mabe MEI2570DVSB User manual

1
models
MEI2570DVSB
MEI3070DVSI
read this manual before installing your microwave oven
PM01
owner's manual
microwave oven

2

3
welcome
Everything you need to know for the proper operation of your
product can be found here and in our web sites. We invite you to
get to know your product, read this manual and get the most out of
it.
Please read these instructions carefully before installing and operat-
ing the oven.
Record in the space below the SERIAL NO. found on the nameplate
on your oven and retain this information for future reference.
SERIAL NO.
contents
Important Safety Instructions ........................................................................... 4
Precautions to avoid possible exposure to excessive microwave energy ........ 5
Before you call for service ................................................................................ 8
Installation ........................................................................................................ 8
Grounding instructions ..................................................................................... 9
Radio interference ............................................................................................ 9
Microwave cooking principles ........................................................................ 10
Utensils Guide ................................................................................................. 10
Part names (MEI3070) ..................................................................................... 11
Control panel (MEI3070) ................................................................................. 12
How to set the oven controls (MEI3070) ........................................................ 13
Setting the clock ............................................................................................. 13
Microwave cooking ......................................................................................... 13
Grill ................................................................................................................. 13
Combination cooking ..................................................................................... 14
Quick start ....................................................................................................... 14
Jet defrost ....................................................................................................... 14
Weight defrost ................................................................................................ 14
Multistage Cooking ........................................................................................ 15
Preset .............................................................................................................. 15
Child Lock ....................................................................................................... 15
Auto Cook ....................................................................................................... 16
Part names (MEI2570) ..................................................................................... 17
Control panel (MEI2570) ................................................................................. 18
How to set the oven controls (MEI2570) ........................................................ 19
Setting the clock ............................................................................................. 19
Microwave cooking ........................................................................................ 19
Grill ................................................................................................................. 19
Combination cooking ..................................................................................... 20
Preset .............................................................................................................. 20
Express Cooking .............................................................................................. 21
Jet defrost ....................................................................................................... 21
Weight defrost ................................................................................................ 21
Multistage Cooking ........................................................................................ 22
Child lock ........................................................................................................ 22
Care and cleaning ........................................................................................... 23
Rated electrical specifications ........................................................................ 24

4
important safety instructions
• Do not use extension cords.
• Do not plug other electric appliances to the same power outlet.
• Hold the connector by the power plug, not by the cord.
• This product is equipped with a "Y" type polarized plug having a
built-in grounding wire.
• Do not remove the grounding terminal or use outlet adapters.
• If the power cord is damaged, it must be replaced by the manufac-
turer, its authorized service agent or by qualified personnel in or-
der to avoid a hazard.
• If voltage variations are usual in your area, have a voltage regula-
tor installed.
• This appliance is not intended for use by persons (including chil-
dren) having reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given su-
pervision or instruction concerning the use of the appliance by a
person responsible for their safety.
• Children should be supervised to make sure they do not use the
appliance as a toy.
• IMPORTANT: Failure to follow these warnings, will make you en-
tirely responsible for personal injuries or material damages that
may occur from using this equipment.
The following conditions are not considered as a normal use of the
appliance:
• If it has not been operated in accordance with the provided opera-
tion instructions.
• Damages caused by accidents, electrical overloads, voltage fluctua-
tions, using an energy other than the specified, or catastrophes.
• If it has been used with commercial or industrial purposes, or for
other than the indicated in the operation instructions.
• If the product has been repaired by unauthorized persons and/or
service workshops.

5
precautions to avoid possible exposure
to excessive microwave energy
1. Do not attempt to operate this oven with the door open since
open door operation can result in harmful exposure to microwave
energy. It is important not to defeat or tamper with the safety in-
terlocks.
2. Do not place any object between the oven front face and the
door or allow soil or cleaner residue to accumulate on sealing sur-
faces.
3. Do not operate the oven if it is damaged. It is particularly impor-
tant that the oven door close properly and that there is no dam-
age to the
a. Door (bent),
b. Hinges and latches (broken or loosened),
c. Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by anyone except
properly qualified service personnel.
important safety instructions
When using electrical appliance basic safety precautions should be
followed, including the following:
• Read all instructions before using the appliance.
• Use this appliance only for its intended use as described in this
manual. Do not use corrosive chemicals or vapors in this appliance.
This type of oven is specifically designed to heat, cook or dry food.
It is not designed for industrial or laboratory use.
• Do not operate the oven when empty.
• Do not operate this appliance if it has a damaged cord or plug, if it
is not working properly or if it has been damaged or dropped.
• WARNING: Only allow children to use the oven without supervi-
sion when adequate instructions have been given so that the child
is able to use the oven in a safe way and understands the hazards
of improper use.
• WARNING: It is hazardous for anyone other than a trained person
to carry out any service or repair operation which involves the re-
moval of any cover which gives protection against exposure to mi-
crowave energy.
WARNING: TO REDUCE THE RISKS OF BURNS, ELEC-
TRIC SHOCK, FIRE, INJURY TO PERSONS OR EXPO-
SURE TO EXCESSIVE MICROWAVE ENERGY:

6
• To reduce the risk of fire in the oven cavity:
a. When heating food in plastic or paper container, keep an eye on
the oven due to the possibility of ignition.
b. Remove wire twist-ties from paper or plastic bags before placing
bag in oven.
c. If smoke is observed, switch off and unplug the appliance and
keep the door closed in order to stifle any flames.
d. Do not use the cavity for storage purposes. Do not leave paper
products, cooking utensils or food in the cavity when not in use.
• WARNING: Liquid or other food must not be heated in sealed con-
tainers since they are liable to explode.
• Microwave heating of beverage can result in delayed eruptive
boiling, therefore care has to be taken when handling the con-
tainer.
• Do not fry food in the oven. Hot oil can damage oven parts and
utensils and even result in skin burns.
• Eggs in their shell and whole hard-boiled eggs should not be
heated in microwave ovens since they may explode even after mi-
crowave heating has ended.
• Pierce foods with heavy skins such as potatoes, whole squashes,
apples and chestnuts before cooking.
• The contents of feeding bottles and baby jars should be stirred or
shaken and the temperature should be checked before serving in
order to avoid burns.
• Cooking utensils may become hot because of heat transferred
from the heated food. Potholders may be needed to handle the
utensil.
• Utensils should be checked to ensure that they are suitable for use
in microwave oven.
• WARNING: It is hazardous for anyone other than a trained person
to carry out any service or repair operation which involves the re-
moval of any cover which gives protection against exposure to mi-
crowave energy.
• This product is a Group 2 Class B ISM equipment. The definition of
Group 2 which contains all ISM (Industrial, Scientific and Medical)
equipment in which radio-frequency energy is intentionally gener-
ated and/or used in the form of electromagnetic radiation for the
treatment of material, and spark erosion equipment. For Class B
equipment is equipment suitable for use in domestic establish-
ments and in establishments directly connected to a low voltage
power supply network which supplies buildings used for domestic
purpose.
• The microwave oven should only be used freestanding.
• WARNING: Do not install oven over a range cooktop or other heat-
producing appliance. If installed, it could be damaged and the
warranty would be avoid.
• The accessible surface may be hot during operation.

7
• The microwave oven shall not be placed in a cabinet.
• The door or the outer surface may get hot when the appliance is
operating.
• The temperature of accessible surfaces may be high when the ap-
pliance is operating.
• The appliance shall be placed against a wall.
• WARNING: If the door or door seals are damaged, the oven must
not be operated until it has been repaired by a competent person.
• This microwave oven is not intended to be operated by means of
an external timer or separate remote-control system.
• The microwave oven is for household use only and not for com-
mercial use.
• Never remove the distance holder in the back or on the sides, as it
ensures a minimum distance from the wall for air circulation.
• Please secure the turntable before you move the appliance to
avoid damages.
• Caution: It is dangerous to repair or maintain the appliance by no
other than a specialist because under these circumstances the
cover have to be removed which assures protection against micro-
wave radiation. This applies to changing the power cord or the
lighting as well. Send the appliance in these cases to our service
centre.
• The microwave oven is intended for defrosting, cooking and
steaming food only.
• Use gloves if you remove any heated food.
• Caution! Steam will escape, when opening lids or wrapping foil.
• Cleaning and user maintenance shall not be made by children un-
less they are aged from 8 years and above and supervised.
• If smoke is emitted, switch off or unplug the appliance and keep
the door closed in order to stifle.

8
before you call for service
If the oven fails to operate:
1. Check to make sure that the oven is plugged in securely. If it is
not, remove the plug from the outlet, wait 10 seconds, and plug it
in again securely.
2. Check for a blown circuit fuse or a tripped main circuit breaker. If
these seem to be operating properly, test the outlet with another
appliance.
3. Check to make sure that the control panel is programmed cor-
rectly and the timer is set.
4. Check to make sure that the door is securely closed engaging the
door safety lock system. Otherwise, the microwave energy will not
flow into the oven.
IF NONE OF THE ABOVE RECTIFIES THE SITUATION, THEN CONTACT
A QUALIFIED TECHNICIAN. DO NOT TRY TO ADJUST OR REPAIR THE
OVEN YOURSELF.
installation
1. Make sure that all the packaging materials are removed from the
inside of the door.
2. WARNING: Check the oven for any damage, such as misaligned or
bent door, damaged door seals and sealing surface, broken or
loose door hinges and latches and dents inside the cavity or on
the door. If there is any damage, do not operate the oven and
contact qualified service personnel.
3. This microwave oven must be placed on a flat, stable surface to
hold its weight and the heaviest food likely to be cooked in the
oven.
4. Do not place the oven where heat, moisture, or high humidity are
generated, or near combustible materials.
5. For correct operation, the oven must have sufficient airflow. Al-
low 20 cm of space above the oven, 10 cm at back and 5 cm at
both sides. Do not cover or block any openings on the appliance.
Do not remove feet.
6. Do not operate the oven without glass tray, roller support, and
shaft in their proper positions.
7. Make sure that the power supply cord is undamaged and does
not run under the oven or over any hot or sharp surface.
8. The power plug must be readily accessible so that it can be easily
unplugged in an emergency.
9. Do not use the oven outdoors.

9
grounding instructions
This appliance must be grounded. This oven is equipped with a cord
having a grounding wire with a grounding plug. It must be plugged
into a wall receptacle that is properly installed and grounded. In the
event of an electrical short circuit, grounding reduces risk of electric
shock by providing an escape wire for the electric current.
It is recommended that a separate circuit serving only the oven be
provided. Using a high voltage is dangerous and may result in a fire
or other accident causing oven damage.
Notes:
• If you have any questions about the grounding or electrical in-
structions, consult a qualified electrician or service person.
• Neither the manufacturer nor the dealer can accept any liability
for damage to the oven or personal injury resulting from failure to
observe the electrical connection procedures.
WARNING: IMPROPER USE OF THE GROUNDING
PLUG CAN RESULT IN A RISK OF ELECTRIC SHOCK.
The wires in the main power cord are colored in accordance with
the following code:
• Green and Yellow: GROUND
• Blue: NEUTRAL
• Brown: LIVE
radio interference
Operation of the microwave oven can cause interference to your ra-
dio, TV, or similar equipment.
When there is interference, it may be reduced or eliminated by tak-
ing the following measures:
• Clean door and sealing surfaces of the oven.
• Reorient the receiving antenna of radio or television.
• Relocate the microwave oven with respect to the receiver.
• Move the microwave oven away from the receiver.
• Plug the microwave oven into a different outlet so that microwave
oven and receiver are on different branch circuits.

10
microwave cooking principles
• Arrange food carefully. Place thickest areas towards outside of
dish.
• Watch cooking time. Cook for the shortest amount of time indi-
cated in the recipe and add more as needed. Food severely over-
cooked can smoke or ignite.
• Cover foods while cooking. Covers prevent spattering and help
foods to cook evenly.
• Turn foods over once during microwaving to speed cooking such
as chicken and hamburgers. Large items like roasts must be turned
over at least once.
• Rearrange foods such as meatballs halfway through cooking both
from top to bottom and from the center of the dish to the outside.
utensils guide
• The ideal material for a microwave utensil is transparent to micro-
waves, it allows energy to pass through the container and heat the
food.
• Microwaves cannot penetrate metal, so metal utensils or dishes
with metallic trim should not be used.
• Do not use recycled paper products when microwave cooking, as
they may contain small metal fragments which may cause sparks
and/or fires.
• Round/oval dishes rather than square/oblong ones are recom-
mend, as food in corners tends to overcook.
• Narrow strips of aluminum foil may be used to prevent overcook-
ing of exposed areas. But be careful don’t use too much and keep
a distance of 1 inch (2,54 cm) between foil and cavity.
Heat–Resistant Glass
Non Heat–Resistant Glass
Heat–Resistant Ceramics
Microwave–Safe Plastic Dish
Kitchen Paper
Metal Tray
Metal Rack
Aluminum Foil & Foil Containers
The following list is a general guide to help you select the correct
utensils.
CombinationGrillMicrowaveCookware
Yes
No
Yes
Yes
Yes
No
No
No
Yes
No
Yes
No
No
Yes
Yes
Yes
Yes
No
Yes
No
No
No
No
No

11
part names (model MEI3070)
MEI3070DVSI
1. Door Safety Lock System
2. Oven Window
3. Turntable Support
4. Shaft
5. Door Release Button
6. Control Panel
7. Wave Guide
8. Glass Tray
9. Grill Heater
10. Metal Rack

12
control panel (model MEI3070)
• Menu action display
Cooking time, power, action indi-
cators, and clock time are dis-
played here.
• STOP
Touch to clear entry before set-
ting a cooking program Touch
once to temporarily stop cooking
or twice to cancel cooking. Touch
and hold to set child lock.
• START
Touch to start cooking program.
• QUICK START
Touch to start cooking or start
the oven quickly.
• WEIGHT DEFROST
Programmed defrosting based
on the weight of the foods to be
defrosted.
• JET DEFROST
Quick defrost function that alter-
nates defrost and stand times to
quickly and effectively defrost
foods.
• PRESET
Preset function allows you to put
food into the oven and program
it to start cooking at a later time.
• CLOCK
Touch to set the digital clock.
• MEMORY
Used for setting a multistage
cooking program.
• GRILL/COMBI
Press up to three times to choose
a cooking mode.
• POWER LEVEL
Used to set a microwave-cooking
power level.
• Quick cook pads
Instant settings to cook popular
foods.
• Number pads
Touch to set clock, cooking time,
or to enter food weight.

13
how to set the oven controls
(model MEI3070)
Each time a button is touched, a beep will sound to acknowledge
the touch.
setting the clock
The clock works in 12 or 24 hour format, you can select it by press-
ing CLOCK repeatedly.
For example, to set the time of 8:30
1. Touch CLOCK pad once or twice.
2. Touch number pads to set the clock time.
3. Touch CLOCK pad again to confirm.
Note: You can check the clock during cooking by touching the
CLOCK button.
By pressing the POWER LEVEL button repeatedly, you are selecting
one of the following microwave power levels:
microwave cooking
To cook using microwaves, time and power level should be set. The
longest cooking time that can be set touching the number pads is 99
min. 99 sec.
Suppose you want to cook for 5 minutes at 60% of microwave
power:
1. Touch POWER LEVEL button a number of times to set power
level.
2. Touch number pads to set cooking time.
3. Touch START button.
Press
Once
Twice
3 times
4 times
5 times
6 times
Power Level
100%
80%
60%
40%
20%
0%
Description
High
Medium High
Medium
Medium Low
Low
Zero
grill
Grill is particularly useful for thin slices of meat, steaks, chops, ke-
babs, sausages and chicken pieces. It is also suitable for hot sand-
wiches and "au gratin" dishes. The longest cooking time is 99 min,
99 sec.
Suppose you want to broil for 12 minutes.
1. Touch GRILL/COMBI button once.
2. Touch number pads to set cooking time.
3. Touch START button.

14
combination cooking
Combi 2
55% time for microwave cooking, 45% for grill cooking. Use for
puddings omelets, baked potatoes and poultry.
Suppose you want to set the oven to COMBI2 cooking for 25 min-
utes:
1. Touch GRILL/COMBI pad twice or 3 times.
2. Touch number pads to set cooking time.
3. Touch START pad.
Combi 1
The longest cooking time is 99 min. 99 sec.
35% time for microwave cooking, 65% for grill cooking.
Recommended for fish or "au gratin".
quick start
This feature allows you to start the oven quickly.
In standby mode, touch QUICK START in quick succession to set time
(each touch adds 30 seconds, up to 99 min. 59 sec.), the oven starts
cooking automatically at full power.
jet defrost
With Jet Defrost, you need to input defrosting time. The longest de-
frosting time is 99 min, 99 sec.
Suppose you want to set the oven to Jet Defrost for 5 minutes:
1. Touch JET DEFROST pad.
2. Touch number pads to enter defrosting time.
3. Touch START pad.
Note: During defrosting program, the system will sound to remind
you to turn over the food, press START to resume defrosting.
weight defrost
Use this feature to defrost meat, poultry, and seafood. Time and de-
frosting power level are automatically set once the food weight is
entered. The maximum defrosting weight is 1800 g.
Suppose you want to defrost 600 g of shrimp:
1. Place food to be defrosted into the oven.
2. Touch the WEIGHT DEFROST pad once.
3. Touch the WEIGHT DEFROST pad repeatedly to enter a weight of
600 g
4. Touch START pad.
Note: During defrosting, the system will sound to remind you to
turn over the food, press START to resume defrosting.

15
multistage cooking
The oven can be programmed to do several consecutive functions.
Suppose you want to set the following cooking program:
1. Microwave cooking;
2. Grill.
1. If necessary, touch STOP pad once to reset the oven.
2. Input Microwave cooking program.
3. Touch MEMORY pad.
4. Input Grill cooking program.
5. Touch START pad.
Note: Quick Start, Defrost and Auto Cook cannot be set in the mul-
tistage cooking program.
The respective lights will come on to indicate which stage the oven
is operating in. After total time has elapsed, beeps sound.
preset
Preset function allows the oven to start up at a later time. Suppose
now the clock running at 11:10 and you want the oven to start
cooking at 11:30.
1. Touch PRESET pad.
2. Use the number pads to enter the time 11:30 when it should
start.
3. Set a cooking program.
4. Touch START pad.
Note: Make sure that the food is placed into the oven in advance
before any cooking starts.
The preset time can be seen by touching PRESET pad, while the time
is displayed, you can press STOP pad to cancel the setting.
child lock
Use to prevent unsupervised operation of the oven by children. The
child lock indicator will show up on display screen, and the oven
cannot be operated while the Child Lock is set.
To set, in standby mode press and hold the STOP pad for 3 seconds,
a beep sounds and lock indicator lights.
To cancel, press and hold the STOP pad for 3 seconds until lock indi-
cator on display goes off.

16
auto cook
For food or the following cooking mode, it is not necessary to pro-
gram the duration and the cooking power. It is sufficient to indicate
the type of food that you wish to cook and the weight of this food.
For example, to cook a certain amount of potato:
1. Place potato in the oven.
2. Press POTATO a number of times to select weight.
3. Press START button.
autocook menu
Food Notes
• For beverage and dinner plate, pa-
rameters on screen are not weight
but number of servings.
• For some foods, oven will pause dur-
ing cooking to let you turn the food
over. Be careful to handle with the
very hot food in the oven. To resume
cooking, just close the door, the oven
will cook for the remaining time.
• Power fluctuation and other factors
may cause the auto cooking not done
exactly to your taste; the user may ad-
just cooking time accordingly.
Beverage (200 ml serving)
Dinner plate (unit)
Reheat (g)
Potato (g)
Pizza (g)
Fish (g)
Chicken (g)
Vegetable (g)
Beef (g)
Sausage (g)
Pork (g)

17
MEI2570DVSB
part names (model MEI2570)
1. Door Safety Lock System
2. Oven Window
3. Turntable Roller
4. Shaft
5. Door Release Pad
6. Control Panel
7. Wave Guide
8. Glass Turntable
9. Grill Heater
10. Metal Rack

18
control panel (model MEI2570)
• Display
Cooking time, power, indicators and
present time are displayed.
(Also see following pages for
more detail.)
• STOP
Touch once to stop cooking tempo-
rarily and twice to cancel the cook-
ing program altogether.
• START/5 Sec. Delay
After finishing setting a cooking pro-
gram, touch the pad once to start
the program after 5 seconds later.
While cooking program stop tempo-
rarily, touch once to start the pro-
gram at the moment.
• WEIGHT DEFROST
Touch to set defrost program based
on the weight entered.
• JET DEFROST
Touch to set defrost program based
on the time entered.
• EXPRESS
Use this feature to program the oven
for 4 popular microwave timings at
HIGH power.
• PRESET
Use to set the oven to start-up at a
later time.
• CLOCK
Use to set the oven clock.
• COMBI 1&COMBI 2
Touch to set combination cooking
program combined with microwave
and grill.
• GRILL
Touch to set grill cooking program.
• +30 Sec.
During cooking process, touch once
to add 30 seconds of cooking time.
• MEMORY
When setting multistage cooking
program, touch the pad to enter set-
ting.
• POWER LEVEL
Use to set microwave power level. To
check power level during cooking,
touch POWER LEVEL pad.
• Number pads
10 Min. 1000 g 1 Min. 100 g 10 Sec.
10 g 1 Sec. 1 g Touch to input time
or weight of food.

19
how to set the oven controls
(model MEI2570)
setting the clock
Suppose you want to set the clock at 8:30
Steps:
1. Touch CLOCK pad once.
2. Touch "10 Sec" pad 3 times and "1 Min" pad 8 times.
3. Touch CLOCK pad once again to confirm the setting.
Note: This is a 12-hour clock. You can check the clock time while
cooking is in progress by touching the CLOCK pad once.
add cooking time
During cooking (except WEIGHT DEFROST), touch +30 SEC pad re-
peatedly to add cooking time. The longest cooking time that can be
set is 99 minutes and 59 seconds.
grill
The longest cooking time is 99 minutes and 99 seconds.
Suppose you want to grill for 10 minutes:
1. Touch GRILL pad.
2. Touch number pads to enter the desired cooking time 10:00.
3. Touch the START/5 Sec Delay pad.
setting microwave cooking
The longest cooking time is 99 minutes and 99 seconds. During
cooking, the power level can be seen by pressing EXPRESS pad.
Suppose you want to cook food for 20 minutes with 80% power.
2. Touch number pads to enter the desired cooking time 20:00 for
this example.
3. Touch START/5Sec. Delay pad once, the cooking program starts 5
seconds later.
Touch POWER LEVEL pad
Once
Twice
3 times
4 times
5 times
6 times
1. Touch POWER LEVEL pad to set P8.
Cooking power
100% (P-100)
80% (P-80)
60% (P-60)
40% (P-40)
20% (P-20)
0% (P-00)

20
combination cooking
The longest cooking time is 99 minutes and 99 seconds.
COMBI 2
55% time for microwave cooking, 45% time for grill cooking.
Suppose you want to set the oven to cook with COMBINATION 2 for
25 minutes:
1. Touch COMBI 2 pad once.
2. Touch number pads to enter your desired cooking time 25:00
3. Touch START/5 Sec Delay pad.
COMBI 1
30% time for microwave cooking, 70% time for grill cooking. Use
for fish or au gratin.
Suppose you want to set the oven to cook with COMBI 1 for 12 min-
utes:
1. Touch COMBI 1 once.
2. Touch number pads to enter your desired cooking time 12:00
3. Touch START/5 Sec Delay once to start.
preset
This function allows the oven to start a cooking program (except ex-
press cooking) at an appointed time automatically.
Suppose you want the oven to cook with microwave 100% power
for 30 minutes starting at 11:30
1. Set your desired cooking programs.
2. Touch PRESET pad.
3. Touch number pads to input desired starting time 11:30
4. Touch START/5 Sec Delay pad.
Notes:
• Be sure the microwave oven clock is set at the correct time be-
fore programming PRESET function.
• After setting, the preset time can be seen by touching PRESET
pad.
• Press the STOP pad if you want to cancel the setting.
