Operation Manual

MacroAir AirLynk

Modbus/BACnet

Table of Contents

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

1

Introduction

Network Installation

Wiring Diagrams

Configuration and Operation

Appendices

Caution & Safety .........................................2

Fan Network Ordering,

Modbus/BACnet Nomenclature .................3

AirLynk Enclosure,

AirLynk Components .................................4

Network Wiring Instructions .......................5

Repeater Install for 370 Fans ......................6

Network Wiring Requirements,

Daisy Chain ..................................................7

Improper Wiring Configuration,

Proper Wiring Configuration .......................8

Excess Cable at Connection Point ...............9

Wiring: CAT5E Pin-Out,

Repeater (370 Fans) ............................ 10

PLC ....................................................... 11

A Quick Start Guide:

PLC Startup .......................................... 12

Fan Setup ............................................. 13

BACnet MSTP Setup ............................ 14

BACnet IP Setup ................................... 15

Certifications ............................................. 16

Introduction, BACnet Setup ...................... 17

Interfacing PLC to Devices ........................ 18

............................ 20

Appendix A: Modbus + BACnet Control

Points ....................................................... 21

Appendix B: Warranty ............................. 27

Technical Support .................................... 28

Introduction

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

2

Caution and Safety

ATTENTION: Safety. READ THE ENTIRE MANUAL BEFORE OPERATING THE FAN. Ensure that

all safety practices and instructions are followed during the installation, operation and servicing

of the fan. Failure to apply these safety practices could result in death or serious injury. If you do

not understand the instructions, please call our Technical Department for guidance.

ATTENTION: Qualified Technicians. All fan controls and incoming power should only be

installed by qualified technicians familiar with the requirements of the National Electrical Code

(NEC) and local codes. Refer to appropriate portions of this manual for other important

ATTENTION: Code Compliance. Installation is to be in accordance with the NEC, ANDSI/NFPA

70-1999 and local codes.

Hazard of Electrical Shock, Explosion or Arc Flash:

ATTENTION: Read. Read and understand this manual before installing or operating a fan unit.

Installation, adjustment, repair, and maintenance must be performed by qualified personnel.

ATTENTION: Code Compliance. The user is responsible for compliance with all international

and National Electrical Code requirements with respect to grounding of all equipment.

WARNING: Do Not Touch. Many of the parts of this unit operate at line voltage. DO NOT

TOUCH.

WARNING: Covers. Install all covers before applying power or starting and stopping the unit.

Installation and Service

WARNING: Damage. Do not operate or install any fans or fan accessories that appear to be

damaged.

WARNING: Death and Injury. Failure to follow this instruction can result in death, serious

injury, or equipment damage.

WARNING: Disconnect Power. If the fan does not operate properly using the procedures in

this manual. BE CERTAIN TO REMOVE ALL POWER TO THE UNIT and contact our technical

department for further assistance.

CAUTION: Moving Parts. Keep all body parts clear of moving parts at all times.

ATTENTION: Qualified Technicians. All electrical troubleshooting and repair must be done by

a qualified technician and meet all applicable codes.

REFER TO FAN INSTALLATION MANUAL(S) FOR FURTHER MAINTENANCE INFORMATION.

Introduction

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

3

Fan Network Ordering

It is important to purchase fans that are setup for a network. MacroAir customizes fans to

operate in a network by:

Addressing the fans.

Providing bean crimps for T-splices (AVD 370).

Supplying an additional 15ft [4.57m] piece of CAT5e (AVD 370).

Modifying the panel enclosure (AVD3, 550, 780, Y and X Series Fans).

Modifying the wiring on the VFD (AVD3, 550, 780, Y and X Series Fans).

Note: If you did not order your fans for a network, please contact Technical Support for

assistance with networking your fans. Also, when installing new fans in an existing mixed

network, contact Technical Support.

Note: For 370 Fans, Repeaters/Isolators must be added every 5 fans for stability. (Page 6)

*If you did not order your fans for a network by default, they will all have a default Node

Address, and you will be missing necessary materials. Contact technical support to modify your

fans when installing for networking.

Modbus/BACnet Nomenclature

ATTENTION: For purposes of this manual the following shall be true:

It shall be recognized that where this manual indicates BACnet it shall be recognized as

Modbus/BACnet .

It shall be recognized that where this manual indicates BACnet IP it shall also be

recognized as Modbus TCP/IP .

It shall be recognized that where this manual indicates BACnet MSTP it shall also be

recognized as Modbus RTU .

Introduction

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

4

AirLynk Enclosure

Dimensions

Components

5Network Installation

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

Network Wiring Instructions

Refer to the appropriate fan installation manual for specific networking instructions.

Fan AVD 370

AVD3, 550, 780, Y and X Series Fans

6Network Installation

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

Repeater Install for AVD 370 Fans

Repeater/Isolator

The Repeater/Isolator boosts the sign

minimizes noise on the line.

Repeaters/Isolators should be evenly placed in the network. Make sure there is at least one

Repeater/Isolator every 5 fans.

7Network Installation

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

Network Wiring Requirements

Use Stranded Twisted Pair, CAT5e (or higher grade) shielded cable

Minimum 24 AWG (0.5mm) cross section

Route wires as far away as possible from high voltage AC cables, fluorescent lights, arc

welders, and other equipment that transmits EMI (electromagnetic interference).

For AVD 370 Fans:

Ground the shielding and drain wire at only one point of the cable run

Add Repeaters/Isolators (1/5fans)

Daisy Chain

Networked MacroAir fans must be connected in one single line, referred to in this document as a

The characteristics of a proper daisy chain are: one beginning (AirLynk) and one

end (last fan).

If the fans are not connected in one line/chain, there will be a de-graduation of the

communication signal and the network may not function as intended (fans in the network may

not operate).

- Control Panel

VFD MC

- Motor Control Cable (supplied with Fan by MacroAir)

8Network Installation

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

Improper Wiring Configuration

End of Line x3 End of Line x8

Proper Wiring Configuration

ONE End of Line

9Network Installation

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

Excess Cable at Connection Point

With noise being emitted throughout a typical industrial/commercial environment, extra cable

should not be coiled up as the coil itself will create noise/interference in the communication

signal. There should be no more than two feet of excess cable at each connection point.

If more than two feet of cable is needed for future relocation of the fan, run the cable up toward

the ceiling and back down in a horseshoe shape.

ALWAYS AVOID SHARP BENDS OF THE CABLE.

10 Wiring Diagrams

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

Wiring: CAT5E Pin-Out

CAT5E-B to MacroAir Equipment Pin-Out

Note: For Fire Alarm assignment, networks with X Series fans and mixed fan networks which

have one or more X Series Fans, use the blue & white/blue pair.

Wiring: Repeater (AVD 370 Fan)

11 Wiring Diagrams

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

Wiring: Airlynk

12 Configuration and Operation

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

A Quick Start Guide

PLC STARTUP

Basic navigation around the PLC display

1. Use the up , down , left , and right

arrows to navigate through the options on the screen.

2. Press OK to select the currently highlighted option

(takes you to another screen or allows you to edit the

selected value).

3. If the option is editable you will then be able to edit it using the up and down arrows. To

get to the next digit press the left or right arrows. When you are done editing, press OK

to set the value.

NOTE: The fans will be auto discovered each time the PLC is powered on. Setting the fans

through the web browser will ensure that the PLC knows there is a fan at that address.

Main Page 1 and 2

13 Configuration and Operation

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

A Quick Start Guide, cont.

Fan Setup (Optional)

1. Select .

2. Check each fan that is on the network

(See Fig. 1 Fan Values Table) to ensure

that the PLC found all the fans.

Fig. 1: Fan Values Table

3. Return to .

4. Optional: Set blade sizes (diameter) for each fan on the network (can be done through

BACnet).

5. Run all fans to ensure fan functionality

# Fan Type

0 No Fan

1 AVD-3

2 AVD 550

3 AVD 780

4 AVD 370

5 Y Series

6 AVD S

7 X Series

30

Local Override

14 Configuration and Operation

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

A Quick Start Guide, cont.

BACnet MSTP setup

1. Use the up

2.

3. tin various settings needed to operate the fans

through BACnet MSTP

Proto - Protocol (BACn for BACnet MSTP)

Modb Modbus RTU

Baud - Baudrate of the protocol

Addr - Address of the PLC

Data - Data bit number

Pari - Parity (Nul-None, Odd, Eve-Even)

Stop - Stop bit

Dev ID - ID that is displayed on BACnet end

Subnet - Subnet that the device is on

15 Configuration and Operation

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

A Quick Start Guide, cont.

BACnet IP setup

Note: If MSTP is set to BACn, BACnet IP will not work.

1. Use the up and down arrows on the right to navigate to

ecting

2.

3. settings needed to operate the fans through

BACnet IP

IP - IP address

Net MSK - Net Mask

Port - BACnet/IP port (0= port 47808)

DHCP - Enabled/Disable DHCP

(1) Enabled, (0) Disable

Gate - Default Gateway

DNS1/2 - DNS server

MAC address of device

ETH - TCP/IP Port number

FTP - FTP Port number (0=port 21)

HTTP - HTTP port number (0=port 80)

16 Configuration and Operation

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

Certifications

BTL Mark BACNET TESTING LABORATORY

The BTL Mark on PLC is a symbol that indicates that a

product has passed a series of rigorous tests conducted by an

independent laboratory which verifies that the product

correctly implements the BACnet features claimed in the

listing. The mark is a symbol of a high-quality BACnet product.

Go to http://www.BACnetInternational.net/blt/ for more

information about the BACnet Testing Laboratory. Click here

for BACnet PIC Statement.

17 Configuration and Operation

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

Introduction

1. PLC Gateway

Auto-Discovery (Every Power-up): Supported RS-485 devices can be automatically detected

and identified for addition to the PLC

Web Configurator (Retains through Power Cycle): For RS-485 devices that are not supported

by Auto-Discovery, use the embedded tool, which is accessed with a browser, referred to in

this manual as the Web Configurator. Select the device(s) from a drop-down list of known

profiles and assign at the stated Modbus address.

Manual Calibration

2. Blade Sizes and Motor Calibration

Blade sizes and a motor calibration must be done manually on all AVD3, 550, 780, and X

Series fans.

Blade Size: Use the fan control points AV 121-150 (pg. 25) to set the blade size.

8-24 for 6-Blade fans.

308-324 for 3-Blade fans.

Motor Calibration: Use fan control points AV 151-158 (pg. 26) to perform a motor

calibration on the fans.

BACnet Setup

3. Configuring Device Communications

Set Modbus RTU Node-ID for each of the devices attached to the PLC.

Set Modbus Node-ID for each of the devices attached to PLC. The Modbus Node-

need to be uniquely assigned between 1 and 30.

- The Modbus Node-ID that is assigned for each device needs to be documented.

The Modbus Node-ID ating the Device Instance

for BACnet/IP and BACnet MS/TP

The Modbus TCP/IP Node-ID will be set to the same value as the Node-ID of the

Modbus RTU device.

18 Configuration and Operation

AirLynk Modbus/BACnet Operation Manual 90-30054-00 Rev A-01 Date: 032720

Interfacing PLC To Devices

4. Fan Connections to PLC (CN1)

Device Pins PLC Pin # Pin Assignment

CN1

Pin RS-485 + Pin1 RS-485-2 +

Pin RS-485 - Pin 2 RS-485-2 -

Pin GND Pin 3 RS-485-2 GS

Figure 3: Power and RS-485 Connections (ref pg. 11)

5. Wiring Field Port to a BACnet MSTP BMS (CN19)

BMS RS-485

Wiring

PLC Pin # Pin Assignment

CN19

RS-485 + Pin 1 RS-485-1 +

RS-485 - Pin 2 RS-485-1 -

- Pin 3 RS-485-1 GS

Figure 4: Connection from PLC to RS-485 Field Network

(ref pg. 11)

MacroAir Technologies AirLynk User manual

Popular Control Unit manuals by other brands
