Parts Breakdown 9032
Page 1 of 2 2/8/2008

Parts Breakdown 9032
Fig # Part ID Part Name Quantity
1 317523-4 BRACKET, 9032 1
2 265999-8 TAPPING SCREW M4X25, HM1800 3
3 153308-2 PULLEY COVER CPL. 1
4 257249-5 RING 9, 9032 1
5 253807-5 F. WASHER 5, 6012HDW 1
6 265494-8 HEX. BOLT M5X13, 9032 1
7 272229-0 LEVER 40, 3901 1
8 961014-3 STOP RING E-8, 3901 1
9 265090-2 P.H. SCREW M4X20, 9032 1
10 941052-1 F. WASHER 4, 9218SB 1
11 265751-4 THUMB SCREW M5X13, 9032 1
12 253807-5 F. WASHER 5, 6012HDW 1
13 421198-4 PLUG, 4190DW 1
14 317522-6 DRIVING ROLLER, 9032 1
15 265092-8 TRUSS HEAD SCREW M5X12, 9032 1
16 345196-3 SAFETY COVER, 9032 1
17 266026-4 TAPPING SCREW 4X12,9046 1
18 345197-1 CAM LEVER, 9032 1
19 265028-7 P.H. SCREW M4X11, 9032 1
20 233333-0 COMPRESSION SPRING 10, 9032 1
21 317525-0 ARM HOLDER, 9032 1
22 265040-7 P.H. SCREW M3X4, 9032 1
23 153314-7 SHOE 9 CPL. 1
24 153310-5 ARM 9 CPL. 1
25 233332-2 COMPRESSION SPRING 6, 9032 1
26 153312-1 ARM TENSIONER CPL. 1
27 232185-6 LEAF SPRING, 1050DWA 1
28 922111-0 H.S.H. BOLT M4X10, LS1011 1
29 911138-5 P.H. SCREW M4X20, 9218SB 1
30 345195-5 ARM COVER, 9032 1
31 265040-7 P.H. SCREW M3X4, 9032 1
32 153314-7 SHOE 9 CPL. 1
33 664013-1 CORD (2X18X8 SJT), N9501B 1
34 682502-4 CORD GUARD 8-85, HP1621F 1
35 687063-9 STRAIN RELIEF, 4323K 1
36 265995-6 TAPPING SCREW 4X18, 4323K 2
37 631184-9 CONTROLLER 100/115V, 9031 1
37 631676-8 CONTROLLER, 9031 1
39 651263-7 SWITCH, 9031 1
40 415635-8 HANDLE COVER, 9031 1
41 265995-6 TAPPING SCREW 4X18, 4323K 3
42 853483-1 NAME PLATE, 9032 1
43 191938-1 CARBON BRUSH 408 SET, 3901 1
44 643550-8 BRUSH CAP , 9031 2
45 819063-3 MAKITA LABEL, 6992DWDE 1
46 159747-4 MOTOR HOUSING COMPLETE,9031 1
47 593496-7 FIELD ASS'Y 115V, 9032 1
48 266052-3 TAPPING SCREW FLANGE PT4X60,HR2410 2
49 415634-0 BAFFLE PLATE, 9031 1
50 210023-2 BALL BEARING 627DDW, 9910 1
51 681614-0 INS. WASHER, 9031 1
52 517386-0 ARMATURE ASS'Y 115V, 9032 1
53 241884-9 FAN 60, TW0350 1
54 210005-4 BALL BEARING 608DDW, 9031 1
1,001 A-34469 3/8X21 ABRASIVE BELT,80GRIT 10/PK 1
5,001 810134-9 N/A 1
Page 2 of 2 2/8/2008
