Machineart MudSling R nineT T User manual

For R nineT Standard Models Only
WARNING AND DISCLAIMER: All parts manufactured, designed or sold by Machineart Moto (“MaMo”) should be installed by a qualified motorcycle technician. The
risk of injury is increased by improper installation or misuse of equipment. MaMo’s customers must exercise good judgment in the use, control, alteration, part
selection and installation, and maintenance of their motorcycles. In the event of a possible defect in material or design, or any other defect in a part manufactured,
designed or sold by MaMo, the responsibility of MaMo is limited to a refund of the purchase price or the replacement of the part if MaMo determines the part to be
defective, and subject to MaMo’s inspection of the part within thirty (30) days from the date of purchase. (Note: any attempted repairs or modifications made to
MaMo products will void this limited warranty). MaMo, under no circumstances will be responsible for incidental and/or consequential damages, property damage,
personal injury damage, or damage, injury, cost or expense of any kind or nature whatsoever except as provided by law. MaMo makes no other warranty, express or
implied, including without limitation any warranties of merchantability and fitness for a particular purpose.
[e-mail]
908. 652. 6779
Installation Guide
MudSling R nineT
TM
*NOTE: Instructions differ between
the standard R nineT & it’s variants.
*Mudsling fits the following
R nineT models:
R NINE T Standard
Begin installation at Step 1
PURE
SCRAMBLER
URBAN G/S
RACER
Begin installation at Step 3
Additional Tools required for
R9T Standard Models:
2mm Allen Wrench/Key
T-25 Torx Drive Socket and Ratchet Wrench
Tools required:
10mm Open End Wrench
T-25 Torx Driver
Parts:
1 - MudSling R nineT
4 - Washers
2 - M5 x25mm Torx Screw
2 - M5 x10mm Torx Screw
2 - M5 Stand-Off
*Before beginning work, read these
instructions from start to finish.
*On level ground, place bike on side
stand or on center stand.
*MudSling can be installed without
removing the rear wheel.
MudSling WILL FIT models with this
version of the charcoal cannister.
MudSling WILL NOT FIT models with
this version of the charcoal cannister.
Note: Some customers remove their charcoal cannisters. Removal may violate emissions requirements,
void the warranty, or even cause a fire or explosion, especially if not done by a qualified technician.
P1
Washer
Washer
M5 x 10mm
Torx Screw
M5 Stand-Off
M5 x 25mm
Torx Screw

2
1
5
3 4
6
Remove the four screws indicated using a T-25 torx driver,
These screws will not be re-used.
Bring MudSling into position. Position MudSling forward and low,
then lift to align its mounting holes with the Stand-offs and rear
mounting holes.
Add a washer to each M5 Torx head screw. Insert an M5 x10 screw
through the MudSling & into each stand-off, and an M5 x 25 screw
through the rear holes of the MudSling into the frame threads. Tighten
all screws with a T25 Torx driver.
R nineT standard models only:
Remove the pre-load adjustment knob. To break the grip of lock-tite, use
of a Ratchet Wrench with a T25 Torx driver may be required. Hold knob
securely to prevent it from turning while screw is being removed.
Using a 2mm hex tool, loosen the set screw indicated.
Note: Be careful not to strip the screw. If there is any concern about
handling this Step, contact a qualified BMW motorcycle technician.
R nineT standard models only:
Rotate the shock so the knob shaft faces the right hand side of the
motorcycle. Using a 2mm hex tool, re-tighten the set screw.
Proceed with Step 3
Install the stand offs into the two forward most mounting locations.
Tighten using a 10mm wrench.
Begin with Step 1 for R nine T standard.
Begin with Step 3 for R nine T Pure, Scrambler, Urban GS and Racer.
P2
