MAG POCS-500 User manual

MAG OZONE
SANITISER
USER MANUAL
Contact us for
information or support:
01422 244733
[e-mail]

DECLARATION OF CONFORMITY
Model No. POCS-500 (POCS= Portable Odour Control System)
This unit fully complies with CE & FCC rules of EMC regulations.
EN 61000-61, EN 61000-62, EN 61010-1, EN 5501 EMC, FCC Part 15
Safety of Low Voltage Directive 73/23/EEC as Amended: EN 61010-1
General Information ............................................. 2
Declaration of Conformity ..................................... 2
Safety Precautions & Warnings .............................. 3
Unpacking ........................................................... 3
Control Panel & Other Indicators ..................... 4 + 5
Operation ..................................................... 4 + 5
Controller Settings ......................................... 4 + 5
Activation, Deactivation & Operating Times ........... 6
Maintenance & Service ............................... 7, 8 + 9
Troubleshooting .................................................. 9
Warranty ........................................................... 10
Technical Specifications ...................................... 11
CONTENTS
GENERAL INFORMATION
The MAG Ozone Sanitiser is a mobile and easy to
use cleaning & deodorising system for indoor use. The
robust product has high safety standards to quickly
and efficiently create Ozone, then decompose this into
Oxygen, allowing immediate access to treated spaces
at the end of each cycle. The unique U.S. patented
double barrier discharge technology achieves an
industry leading Ozone output of 12,000 mg/h.
For support call 01422 244733 or email [e-mail]
2

SAFETY PRECAUTIONS & WARNINGS
Read this manual carefully before operating the unit
Do not expose the equipment to rain or moisture. Should any liquid come into contact with the
system, unplug it and contact your supplier, or a qualified person, before operating it further.
Unplug the equipment when the product is not in use. Unplug this using the plug (do not pull
the cord).
DO NOT enter the treated room during the operation of the system or before hearing the auto
alert that indicates the completion of the cycle.
The system is equipped with a ventilation inlet and outlet. Do not block the inlet / outlet or place
any foreign objects in their vicinity which may block the air flow.
Place the unit in the centre of the room that is to be treated.
Prior to removing the grill for maintenance always disconnect the unit from power.
Avoid electrical shocks. This unit is supplied with an earthed cable - do not attempt
to bypass this. Under no circumstances should the unit be used if the front panel grill
is loose or missing.
There are no user serviceable parts inside the unit. Do not remove the back panel for the safety of
yourself and others. Removing the back panel will void all warranties.
UNPACKING
Open the box and gently place this on its side as pictured.
Li the ozone unit up slightly and then remove this by rolling it on its wheels.
Fasten the handle to the top panel using three hex screws on each side.
For support call 01422 244733 or email [e-mail] 3

OPERATION, PREPARATION AND CONNECTIONS
Before turning on your MAG Ozone Sanitiser
ensure all users have read this user manual in full.
CAUTION Ozone is a powerful oxidiser, use
this equipment with care. This product is only to be
used in UNINHABITED AREAS containing no
people, pets, plants, natural rubber or compounds
containing natural rubber. Read all operating
instructions before using this machine.
Do not attempt to enter the room while the machine
is sanitising. Only re-occupy the room aer the
preset operating time has elapsed and the amber
flashing light has stopped flashing indicating the
machine is no longer in operation.
Before the unit is used ensure all windows, doors
and vents are closed to prevent ozone leakage.
Connect the power cord into the sockets at the bottom rear panel of the machine and only then
connect it to the power source socket.
Ensure the area is free from any persons, animals, plants or natural rubber (e.g. shoe soles,
tubing, squeegee, keyboards)
Wheel the unit to the centre of the room and avoid the wire as a potential trip hazard.
Press the “STOP” (red) button to Reset.
The display will present a code followed by the alternating prompt: Ready and Set Room Size
Select the “Room Size” by pressing the relevant keyboard button. You may choose between
the following four room sizes:
Small: for room volumes below 30m³
Medium: for room volumes between 30m³ and 60m³
Large: for room volumes between 60m³ and 120m³
X-Large: for room volumes between 120m³ and 500m³
Note: For Large and X-Large rooms contact MAG with your room dimensions for a
recommend air circulator (if required).
The display will now prompt: Set Time
Select the Short / Intermediate / Long cycle time by pressing the relevant keyboard button.
Control Panel
For support call 01422 244733 or email [e-mail]
4

Short Cycle Time: for light odour removal & sanitisation
Intermediate Cycle Time: for average odour removal & sanitisation
Long Cycle-Time: for strong odour removal & sanitisation
You can refine your time setting (optional) by pressing the Up or Down (blue) arrow buttons to
extend or shorten the operation cycle time. Please refer to the reference chart on page six.
Note: The cycle time is indicated on the screen in hours and minutes (h= hours, m = minutes).
For example 3 hours and 20 minutes would be indicted as: 3 h 20 m
CAUTION Before you press the “START” “I” (green) button verify the area is vacated of
people, animals, plants and natural rubber.
Press the green (I) button to START the cycle.
The display will prompt you to “Get Out of Room”
and the amber hazard light will begin flashing.
IMPORTANT! The system will begin generation of
Ozone aer a 60 second delay in order to allow you
to leave the room.
You must leave the room immediately, swily & safely.
Remaining in the room while the treatment takes place or entering the room before the cycle
completes may be hazardous to your health.
Outside the room you will hear an audio alert signal indicating the ozone generation has
begun.
Isolate the room, where possible with a lock and warning sign, to prevent access by persons or
animals.
Aer the full operation cycle is completed, including the safe removal of ozone, you will hear a
second audio alert signal indicating that the cycle is complete.
Upon entering the treated room the display should read:
Operation Complete and the amber light should have
stopped flashing.
CAUTION In the event indications do not correspond to
the above, leave the room immediately and contact MAG on
01422 244733.
Aer the cycle is completed unplug the unit before moving this
to the next location.
If at any point you need to reset the keyboard settings press the
STOP (O) (red) button on the keypad.
Get Out Of Room
For support call 01422 244733 or email [e-mail] 5

ACTIVATION, DEACTIVATION & TOTAL OPERATING TIMES
KEYBOARD CONTROLLED MAXIMUM CHANGE FROM DEFAULT TIME
Default Default Default
Short Inter Long
Time (minutes) G D T G D T G D T
Room Volume
Small (<30mm3)2 11 15 25 18 45 118 60 180
Medium (30 - 60mm3)6 22 30 34 24 60 268 90 360
Large (60 - 120mm3)20 38 60 126 52 180 1318 120 1440
X-Large (>120mm3)178 120 300 598 120 720 2698 180 2880
Up Up Down
Short Inter Long
Time (minutes) G D T G D T G D T
Room Volume
Small (<30mm3)17 11 30 70 18 90 28 60 90
Medium (30 - 60mm3)21 22 45 154 24 180 88 90 180
Large (60 - 120mm3)50 38 90 666 52 720 598 120 720
X-Large (>120mm3)238 120 360 1318 120 1440 1258 180 1440
Generation Time = G
Decomposition = D
Total Cycle Time = T
Inter = Intermediate
For support call 01422 244733 or email [e-mail]
6

MAINTENANCE AND SERVICE
To ensure trouble-free performance your MAG
Ozone Sanitiser is required to be maintained
every 500 hours.
The keyboard on your product will display
“Needs Service” aer 500 hours of operation.
To book your maintenance visit contact MAG Equipment on 01422 244733 or email
[email protected].uk
Alternatively MAG can provide training or video assistance to a competent person with a “good pair
of hands” that can follow these instructions. The maintenance procedure should take around 1 hour
to complete.
CAUTION - Prior to any maintenance or service disconnect the power by
unplugging the product
STEP 1 - CLEANING THE DUST FILTER
(a) Remove black front grill panel by
unscrewing the six screws, your
product should now appear as
Figure A
(b) Loosen six screws in the frame
around the dust filter so you can
slide the filter out
Note: Do not remove the earth cable
connected to the grill
(c) Gently slide the filter up and out of its frame as seen in
Figure B
(d) Place the filter under warm tap water and wash out the
dust. It is okay to use a mild soap to loosen the dust if
required. Rinse and dry (it is okay to use a hair dryer).
(e) Slide the dust filter back into its frame and retighten the
six loosened screws.
Figure A
Figure B
For support call 01422 244733 or email [e-mail] 7

STEP 2 - CLEANING OZONE GENERATING CORES (SINGLETS)
(a) There are two singlets to remove and clean
which are located side by side in the unit
(b) Pull out the electrical cable of the Singlet
core on the right side of Figure D and
disconnect the electrical connector.
(c) Unscrew the two nuts holding the Singlet
unit (red circles - Figure D)
(d) Gently pull out the Singlet in a parallel
motion from its supporting screws.
Be careful not to touch or scratch the glass tubes
(e) Clean the Singlet core under warm tap
water, particularly the gaps between the
tubes. You may use a so brush to remove
any accumulated dirt.
Do not wet the electrical connector
(f) Repeat the same procedure above from the
second Singlet core on the le hand side of
Figure D.
(g) Allow the Singlets to air dry or use a so
towel
(h) Re-mount each Singlet core on its leading
screws by sliding it in parallel.
Remember to re-insert the Singlets so that the 3 tubes are facing you as show in Figure C
(i) Re-attach the electrical connector to each Singlet core (ensure they are dry).
(j) Re-screw the two nuts onto each Singlet supporting screw.
Figure C - Singlet Core
Figure D
For support call 01422 244733 or email [e-mail]
8

STEP 3 - REATTACH THE BLACK FRONT GRILL PANEL
(a) Replace the front grill making sure the dust filter is on
the inside of the unit.
Make sure the earth cable to the grill is completely
inside the unit
(b) Re-screw the six screws around the frame of the panel.
TROUBLESHOOTING
DESCRIPTION OF PROBLEM: POSSIBLE SOLUTION:
Display is blank and keypad
does not function
Check the power cord connections. Make sure the
overload switch near the control panel is flipped to the
right side and the green light indicator above the
switch is ON.
Display prompts “Ready”
but keypad does not
function
Disconnect and reconnect the power cord. Wait for the
screen to display “Ready”. Press the STOP (red) button
on the keypad. Press the hard RESET (yellow) button on
the keypad.
Red light (fault indication) is
ON and the display indicates
fault code “AL: Presso-stat”
or “AL: Micro-Switch”
Make note of the fault code indicated on the display.
Disconnect (unplug) the unit and contact MAG for
assistance.
Display shows: “Needs
Service”
This notification will appear every 500 hours of use to
indicate the equipment needs a maintenance visit.
Contact us or refer to the maintenance section in this
manual.
Other Contact us for assistance on 01422 244733
For support call 01422 244733 or email [e-mail] 9

WARRANTY
MAG Equipment Ltd (the “Company”), warrants to the original retail purchaser or buyer of
the product (the “Purchaser”) that the MAG Ozone Sanitiser will conform to and perform in
accordance with the published technical specifications and any accompanying written materials
supplied by MAG and will be free from defects in materials and workmanship under normal use and
conditions for the applicable warranty period. The warranty period is 1 year, commencing on the date
of purchase. During this warranty period the supplier will ensure the a reasonable solution is provided
in the event of any breakdowns. This warranty does not extend to products that have been subject
to misuse, accidental damage, exposure to corrosive substances, tampering or use in a manner not
approved by MAG in writing.
The Ozone Filtering Unit is a consumable part subject and is expressly excluded from this warranty. All
shipping, service calls and/or other incidental and/or related charges are fully payable by Purchaser
only and are not included in this warranty. In the event a machine’s fault requires reparation that can’t
be done by the customer on site, at the supplier’s exclusive discretion, they may make the decision to
replace a machine and the customer must return the old machine if a replacement is provided.
This agreement and any dispute or claim (including non-contractual disputes or claims) arising out
of or in connection with it or its subject matter or formation shall be governed by and construed
in accordance with the law of England and Wales. Each party (the Purchaser and the Company)
irrevocably agrees that the courts of England and Wales shall have exclusive jurisdiction to settle any
dispute or claim (including non-contractual disputes or claims) arising out of or in connection with this
agreement or its subject matter or formation.
The Company reserves the right to update or amend their terms and conditions if it is in the interests
of the Company or in order to meet any legal requirements and regulations. The Company may
exclude or limit their liability for any actions which result in damage, injury or loss to the Purchaser or
any persons or property associated with the Purchaser.
While every effort has been made to ensure the information provided is accurate the Company
accepts no liability for any errors, inaccuracies or omissions and shall not be bound in any manner by
any information provided.
THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO ANY WARRANTIES OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, ALL OF WHICH ARE EXPRESSLY EXCLUDED AND DISCLAIMED. MAG
EQUIPMENT LTD WILL NOT BE LIABLE FOR LOSS OF PROFITS, ANY SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES WHICH PURCHASER MAY SUSTAIN, OR PUNITIVE DAMAGES,
EVEN IN THE EVENT OF NOTICE OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL
LIABILITY UNDER THIS WARRANTY EXCEED THE PURCHASE PRICE OF THE PRODUCT.
For support call 01422 244733 or email [e-mail]
10
