Magnaflux UVe-LUX User manual

Operating
Manual
UVe-Lux Meter
Faraday Road, South Dorcan Industrial Estate, Swindon, SN3 5HE, UK
Telephone: + 44 (0)1793 524566 Fax: [phone]
Email: sales.eu@magnaflux.com Web: eu.magnaflux.com
Bahnhofstr 94-98, 73457 Essingen, Deutschland
Telephone: [phone] Fax: [phone]
Email: sales.de@magnaflux.com Web: eu.magnaflux.com/de

9
CONTENTS
Page
1 Introduction 1
2 System components 2
2.1 Sensor housing 2
2.2 Meter housing 2
2.3 Buttons 3
2.4 Batteries 4
3 Display 5
3.1 Measurement display 6
3.2 Main menu 7
3.3 About screen 7
3.4 Brightness 7
3.5 Power O time 8
3.6 Time/date 8
3.7 Set units 9
3.7 SET UNITS
White Light Lux Units
Select ‘WL - Lux’ from the menu to set the unit to
Lux
White Light Foot Candles
Select ‘WL-Foot candles’ to set the unit to ft-c
UV Light Micro Watt
Select ‘UV - µW/cm2’ to set the unit to µW
UV Light Milli Watt
Select ‘UV - mW/cm2’ to set the unit to mW
Set Units

1
8
1. INTRODUCTION
The UVe-LUX is a compact, lightweight and robust meter specifically designed for
the non-destructive testing environment. The meter is a dual white-light (WL) and
ultra-violet (UV) meter designed to give simultaneous readings of both WL and UV.
The meter has the following specification:
• Single sensor head measures UV and white light at the same time
• 320 x 240 pixel 2.8” TFT colour LCD display
• Dimmable display to extend battery life
• Auto-ranging on both WL and UV scales
• Menu driven setup and multi-function buttons
• ‘Auto Hold’ function to record maximum readings
• Adjustable auto-power down to conserve battery life
• Meets the requirements for non-destructive testing viewing conditions for
penetrant and magnetic particle inspections (ISO 3059)
• Measurement units - WL: lux or fc, UV: μW/cm² 0 m W/cm²
• Measuring range - WL: 0.1 to 5000 lux, UVA: 0 to 10,000 μW/cm²
• Accuracy - WL: better than 5%, UV: better than 5%
• 2 x AA Rechargeable batteries
• Display of time and date
• Save function for logging readings
• Detachable light sensor probe
3.5 POWER OFF TIME
The POWER OFF TIME menu option allows you to
set an automatic timer to power the meter down,
in order to conserve battery power. The power o
timer may be set between 0 and 15 minutes. If the
power o time is set at 0, the meter will never turn
itself o. If the time is set outside the required range,
an ‘ERROR IN TIME’ message will be displayed.
Error message
3.6 TIME/DATE
The SET TIME/DATE menu option allows you to
change the time and date settings.
To set the time:
Select the TIME ONLY option from the menu;
‘ENTER CURRENT TIME’ will display. Increase or
decrease the time using the up and down arrow
buttons. Use the left and right arrow buttons to
move between digits, then use the accept button
to complete.
To set the date:
Select the DATE ONLY option; ‘ENTER CURRENT
DATE’ will display. Increase or decrease the date
using the up and down arrow buttons. Use the left
and right arrow buttons to move between digits,
then use the accept button to complete.
Set time/date

27
2. SYSTEM COMPONENTS
The system consists of a sensor housing containing both the WL and UV sensors,
and the meter housing containing the main system components such as the
screen, battery and user interface. Both the sensor housing and the meter housing
are constructed from reinforced ABS plastic and are rated to IP65 for moisture
and dust ingress. The two housings are linked together with 750mm of flexible
screened cable for ease of use.
2.1 SENSOR HOUSING
The sensor housing contains the individual WL and
UV detectors in one handy unit. The active area of
the sensor housing is the circular glass panel on
the front of the housing. Ensure that the glass panel
remains clean and is not damaged in any way, as
any dirt or damage to the glass panel will aect the
accuracy of the meter.
If the panel requires cleaning, use a damp cloth
with a small amount of detergent to wipe the panel,
then use a dry, lint-free cloth to dry the panel. Do
NOT use abrasive cleaners and solvents as they
may damage the unit.
If the panel gets damaged, return the whole meter
to the manufacturer for repair and re-calibration.
Sensor housing
2.2 METER HOUSING
The meter housing contains the display screen,
buttons and battery for the unit. The meter housing
is rated at IP65 for moisture and dust ingress. If it
needs cleaning, use a damp cloth and mild deter-
gent.
Probe
connection
Charging
socket
3.2 MAIN MENU
Enter the menu system by pressing the accept
button. Once in menu-mode, use the up and down
button to scroll through menu items and press the
Accept button to select menu items. Throughout
the main menu, helpful hints at the bottom of the
display will guide you to the right button for the
desired operation.
Holding the on/o key down for several seconds in
menu mode will power the system down. Main menu screen
3.3 ABOUT SCREEN
The ABOUT screen (also the splash screen) dis-
plays the software number, meter serial number
and the light probe serial number. This screen also
indicates the period of time left before recalibration
is required.
About/splash screen
3.4 BRIGHTNESS
Select this option to adjust the brightness. Use the
arrow buttons to select either BRIGHTER or
DARKER, then press the accept button.
Brightness menu

3
6
3.1 MEASUREMENT DISPLAY
When the unit is powered up, it will normally enter the measurement display after
the splash screen. The measurement display contains six components:
• Battery level - this gives an indication of the state of the battery life.
• Current time and date.
• WL reading - this is the current rounded reading for the white light sensor.
• WL max - this is the maximum absolute value the meter has observed for white
light. This reading is reset when the cancel button is pressed.
• UV reading - this is the current rounded reading for the UV sensor.
• UV max - this is the maximum absolute value the meter has observed for UV. This
reading is reset when the cancel button is pressed.
If the meter is exposed to light levels greater than its designed range, the meter will
saturate and display ‘9999’ to indicate that it has saturated. The meter will return
to normal operation once the light levels have returned to the meter’s designed
range.
2.3 BUTTONS
On/O button:
Press this button (while the unit is o) to switch the UVe-LUX on.
Hold down this button (while the unit is on) to switch the UVe-LUX
o.
Accept button:
Press this button in measurement mode to enter menu mode.
Press this button in menu mode to select/approve the highlighted
menu function.

Cancel Button:
Press this button in measurement mode to reset max values.
Press this button in menu mode to cancel selection or go back to
previous menu function.
Arrow up button:
Press this button in menu mode to cycle up through the menu
options.
Use within submenus for incrementing values.
Arrow down button:
Press this button in menu mode to cycle down through menu
options.
Use within submenus for descending values.
Arrow right button:
Press this button to move right for selection within submenus.
Arrow left button:
Press this button to move left for selection within submenus.

45
2.4 BATTERIES
The UVe-LUX is powered by two AA type, rechargeable batteries. You can access
the batteries by unscrewing the screw holding the battery housing cover on the
rear of the meter housing, and removing the cover. It is important to insert the
batteries in the correct orientation as marked in the battery compartment, other-
wise damage may occur to the meter. The battery housing cover should then be
replaced and screwed back down.
We recommend that the batteries supplied with the meter should be charged
overnight (the meter must be o whilst the batteries are charging). The charger
supplied with the meter is for the sole purposeof charging the batteries and
must not be used independently (i.e. as an external power adaptor) to run the
meter under normal operating conditions.
Whilst connected to the charger, the top-right of the screen will display ‘CHARGING’.
When the batteries are full, the sreen will display ‘CHARGED’. Once the batteries
are fully charged, the meter will run for approximately eight hours before needing a
recharge. ‘BATTERY LOW’ means the batteries need to be recharged or the meter
will power itself down. Ordinary dry cell batteries can be used and no damage will
result if the battery charger supplied is inadvertently used.
5
3. DISPLAY
In normal operation, when the unit is powered up, the first screen to appear is the
logo screen, followed by the splash screen. The splash screen contains informa-
tion about the meter, including the serial number and the date of last calibration for
the unit. This screen can also be found in the main menu under ABOUT.
The LCD display is protected behind a protective plastic cover, but take care to
protect the screen area from blows, scratches or other damage.
Splash screen
