MyPowerS4100SeriesSwitch
InstallManual(S4152F-POE-
ACV2)
V1.0
MaipuCommunicationTechnologyCo.,Ltd
No.16,JiuxingAvenue
Hi-Tech Park
Chengdu,Sichuan Province
P.R.China
610041
Tel:[phone]
Fax:[phone]
URL:http:// www.maipu.com
Mail: [e-mail]

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage2of23
Allrightsreserved.Printedinthe People’sRepublicof China.
Nopartof thisdocument maybereproduced,transmitted,transcribed,storedinaretrievalsystem,ortranslatedintoany
languageorcomputerlanguage,inanyformorbyanymeans,electronic,mechanical,magnetic,optical,chemical,manual
orotherwisewithout thepriorwritten consent of MaipuCommunicationTechnologyCo., Ltd.
Maipumakesnorepresentationsorwarrantieswithrespect tothisdocumentcontentsandspecificallydisclaimsanyimplied
warrantiesofmerchantabilityorfitness foranyspecificpurpose.Further,Maipureservestheright torevisethisdocument
andtomakechangesfromtimetotimeinitscontent withoutbeingobligatedtonotifyanypersonof such revisionsor
changes.
Maipuvaluesandappreciatescommentsyoumayhaveconcerningourproductsorthisdocument.Pleaseaddress comments
to:
MaipuCommunicationTechnologyCo.,Ltd
No.16,JiuXingAvenue,Hi-TechPark
Chengdu,Sichuan Province
P.R.China
610041
Tel:[phone]
Fax:[phone]
URL:http:// www.maipu.com
Mail: [e-mail]
Allotherproductsorservicesmentionedhereinmayberegisteredtrademarks,trademarks,orservicemarksof their
respectivemanufacturers,companies,ororganizations.

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage3of23
MaipuFeedbackForm
Youropinionhelpsusimprove thequalityof ourproduct documentation
andofferbetterservices.Pleasefaxyour commentsandsuggestionsto
(86)28-85148948,85148139oremailto [e-mail].
Document Title MyPowerS4100 SeriesSwitchInstall Manual(S4152F-POE-ACV2)V1.0
Product
Version Document Revision
Number
2.0
Presentation:
(Introductions,procedures,illustrations,completeness,arrangement, appearance)
£Good£Fair £Average £Poor
Accessibility:
(Contents,index, headings,numbering)
£Good£Fair £Average £Poor
Evaluatethis
document
Editorial:
(Language,vocabulary, readability, clarity,technicalaccuracy, content)
£Good£Fair £Average £Poor
Your
suggestionsto
improvethe
document
Pleasechecksuggestionstoimprovethisdocument:
£Improveintroduction £Makemoreconcise
£ImproveContents £Add morestep-by-stepprocedures/tutorials
£Improvearrangement £Add moretechnicalinformation
£Includeimages £Makeitless technical
£Add moredetail £Improveindex
Ifyouwishtobecontacted,completethefollowing:
Name Company
Postcode Address
Telephone E-mail

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage4of23
Contents
ProductIntroduction...................................................................................5
Overview................................................................................................................5
Product Features........................................................................................................................6
Appearance............................................................................................................7
FrontPanel.................................................................................................................................7
BackPanel..................................................................................................................................8
LEDs..........................................................................................................................................8
Installation Notice.....................................................................................12
InstallationGuide..................................................................................................12
Environment.............................................................................................................................12
InstallationInstructions............................................................................................................15
SecurityWarnings....................................................................................................................15
DeviceInstallation.....................................................................................17
InstallationPreparation..........................................................................................17
CheckPackingList....................................................................................................................17
Tools&Utilities.........................................................................................................................17
DeviceInstallation.................................................................................................17
InstallSwitchto19’’rack..........................................................................................................17
ConnectConsoleCable.............................................................................................................18
InstallSFPTransceiver..............................................................................................................19
ConnectCable/Fiber.................................................................................................................20
ConnectPowerSupply..............................................................................................................21

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage5of23
Product Introduction
Overview
MyPowerS4152F-POE-ACV2diagram:
MyPowerS4152F-POE-ACV2 routingswitch
MyPower S4152F-POE-ACV2:
Model 10/100/1000Mauto-sensingEthernet
port(RJ-45port) 1000MSFP port CONSOLE Port
MyPowerS4152F-POE-
ACV2 48 4
1
OneSFPportandtheRJ-45 portformoneCombo port,thatis,onlyoneof
thetwoports thatformtheComboportcanbe usedatonemoment.
MyPower S4152F-POE-ACV2providesfour Comboports,whichareformed
byfour SFPports andRJ-45port45,46,47,48.
Asforperformanceandfunction,MyPowerS4152F-POE-ACV2routing
switchisinaleadingposition inthesimilarproducts andcanmeetthe
networkingrequirementsof hugenetworks.Withrichintelligentand
securityfeatures, itserves ideallyastheconvergencedevices ofcampus
networks,enterprisenetworksandIPmetropolitannetworks,aswell as
coredevicesof small andmedium-sized networks.

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage6of23
ProductFeatures
lRichinterfacetypes
MyPowerS4152F-POE-ACV2routingswitchprovides44fixed RJ-45ports,
fourComboports (SFP/RJ-45)andtwo10Gextended slots.
lSecurePower Supply
MyPowerS4152F-POE-ACV2routingswitchsupports220VACinput,12V
DCinputor 220V AC/12V DCinputsimultaneously.
lSupport10GEthernet
The10GEthernet,whichadoptsfull-duplextechnologyinsteadoflow-
speed, half-duplexCSMA/CDprotocol,isabigleapintheevolutionof
Ethernet.The10GEthernetcanbe deployed instaror ringtopologies.
MyPowerS4100seriesswitchprovidesbroadbandwidthandpowerful
processingcapacity.It issuitablefor MANandWAN. It simplifiesnetwork
structures, andreduces costof networkconstruction.
lSupportrichnetworkprotocols
MyPowerS4100 seriesswitchsupports 802.1d/w/s,802.1Q,802.1p,
802.3ad,802.3x,GVRP,DHCPandSNTP.It supports multicastprotocols
suchasIGMP,DVMRPandPIM.It supports RIPv1/2,OSPFandIPv6.All
these protocolsenableMyPowerS4152F-POE-ACV2routingswitchto
meetrequirementsof complexnetworkconstructions.
lPowerful ACLfunction
MyPowerS4152F-POE-ACV2routingswitchsupports comprehensiveACL
policies.Thetrafficcanbe classifiedbysource/destination IPaddresses,
source/destinationMACaddresses,IPprotocols,TCP/UDP,IPpriority,time
ranges andToS.Variouspolicies canbeusedtoforwardthetraffic.By
implementingACLpolicies, userscanfilterviruspacketssuchas
“Worm.Blaster”,“Worm.Sasser”and“Red Code”.MyPowerS4128Fswitch
supports IEEE802.1xport-basedaccessauthentication,whichcanbe
deployed withRADIUStoensuretheport-levelsecurityandblockinvalid
users.
lRich QoS policies

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage7of23
MyPowerS4100seriesswitchfullysupports DiffServmodule. Eachport
provideseightpriorityqueues.Userspecifies aqueuebandwidthoneach
port.It supports WRR/SP/SWRRscheduling.Usersdeploytrusted CoS,
DSCP,IPpriorityandportpriority.Usersmodifypacketvalues ofDSCP
andCOS.Thetrafficcanbeclassified byport,VLAN,DSCP,IPpriorityand
ACLtable.Theusermodifiespacketpriorityvaluesof DSCPandIP.The
userspecifiesdifferentbandwidthsforvoice/data/videotocustomize
differentqualities ofservices.
lPerfectnetworkmanagement
MyPowerS4152F-POE-ACV2routingswitchsupports SNMP,outbandand
inbandmanagement,CLIandWEBinterfaces,andRMON. It adoptsSMTP
protocoltoautomaticallysendrelated sensitiveinformationtothe
Administrator.It supports SSHprotocoltoensurethesecurityofswitch
configuration andmanagement.
Appearance
Front Panel
1. Frontpaneldiagram
ThefrontpanelofMyPowerS4152F-POE-ACV2 routingswitch isasshown
inthefollowingtable. Thefourcomboports areformed byfourSFPports
andfour RJ-45ports.
DescriptionforthefrontpanelofMyPowerS4152F-POE-ACV2routing
switch:
Model RJ-
45
Port
Combo
Port CONSOLE Port POE Button LED
MyPower
S4152F-POE-
ACV2 44 4 OneRJ-45
serialcontrol
port 1 54(48port
indicators andsix
systemindicators)
TheMyPowerS4152Ffrontpanelprovides44RJ-451000M electricports,
fourcomboports (fourRJ-45 portsandfourSFPports),oneconsoleport
and54LEDs.

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage8of23
ThefrontpanelofMyPowerS4152Froutingswitchisasfollows:
2. Consoleportdescription
MyPowerS4152F-POE-ACV2routingswitchprovidesoneRJ-45serial
consoleport.Withtheinterface, theusercancompletethelocalorremote
configuration for theswitch.
Consoleportsupports theasynchronousmode.Setdatabitsas8,stop
bits as1andparitycheckasnone.Bydefault,thesupported baudrateis
9600bps.
Besides,consoleportsupports thebaudrate14400,19200,38400,57600,
and115200(bps)in Bootrommode,butthebaudratesettingwill become
invalidafter restartingtheswitch.
BackPanel
Thebackpanelof MyPowerS4152F-POE-ACV2includesone220VAC
socket,oneDCpower(redundancypower,RPS) socket,onePOEpower
socket,onegroundingterminal,andtwo10Gextendedslots.
BackpanelofMyPowerS4152F-POE-ACV2
LEDs
ThefrontpanelofMyPowerS4152F-POE-ACV2has54 indicators,
includingportindicators,powerindicators,DCpowerindicators,system
autodiagnosischeckstatusindicator,POE statusindicator,and1/2status
indicatorof extended module. Themeaningdescription isasfollows:
Theindicator descriptionof MyPower S4152F-POE-ACV2routingswitch:
Indicator Panel LabelStatus Meaning
Powerindicator PWR Greenlight Theinternalpowerrunsnormally

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage9of23
Off Nopowerorerror
Greenlight Theredundancypowerunitaccepts
energy.
Redundancypower
indicator RPU Off Theredundancypowerunitisclosedor
error
Flashing
greenlight Systemautodiagnosisdetectionis running
Greenlight Systemautodiagnosisdetectionis
complete
Systemautodiagnosis
detectingstatus
indicator DIAG
Yellowlight Systemautodiagnosisdetectionfails
Greenlight DisplaythePOEstatusofeachport
Flashing
yellowlight
Thepoweralreadyreachesthe
scheduledmaximum valueorisnot
enoughforthenewPOEport
POEindicator POE
STATUS
Off Theportindicatordisplays the
connectionstatusofeachport.
Greenlight Theextendedmoduleisinstalled
Yellowlight Theaccessoftheinstalledextended
moduleiserrororfails.
Extendedmodule
indicator MODULE1/
MODULE2 Off Theextendedmoduleisnotinstalled.
TheportindictorandPOE statusindicator dependonthebuttonof
selectingthemode.Theportindicator showstheconnectionstatusand
POEstatus.Bydefault,itshowstheconnection status.
Thedescription forthebutton of selectingthePOEmode:
POEButtonStatus PortIndictorMode POEStatusIndicator
Mode
Thebuttonisnotpressed DisplaytheLINK-ACTstatus
oftheport Closed
Thebuttonispressed DisplaythePOEstatusofthe
port DisplaythePOEstatus
Thedescription of theportindicators:
LED Status Description
Redlight Theportisinthe10Mor100Mconnectionstatus
Greenlight Theportisinthe1000Mconnectionstatus
Flashingredlight Theportisinthe10Mor100Mconnectionstatus
Flashinggreen
light Theportisinthe1000Mactive status
LINK/ACT
Off Noconnectionorconnectionfails
Redlight ThePDconnectionisnormal
Flashingredlight Theportistransmittingdata
POE Off NoPDconnection

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage10 of23
PowerSystem
lDC/AC powerrange
AC rated voltagerange:100V~240V;
Input frequency requirement:50/60Hz(+/-3Hz);
lRPS
DCpowerrange: -48V~-60V (rated-48V)
lPOE module
Model DCinput Protocolstandard Supported
ports
Max.power
supportedby
eachport
MyPowerS4152F-POE-AC
V2
-52V~-55V
(rated-
52V) IEEE802.3af 48 15.4W;support
full-configured
24ports
System Features
Thesystemfeatures ofMyPowerS4152F-POE-ACV2routingswitch:
Model
Attribute MyPowerS4152F-POE-ACV2
Chassisdimension(WxDxH)
(mm) 440×328.4×43.4
SM41F-2XFPdimension(W×L)
(mm) 107x145.9
Weight 5.19kg
Fixedports 44 RJ-45 ports,fourComboports (fourSFP portandfour
RJ-45ports)
Consoleports OneRJ-45serialConsoleport
Extendedslots 2
AC 100V 240V 50/60Hz
DC -48V~-60V(rated-48V)
Inputpower POE
Module -52V~-55V(rated-52V)
System
power 130W
Max.power POE
power 370W
Runningtemperature 0°C 50°C

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage11 of23
Storagetemperature -40°C 70°C
Relativehumidity 10% 90%,nocondensing
MTBF Lowest 120,000hoursMTBF

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage12 of23
Installation Notice
InstallationGuide
Toensurethesecurityofyouandothersandthenormalrunningofthe
switchwheninstallingandusingMyPowerS4152F-POE-ACV2routing
switch,readthefollowinginstructions.
Environment
lInstall theswitch in aclean place,ormaybedamagedbyelectrostatic
affects.
lMaintainthetemperaturebetween0°Cto50°Candthehumidity
within10%to 90%andnon-condensing.
lKeep theswitchinadryandcool place. Leavesufficientspacing
aroundtheswitchforgoodaircirculation.
lTheswitch shouldworkin thepower input-ACpower: 100V~240VAC
(50/60Hz),DCpower: -48~-60VDC.
lGroundtheswitch properlytoavoidESDdamageandphysicalinjury.
lAvoiddirect sunlighton theswitch.Keeptheswitchawayfromheat
sourcesandstrongelectromagneticinterferencesources.
lMounttheswitchto astandard19’’rackor place itonaflat desk.
Dust &Particles
Dust isharmful to thesafeoperation ofMyPowerS4128Fswitch.Dust can
leadtoelectrostaticaffects,especiallyunderlowrelativehumiditycausing
poorcontact ofmetalconnectorsorcontacts.Electrostaticadherence will
resultinnotonlyreduced productlifespan,butalsoinincreasednumber
ofcommunication failures.Therecommendedvaluefor dust contentand
particlediameter in thesiteisshown below:
Max Diameter(µm) 0.5 1 3 5
Dustdensity 1.4×1077×1052.4×1051.3×105

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage13 of23
(particles/m )
EnvironmentalRequirements: Dust
Theswitchwill getdamaged iftheaircomprisessalt,acidandsulfide
contents.Such harmful gasesspeedupmetalcorrosion andagingofsome
parts.Thesiteshouldavoidharmfulgases such as SO2, H2S, NO2, NH3and
Cl2.Thetablebelowdetailsthresholdvalues.
Gas Average (mg/m ) Max(mg/m )
SO20.2 1.5
H2S 0.006 0.03
NO20.04 0.15
NH30.05 0.15
Cl20.01 0.3
Temperature& Humidity
Foragoodaircirculation aftertheswitchbeinginstalled, itis
recommendedto keep theswitchrackin aroomwith astabletemperature
andhumidity.Please use anair-conditionertocoolitupinsummeranda
heatingsysteminwinter.Ifthehumidityintheequipmentroomistoo
high forlongtime, itcauses thepoorinsulationandeven electricityleakof
insulation materialseasily.Sometimes, themechanicalperformancesof
materialschangeandthemetalpartsarecorroded easily,too.Ifthe
relativehumidityistoo low,insulationpadsshrink,whichcausesthe
fastenedscrewsloose.Meanwhile,in dryenvironment,staticelectricity
appearseasily,whichharmsthecircuitson theswitch.Ifthetemperature
istoohigh,thereliabilityof theswitch reducesgreatly.Thelong-timehigh
temperatureaffectsthelifeandspeedsuptheagingofinsulation
materials.Therecommendedworkingtemperatureandhumidityarelisted
inthefollowingtable:
Temperature: Relativehumidity
Longtermcondition Shortterm condition Longtermcondition Short term condition
15~30°C 0 ~50°C 40 ~ 65% 10 ~ 90%
Note:
Theworkingenvironmenttemperatureandhumidityoftheswitchshould
be measured at 1.5mabovethefloor and0.4min frontof therack,
withoutfrontorbackprotectivepanelon therack.Theshort-termworking
condition meanslessthan 48 hourscontinuouslyandlessthan15 daysfor
theannualtotal;Extremeadverseworkingenvironmentmeansthe
environmenttemperatureandhumiditywhentheair-conditioningsystem
intheequipmentroomfails.Thedurationshouldbe within5hours.

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage14 of23
PowerSupply
Theswitchadoptsmodularpowersupply.Beforeswitchingon,ensure
propergroundingofthepowersupplysystem.Theinputsourcefor the
switchshouldbe reliableandsecure. Useavoltageadaptor,ifnecessary.
Thebuilding’scircuitprotectionsystemshouldincludeafuse orcircuit-
breakerof nogreaterthan240 V,5Ain thecircuit.It isrecommended to
useaUPS formorereliablepower supply.
Groundingthepowersupplyimproperly,extremefluctuationsin theinput
powerorhugepulseresultintheabnormalrunningoftheswitch,oreven
hardwaredamage!
Anti-static
Electrostaticcurrents damagetointernalcircuitsoreven theentireswitch.
Toavoiddamage:
lEnsureproper earth groundingof thedevice
lPerformregularcleaningto reducedust
lMaintainpropertemperatureandhumidity
lWearanESDwrist strapandantistaticuniformwhenin contactwith
circuitboards
Anti-interference
All sourcesofinterference,whetherfromthedevice oroutside
environment,affectoperationsinvariouswayssuchascapacitive
coupling,inductivecoupling,electromagneticradiation,common
impedance (includingthegroundingsystem)andcables/lines (power
cables, signallines,andoutputlines).
Note:
lPreventpower interruptions
lProvide thesystemwithadedicated grounding,ratherthansharing
thegroundingwithelectronicequipmentorlightningprotection
devices

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage15 of23
lKeep awayfromhighpowerradiotransmitters,radartransmitters,
andhighfrequencystrongcircuitdevices
lProvide electromagneticshielding
RackConfiguration
Thedimensionsoftheswitcharedesigned tobemountedonastandard
19’’rack.Thedimensionsare436mmx44 mmx420mm (WxHxD).
Ensuregoodventilation fortherack.
lEverydevice intherackgenerates heat duringoperation.Provide
goodventilation andfansfor theenclosedrack.Donotstackdevices
closely.
lWhenmountingdevicesin anopenrack,preventtherackframefrom
obstructingtheswitchventilation.Besuretocheckpositioningofthe
switch after installation.
Ifastandard19’’rackisnotavailable, theswitch can be placedon aclean
leveldesktop,leaveanappropriateclearance aroundtheswitchfor
ventilation.Donotplaceanythingon topof theswitch.
InstallationInstructions
lReadrelated chaptersin thismanualcarefullyor participatein
concerningtechnologytrainingbeforetheinstallation.Makesureall
materials,toolsandotheritemsrequired bytheinstallationare
prepared, aswellasaproper sitefor installationanddebugging.
lDuringtheinstallation,itisrequiredtouse thebracketsandscrews
provided intheaccessorykit,andpropertoolstoensurestabilityand
reliability.UsersshouldalwayswearantistaticuniformsandESDwrist
strapstopreventdamagingtheswitch,andshouldonlyuseandmake
standardcables andconnecters.Becautioustopotentialdangers
duringtheinstallation,andmakeprotectivepreparationstoavoid
accidents.
lCleanthesiteaftertheinstallation.Pleaseensuretheswitchiswell
grounded beforepoweringiton.Usersshouldalsomaintain theswitch
regularlyto extendits lifespan.
SecurityWarnings
lDonotstaredirectlyatthefiberportduringoperationtopreventeye
damagecaused bythelasertransceiverintheSFPopticalmoduleof
theswitch.
lDonotattempt toconduct anyoperation whichmaycausephysical
injuries,accidents or damagetheswitch.

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage16 of23
lDonotinstall,remove,ordisassembleswitch andmodules withpower
ontoavoidinjuringyourselfordamagingtheequipment.
lDonotopentheswitchwithoutpermission.Pleaseresorttothe
manufacturerfor helpifanyproblemoccurs,topreventphysical
injuriesanddevice damages.
lNocontact betweenmetalsandtheworkingpowerisallowed,anddo
notdropmetalsintotheswitch,topreventshort-circuitanddevice
damages.
lDonottouchthepowerplugandpowersocket,topreventelectric
shock.
lDonotplace thetindernear theswitch,topreventfire.
lDonotdebugtheswitchaloneinadangeroussituation,toprevent
accidents.
lUse standardpowersocketswhichhaveoverloadandleakage
protection,to preventaccidents.
lCheckthecircuits,installationandtheworkingenvironmentfor
potentialdangers,andmaintainthemregularly,forthesakeof
security.
lPlacetheemergencypowerswitchin theworkingsite, sothatthe
power can becutoff immediatelyifanyaccidentoccurs.
Note:
Thepotentialdangersinclude: electricleakagein thepower,theignition of
thepower,brokenelectriccablesorlines, badgrounding,electric
overload,short-circuitandetc.Incases of accidentslikeelectricshock,
fireor short-circuit,pleasecutoffthepowerimmediatelyandcall the
police.Pleasehelpthevictimsafterconfirmingthesecurityandprovide
first aidaccordingtotheirsituations.Callprofessionalmedical
organizationsfor helpin time.

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage17 of23
DeviceInstallation
InstallationPreparation
CheckPacking List
Unpackandchecktheequipmentinsideasper thepackinglist.
Tools&Utilities
Required toolsandutilitiesareasfollows:
lCrosspointscrewdriver
lFlat-blade screwdriver
lESDwrist strap
lAntistaticuniform
Note:
Thetoolsabovearenotprovidedalongwith theswitch.
Device Installation
InstallSwitchto19’’rack
InstallMyPowerS4152F-POE-ACV2routingswitchonthe19’’rackas
explained below:

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage18 of23
InstallingS4152F-POE-ACV2on therack
Installtheswitch accordingto thefollowingsteps:
1. Attachthebracketsonbothsides oftheswitchwithscrewsprovided
intheaccessorykit.
2. Putthebracket-mountedswitch ontoastandard19’’rack.Fasten itat
aproperlocation withthescrewsprovided,leavingenoughspace
aroundtheswitchforgoodaircirculation.
Caution:
Thebracketsareusedtofixswitchontherack.Theycannotserveasa
bearing.Place arackshelfundertheswitch.Donotplaceanythingontop
oftheswitch.Donotblocktheblow-holeson theswitchtoensuregood
operationof theswitch.
ConnectConsole Cable
Theswitch provides aserialconsoleport.Forexample:
Connectingconsolecableto MyPower S4152F-POE-ACV2
Connectconsolecableasfollows:

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage19 of23
1. Findtheconsolecableprovidedin theaccessorykit.Attachone
connector ofthecabletoswitch consoleport.
2. Connect theothersideof theconsolecabletoacharacterterminal
(PC).
3. Poweron theswitchandcharacterterminal.Configureswitchviathe
character terminal.
InstallSFPTransceiver
MyPower S4152F-POE-ACV2 providesmultipleSFP1000Mfiber ports.
Thestepsfor installingSFPGigabitfiber transceiver:
Step 1: Puton ESDwrist strap(or antistaticgloves)
Step2: InsertSFPtransceiverontotheguiderail inside theSFPgigabit
opticalport.DonotputSFPtransceiver up-side-down.
Step3: PushSFPtransceiveralongtheguide rail gentlyuntilyou feelthe
transceiver snapinto place atthebottomof theslot.
SFPtransceiver ishot-swappable.
Caution:
Donotlookdirectlyatthetwo-fiberboreinSFPtransceiverwhenthe
switchisinoperation.Otherwise,thelaser maydamageyour eyes.
Install10G ModuleTransceiver
MyPower S4152F-POE-ACVroutingswitchprovides10Gslot.Thesteps for
installing10GmoduleandtheXFP10Gfiber transceiver on themoduleare
asfollows:
1. Puton ESDwrist strap(or antistaticgloves);
2. Insertthe10Gmoduleintotheinsideguiderail of the10Gextended
slot;
3. Push10Gmodulealongtheguide railuntil connectingthefrontpanel
closely;
4. InsertXFPtransceiverintotheinsideguiderailof the10Gmodule. Do
notputXFPtransceiver up-side-down;

MyPowerS4100 SeriesSwitchInstallManual(S4152F-POE-AC V2)V1.0
MaipuConfidential& ProprietaryInformationPage20 of23
5. Push theXFPtransceiver untilconnectingthe10Gmoduleclosely.
XFP10Gfiber transceiver ishot-swappable.
%Caution
Donotlookdirectlyatthetwo-fiberboreinXFP10Gfibertransceiver
whentheswitchisin operation.Otherwise,thelasermaydamageyour
eyes.
ConnectCable/Fiber
ConnectEthernetcablesasfollows:
Step1: Insertoneendof theEthernetcabletotheRJ-45 Ethernet
interfaceof theswitchelectricalinterface.
Step2: InsertotherendoftheEthernetcabletotheRJ-45 Ethernetport
of someother device.
Step3: Checkall statusindicatorsfor theports;alighted LEDindicates
that thelinkisestablished.Otherwise, thelinkisnotreadyandthecable
shouldbeexamined.
Caution:
Checksignon theinterfacetoensureusingtherightport.Connectingto
wrongportsmaydamagetheswitchmodules.
Connectthefiber asfollows:
Step1: RemovetheprotectiveplugfromSFP/XFPfibertransceiver.
Removeprotectivecapfromoneendof thefibercable.Keep thefiberend
clean.
Step2:Attachoneendof thefibercabletoSFP/XFPtransceiver,and
otherendtothetransceiverofthecorrespondingdevice.TheSFP/XFP
transceiver’sTXportshouldbe connectedtotheRXportofthe
correspondingdevice, andvice versa.
Step3: Checkthefiberportstatusindicator.AlightedLEDindicatesthat
thelinkisestablished. Otherwise,thelinkisnotreadyandshouldbe
examined.
