mabe CLME71214BAT User manual

234D1334P021
read this instruction manual before installing your washer-dryer
model:
CLME71214BAT
owners manual

3important safety information
read all instructions before using the
appliance
warning: To reduce the risk of death, re, explosion, electric
shock, or injury to persons when using your appliance, follow basic
precautions, including the following:
• DONOT wash or dry articles that have been previously cleaned in,
washed in, soaked in or spotted with gasoline, dry-cleaning solvents,
or other ammable or explosive substances, as they give off vapors
that could ignite or explode.
• DO NOT place items exposed to cooking oils in your dryer. Items
contaminated with cooking oils may contribute to a chemical
reaction that could cause a load to catch re. To reduce the risk of re
due to contaminated loads, the nal part of the tumble dryer cycle
occurs without heat (cool down period). Avoid stopping a tumble
dryer before the end of the drying cycle unless all items are quickly
removed and spread out so that the heat is dissipated.
• DONOTadd gasoline, dry-cleaning solvents, or other ammable or
explosive substances to the wash water. These substances give off
vapors that could ignite or explode.
• Under certain conditions, hydrogen gas may be produced in a hot-
water system that has not been used for 2 weeks or more. HYDROGEN
GAS IS EXPLOSIVE. If the hot water system has not been used for
such a period, before using a washing machine, turn on all hot-water
faucets and let the water ow from each for several minutes. This will
release any accumulated hydrogen gas. As the gas is ammable, DO
NOTsmoke or use an open ame during this time.
• DO NOT allow children to play on or in this appliance. Close
supervision of children is necessary when this appliance is used near
children. Before the appliance is removed from service or discarded,
remove the door and lid to the drying and washing compartments.
Failuretofollowtheseinstructionsmayresultindeathorinjuryto
persons.
• DO NOT reach into the appliance if the drum, tub or agitator is
moving to prevent accidental entanglement.
• DO NOT dry articles containing foam rubber or similarly textured
rubber-like materials.
• Clean lint screen before or after each load.
• DONOToperate the dryer without the lint lter in place.
• Follow all fabric care instructions and warnings to prevent melting of
garments or damage to the appliance.
• DO NOT use fabric softeners or products to eliminate static unless
recommended by the manufacturer of the fabric softener or product.
• DO NOT store combustible materials, gasoline or other ammable
liquids near the dryer. Keep area around the exhaust opening and

4
adjacent surrounding areas free from the accumulation of lint, dust
and dirt.
• The interior of the appliance and exhaust duct should be cleaned
periodically by qualied service personnel.
• DONOTinstall or store the appliance where it will be exposed to the
weather.
• DONOTtamper with controls.
• DONOTrepair or replace any part of this appliance or attempt any
servicing unless specically recommended
• in the user maintenance instructions or in published user repair
instructions that you understand and have the skills to carry out.
• DO NOT operate this appliance if it is damaged, malfunctioning,
partially disassembled, or has missing or broken parts including a
damaged cord or plug.
• Unplug the appliance or turn off the circuit breaker before servicing.
Pressing Power or Start/Pause button DOESNOTdisconnect power.
• DONOTspray any type of aerosol into, on or near appliance, at any
time. DO NOT use any type of spray cleaner when cleaning dryer
interior. Hazardous fumes or electrical shock could occur.
• DONOTstore items that may burn or melt (such as clothing, paper
material, plastics or plastic containers, etc.) on top of the appliance
nor hang them from the door.
• DONOTclimb on or stand on this unit.
• See “electrical connection information” located in the Installation
Instructions for grounding instructions.
readandsavetheseinstructions.
additional washer safety
start-up sequence
• Any time the washer is being started or restarts after the washer lid
has been opened and closed, the washer will turn on the cold water
valve for two short periods followed by a 10 second pause before
continuing. If the lid is opened during this period, the washer will
pause. You will have to push the Start button again to restart the
cycle.
automatic drain sequence
• Machine will automatically drain any time the lid is left open for
more than 15 minutes and water is present.
• Machine will automatically drain if left in a paused state with the lid
closed for more than 24 hours and water is present.

5when not in use
• Turn off water faucets to minimize leakage if a break or rupture
should occur. Check the condition of the ll hoses; mabe recommends
changing the hoses every 5 years.
additional gas dryer warnings
warning - re or explosion hazard
Failuretofollowsafetywarningsexactlycouldresultinseriousinjury,
death,orpropertydamage.
- DONOT store or use gasoline or other ammable vapors and liquids in
the vicinity of this or any other appliance.
- whattodoifyousmellgas:
• DONOT try to light any appliance.
• DONOTtouch any electrical switch; DO NOT use any phone in your
building.
• Clear the room, building, or area of any occupants.
• Immediately call your gas supplier from a neighbor’s phone. Follow
the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the re department.
- Installation and service must be performed by a qualied installer,
service agency, or the gas supplier.
read and save these instructions.

6
getting started - washer
warning - Toreducetheriskofre,electricshock,or
injurytopersons,read the important safety warning
information beforeoperatingthisappliance.
Throughout this manual, features and appearance may vary from your
model.
• Loosely add items.
Overloading may negatively
impact wash performance.
See section: sorting wash
loads.
• Add detergent
step 2
step 3 step 4
step 1
• Turn the washer cycles
knob to “wake up” the washer
before each use. The LED lights
will turn on when the washer is
awake and ready to use.
• Select desired wash cycle.
• Select additional settings.
• Close lid.
• Press the Start button.
•
Add fabric softener (optional)
•
Add bleach (optional).
Colors
Heavy
Medium Bulky Items
Casuals
Heavy
Delicates
Light Drain & Spin
Medium
Normal Speed Wash
Light
WASHER CYCLES
Whites
E
DCBG
A
Colors
Heavy
Medium
Heavy
Casuals
Light
Speed
Drain
& Spin
Wash
Bulky
Items
Medium
Delicates
Light
Off
Whites
Normal
FDCBG
A
Colors
Heavy
Medium Bulk
y Items
Casuals
Heavy
Delicates
Light Dr
ain & Spin
Medium
Speed Wash
Light
Whites
Start
Paus e
Normal
Wash Rinse
Spin
Lid Locked
Deep Rinse
Select when usingFabric Softener
Tap Cold
Cold
Cool
Colors
Warm
Hot
DCB GA
Colors
Heavy
Medium Bulky
Items
Casuals
Heavy
Delicate s
Light Dr
ain & Spin
Medium
Speed Wash
Light
Whites
Start
Paus e
Normal
Wash Rins e
Spin
Lid Locked
Deep Rinse
Select when usingFabric Softe ner
Tap Cold
Cold
Cool
Colors
Warm
Hot
Liquid
Bleach
Fabric Softener Detergent

7The panel may vary from
one model to another.
• Loosely add items.
Overloading may negatively
impact wash performance.
See section: sorting wash
loads.
• Add detergent
step 2
step 3 step 4
step 1
• Turn the washer cycles
knob to “wake up” the washer
before each use. The LED lights
will turn on when the washer is
awake and ready to use.
• Select desired wash cycle.
• Select additional settings.
• Close lid.
• Press the Start button.
• Add fabric softener (optional)
• Add bleach (optional).
Colors
Heavy
Medium Bulky Items
Casuals
Heavy
Delicates
Light Drain & Spin
Medium
Normal Speed Wash
Light
WASHER CYCLES
Whites
E
DCBG
A
Colors
Heavy
Medium
Heavy
Casuals
Light
Speed
Drain
& Spin
Wash
Bulky
Items
Medium
Delicates
Light
Off
Whites
Normal
FDCBG
A
Colors
Heavy
Medium Bulky Items
Casuals
Heavy
Delicates
Light Drain & Spin
Medium Speed Wash
Light
Whites
Start
Pause
Normal
Wash Rinse Spin
Lid Locked
Deep Rinse
Select when usingFabricSoftener
Tap Cold
Cold
Cool
Colors
Warm
Hot
DCB GA
Colors
Heavy
Medium Bulky Items
Casuals
Heavy
Delicate s
Light Drain & Spin
Medium Speed Wash
Light
Whites
Start
Pause
Normal
Wash Rins e Spin
Lid Locked
Deep Rinse
Select when usingFabric Softener
Tap Cold
Cold
Cool
Colors
Warm
Hot
Liquid
Bleach
Fabric Softener Detergent
note:This appliance is designed so that the washer and dryer can be
operated at the same time.

8
getting started - washer
lid locked
Your washer has a security system that prevents opening the lid during
the spin cycle. The lid lock prevents anyone (especially children) from
reaching into the washer while the basket is spinning. The lid lock will
release within 5 seconds after the basket stops spinning.
Trying to open the lid while locked could result in injuries. If the lid does
not unlock after spinning, please contact service.
note: If there is a power outage the lid lock can take 3 minutes to release.
washer cycles
The washer cycle controls the type of washing process. The cycle selector
knob can be turned in either direction.
Turning the knob after starting a cycle will stop the washer and change
the cycle to the new selection. Press Start to begin the new cycle selection.
The chart in the next page will help you match the items to be washed
with the best washer cycle settings. For optimal performance, select the
cycle that most closely matches the items being washed. Selections shown
in bold are the recommended settings for that cycle.
off - Washer is turned off and the Start button does not function.
note: When the control is turned to Off, the Status lights are off.
note: The cycle selector does not rotate during the operation of the
washer.

9
items to wash cycle wash temp cycle details
Cycle for
normal, regular,
or typical use
for washing
up to a full load
of normally
soiled cotton
clothing.
Colors
Medium/
Normal
Hot
Warm
Colors
Cool
Cold
Tap Cold
Use colors medium/ normal
cycle for normal, regular, or typical
use for washing up to a full load
of normally soiled cotton clothing.
Choose the Warm or Hot water
temperature selection as appro-
priate for your clothes load for a
higher degree of cleaning. Incor-
porates multi-stage lls and wash
periods to provide optimal fabric
care.
Whites and
household
linens
Whites Hot
Warm
Colors
Cool
Cold
Tap Cold
Cycle tailored to clean and
brighten your whites.
Large coats, bed
spreads,
mattress covers,
sleeping bags,
and similar
large bulky
items
Bulky
Items
Hot
Warm
Colors
Cool
Cold
Tap Cold
Provides a max ll wash water
level to wash bulky items. Also
incorporates a deep ll rinse to
effectively rinse bulky items.
Casual clothes,
lightly ofce
wear.
Casuals Hot
Warm
Colors
Cool
Cold
Tap Cold
Wash cycle tailored to care for
casual clothes and ofce wear items.
Incorporates multi-stage lls and
wash periods to provide optimal
fabric care.
Lingerie and
special care
fabrics with
light soil.
Delicates Hot
Warm
Colors
Cool
Cold
Tap Cold
Utilizes a gentle agitate prole and
a low spin speed to provide special
care to delicate fabrics. It is
recommended to place small or
ultra delicate items in mesh bags
before washing.
Small loads of
lightly soiled
items that are
needed
in a hurry
Speed
Wash
Hot
Warm
Colors
Cool
Cold
Tap Cold
Utilizes an expedited wash cycle
and time-saving continuous spray
rinse to clean small lightly soiled
loads in the fastest time possible
Wet load of
items. For items
that need only
to be rinsed, use
this cycle with
2nd Rinse option
(on some models).
Drain &
Spin
Utilizes a high speed spin to extract
water from wet items. For items
that need to be rinsed, select the
2nd Rinse option (on some models)
when using this cycle.

10
deep rinse
Set this option when adding fabric softener to the washer.
status lights
Thestatus lights show the stage the washer is in. When the selector knob
is set to a new cycle, thestatus lights will ash momentarily, showing
the stages the cycle will go through.
note: If thestatus lights are blinking, the operation of the washer has
been paused. To resume operation press the start button (the lid must
be closed).
temperature
Select the water temperature for the washer cycle (all rinses use cold
water). Always follow fabric manufacturer’s care label or instructions
when laundering.
tapcold* uses incoming tap water, which can provide energy savings.
For all other temperature selections, a mixture of hot and cold water
is used to achieve the ideal temperature for each temperature setting.
* Please note that some detergents do not fully dissolve in very cold
water. If you experience this, it is recommended you choose a setting
other than tapcold.
load size (on some models)
Loosely load clothes no higher than the top row of
holes in the washer basket.
precisell - This selection automatically provides
the correct amount of water suited to the size and
type of load placed in the unit.
If you prefer to manually select the water level,
select Small through Super. While Precise Fill is best for most loads and
general washing, you may want to manually select the load size for
specialty items such as bulky, lightweight comforters or pillows, where
you want to ensure a larger water level is applied. Manual load size
selections should be made for wet items placed in the washer, such as
soaked towels or garments.
status light illuminates
on When the fabric softener option has been selected.
wash When the washer is in the wash portion of the cycle.
rinse When the washer is in the rinse portion of the cycle.
spin When the washer is draining and/or spinning.
lid locked
When the washer lid is locked. This feature prevents
the lid from being opened while the washer is in
the spin cycle or coasting to a stop.

11
options (on some models)
Pre-Soak15mins.-This option begins with a
brief agitation, soaks for this specied period of
time, then moves through the rest of the cycle
automatically.
2nd Rinse - When you use extra detergent or
bleach to clean heavily soiled clothes, use the
2nd Rinse option to better remove additional
residues.
Pre-Soak+2ndRinse- Turns both options on.
Off- Turns these options off.
start
Pressstartto begin the cycle. With the lid closed pressing start again
will pause the cycle andstatus lights will blink.
To continue the cycle, close the lid and press startagain. The water ll
will continue with the lid opened, except when precisell (on some
models) is selected as the load size. The lid must be closed to continue
lling when precisell(on some models) is selected.
If the lid is opened during the cycle, the cycle will pause and the status
lights will blink. To resume the cycle, close the lid and press start.
If the machine is paused for more than 24 hours, the cycle will be
cancelled. To stop the cycle, turn the Cycle Selector to the Off position.
note: Machine will automatically cancel and drain when water is present
and the lid is left open for 15 minutes or the unit is left in a paused state
for 24 hours with the lid closed. Select cycle and press start to begin
new cycle.

12
consumer help indicator
Your washer is equipped with ConsumerHelpIndicator(CHI). CHI is our
way to communicate a simple remedy for some situations that you can
perform without the need to call for service. The chart below describes
the helpful lights you may notice ashing on the display.
spin and rinse
lights blinking
wash and rinse
lights blinking
(Water not
entering washer)
lid locked light
Check your house water supply. Did you forget
to turn on one or both supply valves after
installation or coming back from vacation? As
soon as the lights start to ash, the washer will
initiate a 4 minute lockout period. The washer
controls won’t respond/change during this time.
After the 4 minutes, you can begin your cycle
again. If you try to bypass the lock-out period by
unplugging the washer, the 4 minute timer will
start over again.
lidlocked light will ash if 3 cycles have been
started without opening the lid. The washer will
not start another cycle until the lid is opened.
Try opening, then closing the lid and starting a
new cycle.
If an out-of-balance condition is detected by
the washer, the spin and rinse lights will blink
during the remaining portion of the cycle and
will stay illuminated for a short time after cycle
completion. When this occurs, the washer is
taking actions to correct the out-of-balance
condition and complete the cycle normally.
In some cases, the washer may not be able to
balance the load and spin up to full speed.
If you notice the load is more wet than normal at
the end of the cycle, redistribute the load evenly
in the wash basket and run a drain&spin cycle.

13
fabric softener dispenser (on models with an agitator)
Thefabricsoftenerdispenser automatically releases liquid fabric softener
at the proper time during the cycle. Donotstopthewasherduringthe
rstspin.Thiswillcausethedispensertoemptytoosoon.
To use, follow these steps:
Make sure dispenser is securely attached to agitator.
Use only diluted liquid fabric softener. Pour
into dispenser, using amount recommended
on package.
Never pour fabric softener directly on
clothes.Itmaystainthem.
note: Do not pour bleach into the fabric
softener dispenser.
Add water to dispenser until it reaches
the maximum ll line.
Select deeprinse
button on control panel
for proper dispersion of
the fabric softener.
fabric softener dispenser (on models with an infusor)
Select deeprinse button on control panel.
Add diluted liquid fabric softener during the rinse cycle or use a
fabric softener ball.
liquid bleach funnel
The water ll dilutes liquid chlorine bleach as the washer lls for the
washer cycle.
Check clothing care labels for special instructions.
Measure liquid bleach carefully, following instructions on the bottle.
• Never pour undiluted liquid chlorine bleach directly onto clothes
or into the wash basket.
• Do not pour powdered bleach into bleach funnel.

14
Before starting the washer, pour measured
amount of bleach directly into bleach funnel.
Avoid splashing or over-lling dispenser. If
you prefer to use powdered bleach, add it
into the wash basket with your detergent.
• Do not mix chlorine bleach with an oxi
pre-treatment, ammonia or acids such as
vinegar and/or rust remover. Mixing can
produce a toxic gas which may cause death.
note: Do not pour bleach into fabricsoftener dispenser.
sorting wash loads
Alwaysfollowfabricmanufacturer’scarelabelwhenlaundering.
Sort by color (whites, lights, colors), soil level, fabric type (sturdy cottons,
easy care, delicates) and whether the fabric produces lint (terry cloth,
chenille) or collects lint (velveteen, corduroy). Wash lint producers such as
cotton towels and socks separate from lint collectors including synthetic
garments and dress pants.
do not wash fabrics soiled with ammable liquids or cleaning
solvents. No washer can completely remove oil.
do not wash or dry anything that has been soaked in or spotted
with any type of oil (including cooking oils).
do not reach into the washer until all moving parts have stopped.
Doing so can result in death, explosion, re or amputation.
warning - re hazard
average small load average medium load average large load
water
level
clothes water
level
clothes
water
level
clothes
average small load average medium load average large load
water
level
clothes water
level
clothes
water
level
clothes
Load clothes
around outside
of infusor - not
over it.
loading the washer (on models with an agitator)
Load dry items loosely, no higher than the top row of holes in the washer
basket. When loading wet items, make sure you set the load/water level
high enough to allow the items to move freely. To add items after washer
has started, press start/pause. Lift the lid and submerge additional items
next to the agitator. Close the lid and press start to resume.
• Do not wrap long items like sheets or pants around the agitator.
• Do not wash fabrics containing ammable materials (waxes, clean-
ing uids, etc.).
• Agitation will not start with the lid up.
do not wash fabrics soiled with ammable liquids or cleaning
solvents. No washer can completely remove oil.
do not wash or dry anything that has been soaked in or spotted
with any type of oil (including cooking oils).
do not reach into the washer until all moving parts have stopped.
Doing so can result in death, explosion, re or amputation.
warning - re hazard
average small load average medium load average large load
water
level
clothes water
level
clothes
water
level
clothes
average small load average medium load average large load
water
level
clothes water
level
clothes
water
level
clothes
Load clothes
around outside
of infusor - not
over it.

15
do not wash fabrics soiled with ammable liquids or cleaning
solvents. No washer can completely remove oil.
do not wash or dry anything that has been soaked in or spotted
with any type of oil (including cooking oils).
do not reach into the washer until all moving parts have stopped.
Doing so can result in death, explosion, re or amputation.
warning - re hazard
average small load average medium load average large load
water
level
clothes water
level
clothes
water
level
clothes
average small load average medium load average large load
water
level
clothes water
level
clothes
water
level
clothes
Load clothes
around outside
of infusor - not
over it.
loading the washer (on models with an infusor)
Load dry items loosely in the washer basket. For best results, load items
evenly and loosely around the outside of the basket, lling in towards
the center on larger loads.
To add items after washer has started, press start/pause. Lift the lid and
submerge additional items around the outside of the basket. Close the
lid and press Start to resume.
• Do not place large items such as sheets, blankets and towels across
the Infusor. Load them around the outside of the basket.
• Do not wash fabrics containing ammable
materials (waxes, cleaning uids, etc.).
• Wash action will not start with the lid up
proper use of detergent
Using too little or too much detergent is a common cause of laundry
problems.
Use less detergent if you have soft water, a smaller load or a lightly
soiled load.
For spots, apply pre-treatment to items as recommended on the product
label. Application should be made in the basket to prevent overspray
which may cause the coloring on the lid or graphics to fade.
Place detergent packets in the bottom of the wash basket before adding
clothes.
We recommend the use of High Efciency detergents such as
in your energy efcient washer.
HE detergents are formulated to work with low water wash and rinse
systems. HE detergents reduce the oversudsing problems commonly
associated with regular detergents.
When using high efciency or concentrated detergents, consult the
product label to determine amount required for optimum performance.
Excessive detergent will negatively impact wash performance.

16
care and cleaning - washer
exterior of the washer
Immediately wipe off any spills with a damp cloth.
interior of the washer
Leave the lid open after washing to allow moisture to evaporate. If you
want to clean the basket, use a clean soft cloth dampened with liquid
detergent; then rinse. (Do not use harsh or gritty cleaners.)
cleaning the fabric softener dispenser (on some models)
Remove the dispenser from the top of
the agitator.
Separate the dispenser cup from the cover
by grasping the top and pushing down on
the inside of the cup with your ngers.
Dispenser cup will pop free from the cover.
To clean the dispenser, soak both the
dispenser cup and the dispenser cover in
the following solution:
• 1 US gallon (3.8 liters) warm water
• 1/4 cup (60 ml) heavy-duty liquid
detergent
• 1 cup (240 ml) bleach
If necessary, loosen buildup with a clean, soft cloth after soaking. Do
not use a stiff brush; you may roughen the surface of the dispenser.
Rinse and reassemble dispenser. Place dispenser back on the agitator.
water supply hoses
Hoses connecting washer to faucet should be replaced every 5 years.
moving and storage
Ask the service technician to remove water from drain pump and hoses.
Do not store the washer where it will be exposed to the weather.
long vacations
Be sure water supply is shut off at faucets. Drain all water from hoses
and water lter pump area if weather will be below freezing.

17 getting started - dryer
warning To reduce the risk of re, electric shock, or
injurytopersons,read the important safety warning
information beforeoperatingthisappliance.
· Keep ammable materials and vapors, such as gasoline, away from dryer.
· do not dry anything that has ever had anything ammable on
it (even after washing).
· No washer can completely remove oil.
· do not dry anything that has ever had any type of oil on it
(including cooking oils).
· Items containing foam, rubber, or plastic must be dried on a clothesline.
· Failure to do so can result in death, explosion, or re.
warning - re hazard
Throughout this manual, features and appearance may vary from your
model.
important: cleanthelintltereachtimeyouusethedryer.
note: This appliance is designed so that the washer and dryer can be
operated at the same time.
step 1
• Loosely add items.
• Close door.
note: Dryer will not
start with door open.
step 2
• Select a dry
cycle.
for models without e-dry:
fabric care/temperature
cottons (high heat) For regular to heavy cottons.
easy care (med heat) For synthetics, blends, delicates and
items labeled permanent press.
delicates (low heat) For delicates, synthetics and items
labeled tumble dry low.
quick uff (no heat) For ufng items without heat.
Use the Timed Dry cycle.
timed cycle
timed dry For manual drying.
A
B
dryer cycles
cottons For cottons and most linens. For most loads,
select Optimum dry.
easy care For wrinkle-free, permanent press an
d
delicate items, and knits.
delicates
For delicate items, special-care fabrics and
knits. It is recommended to put small or
ultra-delicate items in mesh bags.
timed dry Set the Cycle Selector at the desired
drying time.
30 min. (damp dry) For leaving items partially damp.
dewrinkle (20 min.) For removing wrinkles from items that are
clean and dry or that are very lightly damp.
quick uff (10 min.)
For freshening or ufng up already dry
clothing, fabrics, linens and pillows.
Provides 10 minutes of no heat tumbling.
A
B
step 3
• Press the
Start button.

18
step 1
• Loosely add items.
• Close door.
note: Dryer will not
start with door open.
step 2
• Select a dry
cycle.
for models without e-dry:
fabric care/temperature
cottons (high heat) For regular to heavy cottons.
easy care (med heat) For synthetics, blends, delicates and
items labeled permanent press.
delicates (low heat) For delicates, synthetics and items
labeled tumble dry low.
quick uff (no heat) For ufng items without heat.
Use the Timed Dry cycle.
timed cycle
timed dry For manual drying.
A
B
dryer cycles
cottons For cottons and most linens. For most loads,
select Optimum dry.
easy care For wrinkle-free, permanent press and
delicate items, and knits.
delicates
For delicate items, special-care fabrics and
knits. It is recommended to put small or
ultra-delicate items in mesh bags.
timed dry Set the Cycle Selector at the desired
drying time.
30 min. (damp dry) For leaving items partially damp.
dewrinkle (20 min.) For removing wrinkles from items that are
clean and dry or that are very lightly damp.
quick uff (10 min.)
For freshening or ufng up already dry
clothing, fabrics, linens and pillows.
Provides 10 minutes of no heat tumbling.
A
B
step 3
• Press the
Start button.
Automatic cycles determine fabric dryness and provide automatic
sensored drying. The timer does not rotate during the cycle until the
thermostats sense that the clothes are dry, then the timer rotates
automatically to off.
Select lessdry if you want your clothes slightly damp at the end of
the drying cycle.
Select moredry if you want them to feel drier. timeddrycycle runs
for a selected time.
start - Close the dryer door. Press start. Opening the door during
operation will stop the dryer. To restart the dryer, close the door
and select start to complete the cycle. A chime will sound at the
end of the dry cycle.

19
time cycle
time dry For manual drying.
A
step
1
• Loosely add items.
• Close door.
note: Dryer will not start with door open.
step 3
• Select
Temperature
if using Time Dry.
step 2
• Select a dry
cycle.
dryer cycles
cottons For cottons and most linens. For most
loads, select medium dry/normal
casuals For wrinkle-free, permanent press and
delicate items, and knits.
delicates
For delicate items, special-care fabrics and
knits. It is recommended to put small or
ultra-delicate items in mesh bags.
time dry
Set the Cycle Selector at the desired drying time.
30 min. (damp dry) For leaving items partially damp.
20 min.
(dewrinkle)
For removing wrinkles from items that are
clean and dry or that are very lightly damp.
10 min.
(quick uff)
For freshening or ufng up already dry
clothing, fabrics, linens and pillows.
Provides 10 minutes of no heat tumbling.
for models with E-Dry:
step 5
• Press Start
button.
step 4
• Press E-Dry
(optional)
Cottons Time Dry
Casuals
Delicates
Temperature
Time Dry Only
E-Dry
Start
Paus e
temperature (fabric care) - for use with time dry
settings only
regular (cottons) For regular to heavy cottons.
medium (casuals) For synthetics, blends, delicates and items
labeled permanent press.
low (delicates) For delicates, synthetics and items labeled
tumble dry low.
no heat (quick uff) For ufng items without heat.
Use the Timed Dry cycle.
B
C
Temperature is automatically set according to fabric type and is
not adjustable:
Regular heat = Cottons; Medium heat = Casuals ;Low heat = Delicates
Use Time Dry with Temperature set to Medium to dry bulky items
such as bedspreads and comforters.
A
BDC
Cottons
Normal
Medium
Regular
Low
No Heat
Temperature
Time Dry Only
Damp DryingCooling
E-Dry
More Dry
Less Dry
80 Min.
60
40
30
Damp
Dry
20
Dewrinkle
10 Min.
More Dry
Less Dry
MediumDry
Time Dry
More Dry
Less Dry
Casuals
Delicates
Start
Paus e
time cycle
time dry For manual drying.
A
step 1
• Loosely add items.
• Close door.
note: Dryer will not start with door open.
step 3
• Select
Temperature
if using Time Dry.
step 2
• Select a dry
cycle.
dryer cycles
cottons For cottons and most linens. For most
loads, select medium dry/normal
casuals For wrinkle-free, permanent press and
delicate items, and knits.
delicates
For delicate items, special-care fabrics and
knits. It is recommended to put small or
ultra-delicate items in mesh bags.
time dry
Set the Cycle Selector at the desired drying time
.
30 min. (damp dry) For leaving items partially damp.
20 min.
(dewrinkle)
For removing wrinkles from items that are
clean and dry or that are very lightly damp.
10 min.
(quick uff)
For freshening or ufng up already dry
clothing, fabrics, linens and pillows.
Provides 10 minutes of no heat tumbling.
for models with E-Dry:
step 5
• Press Start
button.
step 4
• Press E-Dry
(optional)
Cottons Time Dry
Casuals
Delicates
Temperature
Time Dry Only
E-Dry
Start
Paus e
temperature (fabric care) - for use with time dry
settings only
regular (cottons) For regular to heavy cottons.
medium (casuals) For synthetics, blends, delicates and items
labeled permanent press.
low (delicates) For delicates, synthetics and items labeled
tumble dry low.
no heat (quick uff) For ufng items without heat.
Use the Timed Dry cycle.
B
C
Temperature is automatically set according to fabric type and is
not adjustable:
Regular heat = Cottons; Medium heat = Casuals ;Low heat = Delicates
Use Time Dry with Temperature set to Medium to dry bulky items
such as bedspreads and comforters.
A
BDC
Cottons
Normal
Medium
Regular
Low
No Heat
Temperature
Time Dry Only
Damp DryingCooling
E-Dry
More Dry
Less Dry
80 Min.
60
40
30
Damp
Dry
20
Dewrinkle
10 Min.
More Dry
Less Dry
MediumDry
Time Dry
More Dry
Less Dry
Casuals
Delicates
Start
Paus e
important: Clean the lint lter each time you use the dryer.
note: This appliance is designed so that the washer and dryer can be
operated at the same time.

20
time cycle
time dry For manual drying.
A
step 1
• Loosely add items.
• Close door.
note: Dryer will not start with door open.
step 3
• Select
Temperature
if using Time Dry.
step 2
• Select a dry
cycle.
dryer cycles
cottons For cottons and most linens. For most
loads, select medium dry/normal
casuals For wrinkle-free, permanent press and
delicate items, and knits.
delicates
For delicate items, special-care fabrics and
knits. It is recommended to put small or
ultra-delicate items in mesh bags.
time dry
Set the Cycle Selector at the desired drying time.
30 min. (damp dry) For leaving items partially damp.
20 min.
(dewrinkle)
For removing wrinkles from items that are
clean and dry or that are very lightly damp.
10 min.
(quick uff)
For freshening or ufng up already dry
clothing, fabrics, linens and pillows.
Provides 10 minutes of no heat tumbling.
for models with E-Dry:
step 5
• Press Start
button.
step 4
• Press E-Dry
(optional)
Cottons Time Dry
Casuals
Delicates
Temperature
Time Dry Only
E-Dry
Start
Paus e
temperature (fabric care) - for use with time dry
settings only
regular (cottons) For regular to heavy cottons.
medium (casuals) For synthetics, blends, delicates and items
labeled permanent press.
low (delicates) For delicates, synthetics and items labeled
tumble dry low.
no heat (quick uff) For ufng items without heat.
Use the Timed Dry cycle.
B
C
Temperature is automatically set according to fabric type and is
not adjustable:
Regular heat = Cottons; Medium heat = Casuals;Low heat = Delicates
Use Time Dry with Temperature set to Medium to dry bulky items
such as bedspreads and comforters.
A
BDC
Cottons
Normal
Medium
Regular
Low
No Heat
Temperature
Time Dry Only
Damp DryingCooling
E-Dry
More Dry
Less Dry
80 Min.
60
40
30
Damp
Dry
20
Dewrinkle
10 Min.
More Dry
Less Dry
MediumDry
Time Dry
More Dry
Less Dry
Casuals
Delicates
Start
Paus e
Automatic cycles determine fabric dryness and provide automatic
sensored drying. The timer does not rotate during the cycle until the
thermostats sense that the clothes are dry, then the timer rotates
automatically to off.
Selectlessdry if you want your clothes slightly damp at the end of
the drying cycle.
Select moredryif you want them to feel drier. timedry cycle runs
for a selected time.
e-dry
Reduces total energy consumption on automatic cycles by adjusting
certain heat settings. The E-Dryselection can be used with Cottons
only.
note: CycletimewillchangewhenE-Dryisselected.
