................................................................... 22
2.4.1 Virtual Keyboard......................................................................................................... 22
2.5 Device Reset............................................................................................................... 22
2.5.1 Soft Reset (1)............................................................................................................... 22
2.5.2 Soft Reset (2)............................................................................................................... 23
2.6 Connecting with a PC ............................................................................................... 26
3. Using the Application Screen ............................................................................................................ 28
3.1 Phone Function .......................................................................................................... 28
3.1.1 Basics........................................................................................................................... 28
3.2 Wi-Fi ............................................................................................................................. 29
3.2.1 Setting the Wi-Fi Feature ............................................................................................ 29
3.3 Scanner....................................................................................................................... 30
3.3.1 How to Use Scanner................................................................................................... 30
3.3.2 Using the Scanner ...................................................................................................... 31
3.4 Bluetooth..................................................................................................................... 32
3.4.1 Setting the Bluetooth Feature ................................................................................... 32
3.4.2 Connecting Using Bluetooth ..................................................................................... 32
3.5 NFC.............................................................................................................................. 34
3.5.1 Setting the NFC Feature............................................................................................. 34
3.5.2 Connecting the NFC Feature.................................................................................... 35
4. Advanced Use .................................................................................................................................... 37
4.1 OS Update .................................................................................................................. 37
5. Others................................................................................................................................................... 39
5.1 SL10K-N Device Specifications .................................................................................. 39
5.2 SL10K-W Device Specifications ................................................................................. 40
5.3 Service......................................................................................................................... 41
5.4 Contacts ..................................................................................................................... 41

8

9
1. Getting Started
1.1 Package Contents
1.1.1 Device andAccessories
The M3 SL10K package includes the following items:
<M3 SL10K>
<Battery>
<Quick Manual >
<Adapter>
<USB Cable>
<BOOTS>
If one or more items above are damaged or are not included in the package, contact the
store where you purchased the device. (Only one package is provided to one device.)
※NOTE
For data synchronization, either Cradle or Snap-on can be provided depending on your
purchasing option.
If the device is used for purposes other than the original device use or if it is
remodeled, you may be exposed to electromagnetic waves.

10
1.2 Battery
1.2.1 How to Use
Inserting the Battery
⚫ Insert the battery from the bottom in the right direction.
⚫ After inserting the battery, slide the Slide button to the left to fix the locking device.
M3 SL10K uses 3.8 V 4,500mAh Li-ion Battery.
⚫If an unapproved battery is used, it may explode.
⚫When a battery is discarded, follow proper disposal procedure.
⚫Check if the battery is inserted in right direction.
Removing the Battery

11
If the battery is not properly removed, the battery terminal may become bent
or damaged.
Before the battery is removed, close any running program. If it is not closed, an
error may occur in the program.
Before the battery is removed, Save the data being used.
M3 SL10K can be used for up to 7 hours after the battery is fully charged.
(The maximum time of using device depends on usage environment of a
user.)
1.2.2 Charging the Battery
If the following battery warning screen is displayed, charge the battery.
If the device is continuously used without charging the battery, its power will be turned off.
Charging the Battery
⚫ Please connect the device to a cradle that you can additionally purchase to
charge the battery.
⚫ As pictures below, Charging begins when you set a device into the cradle.

12
AC adaptor is made to be used in 100–240V input, 5V 2A
output. If a voltage beyond the range is supplied, the device
may be seriously damaged.
LED Color
Description
Red
Battery is being charged.
Green
Battery is fully charged.
If the battery is used at the temperature other than -20oC (-4oF) to 50oC (122oF),
the device may malfunction or break down.
It takes about 4–5 hours to fully charge a battery that is fully discharged.
⚫It is recommended to replace a battery every two year.
⚫If a battery is charged and used continuously, its lifespan will decrease.
For information on the device battery, Swipe the bottom →Click Settings →Battery.

13
1.3 Turning the Device On/Off
1.3.1 Turning the DeviceOn
Press and hold Power button until the device vibrates. This will turn the device on and initial
screen will display.
If the battery is completely discharged, problems may occur when the device is
turned on. If a problem occurs, charge the battery before turning on the device
again.

14
1.3.2 Turning the DeviceOff
Press and hold the Power button for about one second to display the following pop-up screen.
Select the Power off menu to turn off the power.
1.3.3 Standby Mode
If the device is not used for a long time, M3 SL10K automatically shifts to standby mode to
decrease battery consumption. To manually set the device in standby mode, lightly press
the Power button. By default, if the device is not used for one minute or longer, it shifts to
standby mode. The time when the device shifts to standby mode can be set by the user.
Swipe the bottom → Click Settings → Display → Sleep to change time that the device will
shift to standby mode.
If the device stops its operation for a long time, press and hold the Power button
for about eight seconds to forcibly turn the device off.

15
1.4 Memory Card
1.4.1 Inserting an External Memory Card
The Micro-SD card is used as an external memory of M3 SL10K. After removing the battery, insert
SD memory card into the Micro-SD card slot.

16
To insert Micro-SD card, Remove battery cover on the rear of the device and pull out the battery.
1.4.2 Checking Data
Information stored in the Micro-SD card can be checked by swiping bottom →Click File
Manager →Storage
AndroidTM 8.1 OreoTM, the OS used in M3 SL10K, can support up to 64 GB
for external memory.

17
1.5 SIM Card
1.5.1 Inserting the SIM Card
SIM card supports voice call and data transfer through mobile communications. The card should
be the one verified by a local network supplier.
To insert SIM card, Remove battery cover on the rear of the device and pull out the battery. Either
the front or back of the SIM card can be connected to dual slot.
For more information on how to use the phone, please see phone section.

18
2. Basic Use
2.1 Features
Device Layout

19
2.2 Key
2.2.1 Button
Button
Description
Scanner
Operate scanner while executing scanner program.
Volume High
I n c rea se vo l u me .
Volume Low
Decrease volume.
Camera
Take pictures while executing camera program.
Back
Return to previousstage.
Home
Go to Home screen.
Menu
Display menu.
Function
Execute the work set to the button.
2.3 Home Screen
If the device is turned on, the following screen will be displayed. The screen is divided
into four sections as follows:
Notification Bar 
➔Status Bar
➔Home Screen
➔Dock Bar

20
2.3.1 Status Bar
The Status Bar displays status of the device.
Icon
Icon Name
Description
Battery
Battery charging status or battery residual capacity
Phone
Call strength or no signal
Sound / Vibration
Sound or Vibration status of the device
Wi-Fi
Wi-Fi connection/disconnection
Bluetooth
Bluetooth connection/disconnection
GPS
Status of searching the location data
Alarm
Alarm activation status
Flight Mode
Activation status of Flight mode
N O S I M
S I M c a rd i s not c o nn ec t ed
3G Network
3G network connectionstatus
2.3.2 Notification Bar
The Notification Bar displays device notifications.
Icon
Icon Name
Description
More
There are morenotifications.
Data Sync
Data is beingsynchronized.
Schedule
Displays the schedule.
Wi-Fi
Open Wi-Fi network can be used.
Music
Music is being played.
Data Sync
An error occurs when data is being synchronized.
Data Upload
Data is being uploaded.
