Magnavox TB100MW9 User manual

Owner's Manual
MAGNAVOX
S M A R T .
VERY
S M A R T .
TB100MW9
DTVDigitaltoAnalogConverter (Set Top Box)
THANK YOU FOR CHOOSING MAGNAVOX.
NEEDHELPFAST?
READYOURQUICKGUIDE AND/OROWNER'SMANUAL FIRST FORQUICKTIPS
THATMAKE USINGYOUR MAGNAVOXPRODUCT MOREENJOYABLE.
IFYOUHAVE READYOURINSTRUCTIONSANDSTILLNEEDASSISTANCE,
YOU MAY ACCESS OUR ONLINE HELP
AT WWW.FUNAI-CORP.COM ORCALL1-800-
605
-
8610WHILE
WITH YOUR PRODUCT
.
INSTRUCCIONES EN ESPAÑOL
INCLUIDAS.
BEFORE
USING
___________________________________________
The serial number of this product may be found on the bottom of the unit. You should
record the number and other vital information here and retain this book as a permanent
record.
Serial numbers are not kept on file.
Date of Purchase
Dealer Phone
No.
Dealer Purchase
from
Model No.
Dealer Address
Serial No.
IWARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK
,
DO NOT EXPOSE THIS APPLIANCE
|__________________TO RAIN OR
MOISTURE.____________________________________________________________________
.
. THIS SYMBOL INDICATES
Page
1
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

THAT __________
CAUTION
__________ ^\
>\ DANGEROUS VOLTAGE CONSTITUTING
BffWlSflfSHTBJIFWi 4^. ^Ém. ARISK OF ELECTRIC SHOCK IS
^LKJjyjuUÍUK^^LS ^"^^ ^K^k. PRESENT WITHIN THIS UNIT.
--------------------------------------------------------------------------------- THIS SYMBOL
INDICATES THAT THERE
CAUTION' i\ ARE IMPORTANT OPERATING
AND A m. MAINTENANCE INSTRUCTIONS IN THE
TO REDUCE THE RISK OF ELECTRIC SHOCK, AA LITERATURE ACCOMPANYING
THE
DO NOT REMOVE COVER (OR BACK). APPLIANCE.
NO USER SERVICEABLE PARTS INSIDE. I-----------------------------------------------------
----------------------------
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
The caution marking is located on the bottom of the cabinet.
____________Important Safeguards____________
1. Read instructions-All the safety and operating instructions AMEUBLES- Cet
appareil ne doit étre ^^^^ should be read before the appliance is operated.
place que sur un meuble (avec ou sans ^f^^^k.
2. Retain Instructions-The safety and operating instructions roulettes)
recommandé par le fabricant. Si JJfef\^ should be retained for future reference.
vous 1'mstaUez sur un meuble á roulettes, ES^SLJ
deplacez les deux ensembles avec precau- ^l&hAjSW
3. Heed Warnings-All warmngs on the appliance and in the tion Un arrgtbrusque,
¡'utilisation d'une JB^^L operating instructions should be adhered to.
force excessive et des surfaces irréguliéres
4. Follow Instructions-All operating and use instructions risquent de
déstabiliser l'ensemble et de le renverser. should be followed.
9Ventilation-Slots and openings in the cabinet and the back
5. Cleaning-Unplug this product from the wall outlet before or bottom are
provided for ventilation and to ensure reli-cleaning. Do not use liquid cleaners or aerosol
cleaners. able operation of this product and to protect it from over-Use a
damp cloth for cleaning. heating, and these
openings must not be blocked or cov-EXCEPTION: A product that is meant for
uninterrupted ered. The openings should never be blocked by placing this
service and, that for some specific reason, such as the pos- product on a bed, sofa,
rug, or other similar surface. This sibility of the loss of an authorization code for a CATV
product should never be placed near or over a radiator or converter, is not
intended to be unplugged by the user for heat register. This product should not
be placed in a built-in cleaning or any other purpose, may exclude the reference
installation such as a bookcase or rack unless proper vento unplugging the appliance in
the cleaning description oth- tilation is provided or the manufacturer's instructions
have erwise required in item 5. been adhered
to.
6. Attachments-Do not use attachments not recommended by lO.Power Sources-This
product should be operated only from this product manufacturer as they may cause
hazards. the type of power source indicated on the marking label. If
7. Water and Moisture-Do not use this product near water- You are not sure of the
lyPeof Power suPP!y to Your home^ for example, near a bath tub, wash bowl, kitchen sink,
or consult your appliance dealer or local power company. For laundry tub, in a
wet basement, or near a swimming pool, thls products intended to operate from
battery power, or and the like
other sources, refer to the operating instructions.
8. Accessories-Do not place this product on an unstable cart, ll.Grounding or
Polarization-This product is equipped with stand, tripod, bracket, or table. This product
may faU, caus- apolarized alternating-current Une plug(a plug having
ing serious injury to someone, and serious damage to the one blade wlder than the
other)- Thls Plu§w111 ñt lnto the appliance. Use only with a cart, stand, tripod, bracket, or
Power outlet only one waY- This ls asafety feature- If y°u table recommended by the
manufacturer, or sold with this are unable to lnsert the Plu§ fully lnto the outlet> try
revers" product. Any mounting of the appliance should follow the ln§ the Plu§- If
the Plu§ should stl11fal1 to ñt> contact your manufacturer's instructions and should use a
mounting electrician to replace your obsolete outlet. Do not defeat accessory
recommended by the manufacturer. _ the safety purpose of the polarized
plug. An appliance and cart combination should be ^^5^^ 12.Power-Cord
Protection-Power-supply cords should moved with care. ^^Bv\^k be routed so
that they are not likely to be walked on or Quick stops, excessive force, and uneven
■SisL ■pinched by items placed upon or against them, paying par-surfaces may
cause the appliance and cart ^HLJSÉF ticular attention to cords at plugs,
convenience receptacles, combination to overturn. jBBjgB^ an(j ^ p0jnt where
they exit from the appliance.
BEFORE USING
Page
2
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

13.0utdoor Antenna
grounding
-
If
an
outside antenna or cable system is
connected to this product, be sure the
antenna or cable system is grounded so as
to provide some protection against
voltage surges and built-up static charges.
Article 810 of the National Electrical
Code, ANSI/ NFPA No. 70, provides
information with respect to proper
grounding of the mast and supporting
structure, grounding of the lead-in wire to
an antenna discharge unit, size of
grounding conductors, location of
antenna-discharge unit, connection to
grounding electrodes, and requirements
for the grounding electrode. (Fig. A)
14.Lightning-For added protection for
this product receiver during a lightning
storm, or when it is left unattended and
unused for long periods of time, unplug
it from the wall outlet and disconnect the
antenna or cable system. This will
prevent damage to this product due to
lightning and power-line surges.
15.Power Lines-An outside antenna
system should not be located in the
vicinity of overhead power lines or other
electric light or power circuits, or where
it can fall into such power lines or
circuits. When installing an outside
antenna system, extreme care should be
taken to keep from touching such power
lines or circuits as contact with them
might be fatal.
16.0verloading-Do not overload wall
outlets and extension cords as this can
result in a risk of fire or electric shock.
17.0bject and Liquid Entry-Never push
objects of any kind into this product
through openings as they may touch dan-
gerous voltage points or short out parts
that could result in a fire or electric
shock. Never spill liquid of any kind on
this product.
18.Servicing-Do not attempt to service this
product yourself as opening or removing
covers may expose you to dangerous
voltage or other hazards. Refer all
servicing
to quali
fied service personnel.
19.Damage Requiring
Service
-
Unplug
this product from the wall outlet and
refer servicing to qualified service
personnel under the following
conditions:
a. When the power-supply cord or plug is damaged or
frayed.
b. If liquid has been spilled, or objects
have fallen into this product.
c. If this product has been exposed to rain or water.
d. If this product does not operate
normally by following the operating
instructions. Adjust only those controls
that are covered by the operating
instructions, as improper adjustment of
other controls may result in damage and
will often require extensive work by a
qualified technician to restore this
product to its normal operation.
e. If this product has been dropped or damaged in any way.
f. When this product exhibits a distinct
change in perform-ance-this indicates a
need for service.
20.Replacement Parts-When replacement
parts are required, be sure the service
technician has used replacement parts
specified by the manufacturer that have
the same characteristics as the original
part. Unauthorized substitutions may
result in fire, electric shock, injury to
persons or other hazards.
21.Safety Check-Upon completion of any
service or repairs to this product, ask the
service technician to perform routine
safety checks to determine that this
product is in proper operating condition.
22.Heat-This product should be situated
away from heat sources such as
radiators, heat registers, stoves, or
other products (including amplifiers)
that produce
heat.
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE
SLOT, FULLY
INSERT.
ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA
LAME LA PLUS
LARGE
DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER
JUSQU'AU FOND.
BEFORE
USING
___________________________________________
Precautions
Location_________________________
For safe operation and satisfactory
performance of this product, keep the
following in mind when selecting a place
for its installation:
• Shield it from direct sunlight and keep
it away from sources of intense heat.
• Avoid dusty or humid places.
•
Avoid places with
insufficient ventilation
IMPORTANT COPYRIGHT INFORMATION
Unauthorized recording or use of
broadcast television programming, video
tape, film or other copyrighted material
may violate applicable copyright laws.
We assume no responsibility for the
unauthorized duplication, use or other acts
which infringe upon the rights of
copyright owners.
Page
3
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

for proper heat dissipation. Do not block
the ventilation holes at the top and bottom
of the unit. Do not place the unit on a
carpet because this will block the ventila-
tion holes.
• Install unit in a horizontal position.
• Avoid locations subject to strong vibration.
• Do not place this
product near strong magnetic
fields.
• Avoid moving this product to locations
where temperature differences are
extreme.
Avoid the Hazards of Electrical Shock
and Fire____________________
• Do not handle the power cord with wet hands.
• Do not pull on the power cord when
disconnecting it from an AC wall outlet.
Grasp it by the plug.
• If by accident, water is spilled on your
unit, unplug the power cord immediately
and take the unit to our Authorized Service
Center for servicing.
• Do not put your fingers or objects into
this product cassette holder.
• Do not place anything directly on top of the
unit.
FCC WARNING- This equipment
may generate or use radio frequency
energy. Changes or modifications to
this equipment may cause harmful
interference unless the modifications
are expressly approved in the
instruction manual. The user could
lose the authority to operate this
equipment if an unauthorized change
or modification is made.
This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur
in a particular installation. If this
equipment does cause harmful
interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user
is encouraged to try to correct the interfer-
ence by one or more of the following
measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the
equipment and receiver.
3) Connect the equipment into an outlet
on a circuit different from that to
which the receiver is connected.
4) Consult the dealer or an experienced
radio/TV technician for help.
___________________________________________
BEFORE
USING
BEFORE
USING.................. 2
Important Safeguards................ 2
Precautions........................ 4
Information on Digital Broadcasting .... 6
Major Features of STB............... 6
Trademark Information............... 6
Location of Controls................. 7
Accessories........................ 8
Installing Batteries.................. 8
CONNECTIONS.................. 9
Connecting an Antenna............... 9
Connecting to TV...................10
OTHER CONNECTIONS...........11
STB Connection to a Standard Stereo
System............................11
Connecting to TV and Video Devices
(VCR, DVD Recorder, etc)............12
INITIAL SETUP (SETUP WIZARD) ... 13
Initial Setup........................13
BASIC OPERATION...............15
Selecting Channels on the STB.........15
Channel
Banner.....................
15
ADVANCED OPERATION..........
17
Adding/Deleting Channels............17
Adjusting Antenna...................18
Receiving Channels (Autoscan)........18
Selecting Display Mode..............19
Setting the Time Zone and DST
(Daylight Saving Time)...............20
V-Chip Options.....................21
Closed Caption Options..............23
Auto Power Down...................24
OTHERS........................25
Troubleshooting.....................25
Specifications......................26
Glossary and Acronyms..............26
GUÍA PARA RÁPIDA CONSULTA___27
Antes de utilizar....................27
Conexiones........................28
Ajuste inicial
(ASISTENTE DE AJUSTES)..........29
Warranty.....................Back
Cover
Page
4
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

Choosing Audio
Language............
16
Picture Still........................16
Electronic Program Guide
(EPG).......
16
BEFORE
USING
___________________________________________
Digital broadcasting is the most
advanced format of broadcasting, employing a new
technology for compression of audio and video signals which allows broadcasters to
transmit digital signals using existing terrestrial systems.
Due to this dramatic progress, new features of broadcasting service such as widescreen
formats and higher definition provide ways to experience the full benefits of digital
transmission.
Digital broadcasting overcomes problems experienced with analog TV such as ghosting,
"snowy" pictures and interference. Digital TV has a dramatic effect on these problems by its
very nature.
In addition, the number of channels available has dramatically increased, so that you can
make the best choice among the variety of programs anytime with a clear picture.
It is also possible to transmit multiple Standard Definition TV (SDTV*) programs within
the same bandwidth. Some data capacity can also be allocated to provide more effective
closed captioning or multiple language soundtracks.
Your current TV can be used for its entire
service life. This STB (Set Top Box) will
now make this
possible.
•
Capable of receiving digital (ATSC*)
broadcasts
• Capable of receiving Standard
Definition TV (SDTV*) broadcasts
ATSC - Advanced Television Systems
Committee: This group is working to
establish the standards for digital TV
broadcasting and digital TV equipment for
both SDTV and HDTV.
SDTV - Standard Definition Television:
SDTV signal formats are 480p and 480L
SDTV provides lower resolution, yet
presents a very sharp, clear picture. Lower
resolution allows broadcasters to transmit
multiple programs per
channel.
•
Alternative languages
for OSD
(English, Spanish and French)
• Sub-channels* through a single digital channel
Sub-Channel - The compression of audio
and video signals enables each digital
channel to carry different programs on
sub-channels. Select them by simply
pressing [CH +/—] or the number buttons
on your remote control when
available.
Product that have earned ENERGY
STAR
®
are designed to protect the environment
through superior energy
efficiency.
Page
5
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

___________________________________________
BEFORE
USING
1 STANDBY-ON button: Turns STB on and off
2 Number buttons: Input channel numbers and passwords.
3 SETUP button: Enters or quits "SETUP" menu.
4 STILL button: Pause the image while you continue to listen to the
audio.
5 Navigation buttons ▲/ T / M I ►: Moves the
highlight up, down, left or right.
6 RETURN button: Returns to the previous screen in
"SETUP" menu or exits from the menu.
7 CH + / — buttons: Change the channels up or down.
8 ALT. CH: Returns to the channel you were last watching.
9 DISPLAY button: Displays information on the
channel banner or clears the banner.
10 EPG button: Displays or exits the Electronic Program Guide.
11 AUDIO button: Selects alternative audio languages (if available).
12 OK button: In "SETUP" menu, press to enter your selection.
• To operate this STB with a universal remote, check the
instruction manual for remote and find Magnavox brand
STB code. If you do not find the code or the code does not
work, try to use Sylvania brand STB code instead.
1 Remote
control sensor:
Receives signals from
3 Main Power:
Turns STB's
main power on and off. your remote control so you can control the STB from a
When you use this button to turn off the main power, distance.
make sure that the Power indicator is yellow.
2 POWER indicator: Turns green
when the main power is on and you
are operating on the remote control.
Turns yellow on standby.
| Rear Panel |
1 AC power
cord:
Connect to AC outlet.
2 AUDIO OUT jacks (Right (red) / Left (white)): Connect your TV, stereo system
or VCR with standard audio cables.
3 VIDEO OUT jack (yellow): Connect your TV or VCR with a standard video cable.
4 ANT. IN jack: Connect an antenna.
5
ANT. OUT jack:
Connect to the Aerial jack on your TV to output the
signal.
BEFORE
USING
___________________________________________
Check the following accessories when unpacking the
1 Unsnap the battery cover from the
back of the remote control.
Page
6
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

Remote control: NA383UD
2 AA batteries
2 Install two AA batteries making
sure the polarity (+ /
-
) is correct.
Owner's manual: 1VMN24075
NOTE:
• When replacing batteries, replace them in pairs.
3 Snap the battery cover back.
CAUTION:
• Do not mix battery types (alkaline and
manganese, or old ones and new ones).
• Do not recharge, short-circuit, heat,
burn or disassemble
batteries.
RF cable: WPZ0901TM002
A NOTE ABOUT RECYCLING
This product's packaging materials are recyclable and can be reused. Please dispose of
any materials in accordance with your local recycling regulations.
Batteries should never be thrown away or incinerated but disposed of in accordance with
your local
regula
tions concerning chemical wastes.
CONNECTIONS
Connecting
an Antenna
(
------------------------------------------------------------------------------------
"\
(
---------------------------------------
Page
7
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

-----
>
Supplied cables used in this connection are as follows: Note to the Cable TV
System
• RF cable xl Installer:
„, ,j, ,.. .This reminder is provided to call
Please purchase the rest of the necessary cables at your local store. J the Cable TV system installer's
„ j, .. „ j, „ , . ,T™attention to Article 820-40 of
Before connecting ensure the AC power cords of all devices are NOT ^ National Electrical Cod
connected to the AC outlets. which proyides guiddines for
1 Use an RF cable to connect the antenna to the ANT. IN jack on the proper
grounding - in particular, ^TB-
specifying that the cable ground
2 Use an RF cable to connect the incoming cable to the antenna shall be connected to the
input jack on the cable box. grounding system of the
building,
3 Use an RF cable to connect the antenna output jack on the cable as close to the
point of cable entry box to the antenna input jack on the TV.
as possible.
4 Refer to "Connecting to TV" on page 10 to connect your TV. -----------------------------------------
---
NOTE:
•
When you connect the RF cable to another device, be sure to
use a splitter as shown below.
CONNECTIONS
________________________________________________
Rear panel of STB
f
---------------------------------------------------------------------------------------------------------------------------------
------------------------------------------------------------\
Supplied cables used in this connection are as follows:
• RF cable xl
Please purchase the rest of the necessary cables at your local store,
k________________________________________________________________________________________
Before connecting, ensure the AC power cords of all devices are NOT connected to the AC outlets.
1 Refer to "Connecting an Antenna" on page 9 to connect the STB to an antenna.
2 Use an RF cable to connect the ANT. OUT jack on the STB to the antenna input jack on the TV.
AND/OR Use a standard audio/video cable to
connect the AUDIO/VIDEO OUT jacks on the STB to the audio/video input jacks on the
TV.
3 Plug all AC power cords into AC outlets, then turn all devices on.
4 After you have completed the connections, select an appropriate external input channel
on your TV (ch3 or ch4) (refer to your TV's manual for details), and also set the STB's
output channel to the corresponding channel number (3 or 4). You can switch between 3
and 4 by holding [SETUP] down over 3 seconds.
NOTE:
Page
8
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

•
When using either of
these connections, the resolution of the video signal output will
always be 480L This ensures that all digital TV programming, no matter what the actual
transmitted format is, will be viewable and compatible with your analog TV.
• If your TV is monaural (MONO) and has only one audio jack, connect a standard audio
cable (white) from the AUDIO OUT (white) jack on the STB to an audio input jack
(white) on the TV. The red cable and jack will not be
used.
_____________________________________
OTHER
CONNECTIONS
Rear panel of STB
f
---------------------------------------------------------------------------------------------------------------------------------
------------------------------------------------------------\
Supplied cables used in this connection are as follows:
• RF cable xl
Please purchase the rest of the necessary cables at your local store,
k________________________________________________________________________________________
Before connecting, ensure the AC power cords of all devices are NOT connected to the AC outlets.
1 Refer to "Connecting an Antenna" on page 9 to connect the STB to an antenna.
2 Refer to "Connecting to TV" on page 10 to connect the STB and the TV.
3 Use a standard audio cable to connect the AUDIO OUT jacks on the STB to the audio
input jacks on the stereo component.
4 Plug all AC power cords into AC outlets, then turn all devices on.
5 Set the stereo to the input mode to which you connected the audio
from the STB. Refer to
your stereo's manual for details.
OTHER
CONNECTIONS
_________________________________________
Page
9
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

e.g.: Connection to DVD Recorder
Rear panel of STB
C
--------------------------------------------------------------------------------------------------------------------------------
----\
Supplied cables used in this connection are as follows:
• RF cable xl
Please purchase the rest of the necessary cables at your local store.
^
____________________________________________________________________________________________________________________________________________________
Before connecting, ensure the AC power cords of all devices are NOT connected to the AC outlets.
1 Refer to "Connecting an Antenna" on page 9 to connect the STB to an antenna.
2 Use a standard audio/video cable to connect the AUDIO/VIDEO OUT jacks on the
STB to the audio/video input jacks on the DVD recorder.
3 Use a standard audio/video cable to connect the audio/video output jack on the DVD
recorder to the audio/ video input jack on the TV.
4 Plug all AC power cords into AC outlets, then turn all devices on.
5 Set the TV and DVD recorder to input mode.
Refer to your TV's or DVD recorder's manual for details.
NOTE:
• If your DVD recorder is monaural (MONO) and has only one audio jack, use a standard
audio cable (white) to connect the AUDIO OUT jack (white) on STB to the audio input
jack (white)
on the DVD. The red cable and jack will not be
used.
INITIAL SETUP (SETUP
WIZARD)
I
InitialSetup
I
5 Select the connection for audio
output using H/H. then press [OK].
Select "AUDIO OUT"
if...
- you are using the standard audio cable to
connect the STB to your TV.
Select "RF OUT" if...
- you are using the RF cable to connect
the STB to your TV.
6 Select your time zone using [A/
Y], then press
[OK].
Page
10
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

7 Select "ON" or "OFF" for Daylight
Saving Time (DST) using [</>*],
then press [OK].
8 Select the desired display mode
using [A/Y], then press [OK].
4 Select the language using [▲/T],
then press [OK].
INITIAL SETUP (SETUP
WIZARD)
_____________________________
9 Select "AUTOSCAN" using [A/ Y],
then press
[OK].
•
STB starts
receiving available digital
channels and stores them in the
channel map.
• When the scanning is complete,
"AUTOSCAN COMPLETED" will be
indicated.
• After autoscan is complete, press [CH
+ / —] to verify whether STB is
receiving channels properly.
The "SETUP WIZARD" is now complete.
To cancel during
scanning: Press [OK].
NOTE:
• If autoscan is canceled, some
channels not yet scanned may not be
received. We recommend completing
autoscan.
Page
11
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

BASIC OPERATION
About Sub-channel Broadcasting
Digital broadcasting offers a service that
enables multiple signals, called "sub-
channels", to be sent simultaneously on one
main channel by using its high compression
technology. Therefore, every digital channel
number consists of a main channel and a
sub
-
channel number.
NOTE:
• If you do not have a particular sub-channel
number you want to select, enter the main
channel number and then press [OK]. (If
the main channel number is ldigit, you
should press [OK] twice.) The STB
automatically tunes in to the lowest sub-
channel for the selected main channel.
• Press [ALT. CH] to return to the
previously viewed channel.
• "NO SIGNAL" appears after the sub-
channel broadcast is over. Change the
channel to continue watching.
The channel banner provides you with
information on the channel you have
selected.
1 Press [DISPLAY] to display the
channel banner.
-►:changes
automatically
^>: changes manually
by
using
[CH+/
-
].
This section tells you how to
select the
desired digital channel on the STB.
NOTE:
• Before you begin, make sure you
complete the autoscan in "SETUP
WIZARD" or in "SETUP" menu.
When Using [CH+/-]:
• Press [CH + ] to tune a higher channel
number.
• Press [CH —] to tune a lower channel
number.
When Using the Number Buttons:
1. Enter the main channel number.
If the main channel number is 1 digit,
press [.] when finish entering.
If the main channel number is 2 digits,
proceed to step 2.
2. Enter the sub-channel number.
If the sub-channel number is 1 digit,
press [OK] when finish entering. (You
do not need to press [OK] if the sub-
channel number is 2
digits.)
Information
Icons
LOCK:
Indicates that the current program is
blocked according to your v-chip
setting.
CC (Closed Caption):
Indicates that the program being
broadcast is available with closed
captioning.
BASIC OPERATION
Page
12
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

You can change languages when the
channel
provides alternate languages.
1 Press [AUDIO] repeatedly.
•
Audio language changes as follows.
Electronic Program Guide (EPG) is
the electronic
equivalent of a printed TV program guide.
You can view a list of programs scheduled for the
next few hours.
To display the correct information on "EPG", "TIME
ZONE" and "D.S.T" must be set correctly.
1 Press [EPG] while watching TV.
NOTE:
• "OTHER" is indicated when the
language is not English, Spanish or
French.
• For international stations audio language
will still be displayed as English.
You can freeze the image shown on the TV
screen.
1 Press [STILL].
• The image shown on the screen will be
paused.
• The sound output will not be paused.
• If "NO SIGNAL" is detected or
protected signal is received during still
mode, the image remains paused and
the sound output will be muted.
To cancel still mode, press any
button except [STANDBY-ON].
NOTE:
• If the TV is left on STILL for a long
period of time, the still image may
cause a burn-in effect damaging the
TV screen.
2 Select the desired program
using [-«/►]■
3 Press [EPG] to remove the EPG.
NOTE:
• "EPG" will be cleared after 5 minutes.
• For channel numbers with blank
description, the broadcasting station
may not provide signals for "EPG".
• When the program description consists
of more than 4 lines, use [A / T] to scroll
up/down in the list.
#
ADVANCED OPERATION
Adding/Deleting Channels I
5 Press [OK] again to add the channel
to the channel map.
E.g., adding channel 6
Page
13
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

3 Select "ADD/ DELETE" using
[
A
/
Y], then press
[OK].
To continue adding:
Repeat steps 4 and 5.
6 Press [SETUP] to exit "SETUP" menu.
Delete
Follow steps 1-3 in "Adding/Deleting
Channels" on this page.
4 Select "DELETE" using [A/ Y],
then press
[OK].
Add
4 With "ADD" selected, enter the main
channel number you want to add,
then press [OK] or wait for a few
seconds to fix the number.
If the main channel number is 1 digit,
press [0] first.
NOTE:
• Entering sub-channel number is not
required.
ADVANCED OPERATION
5 Select the channel number you want
to delete from the channel list on the
right using [A/ Y], then press [OK].
E.g., deleting channel 26.
5 Adjust the antenna's direction to
get the best reception.
• A status bar stretches to the right
according to the signal strength.
• The value will be indicated on the
left of the status bar so that you can
adjust the
antenna.
•
The selected channel is now
deleted.
To continue deleting:
Repeat step 5.
NOTE:
• x\ / ^^ : Indicates that there are more
channels above or below.
6 Press [SETUP] to exit "SETUP" menu.
You can verify the signal strength of each
channel to get a clearer picture.
1 Select a channel to adjust using
To adjust other
channels:
Select the channel with [CH + /—],
then adjust it. To cancel during
adjustment: Press [SETUP] or [OK],
6 Press [SETUP] to exit "SETUP" menu.
STB can get available digital channels automatically.
Autoscan receives available digital
channels and stores them in a channel
map. These channels can then be selected
using
[CH
+/
—
].
Page
14
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

the number buttons or [CH +/—].
2 Press [SETUP] to display
"SETUP" menu.
3 Select "CHANNEL" using [A/ T],
then press [OK].
4 Select "ANTENNA" using [A/ T],
then press [OK].
CAUTION:
• If autoscan is skipped, digital channels
may not be received correctly.
1 Press [SETUP] to display
"SETUP" menu.
2 Select "CHANNEL" using [A/ T],
then press [OK].
3 Select "AUTOSCAN" using [A/ T],
then press
[OK].
STB starts receiving the signal for the
channel.
ADVANCED OPERATION
4 Select "AUTOSCAN" using [A/ Y],
then press [OK].
3 Select "DISPLAY MODE" using
[
A
/
Y], then press
[OK].
•
STB starts
receiving available digital
channels and stores them in the channel
map.
• When the scanning is complete,
"AUTOSCAN COMPLETED" will be
indicated.
• After autoscan is complete, press [CH
+ / —] to verify whether STB is
receiving channels properly.
To cancel during
scanning: Press
[SETUP] or [OK].
NOTE:
• If canceled, some channels not yet scanned
may not be received. We recommend
completing autoscan.
• When you want to completely refresh the
channel map, delete all the channels, then
do the autoscan again. See
'Adding/Deleting Channels" on page 17
for details.
When "NO SIGNAL" appears on the
screen:
Verify the antenna connection, then scan
again. The STB tunes in channel 2-1 and
"NO SIGNAL" appears if the STB could
not receive any channels.
4 Select the desired display mode
using [A / Y], then press [OK].
5 Press [SETUP] to exit "SETUP" menu.
Page
15
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

STB allows you to select a display mode to
match the formats of the program being
broadcast on your TV screen.
Display Mode
1 Press [SETUP] to display
"SETUP" menu.
2 Select "DETAIL" using [A / Y],
then press [OK].
ADVANCED OPERATION
INFORMATION on Display Mode
For standard 4:3 TVs displaying
widescreen 16:9 broadcasts, your
choices are:
Time Zone
3 Select "TIME ZONE" using [A/ Y],
then press [OK].
LETTERBOX
Displays the entire picture image
while
fitting the picture to the screen by
applying
gray bars to the top and bottom of the
screen.
No information will be
lost.
ZOOM
Expands the picture image to fill
the screen while cropping some
images on the left and right.
Picture information on the left
and right side will be lost.
FULL
Displays the entire picture image
while fitting the picture to the
screen by stretching the image
vertically, so that it fills the
screen.
No information will be lost, but
there may be a slight distortion of
the picture.
4 Select your time zone using [A/
Y], then press
[OK].
5 Press [SETUP] to exit "SETUP" menu.
D.S.T (Daylight Saving Time)
Follow steps 1-2 in "Setting the Time Zone
and DST" on this page.
3 Select "D.S.T" using [A/ Y], then
press
[OK].
CAUTION:
• If the TV is left in LETTERBOX
mode for a long period of time, the
gray bars may cause a permanent
burn-in effect.
To get the EPG (Electronic Program Guide)
and Channel banner, you will need to set
"TIME ZONE" and "D.S.T" correctly.
1 Press [SETUP] to display
"SETUP" menu.
2 Select "TIME" using [A/ Y], then
press
[OK].
4 Select "ON" or "OFF" using [■+1 ►],
then press [OK].
5 Press [SETUP] to exit "SETUP"
menu.
Page
16
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

ADVANCED OPERATION
See the following description for
setting
each item.
V-chip reads the ratings for programs, then
denies access to the programs which
exceed the rating level you set. With this
function, you can block certain
programming inappropriate for children.
1 Press [SETUP] to display
"SETUP" menu.
2 Select "DETAIL" using [A/ Y],
then press [OK].
3 Select "V-CHIP" using [A/ Y],
then press
[OK].
A
-
"
MPAA Rating"o
this page B... "TV
Rating"o page 22
C... "New
Password" o page
22
NOTE:
• To block any inappropriate
programming, set your limits in "MPAA
RATING", "TV RATING" and
"DOWNLOADABLE RATING".
• "DOWNLOADABLE RATING" will be
available when the STB receives a digital
broadcast using the new rating system.
• If the broadcasting signal does not have
the downloadable rating information,
"Downloadable Rating is currently not
available." will appear. This message will
also appear when you try to access
"DOWNLOADABLE RATING" after
you have cleared the downloadable rating
information, and the new information has
not been downloaded since.
• To clear the downloadable rating
information and its setting, select
"CLEAR DOWNLOADABLE
RATING".
MPAA rating
MPAA Rating is the rating system created by MPAA
(Motion Picture Association of America).
Follow steps 1-4 in "V-Chip Options" on this page.
5 Select "MPAA RATING" using [A/
Y], then press
[OK].
•
Password entry field will
appear.
Proceed to step 4-a if you have not created a
password yet.
Proceed to step 4-b if you have already set a
password.
4-a Enter 4-digit numbers except
4737 as your password using the
number buttons.
CAUTION:
• Do not forget the password. It will be
used as your v-chip access password from
the next time onward.
4-b Enter the password using the
number buttons.
• Asterisk^*) will substitute for your
password.
Select the desired rating using
[A /
Y], then press [OK] repeatedly to
switch between view and
block.
NOTE:
• If you forget the password, enter
"4737" then proceed to "New
Password" on page 22.
• When the password is correct, "V-
CHIP" menu is displayed.
•
When the rating is blocked,
Q
will
appear.
ADVANCED OPERATION
Rating
Category
7 Press [SETUP] to exit "SETUP" menu.
To Set the Sub
Ratings
Page
17
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

X
Mature audience only
higher
T 1
lower
NC
-
17
No one under 17
admitted
R
Restricted; under
17 requires
accompanying
parent or adult
guardian
PG-13 Unsuitable for
children under
13
PG
Parental guidance
suggested
G
General audience
NR
No rating
As for TV
-
MA, TV
-
14, TV
-
PG, or
TV
-
Y7, you can further set the sub ratings to
block specific elements of
programming. To set the sub ratings,
follow the step below.
Press [A/ Y / AI ►] to select the desired
rating or sub rating, then press [OK]
repeatedly to switch between view and
block. Sub rating status will appear
beside the main
rating.
7 Press [SETUP] to exit "SETUP" menu.
NOTE:
• When you select a rating and set it to
block, the higher ratings will be blocked
automatically. The lower ratings will be
available for viewing.
• When you set the highest rating to view,
all ratings turn to view
automatically.
Sub
Rating
Category
Rating
FV Fantasy Violence TV-Y7
VViolence TV-
PG
TV-
14
TV-
MA
SSexual Situation
LCoarse Language
D
Suggestive
Dialogue
TV-PG,
TV
-
14
TV Rating
Follow steps 1-4 in "V-Chip Options" on page
21.
5 Select "TV RATING" using [A/ Y],
then press [OK].
NOTE:
• Changing the main rating to block or view
automatically changes all its sub ratings to
the same (block or view).
NewPassword
When you forget the password or when you
want to change your password, follow the
instructions below.
1 Follow steps 1-3 in "V-Chip
Options" on page 21, then enter
4737 in the password entry field.
2 Select "NEW PASSWORD" using [A/
Y
],
then press
[OK].
6 Select the desired rating using
[
A
/
Y], then press [OK] repeatedly to
switch between view and block.
When the rating is blocked, a will
appear.
Rating
Category
TV
-
MA
Mature audience only
higher
t
1
lower
TV
-
14
Unsuitable for
children under 14
TV-PG Parental guidance
suggested
TV
-
G
General audience
TV
-
Y7
Appropriate for all
children
7 and older
TV
-
Y
Appropriate for all
children
ADVANCED OPERATION
3 Enter the new 4-digit password
using the number buttons.
• Enter password again in "Confirm
password." entry field.
5 Select the desired DTV closed
caption using [A/ Y], then press
[OK].
Page
18
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

DTVCC
OFF
Select if you do
not want DTV CC.
This is the default.
SERVICE1
-
6
Select one of
these before
changing any other
item in "CLOSED
CAPTION" menu.
Choose
"SERVICE1" under
normal
circumstances.
•
Do not forget the
password. It will be
used as your new v-chip access
password from the next time onward.
4 Press [SETUP] to exit "SETUP" menu.
NOTE:
• Make sure new password and confirm
password must be exactly the same. If
they are different, the space is cleared for
reentering.
DTV has its own closed caption called DTV
CC. Use this menu to change the settings for
DTV CC.
1 Press [SETUP] to display
"SETUP" menu.
2 Select "DETAIL" using [A/ Y],
then press [OK].
3 Select "CLOSED CAPTION"
using [▲/ Y], then press [OK].
6 Press [SETUP] to exit "SETUP" menu.
NOTE:
• "DTV CC" that you can switch differs
depending on the broadcast description.
CC Style
You can switch on or off the CC style feature.
1 Press [SETUP] to display
"SETUP" menu.
2 Select "DETAIL" using [A / Y],
then press [OK].
3 Select "CLOSED CAPTION"
using [A / Y], then press [OK].
4 Select "CC STYLE" using [A/ Y],
then press [OK].
5 Select "MANUAL" using [A/ Y],
then press
[OK].
4 Select "DTV CC" using [A/ Y],
then press [OK].
If you select "AUTO", the original
CC
style set by the broadcast station will be
applied.
ADVANCED OPERATION
CC Style Edit
You can edit the style of CC such as font,
color or size, etc. This feature is available
only when "CC STYLE" is set to
"MANUAL".
1 Repeat steps 1 to 3 in "Closed
Caption Options" on page 23.
2 Select "CC STYLE EDIT" using [A/
Y], then
press [OK].
[Back Color]
Background color of the displayed
caption can be switched.
[Back Opacity]
Background opacity of the displayed
caption can be switched.
[Edge Color]
Edge color of the displayed
caption can be switched.
[Edge Type]
Edge type of the displayed caption
can be switched.
4 Press [SETUP] to exit "SETUP" menu.
The auto power down can be set to
automatically turn off the STB after an
incremental period of time. Default setting is
4 hours. (The EPA (U.S. Environmental
Protection Agency) recommends using this
setting to conserve
energy.)
3 Select an item using [A/ Y], then
press [OK]. Then use [A/Y] to select
the desired setting and press
[OK].
Page
19
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht

1 Press [SETUP] to display
"SETUP" menu.
2 Select "DETAIL" using [A / Y],
then press [OK].
3 Select "AUTO POWER DOWN"
using [A/Y], then press [OK].
Picture display
Edge
(Edge Color and Edge Type)
Font (Font Style, Font Size, Font
Color and Font Opacity)
Back
(Back Color and Back Opacity)
• The setting description for each item is
shown below.
[Font Style]
Closed Captioning font style can be
changed.
[Font Size]
Font size of the displayed caption can be
switched.
[Font Color]
Font color of the displayed caption can be
switched.
[Font Opacity]
Font opacity of the displayed
caption can be switched.
4 Select desired amount of time
using [A/Y], then press [OK].
•
Select "OFF" to cancel the auto power
down.
5 Press [SETUP] to exit "SETUP"
menu.
__________________________________________________
OTHERS
Before requesting service for this STB, check the table below for a possible cause of the
problem you are experiencing. Some simple checks or a minor adjustment on your part
may eliminate the problem and restore proper
operation.
Symptom
Remedy
No power • Make sure that the AC power cord is securely plugged into
the power outlet.
•
Make sure that the POWER indicator is
lit.
The STB is not
responding to the
remote control
• Make sure to point the remote control at the remote control
sensor.
• You may be too far from STB. Try moving closer.
• Remove any obstacles between the remote control and the
remote control sensor.
• Make sure that the batteries are installed in the correct
direction (+ and -).
•
The batteries may be
depleted. Replace them with new ones.
No picture
• Make sure that the video cable is correctly connected.
• Make sure that video devices (TV or monitor) are turned on.
• Make sure that video devices (TV or monitor) are correctly
set to STB video output channel. Refer to your TV's manual
for further information.
• Check the video cable.
• Check the antenna and the RF cable. There may be damage
or interfering
sources.
Blocked noise on picture
•
There may be interfering
sources.
No EPG or the
provided information
is wrong
• Make sure that "DST" and "TIME ZONE" is set correctly in
"TIME" menu or in "SETUP
WIZARD".
No sound
• Make sure that the audio cable is correctly connected.
• Make sure that audio devices (stereo, TV or decoder) are
turned on.
• Make sure that audio devices (stereo or decoder) are
correctly set to STB audio output channel.
• When TV has only one audio input jack, use a standard audio
cable (white) to connect the audio output jack (white) on STB
to the audio input jack on the
TV.
Low volume
• Sound volume differs depending on the audio out setting.
Select "RF OUT" at step 5 in the "Setup Wizard" on page 13 if
you feel the volume is too
low.
•
Make sure to
complete autoscan in "SETUP WIZARD"
Page
20
of
25
TB100MW9 DTV Digital to Analog Converter (Set Top Box)
4/6/2009
mhtml:file://N:\WEBSITE\DTV Converter Box Manuals\Magnavox TB100MW9.mht
