Makita BHX2500 Quick start guide

Parts Breakdown BHX2500
Page 1 of 13 2/8/2008

Parts Breakdown BHX2500
Page 2 of 13 2/8/2008

Parts Breakdown BHX2500
Page 3 of 13 2/8/2008

Parts Breakdown BHX2500
Page 4 of 13 2/8/2008

Parts Breakdown BHX2500
Page 5 of 13 2/8/2008

Parts Breakdown BHX2500
Page 6 of 13 2/8/2008

Parts Breakdown BHX2500
Page 7 of 13 2/8/2008

Parts Breakdown BHX2500
Page 8 of 13 2/8/2008

Parts Breakdown BHX2500
Page 9 of 13 2/8/2008

Parts Breakdown BHX2500
Page 10 of 13 2/8/2008

Parts Breakdown BHX2500
Fig # Part ID Part Name Quantity
1 0736289980 CAUTION LABEL, BHX2500 1
2 6659500200 PROTECTOR LABEL, BHX2500 1
2 6659504300 N/A 1
3 6609513200 CAUTION LABEL, BHX2500 1
4 6655500000 GRIP, BHX2500 1
5 6655001000 SWITCH CPL., BHX2500 1
6 6651500500 FRICTION RUBBER, BHX2500 1
7 6651014000 VOLUTE CASE 2 ASS'Y,BHX2500 1
8 0630029730 CONTROL CABLE, BHX2500 1
9 6655500300 THROTTLE LEVER, BHX2500 1
9 6655500301 THROTTLE LEVER, BHX2500 1
10 0043605300 SCREW ASS'Y, RST250 3
11 6651003000 IMPELLER CPL.,BHX2500 1
12 0043606200 SCREW ASSEMBLY, RBL500 2
13 6651010000 VOLUTE CASE 1 ASS'Y,BHX2500 1
14 6655500100 CRUISE LEVER, BHX2500 1
15 6655500200 SPRING, BHX2500 1
16 0150049840 TAPPING SCREW 4X16, BHX2500 1
17 0150059760 T. SCREW 5X16, BHX2500 10
18 6601503400 OUTER SNAP RING, RBL250 1
19 6601502702 PROTECTOR, BHX2500 1
19 6601502704 N/A 1
20 6601503500 RUBBER WASHER, RBL250 1
21 6601503201 SCREW, RBL250 1
22 0150059760 T. SCREW 5X16, BHX2500 1
23 0031205003 WASHER, BHX2500 1
24 6601503001 SPRING, RBL250 1
25 6601503100 SHAFT, RBL250 1
26 0150059760 T. SCREW 5X16, BHX2500 3
27 6656500100 PLUG COVER, BHX2500 1
28 5926501600 OIL GUARD, BHX2500 1
29 5926017000 FUEL TANK CAP ASS'Y, BHX2500 1
30 0140049770 SCREW ASS'Y M4X16(W,SW), RBC201 2
31 6249501501 STRAP, EM4251 1
32 0851189950 TUBE, BHX2500 1
33 0561059990 HOSE CLAMP, EM4251 1
34 5236503900 FILTER, RBL500 1
35 0150059760 T. SCREW 5X16, BHX2500 3
36 0031005003 WASHER, BHX2500 3
37 6653500000 FUEL TANK, BHX2500 1
37 6653500100 N/A 1
38 6656500300 ENGINE COVER, BHX2500 1
39 0043605160 SCREW ASS'Y M5X16(W,SW),EM4251 3
40 5921004001 ROCKER COVER CPL., EM4250 1
41 0650109950 SPARK PLUG CMR6A, EM4251 1
42 5921500800 ROCKER COVER GASKET, EM4251 1
43 5921011000 CYLINDER BLOCK SET, BHX2500 1
43 5921011001 N/A 1
44 5921501800 CHECK VALVE, EM4251 2
45 5926500300 OIL WEIGHT, EM4251 1
46 5926500200 OIL TUBE, EM4251 1
47 0561059970 HOSE CLAMP, BHX2500 1
48 0119059510 S.H. BOLT M5X14, EM4251 8
49 5921500700 CAMGEAR COVER GASKET, EM4251 1
50 5921500502 CAMGEAR COVER, EM4251 1
51 0043605140 SCREW M5X14, RBC251 3
52 0240139950 O RING, BHX2500 1
53 0043605120 SCREW ASSEMBLY M5X12, RBC230 1
54 5926021000 OIL PIPE CPL.,BHX2500 1
55 5926501700 OIL GAUGE, BHX2500 1
Page 11 of 13 2/8/2008

Parts Breakdown BHX2500
56 0213229990 GASKET, BHX2500 1
57 5926501500 OIL CAP, BHX2500 1
58 5926500100 CASE GASKET, EM4251 1
59 5921501000 LEAD VALVE, EM4251 1
60 5921501100 RETAINER PLATE, EM4251 1
61 0119049980 S.H. BOLT M4X10, EM4251 1
62 5926500000 OIL CASE, EM4251 1
63 0043605180 SCREW ASSEMBLY, RBC230 4
64 5922004000 PISTON RING SET, EM4251 1
65 0565089970 CLIP, RST250 2
66 5922500900 PISTON, EM4251 1
67 5232502600 PISTON PIN, RST250 1
68 0440129960 OIL SEAL (L), EM4251 1
69 5421500500 CLIP, EM4251 1
70 0323039990 WOODRUFF KEY, RBC280 1
71 5922003000 CRANKSHAFT ASS'Y, EM4251 1
72 0440109970 OIL SEAL (S), EM4251 1
73 5933002000 ROCKER ARM ASS'Y, BHX2500 2
74 5923500700 PUSH ROD, EM4251 2
75 5923501300 SPRING RETAINER, EM4251 2
76 5923501200 VALVE SPRING, EM4251 2
77 5933500100 ROCKER SHAFT, BHX2500 1
78 5923501500 INTAKE VALVE, EM4251 1
79 5923501400 EXHAUST VALVE, EM4251 1
80 5921501400 SPACER, EM4251 2
81 5933003000 CAM GEAR ASSEMBLY, EM4250 1
82 5923500501 CAM GEAR SHAFT, EM4251 1
83 5923500600 CAM LIFTER SHAFT, EM4251 1
84 5923500001 CAM LIFTER, EM4251 2
85 5925001002 STARTER COVER ASS'Y, EM4251 1
86 5195500000 PULLEY, RBC201 1
87 5195002060 SET SCREW, RBC201 1
88 5195002100 SWING ARM, RBC201 1
89 5195002110 COLLAR, RBC201 1
90 5925001030 REEL, EM4251 1
91 5215002030 SPIRAL SPRING, RBC230 1
92 5225004020 STARTER KNOB, RBC221 1
93 5925001050 STARTER ROPE, EM4251 1
94 6659500300 LABEL, BHX2500 1
95 0140049770 SCREW ASS'Y M4X16(W,SW), RBC201 2
96 5923501801 INSULATOR GASKET, EM4251 1
97 5923013000 INSULATOR CPL.,BHX2500 1
98 0149069972 ADJUST SCREW M6X16, EM4251 1
99 0043605180 SCREW ASSEMBLY, RBC230 2
100 5923501900 CARBURETOR GASKET, EM4251 1
101 0043605140 SCREW M5X14, RBC251 1
102 5926022000 CARBURETOR, BHX2500 1
103 5926002060 PUMP BODY ASS'Y, EM4251 1
104 5016004010 INLET SCREEN, RBC230 1
105 5236046040 METERING DIAPHRAGM GASKET,RBC260 1
106 5926008010 METERING DIAPHRAGM, EM4251 1
107 5236046140 AIR PURGE BODY ASS'Y, EM4251 1
108 5246001150 PRIMER PUMP, RBC230 1
109 5236046050 PRIMER PUMP COVER, EM4251 1
110 5236046010 PUMP COVER SCREW, RBC230 4
111 5206008030 P.H. SCREW, RBC221 2
112 5236018040 SWIVEL, RBC230 1
113 5426005030 WASHER, EM4251 1
114 5316005120 RING, RBC230 1
115 5926002020 PUMP SPRING, EM4251 1
116 5246001010 O RING, RBC230 1
Page 12 of 13 2/8/2008

Parts Breakdown BHX2500
117 5196002020 JET, RBC201 1
118 5926002040 PUMP GASKET, EM4251 1
119 5246001040 PUMP DIAPHRAGM, RBC230 1
120 0561080010 HOSE CLAMP, EM4251 1
121 5921500900 BREATHER PIPE, EM4251 1
122 5933502100 PIPE, BHX2500 1
123 5933001000 CLEANER PLATE ASSY, EM4250 1
124 5923502200 CHOKE LEVER, EM4251 1
125 0240159990 O RING P15, EM4251 1
126 5933005000 AIR CLEANER PLATE CPL, EM4250 1
127 5923502400 CHECK VALVE (1), EM4251 1
128 0240139970 O RING P14, EM4251 1
129 5923502500 CHECK VALVE PLATE, EM4251 1
130 5316500701 CHECK VALVE, EM4251 1
131 5923503500 SEPARATOR GASKET, EM4251 1
132 5933501600 SEPARATOR PLATE,MS2514 1
133 5933500900 AIR CLEANER ELEMENT,EM4250 1
134 5933501200 AIR CLEANER ELEMENT,EM4250 1
135 5933500800 AIR CLEANER COVER,EM4250 1
136 0140059480 SCREW M5X14, EH561 1
137 5923503100 SCREW M5X68(W,SW SUS),EM4251 2
138 5923502600 PLATE, EM4251 1
139 0213069990 GASKET, RBC230 1
140 5923502301 CHOKE PLATE, EM4251 1
141 0119059520 SOCKET HEAD BOLT M5X40, RBC201 2
142 5923014000 EXHAUST MUFFLER, BHX2500 1
142 5923014001 EXHAUST MUFFLER, BHX2500 1
143 5923008010 SPARK ARRESTER, EM4251 1
143 5923008011 SPARK ARRESTER, EM4251 1
144 5923504300 MUFFLER GASKET, BHX2500 1
145 5927010000 WIRE 1, BHX2500 1
146 5927011000 WIRE 2, BHX2500 1
147 5927500100 PLUG CAP, EM4251 1
148 0654009931 PLUG CAP SPRING,RBC221 1
149 5927012010 IGNITION COIL, BHX2500 1
149 5927012011 N/A 1
150 0043704200 SCREW ASS'Y M4X20, BHX2500 2
151 0130069940 BOLT ASS'Y M6X16, BHX2500 1
152 5927500200 FLYWHEEL, BHX2500 1
153 6659500900 PIPE, BHX2500 1
153 6659504000 PIPE, BHX2500 1
154 6659501000 END PIPE, BHX2500 1
1,001 6909059000 TOOL KIT, BHX2500 1
Page 13 of 13 2/8/2008
