Makita GS5000 Manual

P 1/ 9
Models GS5000 and GS6000 are double insulated versions of
model 9105 125mm (5") straight grinder.
The high performance and handling is the same as model 9105.
Featuring are;
•Improved gear durability by change of grease and modification
on the inside of gear housing.
• Ergonomically design handle and barrel for added
extra maneuverability.
Wheel size is:
125mm (5'') for Model GS5000
150mm (6'') for Model GS6000
Dimensions: mm (")
Width (W)
Height (H)
*1: the model that is in compliance with the regulations.
*2: the model that is not in compliance with the regulations.
Length (L)
Model No. GS5000 GS6000
590 (23-1/4)*1, 588 (23-1/8)*2
189 (7-7/16)*1,
143 (5-5/8)*2
216 (8-1/2)*1,
171 (6-3/4)*2
116 (4-9/16)*1,
118 (4-5/8)*2
130 (5-1/8)*1,
120 (4-3/4)*2
Weight according to
EPTA-Procedure 01/2003*4 : kg (lbs)
Power supply cord: m (ft)
Continuous Rating (W)
Cycle (Hz) Input Output Max. Output (W)
50/ 60
50/ 60
50/ 60
50/ 60
50/ 60
750
---
750
750
750
400
450
400
400
400
700
700
850
850
850
GS5000 GS6000
5,600
No
125 (5)
20 (3/4), 12.7 (1/2)
150 (6)
Australia, Brazil: 2.0 (6.6), Other countries: 2.5 (8.2)
5.0 (11.1)*1, 4.9 (10.7)*25.2 (11.5)*1, 5.0 (11.1)*2
Voltage (V)
110
120
220
230
240
7.2
7.0
3.6
3.5
3.3
Current (A)
Specification
Soft start feature
Wheel size*3:
mm (")
Diameter
Model No.
Hole diameter
20 (3/4)Max. thickness
PRODUCT
*1 the model with the wheel that is in compliance with the regulations.
*2 the model with the wheel that is not in compliance with the regulations.
*3 Grinding wheels of Model 9105 cannot be used because of the wheel rotation speed limit.
*4 with Wheel cover, Inner flange, Outer flange, Lock nut
L
H
W
CONCEPT AND MAIN APPLICATIONS
Specification
Standard equipment
Optional accessories
Hanger set
Grinding wheels
Dust cover attachment set
Note: The standard equipment for the tool shown above may vary by country.
Hex wrench 6 ............................................. 1
Wrench holder 5.6 ...................................... 1
Wrench 24 .................................................. 1 (for some country only)
Lock nut wrench 35 .................................... 1 (for some country only)
Grinding wheel ........................................... 1 (for some country only)
Model No.
Description
GS5000, GS6000
Straight Grinders 125mm (5"), 150mm (6")
No load speed: min.ˉ¹=rpm
Protection against electric shock Double insulation
YesRubberized soft grip
The above drawing is GS5000 that is in
compliance with the regulations.
TECHNICAL INFORMATION

P 2/ 9
Repair
[1] NECESSARY REPAIRING TOOLS
CAUTION: Repair the machine in accordance with “Instruction manual” or “Safety instructions”.
Code No. Description Use for
1R037
1R031
1R026 removing Spindle from Helical gear 47
1R291
1R316
1R258
1R243
1R045
supporting Spindle when assembling Helical gear 47
Wrench for Bearing retainer removing/ assembling Bearing retainer 31-48 from/ to Gear housing
[2] LUBRICATION
Apply Makita grease N No.1 to the following portions designated with the black triangle to protect parts and product
from unusual abrasion.
Fig. 1
Item No. Description
Gear housing
O ring 53
O ring 31
Whole portion
Whole portion
Gear room where Helical gear 47 engages with Armature’s gear
a little
Approx. 6 g
a little
AmountPortion to lubricate
Bearing setting pipe 16-8.2
Bearing setting pipe 28-20.2 assembling Helical gear 47 to Spindle
Bearing setting plate 20.2
Gear extractor (large) disassembling Ball bearing 6203LLB from Spindle
disassembling Armature from Gear housing cover
Round bar for Arbor 14-100 removing Ball bearing 6201DDW from Gear housing cover
V block supporting Helical gear 47 when removing Spindle
Retaining ring S and R pliers removing/ assembling Retaining ring S-10 from/ to Spindle
removing/ assembling Retaining ring R-32 from/ to Gear housing cover
Helical gear 47
Gear housing cover

P 3/ 9
Repair
[3] DISASSEMBLY/ASSEMBLY
[3] -1. Helical gear 47, Ball bearings 6203LLB and 6204LLB
DISASSEMBLING
Note: Disassembling can be done without removing Insulation cover completely.
(1) Remove Wheel cover and Grinding wheel.
(2) Separate Gear housing from Motor housing as drawn in Fig. 2.
(3) Remove Spindle section and Ball bearing 6204LLB from Gear housing as drawn in Fig. 3.
1. Remove Retaining ring S-20 with 1R291. 2. Remove Inner flange and Pin 5 from Spindle.
3. Turn over Insulation cover as drawn below,
then remove four 5x50 Tapping screws.
4. Separate Gear housing from Gear housing cover.
1. Remove Spindle from Gear housing
by tapping its end with Plastic hammer.
2. Remove Bearing retainer 31-48 by turning
it with 1R316 counterclockwise.
3. Remove Ball bearing 6204LLB
by pushing it with the handle of
Plastic hammer.
Insulation
cover
5x50 Tapping
screw ( 4 pcs.)
Retaining
ring S-20
1R291
Gear housing
Gear housing cover
Fig. 2
Fig. 3
Bearing retainer 31-48
1R316
Spindle
Ball bearing 6203LLB
Ball bearing 6204LLB
Helical gear 47
Hammer

P 4/ 9
Repair
(4) Ring 17 makes approx. 5 mm gap between Ball bearing 6203LLB and Helical gear 47. The gear can be disassembled
by using this gap. (Fig. 4)
1. Put a pair of 1R258 onto the table of
arbor press as drawn below.
3. While applying 1R026 onto Spindle, press 1R026 with Arbor press. Spindle is separated
together with Ball bearing 203LLB from Helical gear 47. then, remove Ring 17 from Spindle.
2. Fit two Lock nut wrenches to the gap between Helical
gear 47 and Ball bearing 6203LLB on the pair of 1R258.
Fig. 4
1R026
Spindle
1R258
1R045
1R258
Ball bearing
6203LLB
Helical gear 47
1R258 1R258
Ball bearing
6203LLB
Helical gear 47
Ring 17
1R258
Spindle
4. Remove Ball bearing 6203LLB with 1R045
Ball bearing
6203LLB
[3] DISASSEMBLY/ASSEMBLY
[3] -1. Helical gear 47, Ball bearings 6203LLB and 6204LLB (cont.)
DISASSEMBLING

P 5/ 9
Repair
ASSEMBLING
(1) Assemble Spindle section as drawn in Fig. 5.
(2) Assemble by reversing the disassembly procedure. (Refer to Figs. 3 and 2)
Note: Assemble Gear housing section together with Gear housing cover
while facing its Hanger bracket attaching portion
to the opposite side as Switch lever. (Fig. 6)
Fig. 5
Fig. 6
1. While standing Spindle on 1R037, assemble
Ball bearing 6203LLB with 1R031.
Then, Put Ring 17 onto Spindle.
3. Press-fit Helical gear 47 onto Spindle with 1R031.
Ball bearing
6203LLB
1R037
Ring 17
Spindle
Gear housing
Hanger bracket
attaching portion
Gear housing cover
Switch lever
Spindle
1R037
1R031
1R031
Helical gear 47
[3] DISASSEMBLY/ASSEMBLY
[3] -1. Helical gear 47, Ball bearings 6203LLB and 6204LLB (cont.)

P 6/ 9
Repair
[3] DISASSEMBLY/ASSEMBLY
[3] -2. Armature, Ball bearing 6201DDW
DISASSEMBLING
ASSEMBLING
Fig. 7
Fig. 8
Motor housing
2. Before disassembling Armature,
remove Pin 3 not to lose it.
3. Remove Armature from Gear
housing cover with 1R045.
(1) Separate Gear housing from Gear housing cover. (Refer to Fig. 2)
(2) Disassemble Armature as drawn in Fig. 7.
(3) Remove Ball bearing 6201DDW as drawn in Fig. 8.
Gear housing
cover
Armature
Armature
1. Separate Gear housing cover
together with Armature
from Motor housing
1. Remove Retaining ring R-32
with 1R291.
2. Turn Gear housing cover over and set it on the Turn base of Arbor press.
And then, apply 1R243 to Ball bearing 6201DDW and press it with
Arbor press to remove the bearing from Gear housing cover.
Pin 3
1R045
Ball bearing 6201DDW
1R243
1R291
Retaining ring R-32
Assemble Ball bearing 6201DDW and Armature to Gear housing cover by reversing the disassembly procedure.
(Refer to Figs. 8, 7 and 2)
Note: Do not forget to mount Pin 3 to Gear housing cover before assembling Armature to Motor housing.
Refer to the center drawn in Fig. 7.
Gear housing cover

P 7/ 9
Repair
[3] DISASSEMBLY/ASSEMBLY
[3] -3. Insulation cover
ASSEMBLING
Fig. 9
Insulation cover can be assembled as drawn in Fig. 9.
1. Apply soapsuds to the surface
of Gear housing.
2. Apply soapsuds to the inside
of Insulation cover.
Insulation cover
3. Insulation cover can be mounted smoothly
by soapsuds applied to both parts.
Gear housing

Circuit diagram
P 8/ 9
White
Color index of lead wires' sheath
Power supply cord
Blue lead wire is used
for some countries
instead of White.
Brown lead wire is used
for some countries
instead of Black.
Switch
Line filter
Field
(Commutator side view)
Black
Fig. D-1
Noise suppressor
Noise suppressor is not used for
some countries.
Line filter is not used for
some countries.

Wiring diagram
P 9/ 9
Fig. D-2
Fig. D-3
Fig. D-4
Fix Field lead wire (black)
with Lead wire holder.
Note: Pull out Field lead wires (white, black)
so that they are tightened in Motor housing.
Route Field lead wire (white)
inside of the hook.
Wind Field lead wires (black, white)
around Line filter once,
Wiring of Field lead wires
Wiring on Switch
Wiring in Handle
Line filter*
Switch Fix Lead wires of Power supply cord
into the groove.
Line filter and the slack portion of Field lead
wires have to be put in this place.
Note: Be careful not to put them on Boss A.
groove
Boss A
Noise suppressor**
*Line filter is not used for some countries.
**Noise suppressor is not used for some countries.
Receptacle
Connect Receptacles to Switch
as per the above direction.
Lead wire holder
Line filter*
Put Power supply cord lead wires
between Rib and Switch.
Fix Field lead wires
with Lead wire holder.
Rib
