Madeleine Home MH-BD-11506 User manual

estimated
assembly time
30 : 00
people required
2 or more
MH-BD-11506,11510,11517,11518
1

Ok, let’s
get started!
Put on mood music!
To prevent damage to product, use the clean side of
package carton or rug as working surface. In the event
of missing or damaged parts, delivery
problems etc., please reach out to our team.
We will be happy to x the problem!
2

care guide
Clean regularly with a soft and dry cloth.
To protect nish, avoid use of abrasive cleaners.
Wipe up spills immediately. Please!
While assembling the product,
tighten the bolts up to 50%. Once
all parts are in place, only then
fully tighten the bolts.
3

product
parts
4
K
Mid Rail
x1
L
Mid Leg
x3
I
Headboard, Footboard
x2
J
Side Rail
x2

5
M
Slates
x2
N
Left Leg
x2
O
Right Leg
x2

6
(A) - Bolt (8 x 50mm)
x5
(B) - Bolt (8 x 25mm)
x8
(D)-Lock Washer (Ø8mm, Ø15mm)
x8
(C) - Washer (Ø8mm, Ø20 mm)
x8
what’s
included

7
(E) - Bolt (6 x 25mm)
x8
(G)- Allen Key (5mm)
x1
(H)- Allen Key (4mm)
x1

assembly
instructions
Friendly Tip: Take a deep
breath going in. This may be a
tricky part, but nothing too
overwhelming. Just follow
these steps to the T and the
outcome will be
worth it!
8
While assembling the product, tighten the bolts up to 50%.
Once all parts are in place, only then fully tighten the bolts.

Attach (I) to the two side rails (J).
To attach (I) to (J), insert washer (D), lock washer (C) and bolt (B) as
shown in the image above. Tighten the bolt in place using allen key
(G).
step 1:
step 2:
9
IJ
J
I
D
C
B

After attaching all corners, the product will look as shown in this
image.
Now, attach the left legs (N) and right legs (O) in their respective slots
as shown in this image.
step 3:
step 4:
10
N

Using the image as reference, place the Bolts (E) and x it in place with
the help of allen Key (H).
After attaching all corners and legs, the product will look as shown in
the image above.
step 5:
step 6:
11
E
H

Using the image as reference, place the bolt (A) and x the mid-legs
in place with the help of allen key (E).
Attach the mid-rail (K) to the mid-legs (L) using bolts and allen Key,
as shown in the image.
step 7:
step 8:
J
12
E
A
L
LL
K

Make sure the slates are xed in place.
step 9:
M
13
Voila! Your bed is now assembled and secure!
