Mad4One PUSH-N2 Installation instructions

1
This procedure is valid for
both types of pedals,
PUSH-N2 and MadPro-
015.
But first we have to
understand, which is the
RIGHT pedal and which is
the LEFT one.
How to mount the pedals
PUSH-N2 and MAD-PRO-015
1
PUSH-N2
MadPro-015

How to mount the pedals
PUSH-N2 and MAD-PRO-015
2
PUSH-N2
Here is the difference
between the left and right
pedal of the PUSH-N2.
MadPro-015
Here is the difference
between the left and right
pedal of the MadPro-015.
The groove on the left
pedal axis (red arrow)
indicates which pedal
should be mounted on
the left crank.

Montare correttamente i
PEDALI PUSH-N2 e
MAD-PRO 015
1
How to mount the pedals
PUSH-N2 and MAD-PRO-015
3

Important
Pedals, that have
not been tighten
enough, can
irreparably
damage the
cranks.
Before every
ride, please
check if pedals
and cranks have
been tighten
enough.
How to mount the pedals
PUSH-N2 and MAD-PRO-015
4

The Assembly Instructions
We refer also to section 2 of our Manual “Instructions” that You find in
our page “Tipps & Tricks”:
2. Pedals
2.a The left pedal is marked with "L" and MUST be mounted on the left
crank marked with "L". Screw the right pedal in the right crank! The markings
are usually located on the inside of the cranks. The right pedal is screwed in
turning clockwise. The left pedal is screwed in turning counter clockwise.
2.b Put some grease on the pedal threads and tighten gently, but firmly!
What does it mean? Please tighten with small movements (each one not more
than 1/8 of a turn), using progressively more and more strength. If you use a
20-cm key, the final effort will be quite high. If you are not very strong, you will
most probably be forced to use almost all your strength. But do it with caution!
(If you break everything it means that the key used is too long or you are too
strong!!!!).
2.c Check every day your pedals. If you have light aluminum cranks and your
pedals are slightly unscrewed, you run the risk to damage your cranks
seriously.
