Parts Breakdown 9741
Page 1 of 3 2/8/2008

Parts Breakdown 9741
Fig # Part ID Part Name Quantity
1 911248-8 P.H. SCREW M5X28, HM1500 3
2 157777-9 GEAR HOUSING COVER, 9741 1
3 263002-9 RUBBER PIN 4, HR2400 1
4 211101-1 BALL BEARING 6001LLB,9218PB 1
5 253744-3 F. WASHER 12, HR2410 1
6 221756-4 HELICAL GEAR 53, 9741 1
7 961055-9 RETAINING RING S-15, 5057KB 1
8 211227-9 B. BEARING 6002DDW,9015A 1
8 211236-8 BALL BEARING 6002DDW,BO5001 1
9 163269-8 SPINDLE, 9741 1
10 254219-5 KEY 4, 9741 1
11 157776-1 GEAR HOUSING, 9741 1
12 911218-7 P.H. SCREW M5X14, DA6300 3
13 273623-9 GRIP, 9741 1
14 794379-6 NYLON BRUSH WHEEL 120-100, 9741 1
15 285661-9 BEARING RETAINER, 2012 1
16 211275-8 BALL BEARING 6003DDW, LS1013 1
17 912122-3 C.S.H SCREW M4X14,5005BA 2
18 681625-5 INS. WASHER, HR2400 1
19 211031-6 BALL BEARING 608LLB, HR2400 1
20 263014-2 RUBBER PIN 4, 9217SPC 1
21 512926-9 ARMATURE ASSEMBLY, 9741 1
22 241113-0 FAN 1
23 253024-7 F. WASHER 10, LS0714 1
23 213059-0 DUST SEAL, DA6300 1
24 211061-7 B. BEARING 6000LLB, 6222DWE 1
24 211088-7 BALL BEARING 6000DDW, 9005B 1
25 263002-9 RUBBER PIN 4, HR2400 1
26 263002-9 RUBBER PIN 4, HR2400 1
27 263005-3 RUBBER PIN 6,LS1013 1
28 911258-5 P.H. SCREW M5X35, 9045N 3
29 211019-6 BALL BEARING 626, 9901 1
30 263002-9 RUBBER PIN 4, HR2400 1
31 911278-9 P.H. SCREW M5X55, HR2000 2
32 211019-6 BALL BEARING 626, 9901 1
33 153168-2 GEAR COMPLETE 64, 9741 1
34 934301-3 WING NUT M6, N1900B 1
35 253196-8 F. WASHER 6, 2012 1
36 343434-7 DEPTH GUIDE, 9741 1
37 961018-5 STOP RING E-5, LS1011 1
38 855929-3 NAME PLATE, 9741 1
39 643600-9 BRUSH CAP 6-10, 9005B 2
40 191945-4 CARBON BRUSH CB-124, 9045B 1
41 251323-1 P.H. SCREW M4, 9741 1
42 253308-3 T. WASHER 6, JN1600 1
43 343436-3 COVER PLATE, 9741 1
44 253980-1 WAVE WASHER 14, 9741 1
45 253874-0 F. WASHER 4, 4390DW 1
46 157992-5 HOUSING, 9741 1
47 251919-8 C.S.N. BOLT M6X20, 4200H 1
48 162134-8 FRONT ROLLER, 9741 1
49 256655-1 PIN 7, 9741 1
50 343435-5 PLATE, 9741 1
51 322071-0 ARBOR, 9741 1
52 410957-1 BAFFLE PLATE, 9741 1
53 911285-2 P.H. SCREW M5X60, 4200H 2
54 522686-5 N/A 1
55 262515-7 SLEEVE 6, 9741 1
56 262515-7 SLEEVE 6, 9741 1
57 911153-9 P.H. SCREW M4X28, JR3000V 4
Page 2 of 3 2/8/2008

Parts Breakdown 9741
58 410954-7 HANDLE COVER, 9741 1
59 162133-0 ROLLER, 9741 1
60 911133-5 P.H. SCREW M4X18, N9501B 2
61 687002-9 STRAIN RELIEF, 9217SPC 1
62 423096-8 SPONGE SEAL, 9741 1
63 682502-4 CORD GUARD 8-85, HP1621F 1
64 660023-6 N/A 1
65 651332-4 SWITCH, 9741 1
66 421323-7 SWITCH COVER, 9741 1
68 941152-7 F. WASHER 6, HM1500 2
400 410899-9 ADAPTOR JOINT, 9741 1
401 783204-6 HEX WRENCH, 3705, HR5000 2
5,001 810239-5 N/A 1
Page 3 of 3 2/8/2008
