Maisense Freescan User manual

A
B
131-MS013-0001 vr.00 www.maisense.com
[email protected]
線上教學
B
A
Sticker
10
The pulse indicator blinks green
at the same frequency when
your pulse is detected and
measuring.
NO shake until you hear a beep.
The measurement takes approxi-
mately 10 sec.
If you can’t get results of step 6, please find Error message in
the back page.
Event
User
Measurement date Measurement time
Stress level
Heart rate
Systolic pressure
Measurement status
Set up
Measure
Calibrate
Pair
Set up
Measure
Black sticker mark is the best location of pressing pulse.
Initial configuration
Input your language, the current time and personal
data using the Up/ Down, and Set buttons.
Input data will affect the correctness of the measurement.
Step 1
Conrm the location of
your pulse
Step 2
Use your right fingers to find
the pulse along the radial
artery ( red line ) of your left
wrist.
Bend the left palm outward
naturally.
Affix the auxiliary sticker on
the pulse you just found.
Confirm the auxiliary sticker on the correct pulse
position.
Stickers
Position of ngers
Step 3
Start measurement
Step 4
Align the black spot on the device
with the black spot on your left
wrist to get a measurement. A
Press and hold the start button
until the measurement is done.
Please do not move during
measuring. B
Results
Step 6
Observe pulse indicator
while measuring
Step 5
Quick Start Guide A-D
Press the start button with proper
force and place the pulse sensor
over the pulse location.
Put your forearms and elbows
on a table to get the measure-
ment easily and stably.
Sit down. Put both hands
on the table and relax your
shoulders.
Your left wrist is between
your heart and leg while
measuring.
You right thumb and middle
fingle must maintain contact
with the two ends of the
ECG sensors A2.
Hold with your
right fingers.
The measurement has succeeded when you see
this screen. You can read your blood pressure
from the screen.
Ensure that the auxiliary
stickers are aligned.
Do not move or shake your
head, body or the device
during the measurement.

D
C
Round 1
Round 1 result
A
Calibration
Back
Set
Clear
A
USER A
01-01 05:23PM
A
Calibration
Round 1/2
Start
measuring
with Freescan
Adjust to
Calibration
Measure with
Certified BP
Monitor.
Done
Round 2
Round 2 result
Adjust to
Calibration
Measure with
Certified BP
Monitor.
Done
Calibration
Round 2/2
Start
measuring
with Freescan
Download for
Apple iOS
USER A
01-01 05:23
PM
A
Accept
Reject
1234-5678
BT
USER B
01-01 05:24
PM
B
USER A
01-01 05:23
PM
A
USER A
01-01 05:23
PM
A
3
4
Calibrate
Pair
E rror message User Switching
Install myFreescan app on your smartphone.
Scan the below QR code or search on App store / Google Play for
myFreescan app to install it on your smartphone.
Install myFreescan app
on your smartphone
Step 1
Pair device and
myFreescan app
Step 2
Turn on the power of
the device and press
the down button “V”
to enable Bluetooth.
Pick your Freescan
device and verify the
passkey to get paired.
– Click “Setting” on the dashboard of myFreescan app.
– Click “Bluetooth setting“.
– Click the “Pair“ button and search for a pairable
device.
Ensure your smartphone Bluetooth is enabled.
Upload the measured data
to myFreescan app
Step 3
Please ensure your device is
turned on and click “Sync” to
upload the measured data.
can be calibrated with another certified
blood pressure monitor to ensure its accuracy.
Please calibrate your before using it for
the first time, after dramatic weight change, surgeries, or
critical illness, and calibrate it every 6 months afterwards.
No ECG
detected
Press the Start button to measure
again.
1. Use wet wipes to moisturize the
wrist and nger tips.
2. Wipe away grease on the
electrodes.
3. Conrm Step 3 and Step 4 of B
Press the Start button to measure
again.
E01
Device not
stable
1. Rest your shoulder, forearm and
elbow comfortably on the table .
2. Make sure your hands are not
off the table.
3. Do not shake the device.Do not
attempt to view the device screen.
E05
Weak pulse
Press the Start button to measure
again.
Conrm Step 2 of the location of
your pulse and conrm Step 4 of
A and B.
If E05 still appears, rest for 5 minutes and try to measure again.
E07
Radio
interference
If E07 occurs constantly, please contact the distributor for further
assistance.
Keep at least one meter away
from radio sources, such as
computer screens.
Press the Start button to measure
again.
Product Name: Heart Performance Monitor (311020)
Model: Freescan
FCC Notices :
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.This equipment has been
tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures :
– Reorient or relocate the receiving antenna.Receiver is connected.
– Increase the separation between the equipment and receiver.
–Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
–Consult the dealer or an experienced radio/TV technician for help.
CAUTION :
Any changes or modifications not expressly approved by the grantee of this device could void the user's
authority to operate the equipment.
2
1
Eva
Press and hold the up button to switch to the
other user if created.
Start button
released
Press the Start button to measure
again.
Keep the Start button pressed
until the measurement is complete.
Bluetooth
not found
Enable the Bluetooth function on
your smartphone.
Ensure the distance of device and
smartphone are within 5 meters.
Press the Start button to measure
again.
Device
failure
Please reset the device through
the reset hole. If this error reoccurs,
please contact the distributor for
further assistance.
Press the Start button to measure
again.
