Parts Breakdown 5012B
Page 1 of 2 8/18/2010

Parts Breakdown 5012B
Fig # Part ID Part Name Quantity
Products with multiple versions are listed in subsiding order with the newest version on top not indented
1 163150-3 12 GUIDE BAR, 5012B (T2) 1
2 341561-4 CHAIN COVER, 5012B 1
3 251697-0 H.F.H. BOLT M8X17, 5014B 1
4 252070-7 HEX LOCK NUT M8-13, 5012B 1
6 253814-8 F. WASHER 8, 5012B 1
7 221514-8 SPROCKET 6, 5012B 1
8 253813-0 F. WASHER 12, 2708 1
9 321260-4 ADJUST PIN, 5012B 1
10 251210-4 P.H. SCREW M5X25, 5012B 1
10 251293-4 SCREW M5X25, 5012B 1
11 911263-2 P.H. SCREW M5X40, 2711 1
12 321261-2 PLUNGER, 5012B 1
13 213003-7 O RING 6, 5012B 1
14 231294-8 COMP. SPRING 6, 5012B 1
15 253811-4 F. WASHER 5, 5012B, 6891D 1
16 152252-0 CASING COMPLETE, 5012B 1
17 155811-9 OIL RESERVOIR (W/TUBE), 5012B 1
18 242022-6 CAP, 5012B 1
20 263005-3 RUBBER PIN 6,LS1013 1
21 411736-0 BAFFLE PLATE, 5012B 1
22 524581-5 FIELD, 5012B 1
23 911290-9 P.H. SCREW M5X65, GA7911 2
24 211068-3 B. BEARING 6200LB, 6820V 1
25 681623-9 INS. WASHER, LS1020 1
26 518420-9 ARMATURE, 5012B 1
27 241632-6 FAN 90, 5012B 1
28 211206-7 B. BEARING 6202LLB, NHP1310 1
29 263005-3 RUBBER PIN 6,LS1013 1
30 652518-3 OVERLOAD PROTECTOR, 5012B 1
31 156831-6 MOTOR HOUSING COVER, 5012B 1
32 911153-9 P.H. SCREW M4X28, JR3000V 4
34 651252-2 SWITCH,4100NH 1
35 953106-2 RIVET 0-5, HM1500 2
36 815477-4 NAME PLATE, 5012B 1
37 911133-5 P.H. SCREW M4X18, N9501B 2
38 687001-1 STRAIN RELIEF, 6013BR 1
39 664991-5 POWER CORD,5012B,T2 1
40 682504-0 CORD GUARD 10-85, 4200H 1
41 159082-0 MOTOR HOUSING, 5012B 1
42 911273-9 P.H. SCREW M5X50, HR2400 3
43 911263-2 P.H. SCREW M5X40, 2711 1
44 411747-5 PROTECTOR, 5012B 1
45 911233-1 P.H. SCREW M5X20, TW1000 2
46 411737-8 SIDE GRIP, 5012B 1
47 911253-5 P.H. SCREW M5X30, 2030S 3
48 181047-4 CARBON BRUSH SET 154,5402A 1
48 194986-9 CARBON BRUSH SET CB-154, UC3530A 1
49 643650-4 BRUSH HOLDER CAP, 5007MG 2
50 911118-1 P.H. SCREW M4X12, 6221D 1
51 911109-2 P.H. SCREW M4X8, HR2210 1
52 410646-8 RELAY COVER, 410 1
400 182229-1 OIL SUPPLY 100CC, UC120DWA 1
401 242012-9 NOZZLE, 5012B 1
402 744003-1 FILE, 5012B 1
403 782212-4 SOCKET WRENCH 13, LS1011 1
404 783002-8 PHILLIPS SCREWDRIVER # 2, N1900B 1
405 791172-9 12 CHAIN BLADE, 5012B 1
900 321396-9 CHAIN CATCHER, 5014NB 1
901 411936-2 SCABBARD, 5012B 1
902 158024-1 HOOK CPL., UC3530A 1
903 810174-7 N/A 1
