Makita DCS34 Quick start guide

Parts Breakdown DCS34
Page 1 of 8 8/18/2010

Parts Breakdown DCS34
Page 2 of 8 8/18/2010

Parts Breakdown DCS34
Page 3 of 8 8/18/2010

Parts Breakdown DCS34
Page 4 of 8 8/18/2010

Parts Breakdown DCS34
Page 5 of 8 8/18/2010

Parts Breakdown DCS34
Page 6 of 8 8/18/2010

Parts Breakdown DCS34
Fig # Part ID Part Name Quantity
Products with multiple versions are listed in subsiding order with the newest version on top not indented
1 913-650-304 SCREW 5X30, DCS34 3
2 036-118-020 HOOD (GREY), DCS34 1
3 036-173-011 AIR FILTER, DCS34 1
4 923-750-340 NUT, DCS34 2
5 913-650-304 SCREW 5X30, DCS34 2
6 036-171-011 CONNECTING MUFF, DCS34 1
7 913-650-504 SCREW 5X50, DCS34 2
8 369-155-010 PRIMER, DCS34 1
9 965-452-060 VENTILATION LINE, DCS9000 1
10 965-404-980 FUEL LINE, DCS34 1
11 965-603-021 SPARK PLUG,WSR5F DPC6200 1
12 036-140-010 IGNITION ELECTRONIC CPL., DCS34 1
13 913-340-204 SCREW 4X20, DCS34 2
14 970-311-490 SHORT-CIRCUIT CABLE, DCS34 1
15 920-308-024 HEX NUT M8X1, DCS340 1
16 926-208-001 SPRING WASHER 8, DPC7000 1
17 036-141-100 FLYWHEEL W/STARTER RATCH CPL.,DCS34 1
18 010-114-060 TANK PLUG CPL., DCS34 2
19 923-750-340 NUT, DCS34 1
20 913-650-304 SCREW 5X30, DCS34 4
21 963-601-380 SUCTION HEAD, DCS34 1
22 036-112-630 COVER, DCS34 1
23 965-404-031 STARTER GRIP, DCS340 1
24 965-403-490 RUBBER BUFFER, DCS341 1
25 036-163-010 REWIND SPRING. DCS34 1
26 985-000-155 STARTER ROPE 100 METER,DCS431 1
27 036-162-010 CABLE DRUM, DCS34 1
28 924-805-310 DISC (WASHER), DCS430 1
29 913-650-154 SCREW 5X15, DCS34 1
30 036-112-650 STARTER CPL., DCS34 1
31 036-114-100 OIL TANK CPL., DCS34 1
32 965-402-490 SUCTION LINE ASSY FOR OIL, DCS34 1
33 965-404-220 VENT VALVE, DCS330S,430 1
34 036-114-150 FUEL TANK CPL., DCS34 1
35 036-155-020 CHOKE LEVER, DCS34 1
36 036-155-031 CONTACT SPRING, DCS34 1
37 913-650-304 SCREW 5X30, DCS34 1
38 036-310-010 TUBULAR HANDLE, DCS34 1
39 965-402-360 RUBBER BUFFER, DPC7000 1
40 036-117-020 THROTTLE LINKAGE, DCS34 1
41 913-650-154 SCREW 5X15, DCS34 1
42 965-451-750 BUTTON, DCS6000I21 1
43 965-551-160 PRESSURE SPRING, DCS6000I21 1
44 965-551-150 STOP PIN, DCS6000I21 1
45 036-117-660 HANDLE HALF, DCS34 1
46 036-117-050 SPRING,DCS34 1
47 036-117-040 CATCH LEVER, DCS34 1
48 036-117-030 THROTTLE LEVER, DCS34 1
49 036-117-610 HANDLE HALF, DCS34 1
50 913-650-304 SCREW 5X30, DCS34 1
51 036-174-110 SPARK ARREST. MUFFLER ASSY., DCS34 1
52 036-174-200 SPARK ARRESTER SCREEN CPL., DCS34 1
53 913-350-654 SCREW 5X65, DCS34 2
54 928-405-000 WASHER, DCS340 2
55 965-522-032 GASKET, DCS5200I 1
56 036-131-011 CYLINDER, DCS34 1
57 036-131-020 SUCTION HOSE, DCS34 1
58 036-171-020 CLAMP, DCS34 1
59 036-131-030 INSERT FOR SUCTION HOSE, DCS34 1
60 021-132-110 PISTON ASS'Y, DCS341 1
61 021-132-030 PISTON RING, DS340 1
62 021-132-020 PISTON PIN, DCS340 1
63 108-132-050 SPRING RING, DCS340 1
64 962-900-057 RADIAL RING, DCS34 1
Page 7 of 8 8/18/2010

Parts Breakdown DCS34
65 960-102-129 BALL BEARING, DCS431 1
66 036-120-010 CRANKSHAFT ASSY., DCS34 1
67 960-102-129 BALL BEARING, DCS431 1
68 962-900-057 RADIAL RING, DCS34 1
70 965-531-010 GASKET, DCS34 1
71 036-111-010 CRANKCASE LOWER PART, DCS34 1
72 913-350-404 SCREW 5X40/20, DCS34 4
73 036-213-120 HAND GUARD CPL., DCS34 1
74 036-213-070 BUSH, DCS34 1
75 908-005-165 HEAD SCREW M5X16, DCS340 1
76 934-150-200 BOLT 5X22, DCS34 2
77 036-213-030 SPRING, DCS34 1
81 036-213-090 STRAINING SCREW, DCS34 1
82 001-213-042 NUT WITH PIVOT, DCS341 1
83 962-650-128 CYLINDRICAL PIN, DCS34 1
84 036-213-020 BREAK SPRING HOLDER CPL., DCS34 1
85 028-213-200 SPRING, DCS34,T2 1
86 923-208-004 HEX NUT, DCS341 2
87 036-213-650 SPROCKET GUARD CPL., DCS34 1
88 036-213-040 COVER PLATE, DCS34 1
89 927-306-000 SAFETY WASHER , DCS6800I 1
90 900-006-065 SPACER, DCS6800I 1
91 036-223-110 CLUTCH DRUM CPL 3/8, DCS34 1
92 028-213-501 BRAKE SPRING, DCS341 1
93 036-114-020 FIXING BUSH, DCS34 1
94 027-182-030 STOP DISC, DCS5200I 1
95 036-224-010 WASHER 10/16X2.5, DCS34 1
96 036-245-020 WORM, DCS34 1
97 036-110-020 BOLT, DCS34 1
98 965-403-490 RUBBER BUFFER, DCS341 2
99 965-403-490 RUBBER BUFFER, DCS341 1
100 036-110-600 MOTOR HOUSING CPL., DCS34 1
101 036-114-020 FIXING BUSH, DCS34 1
102 913-650-304 SCREW 5X30, DCS34 1
103 036-114-020 FIXING BUSH, DCS34 1
104 913-650-304 SCREW 5X30, DCS34 1
105 021-245-003 OIL PUMP CPL.,UC3500, UC4000 1
106 203-245-001 OIL PUMP HOLDER, UC3500, UC4000 1
107 913-335-060 SCREW 3.5X6.5, DCS34 1
108 927-304-000 SAFETY WASHER , DCS431 1
109 036-213-081 BUSH, DCS34 1
110 980-114-674 LABEL, DCS34 2
111 036-153-150 CARBURETOR COMPLETE, DCS34 1
112 036-153-100 REPAIR KIT, DCS34 1
113 036-153-110 GASKET-DIAPHRAGM KIT, DCS34 1
114 036-153-080 SCREW, DCS34 1
115 036-153-040 SCREEN, DCS34 1
116 036-153-120 SCREW, DCS34 1
117 001-153-020 SCREW, DCS34 2
120 528092652 14 CHAIN, DCS34 & UC3530A 1
120 528092656 16 SAW CHAIN, UC4000 1
121 442035661 GUIDE BAR 14, DCS34 & UC3530A 1
121 442040661 16 GUIDE BAR, DCS34-16 1
122 442035061 SPROCKET NOSE BAR 14, DCS34 1
122 442040061 SPROCKET NOSE BAR 16,DCS34 1
1,001 952100633 CHAIN PROTECT COVER, DCS340 1
1,002 941719131 UNIVERSAL WRENCH, DCS6401 1
Page 8 of 8 8/18/2010
