Maguire Products GRAVIMETRIC AUGER FEEDER MGF-ST User guide

MAGUIRE PRODUCTS INC.
GRAVIMETRIC AUGER FEEDER
MAGUIRE
Model MGF-ST
Standard Controller
GRAVIMETRIC AUGER FEEDER
INSTRUCTION MANUAL
Original Instructions Manual
Revision Date:
February 1
2
, 20
20
Copyright  Maguire Products, Inc. 2020

M A G U I R E P R O D U C T S , I N C .
2
G R A V I M E T R I C A U G E R F E E D E R 
Use this space to record information about your Maguire Machines:
Serial Number
Date of Purchase
Model Number
ID
IP Address
Notes:

M A G U I R E P R O D U C T S , I N C .
3
G R A V I M E T R I C A U G E R F E E D E R 
Maguire Products Inc.
Model MGF-ST
GRAVIMETRIC FEEDER
Table of Contents
Features _____________________________________________________________ 5
Assembly and Installation Instructions ___________________________________ 6
MGF Menu Navigation and Overview _____________________________________ 8
Description of Controls ________________________________________________ 7
Software Setup (First Time Setup) ______________________________________ 10
Startup Instructions __________________________________________________ 13
Normal Operation ____________________________________________________ 14
Alarms and Troubleshooting ___________________________________________ 15
Troubleshooting Controller Problems ___________________________________ 15
Troubleshooting Loss of Color _________________________________________ 15
Settings Menu Explained ______________________________________________ 18
Print Options ________________________________________________________ 23
Parameters _________________________________________________________ 27
Updating the MGF Firmware ___________________________________________ 32
Rate Adjust Reset ____________________________________________________ 33
Set Model ___________________________________________________________ 33
View / Reset Totals ___________________________________________________ 34
MGF Defaults ________________________________________________________ 34
Diagnostic Screen ___________________________________________________ 35
Optional Loader Installation ___________________________________________ 36
AGL Loader Diagram _________________________________________________ 37
MGF Wiring Diagram _________________________________________________ 41
Parts diagram / Dimensions ___________________________________________ 45
Principle of Feeder Operation __________________________________________ 48
Principle of Controller Operation _______________________________________ 48
Warranty ___________________________________________________________ 49
Technical Support and Contact Information ______________________________ 50

M A G U I R E P R O D U C T S , I N C .
4
G R A V I M E T R I C A U G E R F E E D E R 
Copyright  2020 Maguire Products Inc.
The information contained within this manual including any translations thereof, is the property of
Maguire Products Inc. and may not be reproduced, or transmitted in any form or by any means
without the express written consent of Maguire Products Inc.
To every person concerned with use and maintenance of the Maguire Gravimetric Feeder (MGF) it is
recommended to read thoroughly these operating instructions. Maguire Products Inc. accepts no
responsibility or liability for damage or malfunction of the equipment arising from non-observance of
these operating instructions.
To avoid errors and to ensure trouble-free operation, it is essential that these operating instructions
are read and understood by all personnel who are to use the equipment.
Should you have problems or difficulties with the equipment, please contact Maguire Products Inc. or
your local Maguire distributor.
These operating instructions only apply to the equipment described within this manual.
Manufacturer’s Contact Information
Maguire Products Inc.
11 Crozerville Road
Aston, PA. 19014
Phone: [phone]
Fax: [phone]
Website: http://www.maguire.com
Email: [email protected]

M A G U I R E P R O D U C T S , I N C .
5
G R A V I M E T R I C A U G E R F E E D E R 
Maguire MGF-ST Features
MGF-ST
Gravimetric
Feeder
Throughput capacity:
Injection molding –
Up to 40.0 lb/hr
(18 kg/hr)
Extrusion –
Up to 120.0 lb/hr
(55 kg/hr)
Full function gravimetric
feeder for the price of a
volumetric model.
Eliminate Waste of Colorants and Additives
This compact loss-in-weight additive feeder precisely measures the amount of additive
that is fed directly into the machine throat to eliminate costly waste.
Standard features:
3 Standard Modes of Operation
Cyclical, Continuous and Extrusion Following
Modes. Rate (volumetic) also available.
Reduces Input Error
The easiest setup procedure in the industry: enter
let-down ratio and either shot weight or lb/hr
output and press start. Feeder automatically
adjusts to screw recovery time and extruder
output.
Fine Metering Resolution
100 rpm Stepper Motor advances at 200
increments per revolution. In combination with
digital control, the 200-step rotation achieves fine
metering resolution of ± 0.2%.
Automatic Re-calibration Ensures
Continuous Accuracy
Automatic adjustments guarantee that feed rate is
held to within ± 0.2% of desired let-down ratio.
Dual Load Cells
Balanced load readings improve accuracy.
Torque-limiting Drive Coupling
Protects drive motor in case of jammed auger.
Easy-to-Use Microprocessor Controller Saves
Time
User-friendly controller has intuitive setup
procedure.
USB Port
Allows data download, data printout and
software update capability.
Detailed Material Usage Documentation
Microprocessor control allows data collection via
G2 networking software, or MLAN protocol via
Ethernet.
Eliminates Downtime Associated with Color
Change
Feeder automatically re-calibrates to new color,
so no additional setup required. Spare hoppers
available for faster color changes.
Exclusive 5
-
Year Warranty

M A G U I R E P R O D U C T S , I N C .
6
G R A V I M E T R I C A U G E R F E E D E R 
ASSEMBLY AND INSTALLATION INSTRUCTIONS
The MGF consists of these assemblies:
1. The Adaptor Frame Assembly
2. The Bar Assembly (for the Controller).
3. The Controller
4. The Load Cell Assembly
5. The Auger Tube Assembly
6. The Hopper Assembly
MOUNT THE ADAPTOR FRAME
1. The ADAPTOR frame mounts directly to the throat under your current natural material hopper.
For proper ORIENTATION, consider the following:
• Orient the Auger Tube Assembly at 90° to the machine barrel.
• Clearance and ease of access for removing the hopper.
• Easy viewing and access to the controller.
• The feeder will hang from the side of the adapter that has the opening into the flow chamber.
2. Locate and drill the proper bolt patterns (top and bottom of the adapter frame). This frame will be bolted
directly to the feed throat of your process machine and the natural material hopper will be bolted on top.
The TOP plate has the ROUND hole.
The BOTTOM plate has the SQUARE hole.
MOUNT THE CONTROLLER
3. The CONTROLLER will be mounted to a bar that bolts on the left side of the adaptor frame. You may also
mount the controller in a remote location and use optional extension cords to connect the motor and load cell.
Be sure that the mounting screws are tight.
HANG THE LOAD CELL ASSEMBLY
4. Hang the Load Cell Assembly from the
side of the frame with the opening into
the chamber. (See photo) Tilt unit. (1)
Slip upper ear behind the corner post.
(2) Slip the lower ear behind the other
corner post. (3) Raise the lower ear up
and rest the load cell assembly into
frame as shown.
INSTALL AUGER TUBE ASSEMBLY
5. Insert the Auger Tube Assembly into Load Cell Assembly and hang onto the two bolt heads.
INSTALL HOPPER ASSEMBLY
6. Place the hopper assembly on the load cell assembly and secure with the hold downs.
PLUG IN ALL CORDS
7. Plug the motor and load cell cables into the Load Cell Assembly.
8. Plug the black power cable into a standard 120-volt (EURO, 230 VAC) outlet.

M A G U I R E P R O D U C T S , I N C .
7
G R A V I M E T R I C A U G E R F E E D E R 
CONNECT SIGNAL CABLE
9. Standard equipped for contact closure applications only, your controller will be equipped with the supplied
cable lead and 5-pin connector. You will also have a 20’ length of cable with a mating 5-pin connector. This
cable will connect to the MGF controller using the connector, and the open end will be wired to your
equipment. The open ends leads should be wired to the screw signal normally open contact closure. When
the screw is retracting contacts will close and then open at the end of the retract. The time closed is used by
the MGF to adjust output. This 5-pin connector is also used with an extrusion following 0-10 volt signal.
See the MGF wiring diagram on page 41.
10. If optionally ordered with 24 to 120 VDC or VAC plug the "SIGNAL" (gray) cord will be plugged into outlet that
is energized only when the screw is turning. Signal voltage can be from 24 to 120 VDC or VAC. The screw
signal on-time can not be less then 1 second. INJECTION time or CLAMP CLOSE time are options.
Description of Controls
1. POWER ON / OFF SWITCH - Turns power on or off. Switch light
is illuminated when MGF is powered ON.
2. RUN / STOP SWITCH - This switch provides a run signal to the
circuit board. For the MGF feeder to run, a screw turning signal
MUST be present, providing power to the screw signal cord, AND
the RUN switch must be in the RUN position. The only exception
is when the PRIME feature is selected. This will operate the auger
without any Run signal.
3. KEYPAD – Used to enter, modify data and settings. Arrow keys
are used to navigate screens. The Enter button selects menu
options and the Back button cancels or takes you back one step.
The View button displays totals, cycles, date and time with the
option to clear totals and cycles by pressing 00 to clear. Pressing
any non-zero number will cause the controller to write totals to a
USB key. There must be a folder named "maguire" on the USB
key for the print job to write the file printer.txt within that folder.
The i (info) button displays the diagnostics screen with real-time
data and averaged and target data. See page 35 for more details
on the diagnostics screen.

M A G U I R E P R O D U C T S , I N C .
8
G R A V I M E T R I C A U G E R F E E D E R 
MGF Menu Navigation and Overview
The MGF menu system is designed to be easy to use
with quick access to commonly adjusted settings as
well as a password protected Settings section for first
time setup and lesser accessed settings and menu
choices. The following page lists all menu sections of
the MGF in the order that they appear. When
navigating the menu, the currently selected item is
indicated by an arrow to the left of the option.
==== MAIN MENU ======
SHOT WT 200
LDR 1.00%
LOAD=== xxxx =SIG:12
Main Screen of MGF
On the right side of the screen, up and down arrows indicate that there are more menu
options above or below the current screen of choices. Navigation, selection and adjustment of
menu options are accomplished by using the arrow buttons on the keypad to navigate and
pressing the ENTER button to select an option. Adjustments to values are accomplished using
the numeric keys on the keypad. Press the BACK button to go back, exit or cancel an action.
On the MAIN MENU screen, LOAD at the bottom left is displayed when the loader is activated.
In the lower right SIG (Signal) is displayed when in Cycle Mode and displays incrementing
seconds of on
-
time.

M A G U I R E P R O D U C T S , I N C .
9
G R A V I M E T R I C A U G E R F E E D E R 
MGF MENU Navigation - 5 Main Menu Options, 2 sub-menus
LBS/HOUR or SHOT WT – Setting Metering Rate or Shot Weight, grams. See page 10
LDR – Let Down Rate, Percent. See page 10
SETUP – Password protected access to options, settings and parameters See below ↓
FILL BIN – Enabled if Loader Operation is ON. Manual fill of the bin (hopper)
PRIME FUNCTION – Primes and calibrates the MGF See page 14
DIAGNOSTICS – Displays information for troubleshooting purposes See page 35
SETUP – Password protected access to MGF Settings (default: 2222) See page 18
SETTINGS – For changing basic setting of the MGF See below ↓
SCALE CALIBRATION – For calibrating the MGF Scale See page 25
COMMUNICATIONS – MLAN ID, View MAC Address, TCP/IP Address, TCP/IP Setup See page 26
LOADER OPERATIONS – Loader On/Off, Loader on/off grams, Loader Alarm See page 26
METERING RATE – Motor Factor, Weight Error, Low Weight See page 26
PARAMETERS – List of adjustable parameters. See Parameter for more information See page 27
PRINT OPTIONS – Parameter printout or time interval printouts to USB drive See page 23
UPDATE FIRMWARE – For updating MGF Firmware See page 32
UPDATE USB CHIP - For updating MGF’s USB firmware See page 32
RATE ADJ RESET – Used to reset the Rate Adjustment back to 1.0000 See page 33
VIEW/RESET TOTALS – Resets material usage totals and cycle counter See page 34
RESTORE DEFAULTS – Restores MGF factory defaults See page 34
SETTINGS
CHANGE PASSWORD – Changing the MGF Password (default: 2222) See page 18
MODE – Configuring to run CYCLE, CONTINUOUS or Extrusion Following mode See page 19
UNITS – Display units as US (Pounds, ounces) METRIC (Kilograms, grams) See page 20
LANG – Language: English, French, Italian, German, Polish, Czech, Spanish See page 20
SET DATE AND TIME – Date format (USA, Europe) and RTC setup See page 21
VOLUMETRIC - Causes the MGF to run at a fixed rate based on current values. See page 22
AUTO STOP – Used for extrusion and continuous. Turning on requires a See page 22
constant contact closure to run. Used normally to run and stop the MGF Feeder
automatically with the extruder. Only available with extrusion following models.

M A G U I R E P R O D U C T S , I N C .
10
G R A V I M E T R I C A U G E R F E E D E R 
SOFTWARE SETUP - FIRST TIME ONLY
Select Mode of Operation – CYCLE, CONTINUOUS, EXTR FLLW
Turn the MGF Power ON. Power button located on lower left side of controller.
View the LCD window. Allow controller to boot up to MAIN MENU.
Press
To scroll down to SETUP (using arrow key)
Press ENTER Display will say:
ENTER PASSWORD _ _ _ _
Enter 2222 Default password is 2222
Press ENTER to enter SETTINGS. Display will show SETTINGS options.
Press
once, scrolling the display down to MODE.
Press ENTER to toggle between CYCLE, CONTINUOUS and EXTR. FLLW
(Extrusion Following) Mode.
Select CYCLE...
for injection molding, where the MGF auger turns on and off with
each cycle. In this mode the first step is to enter the SHOT
WEIGHT of the part on the main screen. Next set the LDR (Let
Down Ratio) on the main screen. In CYCLE mode your MGF will
dispense the calculated rate (shot weight x LDR) during the
length of screw recover time.
Select CONTINUOUS...
for extrusion, where the MGF auger runs continuously. In this
mode the first step is enter LBS (or KILOS) / HOUR of the
extruder on the main screen. Next set the LDR (Let Down Ratio)
on the main screen. In CONTINUOUS mode your MGF will run
continuously at the calculated rate (lbs/hr x LDR). Auger speed
will adjust automatically to maintain dispense rate.
Select EXTR. FLLW...
for extrusion, where the MGF auger runs continuously by
following the 0-10 volt reference voltage of the extruder screw.
In this mode the first step is to set the XMO parameter. Setting
XMO will automatically calculate extruder throughput on the main
screen based on a 0-10 volt reference. See page 27 for XMO.
Next set the LDR (Let Down Ratio) on the main screen. In
Extrusion Following mode your MGF will run continuously at the
calculated rate (lbs/hr x LDR). Auger speed will adjust
automatically to maintain dispense rate.
With the correct mode selected...
Press BACK to select the mode of operation you will use.
Press
BACK
Twice more to exit SETUP and back to the Main Screen

M A G U I R E P R O D U C T S , I N C .
11
G R A V I M E T R I C A U G E R F E E D E R 
Select Units – US or Metric
Press
To scroll down to SETUP (using arrow key)
Press ENTER Display will say:
ENTER PASSWORD _ _ _ _
Enter 2222 Default password is 2222
Press ENTER to enter SETTINGS. Display will show basic MGF
SETTINGS.
Press
twice, scrolling the display down to UNITS.
Press ENTER to toggle between US and METRIC.
US will display in Pounds and ounces
METRIC will display in Kilograms and grams
With the desired UNITS selected...
Press BACK to make the selection.
Press BACK Twice more to exit SETUP and back to the Main Screen
Re-enter: the following settings if previously set (required when switching weight
units)
1. LBS/HOUR (KGS/HOUR) – MAIN MENU Screen
2. LOW WEIGHT ALARM – See Parameters
3. LOADER ON WEIGHT – Setup / Loader Operations
4. LOADER OFF WEIGHT
–
Setup / Loader Operati
ons

M A G U I R E P R O D U C T S , I N C .
12
G R A V I M E T R I C A U G E R F E E D E R 
Set Date and Time – RTC (Real Time Clock) Setup
Press
To scroll down to SETUP (using arrow key)
Press ENTER Display will say:
ENTER PASSWORD _ _ _ _
Enter 2222 Default password is 2222
Press ENTER to enter SETTINGS.
Press
to scroll the display down to SET DATE AND TIME.
Press ENTER The display will show the Date Format
USA displays as Month/Day/Year, Europe displays as
Day/Month/Year
Press
To toggle Date Format between USA and EUROPE
With the desired Format selected...
Press ENTER to make the selection. The Display will show the current date
and time on the MGF. To adjust:
Use the keypad
digits
To adjust the blinking field.
Press
to advance to the next field. If necessary adjust the
highlighted field using the keypad numbers. Do this for all
fields. When you advance past the last field, the display will
show Date/Time Saved!
Press BACK three more times to exit SETUP and go to the Main
Screen

M A G U I R E P R O D U C T S , I N C .
13
G R A V I M E T R I C A U G E R F E E D E R 
START UP PROCEDURE
1. Turn POWER ON:
The opening screen displays for 5 seconds,
and shows your software version number in
the lower-right and the USB Version in the
upper-right. The display then shows the Main
Screen of the MGF. Depending on your Mode
of Operation, the Main screen will either
display Shot Weight or Pounds Per Hour (or
KGS/Hour).
================03.68
Maguire
MGF
===============J0323A
CYCLE MODE:
==== MAIN MENU ======
SHOT WT 200
LDR 1.00%
LOAD=== xxxx =SIG:XX
CONTINUOUS and
EXTR FLLW MODES:
==== MAIN MENU ======
LBS/HOUR 200
LDR 1.00%
LOAD=== xxxx ======
Adjustments
SHOT/WT or LBS/HOUR - Depending on your selected Mode, the display will show
SHOT/WT or LBS/HOUR. To adjust this value, follow these instructions:
Using the Arrow buttons, select SHOT/WT or LBS/HOUR (selection indicated with the )
Press ENTER Display will highlight the value on the right.
Enter NEW value using the keypad. When new value has been entered, press enter
or fill in all digits.
LDR – Let Down Ratio - To adjust this value, follow these instructions:
Press
once to highlight LDR (selection indicated with the )
Press ENTER Display will highlight the value on the right.
Enter NEW value using the keypad. When new value has been entered, press enter
or fill in all digits. The decimal is hard coded to 100ths of a %.

M A G U I R E P R O D U C T S , I N C .
14
G R A V I M E T R I C A U G E R F E E D E R 
Prime the MGF Auger / Calibrate
It may be necessary to prime the auger prior to running. Prime will allow the MGF to run without a
signal from the process machine. Run time is automatically limited to ONE minute. After one
minute the display will read “PRIME TIMED OUT”. During the Prime, the MGF automatically
calibrates the flow rate of the material. To Prime, follow these instructions:
Press
4 times to highlight PRIME FUNCTION
Press ENTER Display will show: PRIME ON
A 60-second counter will begin to count down. During this time the
MGF will self-calibrate and display CALIBRATED indicating that it has
learned the flow rate of your specific material and has adjusted the
motor factor accordingly. After CALIBRATED has displayed, the prime
function can be ended by pressing the BACK button, otherwise prime
will continue to run for 60 seconds, then timeout and alarm, displaying
“PRIME TIMED OUT”.
Press BACK To stop the prime function or any key on the keypad to silence the
alarm.
When the MGF settings are adjusted and the MGF is primed
with material, it is ready for operation.
Switch to RUN using the paddle switch on the left side if the
controller, located next to the power switch.
What happens during NORMAL OPERATION
The software uses the information you have entered, lbs/hr (or shot wt) and Let Down Ratio, plus
the motor factor, to determine a correct percentage off-time between steps for the motor to control
speed.
Two 10K load cells detect the loss of weight after each dispense. Based on this feedback,
adjustments are made to the percentage off-time to maintain the correct metering rate.
In the CONTINUOUS mode the percentage off-time, (motor speed) is adjusted to hold the correct
loss in weight of the hopper.
In the CYCLE mode the speed is adjusted to meter the correct amount over the full screw signal
cycle time. A change in process screw signal time will result in an adjustment to motor speed.
Speed adjustment is based on the previous screw return time. If screw return time is SHORTER
then the PREVIOUS time, the auger motor will continue past the end of the run signal for 1
additional second. It will run faster on the next dispense to end in time.

M A G U I R E P R O D U C T S , I N C .
15
G R A V I M E T R I C A U G E R F E E D E R 
ALARMS and TROUBLESHOOTING
NO METERING - ALARM CODE:48
This alarm indicates that no loss in weight has been detected during the last
several cycles. After clearing the alarm, metering will continue, however the
alarm will not re appear until after you have remedied the problem.
The following conditions are required to generate the NO METERING ALARM
a. Before this alarm is checked, the system needed to have been running for at least 24
seconds.
b. If the MGF is in continuous or extrusion follow mode, the target rate needs to be more
than 7.5 g/min.
c. If the MGF is in cycle mode, the target rate needs to be more than 2 grams / cycle.
If the above conditions (a and (b or c)) are met, then the MGF will compare the current bin weight
with a captured value from 24 seconds ago.
d. If the MGF is in continuous or extrusion following mode, the difference between the two
weights need to greater than 10 times the target rate.
e. If the MGF is in cycle mode, the difference between the two weights needs to be
greater than 5 times the target rate.
If the above condition (d or e) fails, then a counter is incremented
If the above condition (d or e) passes, then the counter is reset to 0.
If the counter gets incremented past 3, then the NO METERING alarm is triggered.
In cycle mode, the NO METERING alarm is checked only at the start of every cycle.
In continuous or extrusion following mode, the NO METERING alarm is checked every RTU
update.
LOADING TOO SLOWLY - ALARM CODE:49
If the loading feature is enabled and it takes more than LAT (Loader Alarm Time)
seconds to fill the bin to LHF (Loader High Level) grams then this alarm is
triggered.
PRIME ALARM - ALARM CODE:50
This alarm indicates that the 60-second Prime cycle time has ended. The Prime
function is used to prime the feeder and is accessible from the main menu. It
operates by running the feeder auger for one minute to prime the feeder then
alarms to alert the operator that the prime cycle has ended.
LOW WEIGHT ALARM - ALARM CODE:51
If the bin weight falls below the LWA (Low Weight Alarm) setting (Default 400g)
then this alarm will be triggered. If the bin weight rises above the LWA
parameter, then the alarm will shut off.

M A G U I R E P R O D U C T S , I N C .
16
G R A V I M E T R I C A U G E R F E E D E R 
OVER WEIGHT LIMIT ALARM - ALARM CODE:52
This alarm indicates that the weight being read by the load cells exceeds the
capacity of the cells. The ce
lls are 10 Kilos each, 20 Kilos total, about 44 pounds.
The hopper holds about 1/5 cubic foot, about 10 pounds. The weight of the
hopper when empty is about 8.2 pounds.
MOTOR CAPACITY EXCEEDED - ALARM CODE:53
This alarm indicates that the calculated rate exceeds capacity.
The following variables effect the motor off-time calculation
MTF (Motor Factor)
LDR (Let Down Ratio)
PHR (Per Hour Rate) (continuous and extr. Follow only)
SHT (Shot Weight) (cycle mode only)
RATE ADJ
If the target rate calculates out to less than a step every 2 ms, then this alarm is triggered.
The following variables effect the motor step time calculation
MTF (Motor Factor)
RPM (Maximum RPM)
SPR (Steps per Revolution)
LDR (Let Down Ratio)
PHR (Per Hour Rate) (continuous and extr. Follow only)
SHT (Shot Weight) (cycle mode only)
RATE ADJ
BIN REMOVED - ALARM CODE:54
This alarm indicates that the hopper is not installed on the load cells. When this
alarm is active, the MGF will not allow the auger to run and will not allow the
loader to load material. Alarm is triggered if the bin weight falls below the NBW
(Negative Bin Weight) grams.
MAX ADJUST RATE - ALARM CODE:55
Indicates Motor factor is too low which causes the MGF to dispense too much
material over time, causing the rate adjust limit to reach 3.000. When the MGF
makes a correction, the RATE ADJ value is re-calculated to compensate for the
accumulated error. If the new RATE ADJ rises above the UBE (Upper Boundary
Error) (Defaulted to 300 = 3.00), then this alarm is triggered. Doing a prime
calibration is recommended and this will set your motor factor and rest rate adjust
to 1.000.

M A G U I R E P R O D U C T S , I N C .
17
G R A V I M E T R I C A U G E R F E E D E R 
MIN ADJUST RATE - ALARM CODE:56
Indicates Motor factor is too high which causes the MGF to dispense too little
material over time, causing the rate adjust limit to reach .3000. When the MGF
makes a correction, the RATE ADJ value is re-calculated to compensate for the
accumulated error. If the new RATE ADJ falls below the LBE (Lower Boundary
Error) (Defaulted to 30 = 0.30), then this alarm is triggered. Doing a prime
calibration is recommended and this will set your motor factor and rest rate adjust
to 1.000.
LIW TIMED OUT - ALARM CODE:57
When the MGF is configured to poll a Maguire LIW for Steady State Rate (LIW Mode),
this alarm is generated when the MGF cannot poll the Steady State Rate from the LIW.
LOADCELL ERROR - ALARM CODE:58
This error is generated if there is no response from the internal analog-to-digital
converter system that provides a digital measurement from the loadcells. If this error is
generated, it may indicate damage to the A-to-D converter. If you receive this error,
please contact technical support.
TROUBLESHOOTING CONTROLLER PROBLEMS
If you have problems, the more information you can provide us about what caused the problem,
the more we can do to improve our product so that these problems cannot, and do not, occur in
the future. In some cases, we may NOT be able to duplicate YOUR particular problem in our
testing facility. Describe the problem as CAREFULLY and as completely as possible to help us
locate and correct any design weakness that might be responsible for the problems you are
having.
TROUBLESHOOTING LOSS OF COLOR
1. Check that color supply is adequate.
2. Confirm that the motor is turning. Check proper connection of the motor plug.
3. Check that the drive coupling is not slipping and is securely attached to the motor shaft.
The connecting tube between the motor coupling and the auger coupling is designed to
slip under high torque. If excessive loading has caused it to slip, it may have become
worn, or loose, or moved out of correct position.

M A G U I R E P R O D U C T S , I N C .
18
G R A V I M E T R I C A U G E R F E E D E R 
SETUP Menu – Password protected access to MGF Settings including: SETTINGS, SCALE
CALIBRATION, COMMUNICATIONS, LOADER OPERATIONS, METERING RATE,
PARAMETERS, PRINT OPTIONS, UPDATE USB FIRMWARE, UPDATE FIRMWARE, RATE
ADJUST RESET, VIEW/RESET TOTALS, RESTORE FACTORY DEFAULTS.
SETTINGS - CHANGE PASSWORD, MODE, UNITS, LANGUAGE, SET DATE AND TIME.
CHANGE PASSWORD – Used to change the factory password
For security purposes, you want to change the factory password to protect setup
information from modification. The default password is “2222”. Four digits (0 through 9)
are required. A modified password will not reset back to factory default after a software
upgrade. If you changed the password but forgot what it is, please contact Maguire
Products. The following describes how to change the factory password.
Press
To scroll down to SETUP (using arrow key)
Press ENTER Display will say:
ENTER PASSWORD _ _ _ _
Enter 2222 Default password is 2222
Press ENTER to enter SETTINGS.
Press ENTER to select CHANGE PASSWORD
You will be prompted for a New Password.
Enter a new 4-digit password or press BACK to exit without changing the
password.
You will be prompted to confirm the new password. Enter your new password
again.
The display will show Password Changed.
Press
BACK
three more times to exit SETUP and go to the Main Screen

M A G U I R E P R O D U C T S , I N C .
19
G R A V I M E T R I C A U G E R F E E D E R 
MODE - Select Mode of Operation – CYCLE, CONTINUOUS or EXTR FLLW
Turn the MGF Power ON. Power button located on lower left side of controller.
View the LCD window. Allow controller to boot up to MAIN MENU.
Press
To scroll down to SETUP (using arrow key)
Press ENTER Display will say:
ENTER PASSWORD _ _ _ _
Enter 2222 Default password is 2222
Press ENTER to enter SETTINGS. Display will show SETTINGS options.
Press
once, scrolling the display down to MODE.
Press ENTER to toggle between CYCLE, CONTINUOUS and EXTR. FLLW
(Extrusion Following) Mode.
Select CYCLE...
for injection molding, where the MGF auger turns on and off with
each cycle. In this mode the first step is to enter the SHOT
WEIGHT of the part on the main screen. Next set the LDR (Let
Down Ratio) on the main screen. In CYCLE mode your MGF will
dispense the calculated rate (shot weight x LDR) during the
length of screw recover time.
Select CONTINUOUS...
for extrusion, where the MGF auger runs continuously. In this
mode the first step is enter LBS (or KILOS) / HOUR of the
extruder on the main screen. Next set the LDR (Let Down Ratio)
on the main screen. In CONTINUOUS mode your MGF will run
continuously at the calculated rate (lbs/hr x LDR). Auger speed
will adjust automatically to maintain dispense rate.
Select EXTR. FLLW...
for extrusion, where the MGF auger runs continuously by
following the 0-10 volt reference voltage of the extruder screw.
In this mode the first step is to set the XMO parameter. Setting
XMO will automatically calculate extruder throughput on the main
screen based on a 0-10 volt reference. See page 27 for XMO.
Next set the LDR (Let Down Ratio) on the main screen. In
Extrusion Following mode your MGF will run continuously at the
calculated rate (lbs/hr x LDR). Auger speed will adjust
automatically to maintain dispense rate.
With the correct mode selected...
Press BACK to select the mode of operation you will use.
Press
BACK
Twice more to exit SETUP and back to the Main Screen

M A G U I R E P R O D U C T S , I N C .
20
G R A V I M E T R I C A U G E R F E E D E R 
UNITS – Selects the Units to display, US or Metric
Press To scroll down to SETUP (using arrow key)
Press ENTER Display will say:
ENTER PASSWORD _ _ _ _
Enter 2222 Default password is 2222
Press ENTER to enter SETTINGS.
Press twice, scrolling the display down to UNITS.
Press ENTER to toggle between US and METRIC.
US will display in Pounds and ounces
METRIC will display in Kilograms and grams
With the desired UNITS selected...
Press BACK to make the selection.
Press BACK Twice more to exit SETUP and back to the Main Screen
Re
-
enter:
the following settings if previously set (required when switching weight units)
1. LBS/HOUR (KGS/HOUR) – MAIN MENU Screen
2. LOW WEIGHT ALARM – See Parameters
3. LOADER ON WEIGHT – Setup / Loader Operations
4. LOADER OFF W
EIGHT
–
Setup / Loader Operations
LANG – Set the Language of the MGF Controller.
Languages include English, Italian, German, Polish, Czech, French and Spanish
Press To scroll down to SETUP (using arrow key)
Press ENTER Display will say:
ENTER PASSWORD _ _ _ _
Enter 2222 Default password is 2222
Press ENTER to enter SETTINGS.
Press to scroll the display down to LANG (Language).
Press ENTER to toggle through the languages. When the language you desire is displayed,
press BACK to set the new language.
Press BACK three more times to exit SETUP and go to the Main Screen
