Majestic Royalton BE36 Guide

Service Parts BE36
Beginning Manufacturing Date: N/A
Ending Manufacturing Date: Active
Royalton Woodburning Fireplace
Part number list on following page. 01/21
3
1
4
5
2- Damper Kit
(Air Handle)
1Piece Rod
6
7
8
9
10
11
12
13 14
15
16
17
18
19 20
21

Service Parts BE36
Beginning Manufacturing Date: N/A
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Home Technologies does
not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
ITEM DESCRIPTION COMMENTS PART NUMBER
1Starter Section Assembly SRV22069
2Damper Kit Repair SRV4044-029
3**Damper Weight SRV19785
4Damper Rod SRV28900
5Damper Blade Assembly SRV4044-030
6Damper Control SRV4044-152
**If damper rod is in place and needs the damper blade order damper weight
(SRV19785), screws (12460/40) & damper blade (SRV11835)
**Screws Pkg of 40 12460/40
7Top Stando󰀨 Qty 4 req SRV4044-111
8Front Face (Top or Bottom) SRV4044-124BK
9Column (Right or Left) SRV4044-104BK
10 Door Track (Used for Upper) SRV15425TB
SRV15425BK
11 Smoke Shield SRV4044-131BK
12 Refractory Retainer Qty 3 req SRV11847
13 Side Refractory Qty 2 req SRV4044-220
14 Back Refractory SRV4044-222
15 Grate GR41
16 Grate Retainer Qty 2 req SRV4044-170
17 Hearth Retainer SRV4044-128BK
18 Hearth Refractory SRV4044-221
19 Firescreen Assembly Qty 2 req SRV4044-028
20 Firescreen Handle SRV10002
21 Firescreen Rod 1 piece SRV4044-175
Door Pivot Clip Qty 2 req SRV31527
Extended Smoke Shield Kit SRV4044-179BK
SRV4044-179TB
Nailing Flange Qty 4 req SRV4044-161
Smoke Ba󰀪e Qty 2 req SRV4044-116
Strip Protector Qty 2 req SRV18320
Installation Manual 4044-197
Owner’s Manual 4044-198
Touch-Up Paint 71479
