Madeli Rotating-7 User manual

SIDE VIEW
BACK VIEW
Functional Elegance
Rotating-7 Linen Cabinet
Model Number
LCRS-120760-001-XX
Specication & Installation Guide
All Rights Reserved - 2014
Madeli, USA LLC | 9710 NW 110th Ave., Suite 1 | Miami , FL 33178 | madeli.com
Tel: [phone] | Fax: [phone] | Toll Free: 1-800-819-6988
01 | Page
For clarication, please contact Madeli Customer Care at (800)-819-6988 or (305)-718-8817 Ext. 1
All dimensions are approximate and subject to standard tolerance. Specications subject to change without prior notice.
TOP VIEW
59-1/16”
(1500mm)
11-15/16”
(300mm)
6-5/16”
(160mm)
5-15/16”
(150mm)
11-15/16”
(300mm)
5-15/16”
(150mm)
Mirror
3/16”
(50mm)
10-7/16”
(265mm) 6-5/16”
(160mm)
Features
•Free-standing, rotating cabinet
• Wall and front mount
•Cabinet: 59-1/16”(1500mm)H x 11-15/16”(300mm)W x 6-5/16”(160mm)D
•Total Height: 73-11/16”(1870mm)
•Furniture grade plywood layered with solid wood veneer and protected
with several coats of polyurethane.
• Matching Finish inside and out
•Front: dressing mirror
•Rear: Six shelves with retainer rod
Finishes
• Glossy White (GW)
• Walnut (WA)
Package dimension
14"x 8" x 61"
Gross weight
15.91 lbs / 35 kgs
9-1/8”
(231mm)
9-1/8”
(231mm) 9-1/8”
(231mm)
9-1/8”
(231mm)
9-1/8”
(231mm)
9-1/8”
(231mm)
9-1/8”
(231mm)
11-5/8”
(295mm)
Rev. 052815

Functional Elegance
Rotating-7 Linen Cabinet
Model Number
LCRS-120760-001-XX
Specication & Installation Guide
All Rights Reserved - 2014
Madeli, USA LLC | 9710 NW 110th Ave., Suite 1 | Miami , FL 33178 | madeli.com
Tel: [phone] | Fax: [phone] | Toll Free: 1-800-819-6988
02 | Page
For clarication, please contact Madeli Customer Care at (800)-819-6988 or (305)-718-8817 Ext. 1
All dimensions are approximate and subject to standard tolerance. Specications subject to change without prior notice.
SIDE VIEW
7-1/4”
(185mm)
3”
(75mm)
Secure to Wall
Shelf
59-1/16”
(1500mm) 73-11/16”
(1870mm)
11-5/8”
(295mm)
3-1/8”
(80mm)
7-1/4”
(185mm)
3-1/8”
(80mm)
Installation Instructions
1. Secure brackets to cabinets.
2. Secure bracket to oor and wall.
Secure to Cabinet
Retainer Rod
Secure to Floor
Secure to Cabinet
Rev. 052815
