Maico EC 30 E Service manual

D GB
F
Deckenfächer
Ceiling fans
Ventilateurs de plafond
EC 30 E EC 90 B
EC 40 D EC 140 B
Montage- und Betriebsanleitung
Mounting and Operating instructions
Instructions de montage et Mode d’emploi
www.maico.de

11
Ceiling fans EC …
Table of contents
1. Scope of delivery................................... 11
1.1 EC 30 E and EC 40 D..................... 11
1.2 EC 90 B and EC 140 B................... 11
2. Warning symbols used .......................... 12
2.1 Warning symbols............................ 12
2.2 Other symbols ................................ 12
3. Product information ............................... 12
3.1 EC 30 E, EC 40 D unit overview..... 12
3.2 EC 90 B, EC 140 B unit overview...... 12
3.3 Product description......................... 13
4. Technical data....................................... 13
5. Essential safety instructions .................. 13
5.1 General safety instructions ............. 13
5.2 Intended use................................... 13
5.3 Non-permitted operation................. 14
5.4 Safe and correct practices during
operation .............................................. 14
6. Installation preparations ........................ 14
7. Installation............................................. 14
7.1 EC 30 E and EC 40 D installation... 14
7.2 EC 90 B and EC 140 B installation . 15
7.3 Electrical connection....................... 16
7.4 Start-up........................................... 16
8. Long fastening rod................................. 16
8.1 EC 30 E, EC 40 D fastening rod ..... 17
8.2 EC 90 B, EC 140 B fastening rod ... 18
9. Dismantling ........................................... 18
10. Maintenance......................................... 18
10.1 Six-monthly check ........................ 18
11. Cleaning ............................................... 19
12. Fault rectification .................................. 19
13. Disposal ............................................... 19
14. Wiring diagrams ................................... 32
1. Scope of delivery
1.1 EC 30 E and EC 40 D
Fully fitted ceiling fan, mounting and
operating instructions.
1.2 EC 90 B and EC 140 B
Removed ceiling fan, consisting of: canopy,
fastening rod, motor, impeller hub, 3 impeller
blades, cover plate (EC 90 B only), motor
capacitor, bag of accessories and mounting
and operating instructions.
Bag of accessories for EC 90 B
1 1 M6x30 mm hex bolt [22]
1 1 M6 hex lock nut [21]
1 1 shim, inner diameter 10.5 mm [27]
1 1 M10 hex lock nut [28]
1 1 setting ring with threaded pin [19]
1 3 M8 hex lock nuts [26.2]
1 3 shims, inner diameter 8.4 mm [26.1]
1 3 ST2.9x22 tapping screws [30]
1 1 5x6.5 spring washer [24]
Bag of accessories for EC 140 B
1 1 M6x30 mm hex bolt [22]
1 1 M6 hex lock nut [21]
1 1 shim, inner diameter 10.5 mm [27]
1 1 M10 hex lock nut [28]
1 1 setting ring with threaded pin [19]
1 6 M5x12 mm countersunk screws,
coated [26.3]
1 1 5x9 spring washer [24]
Imprint: © Maico Elektroapparate-Fabrik GmbH.
E & OE. We reserve the right to make technical
modifications.
GB

12
2. Warning symbols used
2.1 Warning symbols
DANGER
Danger to life.
Non-observance can lead to
death or serious bodily injuries.
CAUTION
Danger of injury. Damage to
property. Non-observance can
lead to minor or more serious
bodily injuries.
NOTICE Damage to property.
Non-observance can lead to
damage to property.
2.2 Other symbols
INFO symbol: Text passages
marked with this symbol contain
important information and tips.
1 List symbol:
List containing important infor-
mation on the relevant subject.
1 Action symbol:
List of work to be carried out.
Follow the instructions in the
order given.
3. Product information
3.1 EC 30 E, EC 40 D unit overview
1 Ceiling hook (not included in scope of
delivery)
2 Rubber roller
3 Capacitor (EC 40 D only)
4 Canopy
5 Setting ring with locking threaded pin
6 Fastening rod
6.1 Fastening rod, long model (optional)
7 Connecting terminal
8 Connection cables for motor, with
insulation sleeve
9 Lock nut with locking threaded pin
10 Motor
11 Motor cover
11.1 Recess
12 Impeller
13 Protective cage
S1 Rating plate
S2 Wiring diagram
3.2 EC 90 B, EC 140 B unit overview
14 Ceiling hook (not included in scope of
delivery)
15 Connection cables for motor, with
insulation sleeve
16 Connecting terminal
17 Canopy
18 Capacitor
19 Setting ring with locking threaded pin
20 Fastening rod with rubber roller
20.1 Fastening rod, long model (optional)
21 Lock nut
22 M6 x 30 mm hex bolt
23 Motor
23.1 Retaining bolt
24 Feather key
25 Impeller hub with recesses
26 Impeller blade (3 items)
26.1 Shim (EC 90 B only)
26.2 Lock nut (EC 90 B only)
26.3 Bolt (EC 140 B only)
27 Shim
28 Lock nut
29 Cover plate
30 Bolt
S1 Rating plate
S2 Minimum distance note
S3 Lock nuts note
S4 Wiring diagram
S5 Rotation and air direction information
sign
i
1
1
GB

13
3.3 Product description
Ceiling fan for air circulation in commercial
and working areas.
EC 30 E and EC 40 D run clockwise.
EC 90 B and EC 140 B run anti-clockwise
(see direction of rotation arrow sign [S5]).
The motor is designed for continuous
operation. In the event of thermal overload,
an integrated motor overload switches the
unit off.
They are switched on and off using a
separate switch (this should be supplied by
the customer). The unit is speed controllable,
see recommended Maico accessories.
4. Technical data
1 Protective cage diameter
EC 30 E 345 mm
EC 40 D 450 mm
1 Impeller diameter
EC 90 B 900 mm
EC 140 B 1400 mm
1 Mounting height
EC 30 E 410 mm
EC 40 D 420 mm
EC 90 B 450 mm
EC 140 B 420 mm
1 W eight
EC 30 E 2.5 kg
EC 40 D 3.2 kg
EC 90 B 5.1 kg
EC 140 B 8.5 kg
1 Air circulation (max.)
EC 30 E 2,800 m³/h
EC 40 D 4,500 m³/h
EC 90 B 11,000 m³/h
EC 140 B 18,000 m³/h
1 Permissible ambient temperature
EC 30 E, EC 40 D max. + 40 °C
EC 90 B, EC 140 B max. + 60 °C
For other data, see rating plate.
5. Essential safety instructions
5.1 General safety instructions
1 Read the operating instructions through
carefully before starting up.
1 Keep the instructions.
1 The unit should not be used as a toy.
1 Installation is only permitted when
carried out by trained specialists.
1 Electrical connection, repairs and
conversion to a longer fastening rod
(accessories) should only be carried
out by a trained electrician.
1 Only connect unit to a permanently wired
electrical installation.
– Permissible cable cross-section
1.5...2.5 mm².
– Mains isolation device required with
contact openings of at least 3 mm at each
pole.
1 The fan unit may only be operated using
the voltage and frequency shown on the
rating plate.
1 Only operate the fan unit when it is
completely installed.
1 Never operate EC 30 E and EC 40 D
without protective cage.
1 Modifications and alterations to the unit are
not permitted and release Maico from any
guarantee obligations and liability.
Exception: the unit may be modified to a
longer fastening rod (Maico accessories)
according to section 8.
5.2 Intended use
1 Ceiling fan for constant air circulation in
rooms with high ceilings, commercial and
industrial halls, offices, production and
operating facilities. Air circulation produces
an even distribution of temperature in the
room.
1 The air flows from the ceiling to the floor.
1 For surface installation on a ceiling with
sufficient load bearing capacity.
GB

14
1 Operations only permitted when fitted at a
sufficient space from the wall, other ceiling
fans or equipment in the vicinity.
1 EC 90 B, EC 140 B: Operation only
permitted with a minimum gap of 2.3 m
between floor and bottom edge of impeller
blades.
5.3 Non-permitted operation
The fan unit should not be used:
1 close to flammable materials, liquids or
gasses.
1 for the conveying of chemicals, aggressive
gases or vapours.
1 in explosive atmospheres.
5.4 Safe and correct practices during
operation
1 Danger of injury. Do not place anything in
the rotating impeller blades.
1 Danger from rotating impeller blades.
Do not get too close to the unit, to avoid
hair, clothing or jewellery being drawn into
the unit.
1 The unit is not intended to be used by
people whose physical, sensory or mental
capabilities are not sufficient for them to
understand and put into practice the safety
information provided in these instructions.
This limitation also applies to children.
The unit may however be safely used by
such persons if they are supervised by
someone responsible for their safety or if
they are instructed in a suitable way.
6. Installation preparations
1 Observe permissible minimum installation
height. For EC 90 B and EC 140 B
min. 2.3 m (bottom edge of impeller blades
to floor, according to EN 60335-2-80).
1 The following fastenings must be provided
on site:
– 1 ceiling hook with 7 mm diameter,
strength class 4.8
– 1 suitable retaining dowel
1 Make a hole for the retaining dowel in the
ceiling.
1 Insert retaining dowel.
1 Screw in ceiling hook.
7. Installation
7.1 EC 30 E and EC 40 D installation
These ceiling fans come from the factory
ready for installation. For conversion to a
longer fastening rod (accessories), see
section 8.
DANGER
Incorrect installation results in
a danger of injury from falling
unit parts.
1 When installing and also after
dismantling, always use new
lock nuts according to ISO
7042.
CAUTION
Malfunction if the ceiling fan
cannot swing freely.
1 Leave 5 to 8 mm gap between
upper edge of canopy [4] and
ceiling.
1 Lift up ceiling fan and hang rubber roller [2]
of fastening rod in ceiling hook [1].
1 Undertake electrical connection according
to section 7.3.
1 Slide canopy [4] towards ceiling and lock
with setting ring [5].
GB

15
7.2 EC 90 B and EC 140 B installation
DANGER
Incorrect installation results in
a danger of injury from falling
unit parts.
1 Install impeller blades as
shown (fold-out side) and
screw down correctly.
1 Observe tightening torques.
1 Only use impeller blades of the
same weight on the impeller
blade retaining flange.
1 When installing and also after
dismantling, always use new
lock nuts according to ISO
7042.
CAUTION
Malfunction if the ceiling fan
cannot swing freely.
1 Leave 5 to 8 mm gap between
upper edge of canopy [17] and
ceiling.
Assemble ceiling fan first, then attach to
ceiling hook and wire up. For conversion to
a longer fastening rod (accessories), see
section 8.
1 Slide canopy [17] over fastening rod [20].
1 Then slide setting ring [19] over fastening
rod.
1 Attach fastening rod [20] to retaining bolt
[23.1] and screw down with hex bolt [22]
and hex nut [21]. Tighten lock nut to a
tightening torque of 10 Nm.
1 Thread motor connection cables with
insulation hose [15] over cable duct of
fastening rod towards rubber roller.
1 Fit impeller blades [26].
CAUTION
Unit will be damaged if
impeller blades are of different
weights as this will cause
imbalance.
1 Only use impeller blades of
the same weight, see
inscription on impeller blade
foot.
Guide 3 impeller blades [26] into recesses
in impeller hub [25]. The side of the
impeller blade which curves inwards
(concave) must face the floor.
EC 90 B only: The impeller blade retaining
flange must end flush with the top and
bottom edge of the impeller hub.
1 EC 90 B only: Secure 3 impeller blades
with shims [26.1] and lock nuts [26.2].
Tighten lock nuts to a tightening torque
of 10 Nm.
1 EC 140 B only: The 3 impeller blades are
each secured with 2 bolts [26.3]. Tighten
screws to a tightening torque of 2.5 Nm.
1 Insert feather key [24] in slot of motor shaft.
1 Slide impeller hub [25] with impeller blades
already fitted [26] on to motor shaft. Ensure
that the feather key remains in position and
that the air direction arrow on the impeller
hub is pointing to the floor.
1 Fit shim [27] and lock nut [28]. Tighten lock
nut to a tightening torque of 30 Nm.
1 EC 90 B only: Secure cover plate [29] with
3 bolts [30].
1 Wire motor connection cables and
capacitor to connecting terminal as shown
in wiring diagram (see back of instructions
or inside of canopy).
1 Accommodate excess cable in the canopy.
GB

16
1 Lift up ceiling fan.
1 Hang rubber roller of fastening rod [20] in
ceiling hook [14].
1 Undertake electrical connection according
to section 7.3.
1 Slide canopy [17] towards ceiling and lock
with setting ring [19].
7.3 Electrical connection
DANGER
Danger to life from electric
shock
1 Switch the mains fuse off.
The cable length of the motor
connection cables has also been
designed for units with the long
fastening rod.
1 Undertake electrical connection according
to wiring diagram (see rear of instructions
or inside of canopy).
7.4 Start-up
1 Switch the mains fuse on.
1 Switch ceiling fan on and off. Check
direction of rotation at same time.
EC 30 E and EC 40 D: The impeller must
turn clockwise (viewed from below).
EC 90 B and EC 140 B: The impeller must
turn anti-clockwise (viewed from below).
NOTICE Note rotation and air direction
arrows.
1 If the rotation and air direction
is wrong, check the electrical
connection and correct if
necessary.
8. Long fastening rod
DANGER
Danger to life from electric
shock
1 Switch the mains fuse off.
DANGER
Incorrect installation results in
a danger of injury from falling
unit parts.
1 When installing and also after
dismantling, always use new
lock nuts according to ISO
7042.
If using a long fastening rod (option with
0.5 m or 1 m), the unit must be modified.
1 Modification may only be undertaken by a
trained electrician.
1 If ceiling fan has already been fitted, take it
off the ceiling.
1 Never undertake modification with fan fitted
on the ceiling and unit live.
1 The length of the connection cables is
designed ex-factory for the long fastening
rod too.
i
GB

17
8.1 EC 30 E, EC 40 D fastening rod
1 Disconnect motor connection cables [8]
from connecting terminal [7].
1 Slide up motor cover [11].
1 Carefully pull connection cable [8] at
bottom out of fastening rod [6].
1 Loosen retaining threaded pin of lock
nut [9].
1 Unscrew fastening rod [6] out of motor
housing.
1 Slide canopy [4] and setting ring [5] on to
new, long fastening rod [6.1].
1 Fully screw lock nut [9] in hole of fastening
rod.
1 Carefully screw in fastening rod [6.1] until
stop in motor housing is reached. Ensure
that the lock nut does not sit on the motor
housing.
1 Unscrew fastening rod until hole for cable
duct [B] and nut [M] are directly opposite
one another (nut [M] to right of tension
relief [Z]).
NOTICE Unscrew fastening rod by no
more than 1 revolution.
1 In this position, tighten lock nut [9] to a
tightening torque of 20 Nm and secure with
threaded pin.
Tip: Place screwdriver between rubber
roller and fastening rod to counter them so
that the fastening rod is not twisted.
1 Slide enclosed insulation sleeve over motor
connection cables. This must protrude
around 20 mm beyond the existing
insulation sleeve [8].
1 Carefully thread insulation sleeve and
connection cables into fastening rod,
working from the bottom and moving
upwards. If necessary, use threading tool.
1 Slide down motor cover [11].
NOTICE If the motor cover is
positioned wrongly, it cannot
be slid all the way down.
1 Turn motor cover [11] such
that recess [11.1] in motor
cover fits over motor cable [8].
1 Wire motor connection cables and
capacitor to connecting terminal according
to wiring diagram. For wiring diagram, see
back of instructions or inside of canopy.
1 Lift up ceiling fan.
1 Hang rubber roller of fastening rod [6] in
ceiling hook [1].
1 Undertake electrical connection according
to section 7.3.
CAUTION
Malfunction if the ceiling fan
cannot swing freely.
1 Leave 5 to 8 mm gap between
upper edge of canopy and
ceiling.
1 Slide canopy [4] towards ceiling and lock
with setting ring [5].
1 Start up ceiling fan according to section
7.4.
GB

18
8.2 EC 90 B, EC 140 B fastening rod
1 Disconnect motor connection cables [15]
from connecting terminal [16].
1 Carefully pull motor connection cables [15]
at bottom out of fastening rod [20].
1 Remove nut [21] and bolt [22] and pull
fastening rod off retaining bolt [23.1].
1 Take off canopy [17] and setting ring [19]
and slide onto new, long fastening rod
[20.1].
1 Attach new fastening rod [20.1] to retaining
bolt [23.1] and screw down securely with
bolt [22] and nut [21], tightening torque
10 Nm.
1 Slide enclosed insulation sleeve over motor
connection cables. This must protrude
around 20 mm beyond the existing
insulation sleeve [15].
1 Carefully thread insulation sleeve and
connection cables into fastening rod,
working from the bottom and moving
upwards. If necessary, use threading tool.
1 Wire motor connection cables and
capacitor to connecting terminal [16]
according to wiring diagram. For wiring
diagrams, see back of instructions or inside
of canopy.
1 Lift up ceiling fan.
1 Hang rubber roller of fastening rod [20.1] in
ceiling hook [14].
1 Undertake electrical connection according
to section 7.3.
CAUTION
Malfunction if the ceiling fan
cannot swing freely.
1 Leave 5 to 8 mm gap between
upper edge of canopy and
ceiling.
1 Slide canopy [17] towards ceiling and lock
with setting ring [19].
1 Start up ceiling fan according to section
7.4.
9. Dismantling
DANGER
Danger to life from electric
shock
1 Switch the mains fuse off.
1 Dismantling should only be carried out by a
trained electrician.
10. Maintenance
DANGER
Danger to life. Unit is powered
up.
1 Switch the mains fuse off.
DANGER
Danger of injury if lock nuts
are loose. Parts of the ceiling
fan may fall down and cause
injury and damage to
property.
1 Every six months check that
bolts and lock nuts are secure.
1 If the connection is loose, fit
new lock nuts. Tighten these
to the specified tightening
torque.
1 Coat loose bolts, e.g. item
[27.3], with retaining bolt paint
and tighten to specified
torque.
10.1 Six-monthly check
EC 30 E, EC 40 D
1 Check that bolts and nuts at fixing points A
and B are secure, see diagram.
EC 90 B, EC 140 B
1 EC 90 B only: Take off cover plate [13].
1 Check that bolts and nuts are secure, see
diagram:
– EC 90 B: Fixing points A...D
– EC 140 B: Fixing points A...E
1 EC 90 B only: Fit cover plate [13].
GB

19
11. Cleaning
DANGER
Danger to life. Unit is powered
up.
1 Switch the mains fuse off.
1 If the impeller blades are dirty or not
running smoothly (imbalance), clean the
unit with a damp cloth.
12. Fault rectification
1 Call on the services of a trained electrician
any time there is a fault.
1 Repairs should only be carried out by a
trained electrician.
DANGER
Danger to life. Unit is powered
up.
1 Switch the mains fuse off.
CAUTION
Once the overload protection
has cooled the rotating
impeller blades still represent
a danger. The ceiling fan will
automatically start back up
once the fan motor has cooled
down.
1 Do not reach into the area
around the impeller blades.
Fault Countermeasure
– Unit doesn’t run
– Thermal overload
protection of the
motor switches unit
off and back on
again after cooling
down.
Check that the mains
fuse is switched on.
If the thermal
overload protection
has tripped, the
ceiling fan must start
back up again
automatically after
1 hour at the most.
Tab.1: Fault rectification
13. Disposal
Do not dispose of in domestic
waste.
The unit contains in part material that
can be recycled and in part
substances that should not end up as
domestic waste.
1 Dispose of the unit once it has reached the
end of its working life according to the
regulations valid where you are.
i
GB

32
14. Schaltbilder / Wiring diagrams
Schémas de branchement
EC 30 E
EC 90 B, EC 140 B
EC 40 D
Maico Elektroapparate-Fabrik GmbH • Steinbeisstr. 20 • 78056 Villingen-Schwenningen •
Deutschland • Service-Hotline [phone] • i[email protected]
M
1
L
N
PE
N 65
WH BK
M
1
L
N
PE
N 65
WH BK RD
M
1
L
N
PE
N 65
WH BK RD
0185.0131.0000_RLF.2_10.08_DSW
D
GB
F
