Maguire Products VBD-50 Owner's manual

MAGUIRE PRODUCTS INC.
VBD-50 Vacuum Batch Dryer
VBD-50
Maguire Vacuum Batch Dryer 
INSTALLATION •OPERATION •MAINTENANCE
Copyright Maguire Products, Inc. 2008

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50
2
VBD- Vacuum Batch Dryer

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50 3
VBD- Vacuum Batch Dryer
VBD-50 - Vacuum Batch Dryer 
Copyright
2009 Maguire Products Inc.
The information contained within this manual including any translations thereof, is the property of
Maguire Products Inc. and may not be reproduced, or transmitted in any form or by any means
without the express written consent of Maguire Products Inc.
To every person concerned with use and maintenance of the Maguire VBD-50it is
recommended to read thoroughly these operating instructions. Maguire Products Inc. accepts no
responsibility or liability for damage or malfunction of the equipment arising from non-observance
of these operating instructions.
To avoid errors and to ensure trouble-free operation, it is essential that these operating
instructions are read and understood by all personnel who are to use the equipment.
Should you have problems or difficulties with the equipment, please contact Maguire Products
Inc. or your local Maguire distributor.
These operating instructions only apply to the equipment described within this manual.
Manufacturer’s Contact Information
Maguire Products Inc.
11 Crozerville Road
Aston, PA. 19014
Phone: [phone]
Fax: [phone]
Website: http://www.maguire.com
Email: [e-mail]

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50
4
VBD- Vacuum Batch Dryer
Accuracy of this Manual
We make every effort to keep this manual as correct and current as possible.
However, technology and product changes may occur more rapidly then the
reprinting of this manual. Generally, modifications made to the dryer design or to
the operation of the software are may not reflected in the manual for several
months. The date at the footer of this manual will indicate approximately how
current this manual is. Likewise, your Dryer may have been produced at an
earlier time and the information in this manual may not accurately describe your
Dryer since this manual is written for the current line of Dryers in production (as of
the date in the footer). We always reserve the right to make these changes
without notice, and we do not guarantee the manual to be entirely accurate. If you
question any information in this manual, or find errors, please let us know so that
we may make the required corrections or provide you with accurate information.
Additionally we will gladly provide you with an updated copy of any manuals you
need at any time. We welcome comments and suggestions on ways we can
improve this manual.
For additional information, or to download the latest copy of this manual or any
other Maguire manual, please visit our website or contact us directly.
On the Web at: www.Maguire.com
Maguire Products Inc.
Main Headquarters
11 Crozerville Road
Aston, PA 19014
Tel: [phone]
Fax: [phone]
Email:
[e-mail]
Maguire Europe
Tame Park
Tamworth
Staffordshire
B775DY
UK
Tel: + 44 1827 265 850
Fax: + 44 1827 265 855
Email:
[e-mail]
Maguire Products Asia PTE LTD
45 Kallang Pudding Road
#01-02 Alpha Building
Singapore 349317
Tel: [phone]
Fax: [phone]
Email:
[e-mail]
Maguire Italy
Via Zancanaro 40
35020 Vigorovea (PD)
Tel: [phone]
Fax: [phone]
Email:
[e-mail]
Please e-mail comments and suggestions to: [e-mail]

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50 5
VBD- Vacuum Batch Dryer
Table of Contents
PART 1 GETTING STARTED, READ THIS PAGE 6
1.1 5 Year Warranty and Disclaimers 7
1.2 SAFETY Warnings 8
PART 2 INSTALLATION 9
2.1 Transport and Setup 9
2.2 Dryer Installation 10
2.2.1 Compressed Air Connection 10
2.2.2 Electrical Connection 11
PART 3 OPERATION 12
3.1 Standard Operation 12
3.2 Standard Operating Sequence 12
3.3 Recommended Cycle Times 13
3.4 Dryer Overview 14
3.5 Controller & Operator Station 15
PART 4 MAINTENANCE AND SERVICE 26
4.1 Cleaning the Fill Hopper 26
4.2 Cleaning the Heat Vac Vessel 27
4.3 Cleaning the Retention Hopper 27
4.4 Drain and purge Air Filter / Regulator 28
4.5 Air Pressure Adjustments 28
4.6 Updating Dryer Software 29
PART 5 TROUBLESHOOTING 30
5.1 Alarms – Cause and Solution 30
5.2 Print Outputs 31
5.3 Dryer Software – Factory Reset 33
PART 6 General Information
6.1 - Theory of Operation / Performance 34
6.2 - Warranty 35
6.3 – VBD Diagram & Supplements 36
6.4 - Technical Support / Contact Information 39

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50
6
VBD- Vacuum Batch Dryer
1 - Getting Started – READ THIS PAGE
PLEASE READ THIS PAGE
You don't have to read the entire manual....
BUT...
PLEASE READ THE NEXT FEW PAGES.
It will take about 10 minutes.
THESE PAGES COVER:
Warranty and Disclaimers: What we Warranty and
what we cannot promise.
SAFETY Warnings: Safety warnings.
INSTALLATION: Assembly and setup.
OPERATION: What buttons to push.
GETTING STARTED:
PROCEED TO: WARRANTY AND DISCLAIMERS NEXT PAGE

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50 7
VBD- Vacuum Batch Dryer
1.1 - Warranty – Exclusive 5-Year
MAGUIRE PRODUCTS offers THE MOST COMPREHENSIVE
WARRANTY in the plastics auxiliary equipment industry. We
warrant each MAGUIRE VBD – Vacuum Batch Dryer
manufactured by us to be free from defects in material and
workmanship under normal use and service; excluding only those
items listed below as 'excluded items'; our obligation under this
warranty being limited to making good at our factory any Dryer
which shall, within FIVE (5) YEARS after delivery to the original
purchaser, be RETURNED intact to us, transportation charges
PREPAID, and which our examination shall disclose to our
satisfaction to have been thus defective; this warranty being
expressly in lieu of all other warranties expressed or implied and of
all other obligations or liabilities on our part, and MAGUIRE PRODUCTS neither assumes nor authorizes
any other persons to assume for it any other liability in connection with the sale of its Dryers.
This warranty shall not apply to equipment repaired or altered outside MAGUIRE PRODUCTS INC.
factory, unless such repair or alteration was, in our judgment, not responsible for the failure; nor which
has been subject to misuse, negligence or accident, incorrect wiring by others,
or installation or use not in accord with instructions furnished by
Maguire Products, Inc.
Our liability under this warranty will extend only to equipment that is returned to our factory in Aston,
Pennsylvania, PREPAID.
Please note that we always strive to satisfy our customers in whatever manner is deemed most expedient
to overcome any problems they may have in connection with our equipment.
GETTING STARTED:
PROCEED TO: SAFETY WARNINGS NEXT PAGE

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50
8
VBD- Vacuum Batch Dryer
1.2 – SAFETY WARNINGS
HOT SURFACES:
As with all dryers, there are HOT SURFACES to avoid. Temperatures
can reach 350F, (180C) on high temperature models.
Typically these surfaces are not at dangerous temperatures, however
all hot surfaces should be avoided.
Warning Label indicate HOT SURFACES
USE CAUTION when removing and installing canisters.
USE GLOVES.
DO NOT REACH into the dryer enclosure.
RISK OF SHOCK:
Disconnect power supply before servicing the Dryer.
GETTING STARTED: PROCEED TO: INSTALLATION - NEXT PAGE

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50 9
VBD- Vacuum Batch Dryer
2 - Installation
2.1 - Transport and Setup
Shipment
The VBD-50 Dryer is shipped pre-assembled and
bolted to a pallet with 4 bolts.
Lifting and Moving Dryer
The VBD Dryer can be lifted by forklift only if it is
securely attached to a pallet. Once removed from
the pallet, the dryer should only be rolled using the
dryer’s castors.
Do not lift the VBD Dryer directly
with a forklift or damage may
occur to the Dryer’s retention
Hopper located at the bottom of
the Dryer.

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50
10
VBD- Vacuum Batch Dryer
2.2 - Dryer Setup
Once unbolted from the pallet, installation requires only electrical connections, pneumatic air
line connection and intake and output material lines to be connected.
2.2.1 - Compressed Air Connection
Connect an air supply to the air regulator’s IN port using a
male ¼ ” NPT fitting.
An operating air pressure of 80 psi (5.5 bar) while the
vacuum generator is running is required for proper
operation of the Dryer.
If your air supply has oil in it, add an oil separator
(coalescing filter).
Oil in the air will combine with dust drawn from the canisters forming a paste
inside the vacuum generator. It will stop working and require cleaning.
Observe the air pressure gauge to be sure the pressure maintains 80 psi (5.5 bar)
while the vacuum generator is running as you check and adjust the regulator. If
pressure drops below 80 psi, adjust the regulator. If the pressure cannot be
maintained at 80 psi (5.5 bar) while the vacuum generator is running, then the air
supply line is not adequate.
Do not supply Dryer with a lubricated air supply.
Damage to Dryer may result. Use only a clean,
dry, oil-free air supply.

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50 11
VBD- Vacuum Batch Dryer
2.2.2 - Electrical Connection
RISK OF INJURY! Only qualified technicians should
make electrical connections.
Connect Main Power
The electrical cable located on the left side of the Dryer on
the power box supplies the power to the Dryer. Within the
cable is four wires. Three of the wires are black and labeled
with a number: 1, 2, and 3. The fourth wire is a green/yellow
wire and is the ground wire.
See Wiring Diagrams on page 36 for wiring details.
THREE PHASE: 60 cycle 480 volts or 50 cycle 400 volts
Confirm Correct 3-Phase Electrical Connection
THREE PHASE Unit - CONFIRM proper 3-Phase power connection by
following these instructions:
Turn power on using main power switch.
On the outside of the electrical box below
the power switch is a red 3-Phase
indicator light. If 3-Phase power is
correctly connected, the controller will
power up and the red indicator light will
NOT be lit.
If 3-Phase is not correctly connected, the
red 3-Phase indicator light located on the
outside of the electrical box below the
power switch will be ON indicating in-
correct 3-Phase wiring. Power off the
Dryer and reverse any two leads.
PROCEED TO: OPERATION NEXT PAGE

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50
12
VBD- Vacuum Batch Dryer
3 - Operation
3.1 - Standard Operation
1. Ensure all hatches are closed
2. Load material into the hopper’s primary compartment (larger forward compartment of hopper).
3. Turn on Main Power
4. Adjust your settings. LED indicators located below the Select button on the control panel will
indicate the setting you are currently adjusting. The display to the right of the Select button will show
the value of the selected setting. Pressing the Select button toggles between Process Temperature,
Heat Time and Vacuum Time. Up/Down arrow buttons adjust the highlighted setting.
Process Temperature - The first setting in the list is Process Temperature. Confirm or adjust your
desired Process Temperature using the Up/Down arrows. Refer to the “Recommended Heat Times
and Temperatures” table in this manual. Temperature adjusts in 5 degree increments.
Heat Time - Press Select to toggle the display to show Heat Time. Adjust if necessary using the
Up/Down arrows. Refer to the “Recommended Heat Times and Temperatures” table in this manual.
Heat time is adjustable in 1-minute increments. Default heat time is 20 minutes.
Vacuum Time - Pressing the Select button once more will display the Vacuum Time. Adjust
Vacuum Time if necessary using the Up/Down arrows. Vacuum time is adjustable in 1-minute
increments. Default is 20 minutes.
5. When your adjustments have been made, Press the “Start“button.
3.2 – Standard Operating Sequence
This section will help you understand what the dryer is doing after you press the Start button.
6. Dryer display will say: STRT on the upper display and your desired Process Temperature (Set-Point)
on the lower display. As the Fill hopper dispenses material into the Heat/Vacuum Vessel the upper
display will say FILL. As the Dryer heats the material, the upper display will say HEAT. During the
heat process, the process temperature will display. During the ramp up of the temperature, the
Process Temperature LED flashes until the actual temperature is within 2 degrees of the set point.
7. Once the temperature is within 20 degrees of the set point temperature, the Heat Time begins to
count down the Target Heat Time.
8. When the Heat Time elapses the heater shuts off, and after a short delay, the dryer begins to pull a
vacuum. When the absolute pressure within the vessel reaches 100mm of mercury, the Vacuum
Timer will start.
9. When the vacuum timer elapses to zero, the vacuum will be released and the material will be
dispensed in to the retention hopper. If material covers retention hopper level sensor, the dryer will
continue to hold a vacuum on the material within the vessel until the retention hopper level sensor is
uncovered.
10. While the material is being dispensed into the retention hopper the display will say DUMP.
11. After the material has been dispensed into the retention Hopper the current cycle ends and a new
cycle begins.

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50 13
VBD- Vacuum Batch Dryer
3.3 – Recommended Heat Times and Temperatures
MATERIAL FINAL
MOISTURE % * HEAT TIME (MINUTES)**
DRYING TEMPERATURE***
ºC ºF
ABS 0.10 30 - 35 80 - 85 180 – 190
ABS/PC 0.02 35 - 40 100 210
LCP 0.02 30 - 60 150 300
PA 0.20 - 0.10 30 - 40 80 - 85 180 – 190
PBT 0.02 30 - 35 120 250
PC 0.02 30 - 35 125 250
PC/PBT 0.02 30 - 35 125 250
PEEK 0.20 - 0.10 35 - 40 150 300
PEI 0.02 30 - 50 150 300
PES 0.05 - 0.02 35 - 40 150 300
PET (Molding Grade) 0.010 30 - 45 150 300
PET (Preform, Extrusion) 0.005 30 - 45 150 300
PMMA (Acrylic) 0.02 - 0.04 40 85 185
POM (Acetal) 0.20 - 0.10 45 80 - 110 180 – 230
PPO 0.02 45 100 - 120 210 – 250
PPS 0.02 45 150 300
PUR 0.02 45 125 - 140 260 – 280
PSU 0.02 35 - 40 150 300
SAN 0.20 - 0.10 30 - 50 80 180
* Final moisture content as recommended by the raw material manufacturer.
** Recommended heat time is based on average initial moisture content. For high initial
moisture content cycle time should be extended 5 minutes. When in doubt contact Maguire
Service.
*** Drying temperature as recommended by the material manufacturer.
Drying is accomplished when all material reaches the proper temperature, and is then
placed under sufficient vacuumfor a sufficient period of time.
Measurement of moisture content of material, both prior to and after drying, is
accomplished by using a moisture analyzer such as one manufactured by Arizona
Instruments.

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50
14
VBD- Vacuum Batch Dryer
3.4 - Dryer Overview

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50 15
VBD- Vacuum Batch Dryer
3.5 – Controller & Operator Station
Control Panel Overview
The VBD control panel is divided into 3
areas. The upper area contains the Start
button and LED, Shutdown Button and LED
and the upper display. The middle area,
highlighted in red, is the Operator Input area.
The lower area is the Operation LED
indicators that display what the dryer is
currently doing.
Upper Region of Display
START Button
Press to START the cycle.
Lights when the unit is running automatically.
Red LED light to indicate when Dryer is running.
LED must be ON solid (not blinking) to start the drying process.
Holding the START button down for 2 seconds toggles the upper display
to show the current temperature within the vessel.
SHUT DOWN Button
Press SHUT DOWN to end the cycle.
Shut Down LED is on when the unit has been stopped by the operator or
has stopped between cycles in the "clean out" mode.
DISPLAY
All status information will be shown on this display.

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50
16
VBD- Vacuum Batch Dryer
Center Region of Display
SET Region
This region of the display allows adjustment to Process Temperature,
Heat Time and Vacuum Time. Adjustments are made using the UP
and DOWN arrow buttons. This region also displays the current
pressure during the vacuum cycle and is indicated by the Vacuum Level
LED.
Press SELECT to toggle through Process Temperature (F or C), Heat
Time (minutes), Vacuum Time (minutes), Vacuum Level (mm Hg). The
+, - and SELECT buttons are also used to navigate parameters and other
menu items.
Process
Temperature Temperature that the Dryer will heat the air to. Default is set to “150 F“.
Adjustable using the UP (+) and DOWN (-) arrow buttons. Can be
adjusted during operation. Fahrenheit or Celsius.
Heat Time
(minutes) Amount of time that the heated air will pass through material contained
within the heat/vac vessel. Default Heat Time is 20 minutes. Range in
minutes is 001 – 999. Adjustments are in 1-minute increments.
Vacuum Time
(minutes) Amount of time that the heat/vac vessel holds a vacuum after the heating
process. Default is 20 minutes at 65-75 mm of mercury absolute
pressure.
Vacuum Level
(mm Hg) 65-75 mm of mercury absolute pressure.
(Display only, no adjustment)
Lower Region of Display
Operation
The Operation LEDs display only when the dryer is in a running mode
(Start LED is on). These LEDs indicate what the dryer is currently doing.
Blower ON – On when blower is moving heated air through the vessel.
Heater ON – On when heater is heating air.
Heat/Vac Level Sensor – On when the upper senor in the heat/vac
vessel is covered by material. Indicates vessel is full of material.
Retention Hopper Level Sensor – On when lower sensor at the base of
the retention hopper is covered indicating there is material in the
retention hopper. This sensor must be uncovered before material will
dump from the heat/vac vessel into the retention hopper.

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50 17
VBD- Vacuum Batch Dryer
Strobe Light
Beeper Alarm
Silence Alarm Button
This button silences the STROBE and BEEPER ALARMS, but does not
remedy the cause of the alarm. Press once to silence. Press twice to
clear the display of the alarm message.
STROBE LIGHT and BEEPER ALARMS
The Strobe light flashes and the Beeper sounds when any condition
occurs requiring operator intervention.
USB PORT
This is a USB port. It allows information to be ported directly to a USB
Flash Drive giving the benefit of a permanent digital record.
Three printouts are available:
1. A listing of the internal parameter table.
2. A periodic printout of temperature, vacuum reading, and
elapsed cycle time. There is a detailed explanation of
this printout in the PRINTED OUTPUTS section of this
manual.
3. A listing of the alarm log.
See Print Outputs on page 31 for more information about
printouts.
The USB port can also be used to update the controller’s
software. For information about updating the controller software
see Updating Controller Software.
Notes about printing to a USB drive
When saving printout information to a USB drive, the USB drive must
contain a folder named maguire. A file labeled EVENTLG.TXT will
be created for Event Logs. Also note that every time a print occurs, if
these files exist in the maguire folder on the USB drive, the data is
appended to the end of the file and does not overwrite existing data
within the file.

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50
18
VBD- Vacuum Batch Dryer
Program, Clean and Run Modes
Run Mode Run Mode is the mode for standard dryer operation. You must be in run
mode to start a cycle.
Clean Mode Clean Mode opens valves and locks out Run mode operation to allow the
dryer to be manually emptied of all material.
Program Mode Program Mode allows modification of Parameters and settings.
Run, Clean and Program modes can be accessed by holding the SHUT DOWN button and pressing the
SELECT button.
Press and hold the “SHUT DOWN”
button,
then press the “SELECT” button.
Display will show:
MODE
RUN
Press the UP or DOWN arrow button to toggle through Run, Program and Clean modes.
These Modes display as: RUN, CLEN, PRGM
Run Mode: Run Mode is the mode for standard dryer operation.
Display will show:
To enter Run mode toggle to RUN
then press:
Lower display will show
Setpoint temperature:
FILL
345F
Clean Mode: Clean Mode is the mode to use if you need to the remove material from the dryer. See
Cleaning the Heat / Vac Vessel and Cleaning the Retention Hopper for more details on page 27.
Display will show:
To enter Clean mode toggle to CLEN
then press:
Lower display will alternate
between PRES (Press) and
STRT (Start button)
CLEN
PRES
Program Mode: Program Mode gives the user access to parameters, test routines, preferences,
password, firmware updates, reports and logs.
To enter Program mode toggle to PRGM
then press:
Display will
show:
PASS
0000
This is prompting
for the password.
See next section
for how to use
Program Mode.

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50 19
VBD- Vacuum Batch Dryer
Program Mode
Program Mode gives the user access to parameters, test routines, preferences, password,
firmware updates, reports and logs. To change most program options and test mode options,
the machine must be stopped.
Press: the “START” button to enter Program
Mode. The user is prompted for a
password. The default password is
2222.
The display will show:
PASS
0000
Press:
the arrow buttons to
set the blinking digit in
the lower display to
enter the password.
Press SELECT to toggle to the next
digits and enter those digits using the
arrow buttons. Default password is
“2222”. Incorrect password displays
INVD PASS (invalid password)
2222
You are now in Program Mode. Upper display will show:
SETP
PARA
Pressing:
The display will toggle through a list of test routines, preferences, password,
firmware update, reports, logs and then back to parameters. An explanation of
each is below. To enter any of these Modes, the “START” button. Press the
“SHUT DOWN” Button to exit any of these modes.
Pressing:
the “SHUT DOWN” button to exit the current selection.
Pressing: SHUT DOWN again to return to RUN Mode.
Program Mode Options:
SETP
PARA
Edit Parameters - Pressing the “START” button while PARA is displayed will
enter the Parameter Edit Mode. A Full Explanation of all Parameters as
well as how to Edit Parameters is covered in the Parameter section of
this manual on page 22. This section covers other Program Mode options.
Continue below for an explanation of each Program Mode option.
SETP
PARA
TEST
HEAT Test Mode for Heater – This mode tests the dryer’s ability to control the
temperature of the hot air. Press the “START” button to enter TEST HEAT
Mode. The Blower will start, then the Heater will turn on. The dryer will
attempt to reach and hold the Target Temperature. Press the “SHUT
DOWN” Button to end and exit the heater test mode.
TEST
HEAT
TEST
VAC Test Mode for Vacuum – This mode tests the dryer’s ability to pull and hold
a vacuum. Press the “START” button to enter TEST VAC Mode. The
vacuum will start. The dryer will attempt to reach and hold the Target
vacuum pressure. Press the “SHUT DOWN” Button to end and exit the
vacuum test mode.
TEST
VAC

Maguire Products, Inc.
Edition: May 27, 2009 – VBD-50
20
VBD- Vacuum Batch Dryer
SETP
TEMP
Setup Temperature Format – This toggles all displays and logs of
temperature between Celsius (CELC) and Fahrenheit (FAHR) and also
allows adjustment of increments in degrees (1 degree or 5 degree). Press
the or to toggle between Celsius (CELC) and Fahrenheit (FAHR).
Press the “Select” on the desired format to further display the increments in
degrees. Press the or to toggle between ADJ.5 (5 degree temperature
increments or ADJ.1 (1 degree temperature increments). Press the “SHUT
DOWN” Button to choose the format and exit.
SETP
TEMP
SETP
PRES
Setup Pressure Format – This toggles all displays and logs of Pressure
between Absolute (ABS) and Differential (DIFF) pressure. Press the or
to toggle between Absolute (ABS) and Differential (DIFF) pressure. Press
the “SHUT DOWN” Button to choose the format and exit.
SETP
PRES
SET
TIME
Setup Time – This toggles through the complete Date and Time allowing
adjustment of year, month, day, hour, minute, seconds. Press the “SELECT”
button to choose a field to edit then press or to adjust. Press the
“SHUT DOWN” Button to save and exit.
SET
TIME
CHNG
PASS
Change Password – This setting allows the password to be changed.
Press the “START” button to change the password. The user will be
prompted for the OLD password. Press SELECT to toggle to the next digits
and enter the password digits using the arrow buttons. Default password is
“2222”. Incorrect password displays INVD PASS (invalid password). After
entering the OLD password, the user will be prompted for a new password.
Enter the new password using the arrow buttons, using the Select button to
navigate to the next digit. Pressing Select on the final digit will save new
password. Pressing the “SHUT DOWN” Button will entering the new
password will cancel entry of the new password.
CHNG
PASS
DISP
VERS
Display Version – Press the “START” button to display the VBD Dryer’s
software version. DISP
VERS
UPDT
FIRM
Update Firmware – This allows for software updates to be applied to the
VBD Dryer. Pressing the “START” button causes the VBD Dryer to search
for new software versions on a USB Drive plugged into the USB port. Press
or to choose a version if multiple software versions exist on the USB
drive. Press the “SELECT” Button to choose and load the displayed software
version. See Updating Dryer Software Section for More information.
UPDT
FIRM
PRNT
OUTS
Print Outs - This enters a submenu of reports, printouts and logs as well as
an option to clear logs. Press the “START” button to enter the report
submenu. See Print Outputs on page 31 for more information about
printouts.
PRNT
RPRT
PRNT PARA Print Parameter Table – This prints the currently loaded
parameters to a USB Drive inserted in the Dryer’s USB port. The
Dryer will look for a file named PARALG.TXT located on the USB
drive within a folder named MAGUIRE (this folder is required to
be on the drive). If the file PARALG.TXT is not found on the
drive, it will be created. If it exists, new data will be appended to
the end of the file. Press the “START” button to create the
parameter printout.
PRNT
PARA
